Parts
HOUSING ASSEMBLY
IR 317-B-A40
IR 317-B-A40
Housing Assembly Service Part for Ingersoll Rand Air Sander
Includes: Motor housing, Nameplate label, Warning labelProduct Application and Uses: For use with Ingersoll Rand 317-B Air Sander
For Use With
- 317-B
$29.00
PLANET GEAR ASSEMBLY
IR 319A-A10
IR 319A-A10
Planet Gear Assembly for Ingersoll Rand 319A Sander/Polisher
Product Application and Uses: For use with Ingersoll Rand 319A Sander/Polisher
$85.00
MOUNTED POINTS KIT
IR 320-KMP5
IR 320-KMP5
5-Piece Mounted Points Set, 1/8" Shank, 1.5" Length, 75,000 Max RPM
Includes: 5 piece mounted points set; Ball End, Aluminum Oxide mounted point (90 grit, 1/8" head diameter, 1/8" thickness), Flat cone end, Aluminum Oxide mounted point (80 grit, 1/8" head diameter, 1/4" thickness), Cylinder End, Aluminum Oxide (80 grit, 1/8" head diameter, 1/2" thickness), Cylinder End, Aluminum Oxide (80 grit, 3/16" head diameter, 1/2" thickness), Tree End, Aluminum Oxide (60 grit, 7/32" head diameter, 3/8" thickness)Product Application and Uses: For use with Ingersoll Rand 320PG Pencil Grinder
Max Free Speed (rpm): 75000
Product Length (in): 1.5
Shank SIze (in): 1/8
For Use With
- 320PG
- 320PGK
Supersedes
- 320-MP5
$23.00
PIN STRIPE REMOVER
IR 324
IR 324
Adhesive Remover Air Tool Kit, 4" Pad, 3700 RPM, 12 Eraser Pads
With a finely tuned motor and composite housing, you can trust this 324 adhesive remover tool to get the job done.Features And Benefits
- Lock-out Lever: With a unique system that resets a spring-loaded latch each time the lever is released, you’ll never have to worry about accidental throttle operation.
- Lightweight and Ergonomic: Weighing only 1.8lbs, the 324 is easy to use regardless of the angle orientation to get the job done more effectively.
- Speed: Operates at an optimal speed of 3,700 rpm to remove decals, pinstripes, and other adhesives without damaging paint.
- Versatility: With the 324 you will get 12 eraser pads to get you moving and keep you moving. The 324-1 is offered as a low cost alternative that still supplies you with 1 eraser pad.
Includes: (1) tool, (12) eraser pads
Product Application and Uses: This adhesive remover tool is specifically designed to remove pinstripe tape, double-sided tape, adhesive and molding without damage to paint or surface.
Actuation/Throttle Type/Switch Type: Safety Lever
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 5/16"-24 Thread
Average Air Consumption (cfm): 28
Average Air Consumption (l/min): 793
Color: Grey
Configuration/Handle Type: Straight
Housing Material: Impact and chemical-resistant composite housing
Max Free Speed (rpm): 3700
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Pad Diameter or Size (in): 4
Power Source: Air Powered
Product Length (in): 7.9
Product Width (in): 2
Product Height (in): 2.7
Product Weight (lb): 1.8
Sound Pressure/Power Db(A): 89 / 100
Tool Type: Full-size
Vibration Level (m/s2): 3.3
Warranty: 1-year
Similar IR
- 324-1
$340.00
PINSTRIPE REMOVER
IR 324-1
IR 324-1
Adhesive Remover Air Tool, 4" Pad, 3700 RPM, 1 Eraser Pad
With a finely tuned motor and composite housing, you can trust the 324 adhesive remover tool to get the job done.Features And Benefits
- Lock-out Lever: With a unique system that resets a spring-loaded latch each time the lever is released, you’ll never have to worry about accidental throttle operation.
- Lightweight and Ergonomic: Weighing only 1.8lbs, the 324 is easy to use regardless of the angle orientation to get the job done more effectively.
- Speed: Operates at an optimal speed of 3,700 rpm to remove decals, pinstripes, and other adhesives without damaging paint.
Includes: (1) tool, (1) eraser pad
Product Application and Uses: This adhesive remover tool is specifically designed to remove pinstripe tape, double-sided tape, adhesive and molding without damage to paint or surface.
Actuation/Throttle Type/Switch Type: Safety Lever
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 5/16"-24 Thread
Average Air Consumption (cfm): 28
Average Air Consumption (l/min): 793
Color: Grey
Configuration/Handle Type: Straight
Housing Material: Impact and chemical-resistant composite housing
Max Free Speed (rpm): 3700
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Pad Diameter or Size (in): 4
Power Source: Air Powered
Product Length (in): 7.9
Product Width (in): 2
Product Height (in): 2.7
Product Weight (lb): 1.8
Sound Pressure/Power Db(A): 89 / 100
Speed Setting: Variable Speed
Tool Type: Full-size
Vibration Level (m/s2): 3.3
Warranty: 1-year
Similar IR
- 324
$179.00
CUTTER
IR 325A-350
IR 325A-350
Cutter for Ingersoll Rand 325 Series Air Nibbler
For Use With- 325B
$19.00
AIR NIBBLER
IR 325B
IR 325B
Air Nibbler, 18 Gauge Capacity, 4200 Strokes/Min
Instead of shearing or sawing, the 325B Air Nibbler “nibbles” at metals, giving you better control and accuracy when cutting metals up to 18 gauge thicknesses at more than 6 feet per minute.Features And Benefits
- Performance: With trigger actuation, this tool is featherable for variable speed and control.
- Reliability: Engineered for top reliability, you can be sure this tool delivers the same power as it did on day one. Comes with a 1-year warranty.
- Center Cut: With this Nibbler you’re able to begin cuts in the center of your metal without distorting the edges of your material.
Includes: Tool, Manuals
Product Application and Uses: Designed to cut mild steel aluminum, tin and other materials up to 18 gauge (1.2 mm).
Actuation/Throttle Type/Switch Type: Safety Lever
Air Consumption @ Load (cfm): 17
Air Consumption @ Load (l/min): 481
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Average Air Consumption (cfm): 4
Average Air Consumption (l/min): 113
Color: Silver
Configuration/Handle Type: Right Angle
Duty Rating: General Duty
Exhaust Location: Front
Housing Material: Aluminum
Max Free Speed (rpm): 4200
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Number of Power Settings: Continuous
Power Source: Air Powered
Product Length (in): 7.3
Product Width (in): 5.35
Product Height (in): 4.52
Product Weight (lb): 2.1
Sound Pressure/Power Db(A): 96 / 107
Steel Capacity (Gauge): 18
Strokes (per min): 4200
Vibration Level (m/s2): 15.9
Warranty: 1-year
$240.80
HOUSING COVER ASSEMBLY
IR 328B-A109
IR 328B-A109
Housing Cover Assembly for Ingersoll Rand 328B Sander
$15.00
BRIDGE MOUNTING SCREW
IR 329-34
IR 329-34
Bridge Mounting Screw for Ingersoll Rand 429 Reciprocating Saw
$15.00
