INGERSOLL-RAND IR TOOL S12880

IR 80234800

PIPE PLUG 1/8 BSPT

IR 80234487

FITTING 1/8-1/8 BSPP

IR 802T-AP

SWITCH, LIMIT

IR 8033JA2F10144

800J SERIES JIB CRANE 330 LB CAP. 10FT ZRA2 BOOM

IR 8033JA1F10144

STANDARD JIB 8033JA1F10144

IR 8041JA1F08120

800J SERIES JIB ZRA1 8FT BOOM 10FT UC

IR 804-465

BUSHING (48951-167)

IR 8041JA1F08144

800J JIB CRANE

IR 804-640

INSERT

IR 804-639

INSERT

IR 8062-A926-10

ANVIL

IR 8050-A

0 POWER MOTOR

IR 808-207

MOTOR CLAMP WASHER

IR 81025

URETHANE-STEEL BACK .375 THICK

IR 81025A

PLATE, .375 THK URETHANE ALUM BACK SQ-IN

IR 81280398

Socket, Standard, 3/8" Drive, 1/4"

IR 8137-1-A

AIR MOTOR

IR 8200-4A-Q

Forward Rotation Milling Motor, 11/16" Round Collet, 275 RPM, 2HP, 168 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 11/16
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 275
Max Pressure (bar): 6.2
Max Torque (ft-lb): 124
Max Torque (in-lb): 1487
Max Torque (nm): 168
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 14.5
Product Width (in): 5.44
Product Weight (lb): 18.24
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 140
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 75
Torque Output @ Max HP (nm): 101.6
Warranty: 1-year

IR 81709688.1D09

CLAMP PAD MBU RED 4 X 20

IR 8201-4A-S

Forward Rotation Milling Motor, 3/4" Round Collet, 500 RPM, 2HP, 95.5 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 3/4
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 70
Max Torque (in-lb): 845
Max Torque (nm): 95.5
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 14.5
Product Width (in): 5.44
Product Weight (lb): 18.24
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 255
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 41
Torque Output @ Max HP (nm): 55.5
Warranty: 1-year

IR 8200-4A-S

Forward Rotation Milling Motor, 3/4" Round Collet, 275 RPM, 2HP, 168 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 3/4
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 275
Max Pressure (bar): 6.2
Max Torque (ft-lb): 124
Max Torque (in-lb): 1487
Max Torque (nm): 168
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 14.5
Product Width (in): 5.44
Product Weight (lb): 18.24
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 140
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 75
Torque Output @ Max HP (nm): 101.6
Warranty: 1-year

IR 8202-4A-Q

Forward Rotation Milling Motor, 11/16" Round Collet, 900 RPM, 2HP, 54.9 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 11/16
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 900
Max Pressure (bar): 6.2
Max Torque (ft-lb): 40
Max Torque (in-lb): 486
Max Torque (nm): 54.9
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 14.5
Product Width (in): 5.44
Product Weight (lb): 18.24
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 445
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 24
Torque Output @ Max HP (nm): 32.5
Warranty: 1-year

IR 8201-692

ASSY, MOTOR

IR 8203-4A-A

Forward Rotation Milling Motor, 1/4" Round Collet, 2000 RPM, 2HP, 24.4 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 1/4
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 2000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 18
Max Torque (in-lb): 216
Max Torque (nm): 24.4
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1050
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 10.0
Torque Output @ Max HP (nm): 13.5
Warranty: 1-year

IR 8202-4A-S

Forward Rotation Milling Motor, 3/4" Round Collet, 900 RPM, 2HP, 54.9 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 3/4
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 900
Max Pressure (bar): 6.2
Max Torque (ft-lb): 40
Max Torque (in-lb): 486
Max Torque (nm): 54.9
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 14.5
Product Width (in): 5.44
Product Weight (lb): 18.24
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 445
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 24
Torque Output @ Max HP (nm): 32.5
Warranty: 1-year

