GRACO INC. S10595
1/2in Air Regulator
GG 104266
REGULATOR, AIR W PSI 250
Graco 104266 Air Regulator, 1/2(f) inlet/outlet, 0-250 psi (0-17 bar), zinc plated
- Multiple outlets for connecting equipment, gauges, or ball valves
- Accurate adjustment of air pressure for process control
- Air Inlet Size (cm): 1.27
- Air Inlet Size (in): 1/2
- Air Inlet Size (mm): 12.7
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- For Use With: Monark, President Lube Ranger
- Gauge Port Size (cm): 0.635
- Gauge Port Size (in): 1/4
- Gauge Port Size (mm): 6.35
- Gauge Port Type: NPT
- Handle Type: Tee
- Includes: Regulator Only
- Maximum Air Flow Rate (SCFM): 90
- Maximum Air Inlet Pressure (bar): 21
- Maximum Air Inlet Pressure (kPa): 2100
- Maximum Air Inlet Pressure (MPa): 2.1
- Maximum Air Inlet Pressure (psi): 300
- Maximum Operating Temperature ( degree C): 49
- Maximum Operating Temperature ( degree F): 120
- Maximum Regulated Pressure (bar): 17.5
- Maximum Regulated Pressure (kPa): 1800
- Maximum Regulated Pressure (MPa): 1.75
- Maximum Regulated Pressure (psi): 250
- Minimum Operating Temperature ( degree C): 4
- Minimum Operating Temperature ( degree F): 40
- Minimum Regulated Pressure (bar): 0
- Minimum Regulated Pressure (kPa): 0
- Minimum Regulated Pressure (psi): 0
- Outlet Size (cm): 1.27
- Outlet Size (in): 1/2
- Outlet Size (mm): 12.7
- Outlet Thread Gender: Female
- Outlet Thread Type: NPT
1/2in Air Regulator
GG 104267
REGULATOR, AIR 125 LB WORKING PRESSURE
Graco 104267 Air Regulator, 1/2(f) inlet/outlet, 0-125 psi (0-8.6 bar), zinc plated
- Multiple outlets for connecting equipment, gauges, or ball valves
- Accurate adjustment of air pressure for process control
- Air Inlet Size (cm): 1.27
- Air Inlet Size (in): 1/2
- Air Inlet Size (mm): 12.7
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- For Use With: Monark, President, Husky 1030, Glutton
- Gauge Port Size (cm): 0.635
- Gauge Port Size (in): 1/4
- Gauge Port Size (mm): 6.35
- Gauge Port Type: NPT
- Handle Type: Tee
- Includes: Regulator Only
- Maximum Air Flow Rate (SCFM): 90
- Maximum Air Inlet Pressure (bar): 21
- Maximum Air Inlet Pressure (kPa): 2100
- Maximum Air Inlet Pressure (MPa): 2.1
- Maximum Air Inlet Pressure (psi): 300
- Maximum Operating Temperature ( degree C): 49
- Maximum Operating Temperature ( degree F): 120
- Maximum Regulated Pressure (bar): 9
- Maximum Regulated Pressure (kPa): 900
- Maximum Regulated Pressure (MPa): 0.9
- Maximum Regulated Pressure (psi): 125
- Minimum Operating Temperature ( degree C): 4
- Minimum Operating Temperature ( degree F): 40
- Minimum Regulated Pressure (bar): 0
- Minimum Regulated Pressure (kPa): 0
- Minimum Regulated Pressure (psi): 0
- Outlet Size (cm): 1.27
- Outlet Size (in): 1/2
- Outlet Size (mm): 12.7
- Outlet Thread Gender: Female
- Outlet Thread Type: NPT
Stainless Steel High Pressure Fluid Gauge, 0-1000 psi (0-68 bar) pressure range
GG 105770
GAUGE, PRESS, FLUID
Graco 105770 Stainless Steel High Pressure Fluid Gauge, 0-1000 psi (0-68 bar) pressure range
- Stainless Steel High Pressure Fluid Gauges
Corrosion Resistant
2.5 in (63 mm) diameter dial
1/4 in NPT(M) connection
Bottom mount
Shatterproof glass
Liquid filled to reduce indicator pulsation
- Dial Diameter (cm): 6
- Dial Diameter (in): 2.5
- Dial Diameter (mm): 64
- Inlet Size (cm): 0.635
- Inlet Size (in): 1/4
- Inlet Size (mm): 6.35
- Inlet Thread Gender: Male
- Inlet Thread Type: NPT
- Material: Stainless Steel
- Maximum Working Pressure (bar): 69
- Maximum Working Pressure (kPa): 6900
- Maximum Working Pressure (MPa): 6.9
- Maximum Working Pressure (psi): 1000
Cover, Roller
GG 107590
COVER, ROLLER
Graco 107590 9 in Pressure Roller Cover, 1/2 in nap
Roller cover specifically created for the EvenFlow Pressure Roller, 1/2 inch nap for semi-smooth surfaces.
