Hydraullic Units

EP 68029E

SHEAR SEAL
Electric Pump Wheeled Cylinder (PR-Series and equivalent)

• Type: Service Kit

• SubTypes: Seal Kit

EP 68849E

PLATE-BOTTOM
Electric Pump Wheeled Cylinder (PR-Series and equivalent)

• Type: Service Kit

• SubTypes: Plate

EP 68855E

Gear Set 3/8

EP 68884E

SCREEN
Electric Pump Wheeled Cylinder (PR-Series and equivalent)

• Type: Service Kit

• SubTypes: Repair Part

EP 69091E

VALVE HANDLE
Electric Pump Wheeled Cylinder (PR-Series and equivalent)

• Type: Service Kit

• SubTypes: Handle

EP 85726E

GASKET 25/64X19/32
Electric Pump Wheeled Cylinder (PR-Series and equivalent)

• Type: Service Kit

• SubTypes: Gasket

EP 86242E

AIR LUBRICATOR
Electric Pump Wheeled Cylinder (PR-Series and equivalent)

• Type: Service Kit

• SubTypes: Repair Part

EP 89292E

WARNING DECAL POW'R RISER
Air Pump Wheeled Cylinder (PR-Series and equivalent)

• Type: Component

• SubTypes: Decal

EP 89967E

ENERPAC LOGO 10.82" x 2.3"
Air Pump Wheeled Cylinder (PR-Series and equivalent)

• Type: Component

• SubTypes: Repair Part

EP A-252G

25 TON SNAP-IN GROOVED SADDLE

EP A-630

1/4 SPEE-D-COUPLER

EP B1012028

SOCKET HEAD CAP SCREW
Single-Acting Cylinders (RC-Series and equivalent)

• Type: Service Kit

• SubTypes: Screw

EP BRW102

55,4 mm Stroke, 50,6 kN Capacity, General Purpose Hydraulic Cylinder

• Type: Hydraulic Cylinders
• Max Bar: 700
• Max PSI: 10000
• Min Bar: 40

• Product Group: Cylinders and Jacks
• Product Line: Work Holding Tools
• Series: BRW
• Stroke MM: 55.4
• SubTypes: Workholding General Purpose Cylinder

• Single-acting heavy-duty cylinders handle a variety of applications
• High pressure (700 bar) design when additional force is required
• Long stroke lengths in compact design, well suited for welding applications
• Collar thread and base mounting holes allow flexible mounting options
• Hardened snap-in removable saddles for additional plunger protection
• Chrome plated plunger with bronze upper and lower bearing provide long life

EP C211

3/8" NPTF, High Flow Ram Coupler Half with Dust Cap
These premium grade couplers provide maximum fluid flow and are plated to resist corrosion. Cylinder Half Couplers have male 3/8†NPTFthreads & high strength rubber dust caps; Hose Half Couplers have female 3/8†NPTF threads.

• Type: Coupler

• Product Line: Hydraulic Tools
• Series: C - Simplex
• SubTypes: Coupler Set

EP CATS12

Tilt Saddle for 10-15 Ton RC Series Cylinders, and 10 Ton RR Series Cylinders
The use of a tilt saddle can extend the life of an Enerpac cylinder. Hydraulic cylinders are built to ensure efficient and safe use time after time, but even the toughest cylinders can be damaged by an excessive side load. Side loading can occur even when the load is vertically placed on top of the cylinder, when cylinders are extended too far - (especially long stroke cylinders), or when the saddle on the end of the plunger fails to make sufficient contact with the load. Greater contact can be achieved using Enerpac Tilt Saddles.

• Type: Cylinder Accessories

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: CATS
• SubTypes: Tilt Saddle

• With safety and convenience in mind the new tilt saddles are designed to allow bolting to the cylinder - which means they can be used safely in any orientation without the risk of the saddle dropping off.
• CATS-Tilt Saddles use a nitrocarburization surface treatment for improved corrosion protection, helping to maintain a professional look through their usage life.

EP CATS200

Tilt Saddle for 150 Ton RAC Series Cylinders, and 200 Ton HCG and HCR Series Cylinders
The use of a tilt saddle can extend the life of an Enerpac cylinder. Hydraulic cylinders are built to ensure efficient and safe use time after time, but even the toughest cylinders can be damaged by an excessive side load. Side loading can occur even when the load is vertically placed on top of the cylinder, when cylinders are extended too far - (especially long stroke cylinders), or when the saddle on the end of the plunger fails to make sufficient contact with the load. Greater contact can be achieved using Enerpac Tilt Saddles.

• Type: Cylinder Accessories

• Product Group: Cylinders and Jacks
• Product Line: Industrial Tools
• Series: CATS
• SubTypes: Tilt Saddle

• With safety and convenience in mind the new tilt saddles are designed to allow bolting to the cylinder - which means they can be used safely in any orientation without the risk of the saddle dropping off.
• CATS-Tilt Saddles use a nitrocarburization surface treatment for improved corrosion protection, helping to maintain a professional look through their usage life.

EP CB241218W

TREADLE-AIR PUMPS
PA-Series

• Type: Service Kit

• SubTypes: Repair Part

EP CBE837028-1A

SCREW-SHCS, HEX, M8X1.25 X 60, 8.8, ZINC
VE Pump Mounted Directional Control Valves

• Type: Service Kit

• SubTypes: Screw

EP CDT-18251

3950LB. THRD. CYL, .98 STROKE IMPERIA

EP CL343550

HANDLE GRIP
Ultra High Pressure Hand Pumps

• Type: Service Kit

• SubTypes: Handle & Grip Assembly

EP CST-18131

3950 LB. THRD. CYL .51 STROKE IMPERIAL

EP CST27151

6110 lbs Capacity, 0.59 in Stroke, Single-Acting, Threaded Body, Hydraulic Cylinder
Applications: Push

• Type: Hydraulic Cylinders
• Max PSI: 5000

• Product Group: Cylinders and Jacks
• Product Line: Work Holding Tools
• Series: CST
• Stroke Inches: 0.59
• SubTypes: Workholding Threaded Cylinder

• Minimum cylinder diameter combined with maximized clamping forces
• Threaded body allows fine positioning and easy installation
• Internal plunger wipers allow maintenance-free, high-cycle performance
• Center-tapped plungers will hold workpiece contact buttons
• Single-acting models with spring return simplify hydraulic tubing requirements
• Double-acting models are recommended for high-cycle applications

• Accessories: MF421, FN421, BS91

EP CW261225

EYELET
PU/PMU/WU-Series

• Type: Service Kit

• SubTypes: Repair Part

EP DA5875380

TRANSFORMER 115/230 VAC PRI 24VDC SEC
PU/PMU/WU-Series

• Type: Service Kit

• SubTypes: Repair Part

EP DA608024

VENT PLUG
Battery BP-Series

• Type: Service Kit

• SubTypes: Plug
