GRACO INC. S10595

GG 286655

RAC 5 TIP, SPRAY

Graco 286655 RAC 5 SwitchTip, 655

The Reverse-A-Clean (RAC) 655 RAC 5 SwitchTip produces a 12 to 14 inch fan and has a 0.055 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 3.25
• Maximum Flow Rate (L/min): 12.30

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.055

• Pattern Size (in): 12 to 14
• Pattern Size (mm): 304.8 to 355.6

GG 286831

RAC 5 TIP, SPRAY

Graco 286831 RAC 5 SwitchTip, 831

The Reverse-A-Clean (RAC) 831 RAC 5 SwitchTip produces a 16 to 18 inch fan and has a 0.031 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 45.7
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 1.03
• Maximum Flow Rate (L/min): 3.90

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.031

• Pattern Size (in): 16 to 18
• Pattern Size (mm): 406.4 to 457.2

GG 286821

RAC 5 TIP, SPRAY

Graco 286821 RAC 5 SwitchTip, 821

The Reverse-A-Clean (RAC) 821 RAC 5 SwitchTip produces a 16 to 18 inch fan and has a 0.021 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 45.7
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.021

• Pattern Size (in): 16 to 18
• Pattern Size (mm): 406.4 to 457.2

GG 286631

RAC 5 TIP, SPRAY

Graco 286631 RAC 5 SwitchTip, 631

The Reverse-A-Clean (RAC) 631 RAC 5 SwitchTip produces a 12 to 14 inch fan and has a 0.031 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Elastomer, Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 35.6
  • Maximum Fan Width (in): 12
  • Maximum Fan Width (mm): 356
  • Maximum Flow Rate (GPM): 1.03
  • Maximum Flow Rate (L/min): 3.90
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 12
  • Minimum Fan Width (mm): 305
  • Orifice Diameter (in): 0.031

GG 286625

RAC 5 TIP, SPRAY

Graco 286625 RAC 5 SwitchTip, 625

The Reverse-A-Clean (RAC) 625 RAC 5 SwitchTip produces a 12 to 14 inch fan and has a 0.025 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Elastomer, Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 35.6
  • Maximum Fan Width (in): 12
  • Maximum Fan Width (mm): 356
  • Maximum Flow Rate (GPM): 0.67
  • Maximum Flow Rate (L/min): 2.54
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 12
  • Minimum Fan Width (mm): 305
  • Orifice Diameter (in): 0.025

GG 287020

EXTENSION, TIP, 15"

Graco 287020 RAC X Tip Extension, 15 in

The 15 inch RAC X Tip Extension is ideal for hard-to-reach areas such as soffits, stairways, and vaulted ceilings. Includes RAC X HandTite Guard. Can be combined for extended reach up to 6 feet.

• Includes RAC X HandTite Guard standard with 7/8 inch gun nut and OneSeal
• Can be combined for extended reach up to 6 ft

• Model: RAC X
• Series: Tip Extension

• Compatible Spray Tip: RAC X

• For Use With: RAC X SwitchTips

• Includes: RAC X HandTite Guard Standard, 7/8 in Gun Nut, OneSeal

• Maximum Working Pressure (bar): 279
• Maximum Working Pressure (kPa): 27900
• Maximum Working Pressure (MPa): 27.9
• Maximum Working Pressure (psi): 4050

• Overall Length (cm): 38.1
• Overall Length (in): 15

GG 287019

EXTENSION, TIP, 10"

Graco 287019 RAC X Tip Extension, 10 in

The 10 inch RAC X Tip Extension is ideal for hard-to-reach areas such as soffits, stairways, and vaulted ceilings. Includes RAC X HandTite Guard. Can be combined for extended reach up to 6 feet.

