INGERSOLL-RAND IR TOOL S12880

IR 34009

GEARING ASSEMBLY-SEE 7.5.15AM

IR 34027

GEAR, SPUR

IR 34055

WASHER

IR 34061

GEAR, SPUR

IR 34064

GEAR, SPUR-SEE 7.5.15 AM

IR 34065

GEAR, SPUR-SEE 7.5.15 AM

IR 34067

GEAR, SPUR-SEE 7.5.15 AM

IR 34082-1

MOTOR ASSEMBLY

IR 34083

CYLINDER

IR 34152

PIN, ROLL

IR 341SR-14

HEAD BLOCK

IR 341SR-R10

BARREL

IR 34312

PLUG, PLASTIC

IR 34325

BEARING

IR 34326

BUSHING

IR 34332-11

ROLLER CHAIN ASSEMBLY, NON-RETURNABLE PART

IR 34332-18

ROLLER CHAIN ASSEMBLY, NON-RETURNABLE PART

IR 34332-20

ROLLER CHAIN ASSEMBLY, NON-RETURNABLE PART

IR 34332-40

ROLLER CHAIN ASSEMBLY, NON-RETURNABLE PART

IR 34332-42

ROLLER CHAIN ASSEMBLY, NON-RETURNABLE PART

IR 34332-51

ROLLER CHAIN ASSEMBLY, NON-RETURNABLE PART

IR 34332-6

ROLLER CHAIN ASSEMBLY, NON-RETURNABLE PART

IR 34335

BUSHING

IR 34336

BUSHING

IR 34341

BRACKET

IR 34396-1

SEAT, BUNA N

IR 34398

STEM, VALVE

IR 34399

LEVER

IR 34422

CAP, HOUSING

IR 3445-53

ROTOR

IR 3445MAX-300

MODEL LABEL

IR 34474

SPRING

IR 34485

ENDPLATE

IR 34486

ENDPLATE

IR 34487

CYLINDER

IR 34491

HOUSING, NOSE

IR 34492

ADAPTER

IR 34494

HOUSING

IR 34497-J

CAP, HOUSING

IR 34498

CAP, HOUSING

IR 34498-J

CAP, HOUSING

IR 34540

CYLINDER

IR 34570

SPACER

IR 34573

SPACER

IR 345MAX-300

MODEL LABEL

IR 345MAX-M-300

MODEL LABEL

IR 34649N

34649N : BRONZE HOOK, MACHINED

IR 34651N

HOOK AND LATCH ASSEMBLY

IR 34655

HOOK ASSEMBLY

IR 34655-1

HOOK ASSEMBLY

IR 34664-1

ADAPTER

IR 34671

PIN, ROLL

IR 34684

NUT

IR 34711

RING STOP

IR 34718-10

HOSE ASSEMBLY

IR 34718-4

HOSE ASSEMBLY

IR 34718-6

HOSE ASSEMBLY, NON-RETURNABLE PART

IR 34718-7

HOSE ASSEMBLY

IR 34722

FITTING

IR 34734-1

ROTOR

IR 34735

SHAFT

IR 34736

SPACER

IR 34741

GEAR, SPUR

IR 34746-2

MOTOR ASSEMBLY

IR 34747

CYLINDER

IR 34750

BEARING, NDL

IR 34761

BUSHING

IR 34763-Z-1

CASTING HANDLE

IR 34778-1

SPACER

IR 34793

SCREW

IR 34802

WASHER, SPRF

IR 34815

BUSHING

IR 34846

RETAINER

IR 34975-20

HOSE ASSEMBLY, NON-RETURNABLE PART

IR 34975-25

HOSE ASSEMBLY

IR 34975-3

HOSE, NON-RETURNABLE PART

IR 34991

GUIDE

IR 34R-52

SHAFT

IR 34RA005

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 1080 RPM, 4.1 HP, 93.6 NM, Reversible

Air Consumption at Max HP (scfm): 183
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Single
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 1080
Max Pressure (bar): 6.2
Max Torque (ft-lb): 69
Max Torque (in-lb): 828
Max Torque (nm): 93.6
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 43
Rated Power (hp): 4.1
Rated Power (kW): 3.06
Reversible: Reversible
Speed at Max Power (rpm): 560
Starting Torque (ft-lb): 44
Starting Torque (nm): 60
Warranty: 1-year

IR 34RA008

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 740 RPM, 4.1 HP, 137 NM, Reversible

Air Consumption at Max HP (scfm): 183
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Single
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 740
Max Pressure (bar): 6.2
Max Torque (ft-lb): 101
Max Torque (in-lb): 1213
Max Torque (nm): 137
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 43
Rated Power (hp): 4.1
Rated Power (kW): 3.06
Reversible: Reversible
Speed at Max Power (rpm): 385
Starting Torque (ft-lb): 65
Starting Torque (nm): 88
Warranty: 1-year

IR 34RA014

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 390 RPM, 4.1 HP, 260 NM, Reversible

Air Consumption at Max HP (scfm): 183
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Single
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 390
Max Pressure (bar): 6.2
Max Torque (ft-lb): 192
Max Torque (in-lb): 2301
Max Torque (nm): 260
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 43
Rated Power (hp): 4.1
Rated Power (kW): 3.06
Reversible: Reversible
Speed at Max Power (rpm): 201
Starting Torque (ft-lb): 124
Starting Torque (nm): 168
Warranty: 1-year

IR 34RB036

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 152 RPM, 4 HP, 627 NM, Reversible

Air Consumption at Max HP (scfm): 180
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Double
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 152
Max Pressure (bar): 6.2
Max Torque (ft-lb): 462
Max Torque (in-lb): 5549
Max Torque (nm): 627
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 75
Rated Power (hp): 4
Rated Power (kW): 2.98
Reversible: Reversible
Speed at Max Power (rpm): 80
Starting Torque (ft-lb): 277
Starting Torque (nm): 376
Warranty: 1-year

IR 34SR-54

EXHAUST DELECTOR PLIERS

IR 34U-104

SCREW (29471-01, 474-01)

IR 34U-118

RETAINER (29476-01)

IR 34U-150

CAP SCREW

IR 34U-215A

SOCKET PIN

IR 34U-351

LOCK WASHER

IR 34U-364

BUSHING

IR 34U-463

CALL FOR SUPERCESSION

IR 34U-528

WASHER (29519-01)

IR 34U-641A

BUSHING (28201-02)

IR 34U-726A

ANVIL (29547-01)

IR 34U-81

HANDLE (29466-01)

IR 34U-9

GEAR (28197-01)

IR 35007N

HOOK AND LATCH ASSEMBLY

IR 35008N

BRONZE HOOK, MACHINED

IR 35009

SWIVEL

IR 35069-11

COLLET ASSEMBLY

IR 35069-2

COLLET ASSEMBLY
