INGERSOLL-RAND IR TOOL S12880

IR QXXD2PT012PS06

3/8in 20V Cordless QX Precision Fastening Screwdriver, 106 in-lb Torque, 750 RPM, Display, Pistol

Description: A member of the QX Connect Series Precision Fastening System, the 20V QXXD Cordless Precision Screwdriver offer the full feature set of the QX Connect Series. With up to 32 programmable configurations, wireless data transmission and on tool display, Bluetooth connectivity, this tool is designed to improve accuracy and productivity of your precision fastening and assembly operations. Reducing torque reaction doesn't have to be complicated with the QX Connect Series Ergonomic Tightening System. The Bluetooth capability further enhances mobility by enabling users to wirelessly program the QX Connect Series assembly tools using the INSIGHT Connect App.

Features And Benefits:

• Now Comes with 32 programmable tightening configuration.
• Bluetooth further adds mobility to enable Wireless programming using the INSIGHT Connect app.
• Enhanced quantitative feedback - displaying the actual measured torque or angle result.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• All QX Series IQV20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20 volt batteries utilize our 20V battery charger.
• Offer option for Insight Connect Android APP LINK
• Optional ergonomic tightening system to reduce torque reaction experienced by operator.
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Insight Connect Android and IOS App, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 750
• Max Torque (ft-lb): 8.9
• Max Torque (in-lb): 106
• Max Torque (nm): 12
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 8.35

• Product Height (in) (with Battery): 10.07
• Product Weight (lb): 2
• Recommended Forward Torque Range (ft-lb): 1.8-8.9
• Recommended Forward Torque Range (in-lb): 21-106
• Recommended Forward Torque Range (nm): 2.4-12
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 1
• Side to Center Distance (mm): 25

• Sound Pressure/Power Db(A): < 70.0

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4
• Wireless Tool Tracking: USB-C

IR QXXD5PT01KPW16

1" 40V Cordless Torque Wrench, Bare Tool, 8851 in-lb Torque, Bluetooth/802.15.4, Pistol

Description: The Ingersoll Rand QX Series 40V Cordless Torque Multiplier is built with one vital industry in mind: Heavy trucking and transportation. With a custom reaction arm optimized for commercial truck tires, programmable torque up to 750 ft-lbs, and torque recording that helps you maintain real-time records of service and proof of performance, the QX Series 40V Cordless Torque Multiplier helps increase efficiency, safety, and power on the shop floor. Even when the job is tough, our tools are tougher.

Features And Benefits:

• Power: The brushless motor and premium Norbar gearbox provide up to 750 ft-lbs of torque.
• Accuracy and Efficiency: Digitally traceable tightening provides consistent, reliable torque within 5% accuracy and reduces the need for manual torqueing and torque wrench confirmation.
• Connectivity: Real-time digital torque recording automatically generates a record of service via Wi-Fi or Bluetooth Access via the Ingersoll Rand INSIGHT Connect Mobile App whenever you need it.
• Comfort: Reaction arm crafted specifically for truck tires and an articulating top handle that moves two axes allows for mounting and maneuvering in almost any configuration.
• Durability: Chemical resistant housing reinforced with an IP5X rating for increased protection in harsh environments. Backed by a 1-year warranty and rigorously tested to ensure peak performance during tough jobs.
• Also available in the QXXD5PT01KPW16K2 kit which includes the QXXD5PT01KPW16 Torque Wrench, (2) 40V 2.5 Ah BL4011 Batteries, BC1161 40V Universal Charger, 33mm socket and retainer.

Product Application and Uses:

Designed for the heavy trucking and transportation industry in applications requiring precise torque control, accuracy, consistency and repeatability and are recommended for tightening requirements.