- Model: Graco
- Series: Roller Cover
- For Use With: EvenFlow Roller Frame
Element, Filter
GG 108107
ELEMENT, FILTER
Graco 108107 Pump Feed Kit, 36 sq. in., 60 mesh, Carbon Steel Fluid Filter Element
Recommended "tool box" spare parts. Keep on hand to reduce down time.
Application: For use with Low Pressure, Medium Volume " Red Alert" Filters
Element, Filter
GG 108108
ELEMENT, FILTER
Graco 108108 Pump Feed Kit, 36 sq. in., 100 mesh, Carbon Steel Fluid Filter Element
Recommended "tool box" spare parts. Keep on hand to reduce down time.
Application: For use with Low Pressure, Medium Volume " Red Alert" Filters
Element, Filter
GG 108112
ELEMENT, FILTER
Graco 108112 Replacement Fluid Filter, 60 stainless steel mesh
Recommended "tool box" spare parts. Keep on hand to reduce down time.
Application: For use with High Pressure, Medium Volume " Red Alert" Filters
FRP Rs Gel System, Xg, 13:1, Cart, 25
GG 16R001
FRP RS GEL SYSTEM, XG, 13:1, CART, 25
Graco 16R001 13:1 Ratio External Mix Gel System with 25 ft (7.6 m) Hose and Cart
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XG
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Includes: Hose, Cart
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa): 9000
- Maximum Wo
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Gel System, Xg, 17:1, Cart, 25
GG 16R005
FRP RS GEL SYSTEM, XG, 17:1, CART, 25
Graco 16R005 17:1 Ratio External Mix Gel System with 25 ft (7.6 m) Hose and Cart
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XG
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Includes: Hose, Cart
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 4160
- Maximum Flow Rate (GPM): 1.1
- Maximum Flow Rate (L/min): 4.16
- Maximum Working Pressure (bar): 119
- Maximum Working Pressure (kPa): 11900
- Maximum
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
Kit, Relief/Recirc Valve
GG 16N975
KIT,RELIEF/RECIRC VALVE
KIT INCLUDES: VALVE, 3000 PSI BLOW OFF [QTY. 1], BASE, VALVE [QTY. 1], HANDLE, [QTY. 1], PIN, SPRING [QTY. 2]
- Color: Black
FRP Rs Chop System, Ic, 13:1, Cmb, 25
GG 16R004
FRP RS CHOP SYSTEM, IC, 13:1, CMB, 25
Graco 16R004 13:1 Ratio Internal Mix Chop System with 25 ft (7.6 m) Hose, Cart, Mast, and Boom
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized Ratio Stability
- Lower Cost of Ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: IC
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Includes: Hose, Cart, Mast, Boom
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa):
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower Cost of Ownership
FRP Rs Gel System, Xg, 13:1, Cmb, 25
GG 16R018
FRP RS GEL SYSTEM, XG, 13:1, CMB, 25
Graco 16R018 13:1 Ratio External Mix Gel System with 25 ft (7.6 m) Hose, Cart, Mast, and Boom
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XG
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component A Inlet Size (mm): 9.525
- Component B Inlet Size (in): 1-5/16
- Component B Inlet Size (mm): 33.34
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Includes: Hose, Cart, Mast, Boom
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi):
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Gel System, Ig, 13:1, Cart, Nh
GG 16R050
FRP RS GEL SYSTEM, IG, 13:1, CART, NH
Graco 16R050 13:1 Ratio Cart Mounted Internal Mix Gel System
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized Ratio Stability
- Lower Cost of Ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: IG
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Includes: Cart
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa): 9000
- Maximum Working Pressure (MPa): 9
- Maximum Working Pressure (psi): 1300
- Overall
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower Cost of Ownership
FRP Rs Gel System, Xg, 13:1, Cart, 50
GG 16R012
FRP RS GEL SYSTEM, XG, 13:1, CART, 50
Graco 16R012 13:1 Ratio External Mix Gel System with 50 ft (15.2 m) Hose and Cart