• Includes RAC X HandTite Guard standard with 7/8 inch gun nut and OneSeal
• Can be combined for extended reach up to 6 ft
• Ideal for hard-to-reach areas such as soffits, stairways, and vaulted ceilings
• Extend range and spray more efficiently without ladders or scaffolding
• Made from aluminum for a durable and lightweight design
• Extension lengths can be combined for extended reach up to 6 feet (1.82 meters)
• Includes RAC X HandTite Guard standard with 7/8 inch gun nut and OneSeal

• Model: RAC X
• Series: Tip Extension

• Compatible Spray Tip: RAC X

• For Use With: RAC X SwitchTips

• Includes: RAC X HandTite Guard Standard, 7/8 in Gun Nut, OneSeal

• Maximum Working Pressure (bar): 279
• Maximum Working Pressure (kPa): 27900
• Maximum Working Pressure (MPa): 27.9
• Maximum Working Pressure (psi): 4050

• Overall Length (cm): 25.4
• Overall Length (in): 10

GG 287024

GUN, POLE, 6', DOMESTIC

Graco 287024 Pole Gun, 6 ft

Eliminate the hassles of ladders and scaffolding to safely spray hard-to-reach areas like high walls, vaulted ceilings, stairways, and soffits. Complete the job faster with less setup time with a pole gun.

• For unmatched spraying performance in high or recessed areas
• Provides better spray control and less fatigue
• Balanced design with no excessive weight at the end of the pole

• Model: Graco

• Bleed Type: Bleeder

• Compatible Material: Water-Based Paint

• Component A Inlet Size (in): 1/4
• Component Type: Single Component

• Fluid Orifice Size (cm): 0.229
• Fluid Orifice Size (in): 0.090
• Fluid Orifice Size (mm): 2.29

• For Use With: Electric Airless Sprayer

• Gun Activation: Manual
• Gun Type: Pole Gun
• Gun Weight (kg): 0.1589
• Gun Weight (lb): 3.5

• Includes: Cleanshot Shut-off Valve, Contractor In-line Valve

• Maximum Fluid Pressure (bar): 248
• Maximum Fluid Pressure (kPa): 24800
• Maximum Fluid Pressure (MPa): 24.8
• Maximum Fluid Pressure (psi): 3600

• Maximum Fluid Pressure (bar): 248
• Maximum Fluid Pressure (kPa): 24800
• Maximum Fluid Pressure (MPa): 24.8
• Maximum Fluid Pressure (psi): 3600

• Purge Method: Liquid

GG 286619

RAC 5 TIP, SPRAY

Graco 286619 RAC 5 SwitchTip, 619

The Reverse-A-Clean (RAC) 619 RAC 5 SwitchTip produces a 12 to 14 inch fan and has a 0.019 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.019

GG 286721

RAC 5 TIP, SPRAY

Graco 286721 RAC 5 SwitchTip, 721

The Reverse-A-Clean (RAC) 721 RAC 5 SwitchTip produces a 14 to 16 inch fan and has a 0.021 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 40.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.021

• Pattern Size (in): 14 to 16
• Pattern Size (mm): 355.6 to 406.4

GG 287030

VALVE, SPRAY, PKG

Graco 287030 CleanShot Valve

Unique needle valve shuts fluid off at the tip for a clean pattern, no spitting. A great addition to any extension.

• Unique needle valve shuts fluid off at the tip for a clean pattern - no spitting
• 180 degree tip swivel provides versatility when spraying walls and ceilings
• Pressure-actuated - operates at a minimum of 700 psi (4.8 MPa, 48 bar)

• Model: CleanShot
• Series: CleanShot

• For Use With: JetRoller

• Includes: Gasket
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPSM

• Maximum Working Pressure (bar): 248
• Maximum Working Pressure (kPa): 24800
• Maximum Working Pressure (MPa): 24.8
• Maximum Working Pressure (psi): 3600

• Outlet Size (cm): 2.2225
• Outlet Size (in): 7/8
• Outlet Size (mm): 22.225
• Outlet Thread Type: UNF

GG 287033

KIT, FILTER, GUN, 100 MESH

Graco 287033 Gun Filter, 100 mesh

The Gun Filter helps reduce tip plugging and provides a better quality finish by eliminating unwanted particles from the spray pattern. Use 100 mesh for thinner materials such as stain and lacquer.