• Includes: 33mm socket and retainer. Bare tool only, batteries and charger sold separately or with other kits.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: Yes

• Clutch Type: None
• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Heavy Duty

• Gearbox Width (in): 2.8

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 15
• Max Torque (ft-lb): 738
• Max Torque (in-lb): 8851
• Max Torque (nm): 1000
• Motor: Brushless Motor

• Number of Batteries Required: 1
• Power Source: Battery Powered
• Product Length (in): 16.5

• Product Weight (lb): 20
• Product Weight (lb) (with Battery): 21.5
• Reaction Bar: Yes
• Recommended Forward Torque Range (ft-lb): 148-738
• Recommended Forward Torque Range (in-lb): 1770-8851
• Recommended Forward Torque Range (nm): 200 - 1000
• Retainer Type: Thru-hole
• Reversible: Reversible

• Speed Setting: Variable Speed
• Standards/Certifications: UL/CSA/CE/IP5X

• Tether Style: Tether Included
• User Interface: Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4

• Accessories: BC1161
• Accessories: BL4011

IR QXXD5PT01KPW16K2

1" 40V Cordless Torque Wrench 2 Battery Kit, 8851 in-lb Torque, Bluetooth/802.15.4, Pistol

Description: The Ingersoll Rand QX Series 40V Cordless Torque Multiplier is built with one vital industry in mind: Heavy trucking and transportation. With a custom reaction arm optimized for commercial truck tires, programmable torque up to 750 ft-lbs, and torque recording that helps you maintain real-time records of service and proof of performance, the QX Series 40V Cordless Torque Multiplier helps increase efficiency, safety, and power on the shop floor. Even when the job is tough, our tools are tougher.

Features And Benefits:

• Power: The brushless motor and premium Norbar gearbox provide up to 750 ft-lbs of torque.
• Accuracy and Efficiency: Digitally traceable tightening provides consistent, reliable torque within 5% accuracy and reduces the need for manual torqueing and torque wrench confirmation.
• Connectivity: Real-time digital torque recording automatically generates a record of service via Wi-Fi or Bluetooth Access via the Ingersoll Rand INSIGHT Connect Mobile App whenever you need it.
• Comfort: Reaction arm crafted specifically for truck tires and an articulating top handle that moves two axes allows for mounting and maneuvering in almost any configuration.
• Durability: Chemical resistant housing reinforced with an IP5X rating for increased protection in harsh environments. Backed by a 1-year warranty and rigorously tested to ensure peak performance during tough jobs.
• Includes: 40V Torque Wrench, (2) 40V 2.5 Ah BL4011 Batteries, BC1161 40V Universal Charger, 33mm socket and retainer.

Product Application and Uses:

Designed for the heavy trucking and transportation industry in applications requiring precise torque control, accuracy, consistency and repeatability and are recommended for tightening requirements.

• Includes: QXXD5PT01KPW16 40V Torque Multiplier, (2) 40V 2.5 Ah BL4011 Batteries, BC1161 40V Universal Charger, 33mm socket and retainer.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: Yes

• Clutch Type: None
• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Heavy Duty

• Gearbox Width (in): 2.8

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 15
• Max Torque (ft-lb): 738
• Max Torque (in-lb): 8851
• Max Torque (nm): 1000
• Motor: Brushless Motor

• Number of Batteries Required: 1
• Power Source: Battery Powered
• Product Length (in): 16.5

• Product Weight (lb): 20
• Product Weight (lb) (with Battery): 21.5
• Reaction Bar: Yes
• Recommended Forward Torque Range (ft-lb): 148-738
• Recommended Forward Torque Range (in-lb): 1770-8851
• Recommended Forward Torque Range (nm): 200 - 1000
• Retainer Type: Thru-hole
• Reversible: Reversible

• Speed Setting: Variable Speed
• Standards/Certifications: UL/CSA/CE/IP5X

• Tether Style: Tether Included
• User Interface: Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4

• Accessories: BC1161
• Accessories: BL4011

• Bundle Kit: QXXD5P

IR QXXD5PT10CPM12K2

3/4" 40V Cordless Torque Wrench 2 Battery Kit, Bluetooth/802.15.4, Pistol

Description: Meet the tool that's taking torque to the next level - the QX Series 40V Cordless Torque Multiplier, packed with all the power and precision to perform like no wrench has before. A highly evolved 40V addition to the QX Series, QX Series 40V Cordless Torque Multiplier is more rugged, powerful, and twice as fast as its 20V QX Series counterpart while still offering premium accuracy, comfort, and control. An on-board persistent clock automatically timestamps, an advanced cooling fan extends runtime, and an ergonomic handle maximizes support. But next-gen torque demands next-gen tech, which is why the 40V seamlessly integrates with the INSIGHT Connect app and INSIGHTqcx Controller to easily log tightening data, program tool functions, and so much more. Unmatched speed, unbound accessibility, unmistakable data - only with the uncompromising QX Series 40V Cordless Torque Multiplier.