IR 8203-4A-J

Forward Rotation Milling Motor, 1/2" Round Collet, 2000 RPM, 2HP, 24.4 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 2000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 18
Max Torque (in-lb): 216
Max Torque (nm): 24.4
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1050
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 10.0
Torque Output @ Max HP (nm): 13.5
Warranty: 1-year

IR 8203-4A-H

Forward Rotation Milling Motor, 15/32" Round Collet, 2000 RPM, 2HP, 24.4 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 15/32
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 2000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 18
Max Torque (in-lb): 216
Max Torque (nm): 24.4
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1050
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 10.0
Torque Output @ Max HP (nm): 13.5
Warranty: 1-year

IR 8204-4A-F

Forward Rotation Milling Motor, 13/32" Round Collet, 3500 RPM, 2HP, 13.8 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 13/32
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 3500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 10
Max Torque (in-lb): 122
Max Torque (nm): 13.8
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1740
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 6.0
Torque Output @ Max HP (nm): 8.1
Warranty: 1-year

IR 8203-4A-N

Forward Rotation Milling Motor, 5/8" Round Collet, 2000 RPM, 2HP, 24.4 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 5/8
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 2000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 18
Max Torque (in-lb): 216
Max Torque (nm): 24.4
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1050
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 10.0
Torque Output @ Max HP (nm): 13.5
Warranty: 1-year

IR 8204-4A-J

Forward Rotation Milling Motor, 1/2" Round Collet, 3500 RPM, 2HP, 13.8 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 3500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 10
Max Torque (in-lb): 122
Max Torque (nm): 13.8
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1740
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 6.0
Torque Output @ Max HP (nm): 8.1
Warranty: 1-year

IR 8204-4A-H

Forward Rotation Milling Motor, 16/32" Round Collet, 3500 RPM, 2HP, 13.8 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 16/32
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 3500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 10
Max Torque (in-lb): 122
Max Torque (nm): 13.8
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1740
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 6.0
Torque Output @ Max HP (nm): 8.1
Warranty: 1-year

IR 8204-A

Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 3500 RPM, 2 HP, 13.8 NM, Non-reversible

Air Consumption at Max HP (scfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 4:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 3500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 10
Max Torque (in-lb): 122
Max Torque (nm): 13.8
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1740
Torque Output @ Max HP (ft-lb): 6.0
Torque Output @ Max HP (nm): 8.1
Warranty: 1-year

IR 8204-4A-R

Forward Rotation Milling Motor, 23/32" Round Collet, 3500 RPM, 2HP, 13.8 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 23/32
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 3500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 10
Max Torque (in-lb): 122
Max Torque (nm): 13.8
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1740
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 6.0
Torque Output @ Max HP (nm): 8.1
Warranty: 1-year

IR 8205-4A-D

Forward Rotation Milling Motor, 11/32" Round Collet, 14000 RPM, 2HP, 3.9 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 11/32
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 14000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 2.9
Max Torque (in-lb): 35
Max Torque (nm): 3.9
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 7000
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 1.5
Torque Output @ Max HP (nm): 2
Warranty: 1-year

IR 8205-4A-C

Forward Rotation Milling Motor, 5/16" Round Collet, 14000 RPM, 2HP, 3.9 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 5/16
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 14000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 2.9
Max Torque (in-lb): 35
Max Torque (nm): 3.9
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 7000
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 1.5
Torque Output @ Max HP (nm): 2
Warranty: 1-year

IR 8205-4A-J

Forward Rotation Milling Motor, 1/2" Round Collet, 14000 RPM, 2HP, 3.9 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 14000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 2.9
Max Torque (in-lb): 35
Max Torque (nm): 3.9
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 7000
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 1.5
Torque Output @ Max HP (nm): 2
Warranty: 1-year

IR 8205-4A-E

Forward Rotation Milling Motor, 3/8" Round Collet, 14000 RPM, 2HP, 3.9 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 14000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 2.9
Max Torque (in-lb): 35
Max Torque (nm): 3.9
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 7000
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 1.5
Torque Output @ Max HP (nm): 2
Warranty: 1-year

IR 8205-4A-N

Forward Rotation Milling Motor, 5/8" Round Collet, 14000 RPM, 2HP, 3.9 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 5/8
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 14000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 2.9
Max Torque (in-lb): 35
Max Torque (nm): 3.9
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 7000
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 1.5
Torque Output @ Max HP (nm): 2
Warranty: 1-year

IR 8205-4A-M

Forward Rotation Milling Motor, 19/32" Round Collet, 14000 RPM, 2HP, 3.9 Nm, Non-reversible

The inline planetary gear and vane motor allows the 44-Series Milling Motors to handle high torque applications with ease.