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XG
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 50
- Hose Length (m): 15.2
- Includes: Hose, Cart
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa): 9000
- Maximum
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
Ext Mix Chop System, Xc, 13:1 Cart, 50 ft Hose Obsolete
GG 16R082
FRP RS CHOP SYSTEM, XC, 13:1, CART, 50
Graco 16R082 13:1 Ratio External Mix Chop System with 50 ft (15.2 m) Hose and Cart
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XC
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component A Inlet Size (mm): 9.525
- Component B Inlet Size (in): 1-5/16
- Component B Inlet Size (mm): 33.34
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 50
- Hose Length (m): 15.2
- Includes: Hose, Cart
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- <
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
Kit, Repair, Throat Seals, Catal
GG 16N963
KIT,REPAIR,THROAT SEALS,CATAL
KIT INCLUDES: SEAL, SLAVE PUMP WEEP [QTY. 2], SEAL, SNAP ON, CARTRIDGE [QTY. 1], O-RING, SILICONE #016 [QTY. 1], O-RING, O-RING, SILICONE, 2-014 [QTY. 2], RING, BACKUP, .518 ID, .053 WIDE [QTY. 2], TOOL, ASSEMBLY BULLET [QTY. 1], KIT, ASSEMBLY TOOL, WEEP SEAL [QTY. 1]
FRP Rs Chop System, Xc, 13:1, Cmb, 25
GG 16R003
FRP RS CHOP SYSTEM, XC, 13:1, CMB, 25
Graco 16R003 13:1 Ratio External Mix Chop System with 25 ft (7.6 m) Hose, Cart, Mast, and Boom
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XC
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Includes: Hose, Cart, Mast, Boom
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa):
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Chop System, Xc, 13:1, Cart, 25
GG 16R088
FRP RS CHOP SYSTEM, XC, 13:1, CART, 25
Graco 16R088 13:1 Ratio External Mix Chop System with 25 ft (7.6 m) Hose and Cart
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XC
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Includes: Hose, Cart
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa): 9000
- Maximum
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Chop System, Xc, 13:1, Cmb, 35
GG 16R091
FRP RS CHOP SYSTEM, XC, 13:1, CMB, 35
Graco 16R091 13:1 Ratio External Mix Chop System with 35 ft (10.7 m) Hose, Cart, Mast, and Boom
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XC
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 35
- Hose Length (m): 10.7
- Includes: Hose, Cart, Mast, Boom
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa):
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
Transformer, 120VAC to24VDC, M12 Conn
GG 16N946
Transformer, 120VAC to24VDC, M12 Conn
FRP Rs Chop System, Xc, 13:1, Cmb, 50
GG 16R094
FRP RS CHOP SYSTEM, XC, 13:1, CMB, 50
Graco 16R094 13:1 Ratio External Mix Chop System with 50 ft (15.2 m) Hose, Cart, Mast, and Boom
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XC
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 50
- Hose Length (m): 15.2
- Includes: Hose, Cart, Mast, Boom
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa):
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Chop System, Xc, 13:1, No, 25
GG 16R100
FRP RS CHOP SYSTEM, XC, 13:1, NO, 25
Graco 16R100 13:1 Ratio External Mix Chop System with 25 ft (7.6 m) Hose
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
Easy user interface with all gauges in one location
- Model: FRP
- Series: XC
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Includes: Hose,
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa): 9000
- Maximum Working Pressure (MPa): 9
- Maximum Working Pressure (psi): 1300
- Overall Depth (cm): 81.3
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Chop System, Xc, 13:1, No, 50
GG 16R106
FRP RS CHOP SYSTEM, XC, 13:1, NO, 50
Graco 16R106 13:1 Ratio External Mix Chop System with 50 ft (15.2 m) Hose
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
Easy user interface with all gauges in one location