Features And Benefits:

• PRODUCTIVITY: Integrate together with other QX Series tools in your assembly operations with wireless connection to the INSIGHTqcx Controller. Share tightening data via email for post processing verification through the free INSIGHT Connect app. Easy pairing to any Apple iOS or Google Android device to program torque, angle or both without t he need for a Wi-Fi network
• CONFIDENCE: Precision where you need it most. Ingersoll Rand's closed-loop transducer control at the heart of the tool delivers accurate, traceable torque and angle results. Forget manual pen and paper recording. Automatically record every tightening cycle to the day and minute with a persistent internal clock. Store 1,200 records on-board and easily download and share them through the free INSIGHT Connect app.
• DURABILITY: Longevity in harsh applications with steel reinforced motor housing. Cool under pressure, Internal fan operates independently of drive motor enabling repeated high torque operation without overheating. Bolt after bolt performance. Tighten up to 300 bolts to 995 foot pounds per charge on the IQV 40 Series battery.
• SAFETY: Tethering ring included for safety and drop prevention.
• COMFORT: Dual Axis 360 degree handle provides instant adjustability, maximizing comfort and flexibility when working on multiple joints and applications.
• KIT INCLUDES: (2) 40V 2.5 Ah BL4011 Batteries and BC1161 40V Universal Charger

• Includes: (2) 40V 2.5 Ah BL4011 Batteries, BC1161 40V Universal Charger
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Bolts per Charge (on and Off): 300
• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Heavy Duty

• Gearbox Width (in): 2.8

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 15
• Max Torque (ft-lb): 738
• Max Torque (in-lb): 8851
• Max Torque (nm): 1000
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 16.7

• Product Weight (lb): 20
• Product Weight (lb) (with Battery): 21.5
• Reaction Bar: Yes
• Retainer Type: Thru-hole
• Reversible: Reversible

• Tether Style: Tether Included
• User Interface: Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth

IR QXXD5PT13CPM16K2

1" 40V Cordless Torque Wrench 2 Battery Kit, Bluetooth/802.15.4, Pistol

Description: Meet the tool that's taking torque to the next level - the QX Series 40V Cordless Torque Multiplier, packed with all the power and precision to perform like no wrench has before. A highly evolved 40V addition to the QX Series, QX Series 40V Cordless Torque Multiplier is more rugged, powerful, and twice as fast as its 20V QX Series counterpart while still offering premium accuracy, comfort, and control. An on-board persistent clock automatically timestamps, an advanced cooling fan extends runtime, and an ergonomic handle maximizes support. But next-gen torque demands next-gen tech, which is why the 40V seamlessly integrates with the INSIGHT Connect app and INSIGHTqcx Controller to easily log tightening data, program tool functions, and so much more. Unmatched speed, unbound accessibility, unmistakable data - only with the uncompromising QX Series 40V Cordless Torque Multiplier.

Features And Benefits:

• PRODUCTIVITY: Integrate together with other QX Series tools in your assembly operations with wireless connection to the INSIGHTqcx Controller. Share tightening data via email for post processing verification through the free INSIGHT Connect app. Easy pairing to any Apple iOS or Google Android device to program torque, angle or both without t he need for a Wi-Fi network
• CONFIDENCE: Precision where you need it most. Ingersoll Rand's closed-loop transducer control at the heart of the tool delivers accurate, traceable torque and angle results. Forget manual pen and paper recording. Automatically record every tightening cycle to the day and minute with a persistent internal clock. Store 1,200 records on-board and easily download and share them through the free INSIGHT Connect app.
• DURABILITY: Longevity in harsh applications with steel reinforced motor housing. Cool under pressure, Internal fan operates independently of drive motor enabling repeated high torque operation without overheating. Bolt after bolt performance. Tighten up to 300 bolts to 995 foot pounds per charge on the IQV 40 Series battery.
• SAFETY: Tethering ring included for safety and drop prevention.
• COMFORT: Dual Axis 360 degree handle provides instant adjustability, maximizing comfort and flexibility when working on multiple joints and applications.
• KIT INCLUDES: (2) 40V 2.5 Ah BL4011 Batteries and BC1161 40V Universal Charger