Features And Benefits

• Ease of Service: Without having to spend time repairing your tools, your productivity can soar.
• Durable: Able to withstand harsh conditions, these milling motors are ones you can count on. Ideal for increased side loading applications such as milling and sawing.
• Safety: ATEX and CE certified for reliable performance in hazardous environments requiring intrinsically safe components.

Air Consumption (cfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 19/32
Drive Type: Collet
Exhaust Location: Rear- 360 adjustable
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 14000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 2.9
Max Torque (in-lb): 35
Max Torque (nm): 3.9
Motor: Rotary Vane
Motor: Milling
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Length (in): 11.69
Product Width (in): 5.44
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 7000
Standards/Certifications: ATEX
Torque Output @ Max HP (ft-lb): 1.5
Torque Output @ Max HP (nm): 2
Warranty: 1-year

IR 8208-A

Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 900 RPM, 1.9 HP, 47.4 NM, Reversible

Air Consumption at Max HP (scfm): 93.5
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 16:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 900
Max Pressure (bar): 6.2
Max Torque (ft-lb): 35
Max Torque (in-lb): 420
Max Torque (nm): 47.4
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 18.24
Rated Power (hp): 1.9
Rated Power (kW): 1.42
Reversible: Reversible
Sound Level dB(A): 95
Speed at Max Power (rpm): 450
Torque Output @ Max HP (ft-lb): 22
Torque Output @ Max HP (nm): 30.1
Warranty: 1-year

IR 8205-A

Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 14000 RPM, 2 HP, 3.9 NM, Non-reversible

Air Consumption at Max HP (scfm): 95
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 1:1
Gear Reduction: Direct Drive
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 14000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 2.9
Max Torque (in-lb): 35
Max Torque (nm): 3.9
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 13.82
Rated Power (hp): 2
Rated Power (kW): 1.49
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 7000
Torque Output @ Max HP (ft-lb): 1.5
Torque Output @ Max HP (nm): 2
Warranty: 1-year

IR 8209-A

Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 2000 RPM, 1.9 HP, 20.3 NM, Reversible

Air Consumption at Max HP (scfm): 93.5
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 7:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 2000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 15
Max Torque (in-lb): 180
Max Torque (nm): 20.3
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 13.82
Rated Power (hp): 1.9
Rated Power (kW): 1.42
Reversible: Reversible
Sound Level dB(A): 95
Speed at Max Power (rpm): 1000
Torque Output @ Max HP (ft-lb): 10.0
Torque Output @ Max HP (nm): 13.5
Warranty: 1-year

IR 8210-A

Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 3500 RPM, 1.9 HP, 11.5 NM, Reversible

Air Consumption at Max HP (scfm): 93.5
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 4:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 3500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 8.5
Max Torque (in-lb): 102
Max Torque (nm): 11.5
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 13.82
Rated Power (hp): 1.9
Rated Power (kW): 1.42
Reversible: Reversible
Sound Level dB(A): 95
Speed at Max Power (rpm): 1800
Torque Output @ Max HP (ft-lb): 5.5
Torque Output @ Max HP (nm): 7.5
Warranty: 1-year

IR 821-216-08

AIR BAG WINDJAMMER ACTUATOR 8IN LG

IR 8211-A

Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 14000 RPM, 1.9 HP, 3 NM, Reversible