• The Gun Filter helps reduce tip plugging and provides a better quality finish by eliminating unwanted particles from the spray pattern
• Filters keep downtime to a minimum by reducing plugging at the spray tip
• Use 100 mesh for thinner materials such as stain and lacquer

• Model: Graco

• For Use With: Contractor PC Spray Gun, Contractor II Spray Gun, FTx Spray Gun

• Mesh Size: 100

• Number of Pieces: 1

• Overall Depth (cm): 0.9525
• Overall Depth (in): 0.375
• Overall Depth (mm): 9525

• Overall Height (cm): 10.16
• Overall Height (in): 4
• Overall Height (mm): 101.6
• Overall Width (cm): 0.9525
• Overall Width (in): 0.375
• Overall Width (mm): 9525

GG 287032

KIT, FILTER, GUN, 60 MESH

Graco 287032 Gun Filter, 60 mesh

The Gun Filter helps reduce tip plugging and provides a better quality finish by eliminating unwanted particles from the spray pattern. Use 60 mesh for materials such as primer and latex paint.

• The Gun Filter helps reduce tip plugging and provides a better quality finish by eliminating unwanted particles from the spray pattern
• Filters keep downtime to a minimum by reducing plugging at the spray tip
• Use 60 mesh for materials such as primer and latex paint.

• Model: Graco

• For Use With: Contractor PC Spray Gun, Contractor II Spray Gun, FTx Spray Gun

• Mesh Size: 60

• Number of Pieces: 1

• Overall Depth (cm): 0.9525
• Overall Depth (in): 0.375
• Overall Depth (mm): 9525

• Overall Height (cm): 10.16
• Overall Height (in): 4
• Overall Height (mm): 101.6
• Overall Width (cm): 0.9525
• Overall Width (in): 0.375
• Overall Width (mm): 9525

GG 287034

KIT, FILTER, GUN, 60/100MESH

Graco 287034 Gun Filters, (1) 60 mesh and (1) 100 mesh

The Gun Filter helps reduce tip plugging and provides a better quality finish by eliminating unwanted particles from the spray pattern. Use 60 mesh for materials such as primer and latex paint. Use 100 mesh for thinner materials such as stain and lacquer.

• Model: Graco

• For Use With: Contractor II Spray Gun, FTx Spray Gun

• Mesh Size: 60, 100

• Number of Pieces: 2

GG 287095

KIT, ACCESSORY, FLEX, 3/8, LTX

Graco 287095 Flex Plus Airless Spray Gun, RAC X, BlueMax II Airless Hose, 1/4 in x 50 ft, 3 ft Whip Hose

Get up and spraying quickly with the ideal spray gun for applications using heavy coatings and joint compounds along with needed accessories. Keep a spare kit on hand to always be prepared for large projects where dual gun applications are required.

• Flex Plus Airless Spray Gun


  Ergonomic handle

  No adjustment needle

  Patented needle design

  Large fluid path

• RAC X LTX 517 SwitchTip


  Provides 10 inch spray pattern

  Ideal for larger surfaces such as houses/buildings, walls and ceilings

  100% tested for flow rate

• BlueMax II Airless Hoses


  The lightest, most flexible hoses on the market

  Easy to connect and maintain

  The highest level of performance from the sprayer to the gun

• Model: Silver Gun

• Kit Type: Spray Gun and Hose Kit

GG 287222

VALVE, DISPENSE

Graco 287222 Air Actuated Fluid Valve

GG 287314

KIT REPAIR, HOSE, CPLD

Graco 287314 RotoFlex HD Pump Hose

• Model: Graco
• Series: RotoFlex HD

GG 287545

GG 287449

GG 287285

GG 287228

GG 287570

GG 287734

NEEDLE, ASSY

GG 287683

GG 287819

GG 287850

KIT, ACCY, SILVER PLUS GUN, GH83

Get up and spraying quickly with the industry's preferred spray gun for high-pressure applications and needed accessories. Keep a spare kit on hand to always be prepared for large projects where dual gun applications are required.