• Includes: (2) 40V 2.5 Ah BL4011 Batteries, BC1161 40V Universal Charger
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Bolts per Charge (on and Off): 300
• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Heavy Duty

• Gearbox Width (in): 2.8

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 11
• Max Torque (ft-lb): 996
• Max Torque (in-lb): 11949
• Max Torque (nm): 1350
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 16.7

• Product Weight (lb): 20
• Product Weight (lb) (with Battery): 21.5
• Reaction Bar: Yes
• Retainer Type: Thru-hole
• Reversible: Reversible

• Tether Style: Tether Included
• User Interface: Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wir

IR QXXD5PT20CPM16K2

1" 40V Cordless Torque Wrench 2 Battery Kit, 17701 in-lb, Bluetooth/802.15.4, Pistol

Description: Meet the tool that's taking torque to the next level - the QX Series 40V Cordless Torque Multiplier, packed with all the power and precision to perform like no wrench has before. A highly evolved 40V addition to the QX Series, QX Series 40V Cordless Torque Multiplier is more rugged, powerful, and twice as fast as its 20V QX Series counterpart while still offering premium accuracy, comfort, and control. An on-board persistent clock automatically timestamps, an advanced cooling fan extends runtime, and an ergonomic handle maximizes support. But next-gen torque demands next-gen tech, which is why the 40V seamlessly integrates with the INSIGHT Connect app and INSIGHTqcx Controller to easily log tightening data, program tool functions, and so much more. Unmatched speed, unbound accessibility, unmistakable data - only with the uncompromising QX Series 40V Cordless Torque Multiplier.

Features And Benefits:

• PRODUCTIVITY: Integrate together with other QX Series tools in your assembly operations with wireless connection to the INSIGHTqcx Controller. Share tightening data via email for post processing verification through the free INSIGHT Connect app. Easy pairing to any Apple iOS or Google Android device to program torque, angle or both without t he need for a Wi-Fi network
• CONFIDENCE: Precision where you need it most. Ingersoll Rand's closed-loop transducer control at the heart of the tool delivers accurate, traceable torque and angle results. Forget manual pen and paper recording. Automatically record every tightening cycle to the day and minute with a persistent internal clock. Store 1,200 records on-board and easily download and share them through the free INSIGHT Connect app.
• DURABILITY: Longevity in harsh applications with steel reinforced motor housing. Cool under pressure, Internal fan operates independently of drive motor enabling repeated high torque operation without overheating. Bolt after bolt performance. Tighten up to 300 bolts to 995 foot pounds per charge on the IQV 40 Series battery.
• SAFETY: Tethering ring included for safety and drop prevention.
• COMFORT: Dual Axis 360 degree handle provides instant adjustability, maximizing comfort and flexibility when working on multiple joints and applications.
• KIT INCLUDES: (2) 40V 2.5 Ah BL4011 Batteries and BC1161 40V Universal Charger

• Includes: (2) 40V 2.5 Ah BL4011 Batteries, BC1161 40V Universal Charger
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Bolts per Charge (on and Off): 300
• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Heavy Duty

• Gearbox Width (in): 2.8

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 6.8
• Max Torque (ft-lb): 1475
• Max Torque (in-lb): 17701
• Max Torque (nm): 2000
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 18

• Product Weight (lb): 21
• Product Weight (lb) (with Battery): 22.5
• Reaction Bar: Yes
• Recommended Forward Torque Range (ft-lb): 295-1475
• Recommended Forward Torque Range (in-lb): 3540-17701
• Recommended Forward Torque Range (nm): 400-2000
• Retainer Type: Thru-hole
• Reversible: Reversible

• Tether Style: Tether

IR QXXD5PT10CPM12

3/4" 40V Cordless Torque Wrench, Bare Tool, 8851 in-lb Torque, Bluetooth/802.15.4, Pistol