Air Consumption at Max HP (scfm): 93.5
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 1:1
Gear Reduction: Direct Drive
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 14000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 2.2
Max Torque (in-lb): 27
Max Torque (nm): 3
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 13.82
Rated Power (hp): 1.9
Rated Power (kW): 1.42
Reversible: Reversible
Sound Level dB(A): 95
Speed at Max Power (rpm): 7000
Torque Output @ Max HP (ft-lb): 1.4
Torque Output @ Max HP (nm): 1.9
Warranty: 1-year

IR 821-216-14

AIR BAG

IR 8226-10A

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 170 RPM, 0.6 HP, 88.1 NM, Non-reversible

Air Consumption at Max HP (scfm): 40.5
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 109.7:1
Gear Reduction: Triple
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 170
Max Pressure (bar): 6.2
Max Torque (ft-lb): 65
Max Torque (in-lb): 780
Max Torque (nm): 88.1
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 5.56
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 87
Torque Output @ Max HP (ft-lb): 36
Torque Output @ Max HP (nm): 48.8
Warranty: 1-year

IR 8226-12A

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 90 RPM, 0.6 HP, 165.3 NM, Non-reversible

Air Consumption at Max HP (scfm): 40.5
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 203.8:1
Gear Reduction: Triple
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 90
Max Pressure (bar): 6.2
Max Torque (ft-lb): 122
Max Torque (in-lb): 1463
Max Torque (nm): 165.3
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 5.56
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 45
Torque Output @ Max HP (ft-lb): 70
Torque Output @ Max HP (nm): 94.8
Warranty: 1-year

IR 8226-14A

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 50 RPM, 0.6 HP, 306.2 NM, Non-reversible

Air Consumption at Max HP (scfm): 40.5
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 378.5:1
Gear Reduction: Triple
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 50
Max Pressure (bar): 6.2
Max Torque (ft-lb): 226
Max Torque (in-lb): 2710
Max Torque (nm): 306.2
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 5.56
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 25
Torque Output @ Max HP (ft-lb): 125
Torque Output @ Max HP (nm): 169.4
Warranty: 1-year

IR 8226-13A

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 60 RPM, 0.6 HP, 249.3 NM, Non-reversible

Air Consumption at Max HP (scfm): 40.5
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 306.7:1
Gear Reduction: Triple
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 60
Max Pressure (bar): 6.2
Max Torque (ft-lb): 184
Max Torque (in-lb): 2206
Max Torque (nm): 249.3
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 5.56
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 30
Torque Output @ Max HP (ft-lb): 103
Torque Output @ Max HP (nm): 139.6
Warranty: 1-year

IR 8226-7A

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 450 RPM, 0.6 HP, 35.2 NM, Non-reversible

Air Consumption at Max HP (scfm): 40.5
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 41.3:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 450
Max Pressure (bar): 6.2
Max Torque (ft-lb): 26
Max Torque (in-lb): 312
Max Torque (nm): 35.2
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 4.25
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 225
Torque Output @ Max HP (ft-lb): 14
Torque Output @ Max HP (nm): 18.6
Warranty: 1-year

IR 8226-6A

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 700 RPM, 0.6 HP, 23.3 NM, Non-reversible

Air Consumption at Max HP (scfm): 40.5
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 27.4:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 700
Max Pressure (bar): 6.2
Max Torque (ft-lb): 17
Max Torque (in-lb): 206
Max Torque (nm): 23.3
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 4.25
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 350
Torque Output @ Max HP (ft-lb): 9.0
Torque Output @ Max HP (nm): 12.2
Warranty: 1-year

IR 8226-8A

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 375 RPM, 0.6 HP, 43.4 NM, Non-reversible

Air Consumption at Max HP (scfm): 40.5
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 50.9:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 375
Max Pressure (bar): 6.2
Max Torque (ft-lb): 32
Max Torque (in-lb): 384
Max Torque (nm): 43.4
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 4.25
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 185
Torque Output @ Max HP (ft-lb): 17
Torque Output @ Max HP (nm): 23
Warranty: 1-year

IR 8228-11B

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 100 RPM, 0.5 HP, 81.3 NM, Reversible