• Silver Plus Gun


  Lightweight, Rugged Design

  Exclusive Needle Design

  2-Finger Trigger Design and Handle

  Stainless Steel Fluid Tube

• RAC X LTX 517 & 655 SwitchTips


  Provides a 10 inch and 12 inch spray patterns

  Ideal for larger surfaces such as houses/buildings, walls and ceilings

  100% tested for flow rate

• BlueMax II Airless Hoses


  The lightest, most flexible hoses on the market

  Easy to connect and maintain

  The highest level of performance from the sprayer to the gun

• Model: Silver Plus

GG 286729

RAC 5 TIP, SPRAY

Graco 286729 RAC 5 SwitchTip, 729

The Reverse-A-Clean (RAC) 729 RAC 5 SwitchTip produces a 14 to 16 inch fan and has a 0.029 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 40.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.9
• Maximum Flow Rate (L/min): 3.41

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.029

• Pattern Size (in): 14 to 16
• Pattern Size (mm): 355.6 to 406.4

GG 287902

GG 20378-01

GG 204385

ELEVATOR, DRUM

Graco 204385 Standard Elevator with Fixed Mounting, For Graco Circulation and Supply Pumps, Series D

GG 204500

GG 204501

GG 203965

ROD, TRIP

Graco 203965 Monark Air Motor Trip Rod

GG 204762

GG 20496-00

GG 204995

AGITATOR, 55 GAL

Graco 204995 Drum agitator without mounting tube, air driven, 1/2 HP, 31.25 inches (79.3 cm) in length, carbon steel material

Mounts on 237307 cover, mounts to suction tube or pump cylinder.

• Agitators mount directly to mix tank or drum covers
• Dual propeller ensures efficient and thorough mixing
• Easy adjustment knob for fine tuning agitator speed to ideal mixing parameters

• For Use With: 55 Gallon Drums

• Maximum Speed (RPM): 800

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Motor Type: Pneumatic - Rotary Vane

• Power Rating (HP): 0.75

GG 205038

MOTOR,AIR, PRES

Graco 205038 President Air Motors- for use with Graco fluid handling pumps

GG 205061

GG 205122

REGULATOR, PRESSURE BACK

Graco 205122 Back Pressure Regulator, Low Pressure Mini, 180 Max psi, CS, Manual, 3/8 (m) x 3/8 (f), with Gauge

Back pressure regulators use closed loop control to maintain the pressure of the system regardless of flow demand

• Stainless steel wetted materials are compatible with catalyst and waterborne materials
• Tungsten and carbide materials ensure low wear and long life
• Compact and lightweight design saves space and reduces payload for small circulation systems
• Air operated model available for automated control, Conversion kit (237448)

• Compatible Material: Catalyst, Waterborne

• Gauge Port Size (cm): 0.635
• Gauge Port Size (in): 1/4
• Gauge Port Size (mm): 6.35

• Includes: Gauge
• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Type: NPSM

• Maximum Flow Rate (GPM): 2
• Maximum Flow Rate (L/min): 7.6

• Maximum Regulated Pressure (bar): 12.4
• Maximum Regulated Pressure (kPa): 1240
• Maximum Regulated Pressure (psi): 180

• Maximum Viscosity (cP): 1000

• Maximum Working Pressure (bar): 21
• Maximum Working Pressure (kPa): 2100
• Maximum Working Pressure (psi): 300

• Minimum Regulated Pressure (bar): 0
• Minimum Regulated Pressure (kPa): 0
• Minimum Regulated Pressure (MPa): 0
• Minimum Regulated Pressure (psi): 0

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Type: NPSM

GG 205183

SCREW, METERING

Graco 205183 Metering Screw for 205425 Fluid Regulator

GG 205334

GG 205342

GG 205394

FIREBALL 425 PUMP, 50:1, 120LB

Graco 205394 Fire-Ball 425 Series 50:1 120 lb (55 kg). Grease Pump

The Fire-Ball 425 features a large air motor to supply the power you need for long pipe runs and higher-volume dispensing. An ideal choice for applications where multiple dispenses happen at the same time.