Description: Meet the tool that's taking torque to the next level - the QX Series 40V Cordless Torque Multiplier, packed with all the power and precision to perform like no wrench has before. A highly evolved 40V addition to the QX Series, QX Series 40V Cordless Torque Multiplier is more rugged, powerful, and twice as fast as its 20V QX Series counterpart while still offering premium accuracy, comfort, and control. An on-board persistent clock automatically timestamps, an advanced cooling fan extends runtime, and an ergonomic handle maximizes support. But next-gen torque demands next-gen tech, which is why the 40V seamlessly integrates with the INSIGHT Connect app and INSIGHTqcx Controller to easily log tightening data, program tool functions, and so much more. Unmatched speed, unbound accessibility, unmistakable data - only with the uncompromising QX Series 40V Cordless Torque Multiplier.

Features And Benefits:

• PRODUCTIVITY: Integrate together with other QX Series tools in your assembly operations with wireless connection to the INSIGHTqcx Controller. Share tightening data via email for post processing verification through the free INSIGHT Connect app. Easy pairing to any Apple iOS or Google Android device to program torque, angle or both without t he need for a Wi-Fi network
• CONFIDENCE: Precision where you need it most. Ingersoll Rand's closed-loop transducer control at the heart of the tool delivers accurate, traceable torque and angle results. Forget manual pen and paper recording. Automatically record every tightening cycle to the day and minute with a persistent internal clock. Store 1,200 records on-board and easily download and share them through the free INSIGHT Connect app.
• DURABILITY: Longevity in harsh applications with steel reinforced motor housing. Cool under pressure, Internal fan operates independently of drive motor enabling repeated high torque operation without overheating. Bolt after bolt performance. Tighten up to 300 bolts to 995 foot pounds per charge on the IQV 40 Series battery.
• SAFETY: Tethering ring included for safety and drop prevention.
• COMFORT: Dual Axis 360 degree handle provides instant adjustability, maximizing comfort and flexibility when working on multiple joints and applications.

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Bolts per Charge (on and Off): 300
• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Heavy Duty

• Gearbox Width (in): 2.8

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 15
• Max Torque (ft-lb): 738
• Max Torque (in-lb): 8851
• Max Torque (nm): 1000
• Motor: Brushless Motor

• Number of Batteries Required: 1
• Power Source: Battery Powered
• Product Length (in): 16.7

• Product Weight (lb): 20
• Product Weight (lb) (with Battery): 21.5
• Reaction Bar: Yes
• Recommended Forward Torque Range (ft-lb): 148-738
• Recommended Forward Torque Range (in-lb): 1770-8851
• Recommended Forward Torque Range (nm): 200 - 1000
• Retainer Type: Thru-hole
• Reversible: Reversible

• Tether Style: Tether Included
• User Interface: Dis

IR TL15B

Linear Torque Arm, 15Nm Max Torque, 12in Reach, Bench Mount

Features And Benefits:

• Spring balancer adjusts easily and offers effortless vertical movement.
• Simple, proven design for easy setup and dependability.
• Multiple Torque Options: Available in 15 Nm and 30 Nm models to accommodate a wide range of torque requirements.
• Compact Linear Design: Reach lengths of 300mm to provide precise, linear tool guidance in confined workspaces.
• Bench Mount Configuration: Both models are designed for bench mounting, ensuring a stable and secure setup for consistent torque application.
• Durable Construction: Built for industrial environments, offering long-lasting performance with minimal maintenance.
• Smooth Linear Motion: Engineered for low-friction movement, enabling effortless tool positioning and improved ergonomics.

Product Application and Uses:

For use with Ingersoll Rand IQI and QE2 Series Precision Fastening Screwdrivers.