Air Consumption at Max HP (scfm): 30
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 165.1:1
Gear Reduction: Triple
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 100
Max Pressure (bar): 6.2
Max Torque (ft-lb): 60
Max Torque (in-lb): 720
Max Torque (nm): 81.3
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 5.56
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 54
Torque Output @ Max HP (ft-lb): 48
Torque Output @ Max HP (nm): 65
Warranty: 1-year

IR 8228-14B

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 40 RPM, 0.5 HP, 81.3 NM, Reversible

Air Consumption at Max HP (scfm): 30
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 378.5:1
Gear Reduction: Triple
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 40
Max Pressure (bar): 6.2
Max Torque (ft-lb): 60
Max Torque (in-lb): 720
Max Torque (nm): 81.3
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 5.56
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 22
Torque Output @ Max HP (ft-lb): 60
Torque Output @ Max HP (nm): 81.3
Warranty: 1-year

IR 8228-5B

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 800 RPM, 0.5 HP, 15.2 NM, Reversible

Air Consumption at Max HP (scfm): 30
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 22.2:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 800
Max Pressure (bar): 6.2
Max Torque (ft-lb): 11
Max Torque (in-lb): 135
Max Torque (nm): 15.2
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 4.25
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 420
Torque Output @ Max HP (ft-lb): 6.3
Torque Output @ Max HP (nm): 8.5
Warranty: 1-year

IR 8228-2B

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 3200 RPM, 0.5 HP, 3.9 NM, Reversible

Air Consumption at Max HP (scfm): 30
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 5.56:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 3200
Max Pressure (bar): 6.2
Max Torque (ft-lb): 2.9
Max Torque (in-lb): 35
Max Torque (nm): 3.9
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 4.25
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1550
Torque Output @ Max HP (ft-lb): 1.7
Torque Output @ Max HP (nm): 2.3
Warranty: 1-year

IR 8228-7B

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 425 RPM, 0.5 HP, 27.1 NM, Reversible

Air Consumption at Max HP (scfm): 30
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 41.3:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 425
Max Pressure (bar): 6.2
Max Torque (ft-lb): 20
Max Torque (in-lb): 240
Max Torque (nm): 27.1
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 4.25
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 220
Torque Output @ Max HP (ft-lb): 12
Torque Output @ Max HP (nm): 16.3
Warranty: 1-year

IR 8229-3A

Inline Multi-Vane Air Motor, 3/8"-24 Thd Spindle, 3500 RPM, 0.6 HP, 4.7 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Drive Type: Threaded
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 5.56:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 3500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 3.5
Max Torque (in-lb): 42
Max Torque (nm): 4.7
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.45
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1750
Torque Output @ Max HP (ft-lb): 1.8
Torque Output @ Max HP (nm): 2.4
Warranty: 1-year

IR 8229-7A

Inline Multi-Vane Air Motor, 3/8"-24 Thd Spindle, 800 RPM, 0.6 HP, 20 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Drive Type: Threaded
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 23.4:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 800
Max Pressure (bar): 6.2
Max Torque (ft-lb): 15
Max Torque (in-lb): 177
Max Torque (nm): 20
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 390
Torque Output @ Max HP (ft-lb): 8.0
Torque Output @ Max HP (nm): 10.8
Warranty: 1-year

IR 8229-5A

Inline Multi-Vane Air Motor, 3/8"-24 Thd Spindle, 1650 RPM, 0.6 HP, 10.2 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Drive Type: Threaded
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 11.6:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1650
Max Pressure (bar): 6.2
Max Torque (ft-lb): 7.5
Max Torque (in-lb): 90
Max Torque (nm): 10.2
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 840
Torque Output @ Max HP (ft-lb): 3.8
Torque Output @ Max HP (nm): 5.1
Warranty: 1-year

IR 8229-6A

Inline Multi-Vane Air Motor, 3/8"-24 Thd Spindle, 1000 RPM, 0.6 HP, 16.3 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Drive Type: Threaded
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 18.9:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 12
Max Torque (in-lb): 144
Max Torque (nm): 16.3
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 500
Torque Output @ Max HP (ft-lb): 6.2
Torque Output @ Max HP (nm): 8.4
Warranty: 1-year