• Durable Casting - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 425

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 4.25

• Application: Industrial

• Compatible Material: Grease

• Cycles Per Gallon: 110

• Fluid Inlet Type: Slotted

• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Grease

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Flow Rate (GPM): 0.5
• Maximum Flow Rate (L/min): 1.89

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (MPa): 51.7
• Maximum Working Pressure (psi): 7500

• Power Type: Pneumatic

• Pump Ratio: 50:1

GG 205395

FIREBALL 425 PUMP, 50:1, 400LB

Graco 205395 Fire-Ball 425 Grease Pump for 400 lb (180 kg). Drum

The Fire-Ball 425 features a large air motor to supply the power you need for long pipe runs and higher-volume dispensing. An ideal choice for applications where multiple dispenses happen at the same time.

• Durable Casting - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 425

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 4.25

• Application: Industrial

• Compatible Material: Grease

• Cycles Per Gallon: 110

• Fluid Inlet Type: Slotted

• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Grease

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Flow Rate (GPM): 0.5
• Maximum Flow Rate (L/min): 1.89

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (MPa): 51.7
• Maximum Working Pressure (psi): 7500

• Power Type: Pneumatic

• Pump Ratio: 50:1

GG 205406

GG 205425

GG 205447

GG 205435

VALVE, DISP AUTO

Graco 205435 Auto Dispense Valve

Air-operated dispense valves for use with paints, coatings, solvents and lubrication-fluids.

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Male
• Air Inlet Thread Type: NPSM

• Compatible Material: Non Abrasive

• Flow Control Type: Control
• Fluid Inlet Size (cm): 0.9525
• Fluid Inlet Size (in): 3/8
• Fluid Inlet Size (mm): 9.525
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Gender: Male
• Fluid Outlet Thread Type: NPT

• Maximum Working Pressure (bar): 206.8
• Maximum Working Pressure (kg/cm 2): 210.9
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (psi): 3000

• Metering Valve Orifice Size (cm): 0.3175
• Metering Valve Orifice Size (in): 1/8
• Metering Valve Orifice Size (mm): 3.175

GG 205528

GG 204649

GG 205529

GG 205585

STANDARD SPRAYER,PAINT, 2-1,5 GL

Graco 205585 5 Gallon Duo Paint Sprayer with Agitator

GG 205612

VALVE, DISP, AUTO

GG 205626

FIREBALL 425 PUMP, 10:1, UNIVERSAL

Graco 205626 Fire-Ball 425 Series 10:1 Universal Size Oil Pump

With a large 4.25 inch (107.9 mm) air motor to supply the power you need for long pipe runs and higher volume dispensing, the Fire-Ball 425 delivers field-proven durability for multiple fluid types and exceptional cost savings that are hard to beat!

• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Extended Seal Life - In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 425

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 4.25

• Application: Industrial

• Compatible Material: Oil

• Cycles Per Gallon: 19.6

• Fluid Inlet Size (in): 1-1/2
• Fluid Inlet Size (mm): 38.1
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Petroleum- and synthetic-based oils (motor, gear and ATF)

• Maximum Air Inlet Pressure (bar): 12.41
• Maximum Air Inlet Pressure (kPa): 1241
• Maximum Air Inlet Pressure (psi): 180