• Capacity (lb): 11

• Max Torque (ft-lb): 11
• Max Torque (in-lb): 133
• Max Torque (nm): 15

• For Use With: IQI4LT1500TQ4
• For Use With: IQI2LT0250TQ4
• For Use With: IQI2LC0250TQ4
• For Use With: IQI4LT0500TQ4
• For Use With: IQI4LC1000PQ4
• For Use With: IQI4LC1500TQ4
• For Use With: IQI2LC0050TQ4
• For Use With: IQI2LC0200TQ4
• For Use With: IQI4LC1000TQ4
• For Use With: IQI2LT0017PM4
• For Use With: IQI4LC0500TQ4
• For Use With: IQI2LC0017PQ4
• For Use With: IQI2LC0200PQ4
• For Use With: IQI4LT0500PQ4
• For Use With: IQI2LC0100TQ4
• For Use With: IQI2LT0017PQ4
• For Use With: IQI2LT0250PQ4
• For Use With: IQI2LC0017PM4
• For Use With: IQI2LC0050PQ4
• For Use With: IQI4LC1500PQ4
• For Use With: IQI2LT0100TQ4

• For Use With: IQI4LT1500PQ4
• For Use With: IQI2LC0100PQ4
• For Use With: IQI2LT0050PQ4
• For Use With: IQI2LT0200PQ4
• For Use With: IQI2LT0017TM4
• For Use With: IQI2LT0200TQ4
• For Use With: IQI2LC0017TQ4
• For Use With: IQI2LC0250PQ4
• For Use With: IQI2LT0100PQ4
• For Use With: IQI2LT0050TQ4
• For Use With: IQI4LC0500PQ4
• For Use With: IQI4LT1000TQ4
• For Use With: IQI2LT0017TQ4
• For Use With: IQI2LC0017TM4
• For Use With: IQI4LT1000PQ4

IR TL30B

IR TK-VP1-550-Q4

Standard 1/4" QC Drive Angle head

Product Application and Uses:

Common applications requiring a Special Head Adapter include assembling aircraft wings or installing door hinges on cars and trucks.

• Color: Grey

IR TK-VP1-550-S6

Standard 3/8" Square Drive Angle head

Product Application and Uses:

Common applications requiring a Special Head Adapter include assembling aircraft wings or installing door hinges on cars and trucks.

• Color: Grey

IR TP-VP1-A093RD

IR TK-RTS-726-S8-HWK

IR TK-RTS-499-2

IR TK-RTS-441

IR TK-RTS-726-S6

IR TR180S8

IR TP-VA1-A093RD

IR TR250S12

IR TK-RTS-BOOT-RD

IR TK-RTS-MRK

IR TP-VA1-070RD

IR VP2-49

Auxiliary Band Screw Service Part for Ingersoll Rand Torque Wrench

Product Application and Uses:

For Use with Ingersoll Rand QX Connect Precision Torque Multiplier Series

• Color: Grey

• For Use With: QXX2A52T0396PS12
• For Use With: QXX2A52T0594PS12
• For Use With: QXX5A45T0180PS12
• For Use With: QXX5A45T0270PS12
• For Use With: QXX5A52T0880PS12
• For Use With: QXX5A72T1080PS16
• For Use With: QXX5A72T1620PS16
• For Use With: QXXD2PT10CPM12
• For Use With: QXXD2PT10CPM12-K2
• For Use With: QXXD2PT200PM12
• For Use With: QXXD2PT200PM12-K2
• For Use With: QXXD2PT500PM12
• For Use With: QXXD2PT500PM12-K2
• For Use With: QXXD5PT01KPW16
• For Use With: QXXD5PT01KPW16K2
• For Use With: QXXD5PT10CPM12K2
• For Use With: QXXD5PT13CPM16
• For Use With: QXXD5PT13CPM16K2
• For Use With: QXXD5PT200PM12K2
• For Use With: QXXD5PT20CPM16K2
• For Use With: QXXD5PT27CPM16

• For Use With: QXXD5PT27CPM16K2
• For Use With: QXXD5PT40CPM16K2
• For Use With: QXXD5PT500PM12K2

IR VP2-49-2

Auxiliary Band Washer Service Part for Ingersoll Rand Torque Wrench

Product Application and Uses:

For Use with Ingersoll Rand QX Connect Precision Torque Multiplier Series

• Color: Grey

• For Use With: QXX2A52T0396PS12
• For Use With: QXX2A52T0594PS12
• For Use With: QXX5A45T0180PS12
• For Use With: QXX5A45T0270PS12
• For Use With: QXX5A52T0880PS12
• For Use With: QXX5A72T1080PS16
• For Use With: QXX5A72T1620PS16
• For Use With: QXXD2PT10CPM12
• For Use With: QXXD2PT10CPM12-K2
• For Use With: QXXD2PT200PM12
• For Use With: QXXD2PT200PM12-K2
• For Use With: QXXD2PT500PM12
• For Use With: QXXD2PT500PM12-K2
• For Use With: QXXD5PT01KPW16
• For Use With: QXXD5PT01KPW16K2
• For Use With: QXXD5PT10CPM12K2
• For Use With: QXXD5PT13CPM16
• For Use With: QXXD5PT13CPM16K2
• For Use With: QXXD5PT200PM12K2
• For Use With: QXXD5PT20CPM16K2
• For Use With: QXXD5PT27CPM16

• For Use With: QXXD5PT27CPM16K2
• For Use With: QXXD5PT40CPM16K2
• For Use With: QXXD5PT500PM12K2

IR VP2-405

Auxiliary Handle Spring Service Part for Ingersoll Rand Torque Wrench

Product Application and Uses:

For Use with Ingersoll Rand QX Connect Precision Torque Multiplier Series

• Color: Grey

• For Use With: QXX2A52T0396PS12
• For Use With: QXX2A52T0594PS12
• For Use With: QXX5A45T0180PS12
• For Use With: QXX5A45T0270PS12
• For Use With: QXX5A52T0880PS12
• For Use With: QXX5A72T1080PS16
• For Use With: QXX5A72T1620PS16
• For Use With: QXXD2PT10CPM12
• For Use With: QXXD2PT10CPM12-K2
• For Use With: QXXD2PT200PM12
• For Use With: QXXD2PT200PM12-K2
• For Use With: QXXD2PT500PM12
• For Use With: QXXD2PT500PM12-K2
• For Use With: QXXD5PT01KPW16
• For Use With: QXXD5PT01KPW16K2
• For Use With: QXXD5PT10CPM12K2
• For Use With: QXXD5PT13CPM16
• For Use With: QXXD5PT13CPM16K2
• For Use With: QXXD5PT200PM12K2
• For Use With: QXXD5PT20CPM16K2
• For Use With: QXXD5PT27CPM16

• For Use With: QXXD5PT27CPM16K2
• For Use With: QXXD5PT40CPM16K2
• For Use With: QXXD5PT500PM12K2

IR VP2-405-2

Auxiliary Handle Wave Spring Service Part for Ingersoll Rand Torque Wrench

Product Application and Uses:

For Use with Ingersoll Rand QX Connect Precision Torque Multiplier Series

• Color: Grey

• For Use With: QXX2A52T0396PS12
• For Use With: QXX2A52T0594PS12
• For Use With: QXX5A45T0180PS12
• For Use With: QXX5A45T0270PS12
• For Use With: QXX5A52T0880PS12
• For Use With: QXX5A72T1080PS16
• For Use With: QXX5A72T1620PS16
• For Use With: QXXD2PT10CPM12
• For Use With: QXXD2PT10CPM12-K2
• For Use With: QXXD2PT200PM12
• For Use With: QXXD2PT200PM12-K2
• For Use With: QXXD2PT500PM12
• For Use With: QXXD2PT500PM12-K2
• For Use With: QXXD5PT01KPW16
• For Use With: QXXD5PT01KPW16K2
• For Use With: QXXD5PT10CPM12K2
• For Use With: QXXD5PT13CPM16
• For Use With: QXXD5PT13CPM16K2
• For Use With: QXXD5PT200PM12K2
• For Use With: QXXD5PT20CPM16K2
• For Use With: QXXD5PT27CPM16

• For Use With: QXXD5PT27CPM16K2
• For Use With: QXXD5PT40CPM16K2
• For Use With: QXXD5PT500PM12K2

IR VP1-105

IR VP1-365

Suspension Bail Kit for Ingersoll Rand QC Clutch Tools

Product Application and Uses:

For use with Ingersoll Rand 20V QC Series Clutch Tools (QCP2A30S6, QCP2P02Q4, QCP2P04Q4, QCP2P08Q4, QCP2P12Q4, QCN2A30S6, QCN2P02Q4, QCN2P04Q4, QCN2P08Q4, QCN2P12Q4)

• Includes: Suspension Bail

• For Use With: QCN2A30S6
• For Use With: QCN2A30S6-K2
• For Use With: QCN2A30S6-K2-CN
• For Use With: QCN2A30S6-K2-EU
• For Use With: QCN2A30S6-K2-IN
• For Use With: QCN2P02Q4
• For Use With: QCN2P02Q4-K2
• For Use With: QCN2P02Q4-K2-CN
• For Use With: QCN2P02Q4-K2-EU
• For Use With: QCN2P02Q4-K2-IN
• For Use With: QCN2P04Q4
• For Use With: QCN2P04Q4-K2
• For Use With: QCN2P04Q4-K2-CN
• For Use With: QCN2P04Q4-K2-EU
• For Use With: QCN2P04Q4-K2-IN
• For Use With: QCN2P08Q4
• For Use With: QCN2P08Q4-K2
• For Use With: QCN2P08Q4-K2-CN
• For Use With: QCN2P08Q4-K2-EU
• For Use With: QCN2P08Q4-K2-IN
• For Use With: QCN2P12Q4

• For Use With: QCN2P12Q4-K2
• For Use With: QCN2P12Q4-K2-CN
• For Use With: QCN2P12Q4-K2-EU
• For Use With: QCN2P12Q4-K2-IN
• For Use With: QCP2A30S6
• For Use With: QCP2A30S6-K2-CN
• For Use With: QCP2A30S6-K2-EU
• For Use With: QCP2A30S6-K2-IN
• For Use With: QCP2P02Q4
• For Use With: QCP2P02Q4-K2-CN
• For Use With: QCP2P02Q4-K2-EU
• For Use With: QCP2P02Q4-K2-IN
• For Use With: QCP2P04Q4
• For Use With: QCP2P04Q4-K2-CN
• For Use With: QCP2P04Q4-K2-EU
• For Use With: QCP2P04Q4-K2-IN
• For Use With: QCP2P08Q4
• For Use With: QCP2P08Q4-K2-CN
• For Use With: QCP2P08Q4-K2-EU
• For Use With: QCP2P08Q4-K2-IN
• For Use With: QCP2P12Q4
• For Use With: QCP2P12Q4-K2-CN
• For Use With: QCP2P12Q4-K2-EU
• For Use With: QCP2P12Q4-K2-IN
• For Use With: RTS025PQ4
• For Use With: RTS025PQ4-K2

• For Use With: RTS060PH6
• For Use With: RTS060PH6-K2
• For Use With: RTS060PH8
• For Use With: RTS060PH8-K2
• For Use With: RTS060PS6
• For Use With: RTS060PS6-K2
• For Use With: RTS060PS8
• For Use With: RTS060PS8-K2
• For Use With: RTS140PH8
• For Use With: RTS140PH8-K2
• For Use With: RTS140PS8
• For Use With: RTS140PS8-K2
• For Use With: RTS225PH8
• For Use With: RTS225PH8-K2
• For Use With: RTS225PS8
• For Use With: RTS225PS8-K2

IR VP1-K40

QX Pistol Special Head Adapter

Description: The QX Pistol Special Head Adapter is the perfect solution to simply increase the flexibility of your QX pistol screwdriver. Using this adapter leverages the closed loop capability of the QX tool to the most unique applications. The adapter helps manufacturers meet the requirements of unique applications, including where restricted access requires a custom head to reach the fastener. Common applications requiring a Special Head Adapter include assembling aircraft wings or installing door hinges on cars and trucks.

Product Application and Uses:

Common applications requiring a Special Head Adapter include assembling aircraft wings or installing door hinges on cars and trucks.

• Color: Grey

IR VP1-GN-BOOT-NP

IR VP1-GN-BOOT

IR VP1-BL-BOOT-NP

IR VP1-BK-BOOT

IR VP1-A8-S6

IR Y-9010-1055-0000

IR Y-9010-6048-0000

IR W64-118

IR WDBR1-47RKT