IR 8229-8A

Inline Multi-Vane Air Motor, 3/8"-24 Thd Spindle, 600 RPM, 0.6 HP, 26.5 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Drive Type: Threaded
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 30.9:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 600
Max Pressure (bar): 6.2
Max Torque (ft-lb): 20
Max Torque (in-lb): 235
Max Torque (nm): 26.5
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 315
Torque Output @ Max HP (ft-lb): 10.0
Torque Output @ Max HP (nm): 13.5
Warranty: 1-year

IR 8229-9A

Inline Multi-Vane Air Motor, 3/8"-24 Thd Spindle, 500 RPM, 0.6 HP, 32.5 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Drive Type: Threaded
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 38.1:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 24
Max Torque (in-lb): 288
Max Torque (nm): 32.5
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 250
Torque Output @ Max HP (ft-lb): 12
Torque Output @ Max HP (nm): 16.9
Warranty: 1-year

IR 8230-1A

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 19000 RPM, 0.6 HP, 0.9 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 1:1
Gear Reduction: Direct Drive
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 19000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 0.7
Max Torque (in-lb): 8.0
Max Torque (nm): 0.9
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.45
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 9800
Torque Output @ Max HP (ft-lb): 0.3
Torque Output @ Max HP (nm): 0.4
Warranty: 1-year

IR 8230-3A

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 3500 RPM, 0.6 HP, 4.7 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 5.56:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 3500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 3.5
Max Torque (in-lb): 42
Max Torque (nm): 4.7
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.45
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1750
Torque Output @ Max HP (ft-lb): 1.8
Torque Output @ Max HP (nm): 2.4
Warranty: 1-year

IR 8230-2A

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 5700 RPM, 0.6 HP, 2.9 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 3.4:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 5700
Max Pressure (bar): 6.2
Max Torque (ft-lb): 2.1
Max Torque (in-lb): 26
Max Torque (nm): 2.9
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.45
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 2900
Torque Output @ Max HP (ft-lb): 1.1
Torque Output @ Max HP (nm): 1.5
Warranty: 1-year

IR 8230-4A

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 2800 RPM, 0.6 HP, 6.1 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 6.86:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 2800
Max Pressure (bar): 6.2
Max Torque (ft-lb): 4.5
Max Torque (in-lb): 54
Max Torque (nm): 6.1
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.45
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1400
Torque Output @ Max HP (ft-lb): 2.2
Torque Output @ Max HP (nm): 3
Warranty: 1-year

IR 8230-5A

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 1650 RPM, 0.6 HP, 10.2 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 11.6:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1650
Max Pressure (bar): 6.2
Max Torque (ft-lb): 7.5
Max Torque (in-lb): 90
Max Torque (nm): 10.2
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 840
Torque Output @ Max HP (ft-lb): 3.8
Torque Output @ Max HP (nm): 5.1
Warranty: 1-year

IR 8230-6A

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 1000 RPM, 0.6 HP, 16.3 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 18.9:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 12
Max Torque (in-lb): 144
Max Torque (nm): 16.3
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 500
Torque Output @ Max HP (ft-lb): 6.2
Torque Output @ Max HP (nm): 8.4
Warranty: 1-year

IR 8230-9A

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 500 RPM, 0.6 HP, 32.5 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 38.1:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 24
Max Torque (in-lb): 288
Max Torque (nm): 32.5
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 250
Torque Output @ Max HP (ft-lb): 12
Torque Output @ Max HP (nm): 16.9
Warranty: 1-year

IR 8230-8A

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 600 RPM, 0.6 HP, 26.5 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 30.9:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 600
Max Pressure (bar): 6.2
Max Torque (ft-lb): 20
Max Torque (in-lb): 235
Max Torque (nm): 26.5
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 315
Torque Output @ Max HP (ft-lb): 10.0
Torque Output @ Max HP (nm): 13.5
Warranty: 1-year