• Maximum Continuous Cycle Rate (CPM): 66

• Maximum Intermittent Cycle Rate (CPM): 66

• Maximum Working Pressure (bar): 124
• Maximum Working Pressure (kPa): 12400
• Maximum Working Pressure (MPa): 12.4
• Maximum Working Pressure (psi): 1800

• Power Type: Pneumatic

• Pump Ratio: 10:1

GG 205645

SEAT, VALVE

Graco 205645 Valve Seat, 303 SST, carbide, without diffuser

• Compatible Material: Sealants, Adhesives

GG 205997

MOTOR,AIR,MONARK

Graco 205997 Monark Air Motor Assembly, Series K, for 3 tie rod mounting

GG 20586-00

GG 206019

REGULATOR, PRESS, BACK

Graco 206019 Low Pressure Fluid Back Pressure Regulator, 180 psi (12 bar) max pressure, AL wetted parts, manual, 1(f) inlet, 1(f) outlet with gauge

Back pressure regulators use closed loop control to maintain the pressure of the system regardless of flow demand

• Electroless nickel plated aluminum housing with smooth flow orifices
• Tungsten and carbide materials to resist wear
• PTFE/Elastomer hybrid diaphragm withstands wear while maintaining accurate responsiveness

• Compatible Material: Solvent borne

• Gauge Port Size (cm): 0.635
• Gauge Port Size (in): 1/4
• Gauge Port Size (mm): 6.35

• Gauge Port Type: NPT

• Includes: Gauge
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 6
• Maximum Flow Rate (L/min): 22.7

• Maximum Regulated Pressure (bar): 12.4
• Maximum Regulated Pressure (kPa): 1240
• Maximum Regulated Pressure (psi): 180

• Maximum Viscosity (cP): 1000

• Maximum Working Pressure (bar): 21
• Maximum Working Pressure (kPa): 2100
• Maximum Working Pressure (psi): 300

• Minimum Regulated Pressure (bar): 0
• Minimum Regulated Pressure (kPa): 0
• Minimum Regulated Pressure (MPa): 0
• Minimum Regulated Pressure (psi): 0

• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Type: NPT

GG 206171

GAUGE, PRESS, FL, DMP

Graco 206171 Stainless Steel Fluid Gauge with Dampener, 0-200 psi (0-14 bar)

• Dampener protects gauge from severe pressure pulsation
• Corrosion Resistant
• 2.5 in (63mm) diameter dial

• Dial Diameter (cm): 5
• Dial Diameter (in): 2
• Dial Diameter (mm): 51

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Working Pressure (bar): 14
• Maximum Working Pressure (kPa): 1400
• Maximum Working Pressure (MPa): 1.4
• Maximum Working Pressure (psi): 200

GG 206219

AGITATOR, 55 GAL

Graco 206219 Drum Agitator with Mounting Tube, Air-Driven, 1/2 HP, 31.25 inches (79.3 cm) long, CS

Mounts on cover 237308

• Agitators mount directly to mix tank or drum covers
• Dual propeller ensures efficient and thorough mixing
• Easy adjustment knob for fine tuning agitator speed to ideal mixing parameters

• For Use With: 55 Gallon Drums

• Includes: Mounting Tube

• Maximum Speed (RPM): 800

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Motor Type: Pneumatic - Rotary Vane

• Power Rating (HP): 0.75

GG 206235

NOZZLE, SPRAY, SWIV

• Single nozzle swivels 180, permits changing spray pattern direction to suit job. (Spray tip not included)
• 3000 psi (21 MPa, 210 bar) Maximum Working Pressure

• For Use With: Automatic and Handheld Hydra-Spray, Airless Spray Gun

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (psi): 3000

GG 206264

VALVE, NEEDLE

Graco 206264 Air Needle Valve Assembly with 1/8 npt(f) outlet port and 1/4 npt(m) inlet port

Controls pump speed by restricting air flow to pump or other air-operated equipment.