- Model: FRP
- Series: XC
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component A Inlet Size (mm): 9.525
- Component B Inlet Size (in): 1-5/16
- Component B Inlet Size (mm): 33.34
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 50
- Hose Length (m): 15.2
- Includes: Hose,
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min):
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Chop System, Xc, 13:1, No, Nh
GG 16R109
FRP RS CHOP SYSTEM, XC, 13:1, NO, NH
Graco 16R109 13:1 Ratio External Mix Chop System
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
Easy user interface with all gauges in one location
- Model: FRP
- Series: XC
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component A Inlet Size (mm): 9.525
- Component B Inlet Size (in): 1-5/16
- Component B Inlet Size (mm): 33.34
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa): 9000
- Maximum Working Pres
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Chop System, Ic, 13:1, Cmb, 35
GG 16R126
FRP RS CHOP SYSTEM, IC, 13:1, CMB, 35
Graco 16R126 13:1 Ratio Internal Mix Chop System with 35 ft (10.7 m) Hose, Cart, Mast, and Boom
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized Ratio Stability
- Lower Cost of Ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: IC
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 35
- Hose Length (m): 10.7
- Includes: Hose, Cart, Mast, Boom
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa):
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower Cost of Ownership
FRP Rs Chop System, Ic, 13:1, No, 25
GG 16R135
FRP RS CHOP SYSTEM, IC, 13:1, NO, 25
Graco 16R135 13:1 Ratio Internal Mix Chop System with 25 ft (7.6 m) Hose
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized Ratio Stability
- Lower Cost of Ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: IC
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component A Inlet Size (mm): 9.525
- Component B Inlet Size (in): 1-5/16
- Component B Inlet Size (mm): 33.34
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Includes: Hose,
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flo
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower Cost of Ownership
FRP Rs Chop System, Ic, 13:1, No, 50
GG 16R141
FRP RS CHOP SYSTEM, IC, 13:1, NO, 50
Graco 16R141 13:1 Ratio Internal Mix Chop System with 50 ft (15.2 m) Hose
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized Ratio Stability
- Lower Cost of Ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: IC
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component A Inlet Size (mm): 9.525
- Component B Inlet Size (in): 1-5/16
- Component B Inlet Size (mm): 33.34
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 50
- Hose Length (m): 15.2
- Includes: Hose,
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum F
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower Cost of Ownership
FRP Rs Gel System, Xg, 17:1, Cart, 35
GG 16R149
FRP RS GEL SYSTEM, XG, 17:1, CART, 35
Graco 16R149 17:1 Ratio External Mix Gel System with 35 ft (10.7 m) Hose and Cart
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XG
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 35
- Hose Length (m): 10.7
- Includes: Hose, Cart
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 4160
- Maximum Flow Rate (GPM): 1.1
- Maximum Flow Rate (L/min): 4.16
- Maximum Working Pressure (bar): 119
- Maximum Working Pressure (kPa): 11900
- Maximu
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Gel System, Xg, 17:1, Cart, 50
GG 16R152
FRP RS GEL SYSTEM, XG, 17:1, CART, 50
Graco 16R152 17:1 Ratio External Mix Gel System with 50 ft (15.2 m) Hose and Cart
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XG
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 50
- Hose Length (m): 15.2
- Includes: Hose, Cart
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 4160
- Maximum Flow Rate (GPM): 1.1