IR 8231-2B

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 5300 RPM, 0.5 HP, 2.3 NM, Reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 3.4:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 5300
Max Pressure (bar): 6.2
Max Torque (ft-lb): 1.7
Max Torque (in-lb): 20
Max Torque (nm): 2.3
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.45
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 2600
Torque Output @ Max HP (ft-lb): 1.0
Torque Output @ Max HP (nm): 1.3
Warranty: 1-year

IR 8231-5B

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 1500 RPM, 0.5 HP, 8 NM, Reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 11.6:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 5.9
Max Torque (in-lb): 71
Max Torque (nm): 8
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 780
Torque Output @ Max HP (ft-lb): 3.5
Torque Output @ Max HP (nm): 4.7
Warranty: 1-year

IR 8231-3B

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 3200 RPM, 0.5 HP, 3.9 NM, Reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 5.56:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 3200
Max Pressure (bar): 6.2
Max Torque (ft-lb): 2.9
Max Torque (in-lb): 35
Max Torque (nm): 3.9
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.45
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1550
Torque Output @ Max HP (ft-lb): 1.7
Torque Output @ Max HP (nm): 2.3
Warranty: 1-year

IR 8231-6B

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 950 RPM, 0.5 HP, 12.9 NM, Reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 18.9:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 950
Max Pressure (bar): 6.2
Max Torque (ft-lb): 9.5
Max Torque (in-lb): 114
Max Torque (nm): 12.9
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 480
Torque Output @ Max HP (ft-lb): 5.5
Torque Output @ Max HP (nm): 7.4
Warranty: 1-year

IR 61H120L6-EU

GRINDER

IR 61H150L6-EU

GRINDER

IR 61H-16-4H6

FLANGE

IR 61H-203

DEFLECTOR RET RING

IR 61H120-EU-A160

HANDLE

IR 61H120L6

Cone and Plug Air Grinder, 12,000 RPM, 1.25 HP, 3/8"-24 Thread, Side Exhaust

Ingersoll Rand Pro Series grinder are tough, easy to handle and ready to tackle any project you need them to. Specifically designed for heavy duty production applications. With their superior output, they are best suited for big tasks involving heavy material removal in foundries, welding shops, fabrication facilities, steel mills or shipyard.

Features And Benefits

• POWER: With a powerful 1.25 HP vane motor and 12,000 RPM, these grinders remove materials at top speed for maximum efficiency.
• RELIABILITY: The 61 Pro Series Cone and Plug Grinders come with a built-in mist lubricator, motor controller and grit rejection system to prolong the life of your tools.
• DURABILITY: The metal housing on these grinders ensures a strong tool that can withstand harsh environments and repeated drops.

Air Consumption @ Load (cfm): 37
Air Consumption @ Load (l/min): 1048
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Configuration/Handle Type: Straight
Exhaust Location: Side
Max Free Speed (rpm): 12000
Max Pressure (bar): 6.2
Min Hose Size (in): 1/2
Power Source: Air Powered
Product Length (in): 14.75
Product Weight (lb): 4.25
Rated Power (hp): 1.25
Warranty: 1-year
Wheel Type: Cone

IR 61H150-A160

THROTTLE HANDLE ASSEMBLY

IR 61H150-EU-A160

HANDLE

IR 61H-35

DUST WASHER

IR 61H-405

SPRING

IR 61H-207

MOTOR CLAMP WASHER

IR 61H-42

VANE

IR 61H-53

ROTOR

IR 61H-23

EXHAUST DEFLECTOR

IR 61H-24

FRONT ROTOR BEARING

IR 61H-31

SEAL

IR 61H-61

AIR STRAINER SCREEN

IR 61H-33

WHEEL END BEARING

IR 61H-669

RETAINING SCREW

IR 61H-86-3H6

INNER WHEEL FLANGE

IR 61H-86-4H6

FLANGE

IR 61H-70

INNER WHEEL FLANGE KEY

IR 61H-A11

FRONT END PLATE ASSEMBLY

IR 61H-A40

HOUSING