- Maximum Flow Rate (L/min): 4.16
- Maximum Working Pressure (bar): 119
- Maximum Working Pressure (kPa): 11900
- Maximu
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Gel System, Xg, 17:1, Cmb, 25
GG 16R158
FRP RS GEL SYSTEM, XG, 17:1, CMB, 25
Graco 16R158 17:1 Ratio External Mix Gel System with 25 ft (7.6 m) Hose, Cart, Mast, and Boom
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XG
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component A Inlet Size (mm): 9.525
- Component B Inlet Size (in): 1-5/16
- Component B Inlet Size (mm): 33.34
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Includes: Hose, Cart, Mast, Boom
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi):
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Gel System, Xg, 17:1, Cmb, 35
GG 16R161
FRP RS GEL SYSTEM, XG, 17:1, CMB, 35
Graco 16R161 17:1 Ratio External Mix Gel System with 35 ft (10.7 m) Hose, Cart, Mast, and Boom
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XG
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component A Inlet Size (mm): 9.525
- Component B Inlet Size (in): 1-5/16
- Component B Inlet Size (mm): 33.34
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 35
- Hose Length (m): 10.7
- Includes: Hose, Cart, Mast, Boom
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi):
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Gel System, Xg, 17:1, Cmb, 50
GG 16R164
FRP RS GEL SYSTEM, XG, 17:1, CMB, 50
Graco 16R164 17:1 Ratio External Mix Gel System with 50 ft (15.2 m) Hose, Cart, Mast, and Boom
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XG
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component A Inlet Size (mm): 9.525
- Component B Inlet Size (in): 1-5/16
- Component B Inlet Size (mm): 33.34
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 50
- Hose Length (m): 15.2
- Includes: Hose, Cart, Mast, Boom
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi):
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Gel System, Xg, 17:1, No, Nh
GG 16R179
FRP RS GEL SYSTEM, XG, 17:1, NO, NH
Graco 16R179 17:1 Ratio Cart Mounted External Mix Gel System
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
Easy user interface with all gauges in one location
- Model: FRP
- Series: XG
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component A Inlet Size (mm): 9.525
- Component B Inlet Size (in): 1-5/16
- Component B Inlet Size (mm): 33.34
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 4160
- Maximum Flow Rate (GPM): 1.1
- Maximum Flow Rate (L/min): 4.16
- Maximum Working Pressure (bar): 119
- Maximum Working Pressure (kPa): 11900
- Maximum
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
FRP Rs Gel System, Ig, 17:1, Cart, 50
GG 16R187
FRP RS GEL SYSTEM, IG, 17:1, CART, 50
Graco 16R187 17:1 Ratio Internal Mix Gel System with 50 ft (15.2 m) Hose and Cart
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized Ratio Stability
- Lower Cost of Ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: IG
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 50
- Hose Length (m): 15.2
- Includes: Hose, Cart
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 4160
- Maximum Flow Rate (GPM): 1.1
- Maximum Flow Rate (L/min): 4.16
- Maximum Working Pressure (bar): 119
- Maximum Working Pressure (kPa): 11900
- Maximu
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower Cost of Ownership
Kit, Housing, Fluid, Ep, Assy
GG 16T553
KIT,HOUSING,FLUID,EP,ASSY
KIT INCLUDES: HOUSING, FLUID, ASSY, EP [QTY. 1], GUN, GREASE, 3 OZ [QTY. 1], LUBRICANT, GREASE, FOOD GRADE [QTY. 1], FLUID, TSL 8 OZ BOTTLE [QTY. 1]
Kit, Scraper, Cartridge
GG 16T531
KIT,SCRAPER,CARTRIDGE
Graco 16T531 Scraper Cartridge Kit
KIT INCLUDES: PACKING, O-RING, 015, VITON [QTY. 1], HOUSING, SCRAPER, CARTRIDGE, ASSY [QTY. 1]
Element, Mixer, 0.773X8El, Acetal, Mod
GG 16U216
Element, Mixer, 0.773X8El, Acetal, Mod
Payment options