• 1/8 npt(f) outlet port, 1/4 npt(m) inlet port

GG 206266

TUBE, SUCTION

Graco 206266 55 Gallon Siphon Tube

GG 206269

GG 20639-01

GG 206405

FIREBALL U-COAT PUMP, 300, 35 LB

Graco 206405 Fire-Ball 300 Series 15:1 Grease Pump For 35 lb (16 kg). Pail

As the mainstay pump in the industry for decades, the reputation of Fire-Ball is unrivaled. Built to withstand the test of time with fewer moving parts, our flagship pump is built to extend uptime so customers can be more productive. The durable pumps are renowned for their durability, with pumps built decades ago still operating efficiently.

• Reliable Flow - A 3 inch (76.2 mm) differential air motor and the double-acting pump design provides reliable fluid flow and accurate dispense.
• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Reduce Downtime - Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 300

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 3

• Application: Industrial

• Compatible Material: Grease, Rustproofing, Undercoating

• Cycles Per Gallon: 90

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Grease

• Maximum Air Consumption (SCFM): 14
• Maximum Air Inlet Pressure (bar): 12.41
• Maximum Air Inlet Pressure (kPa): 1241
• Maximum Air Inlet Pressure (psi): 180

• Maximum Continuous Cycle Rate (CPM): 66

• Maximum Working Pressure (bar): 186
• Maximum Working Pressure (kPa): 18600
• Maximum Working Pressure (MPa): 18.6
• Maximum Working Pressure (psi): 2700

• Power Type: Pneumatic

• Pump Ratio: 15:1

GG 206485

GG 206481

GG 206502

GG 206529

GG 206513

VALVE, AUTO, SPRAY

Graco 206513 Hydra Spray Gun, automatic, airless, stainless steel, with no tip, Series J

Standard packings are two UHMWPE packings (181523)

Application: For Automatic, Airless, Circulating, and Non-Circulating Systems.

• 3000 psi

GG 206537

CLAMP, DRUM, SET OF 2

Graco 206537 Drum Clamp for Ram Mounted Pumps

GG 206660

VALVE, SPRAY, AUTO

Graco 206660 Automatic Spray Gun Valve, 1/4 npt inlet, 1/8 npt outlet

• Automatic Spray Gun Valve

  • Automate your system with this robust pneumatically operated valve
  • Mount easily to 1/2in (12.7mm) rod using built-in set screw
  • Stainless steel wetted materials are compatible with catalyst, waterborne, and other finishing materials
  • Easily install a wide variety of flat tips for many spraying options
  • Adjustment knob for fine tuning your process

GG 206661

REGULATOR, PRESS, FLUID

Graco 206661 High Pressure Fluid Regulator, 3000 Max psi, 1000-3000 psi Range, 3.5 GPM, CS, Spring Type, 3/8(f) x 1/4(f), 1/4(f) Port, with gauge

• Tungsten and carbide materials ensure low wear and long life
• Plated carbon steel housing is compatible with solvent-borne materials
• Laser-marked indication lines for easy pressure adjustment and process control

• Actuation Type: Spring

• Gauge Port Size (cm): 0.635
• Gauge Port Size (in): 1/4
• Gauge Port Size (mm): 6.35

• Gauge Port Thread Gender: Female
• Gauge Port Type: NPT

• Includes: Regulator Only
• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 3.5
• Maximum Flow Rate (L/min): 13.25

• Maximum Regulated Pressure (bar): 207
• Maximum Regulated Pressure (kPa): 20700
• Maximum Regulated Pressure (MPa): 21
• Maximum Regulated Pressure (psi): 3000

• Maximum Viscosity (cP): 500

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 21
• Maximum Working Pressure (psi): 3000

• Minimum Regulated Pressure (bar): 70
• Minimum Regulated Pressure (kPa): 7000
• Minimum Regulated Pressure (MPa): 7
• Minimum Regulated Pressure (psi): 1000

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35
• Outlet Thread Gender: Female

GG 206699

FIREBALL U-COAT PUMP, 300, 120 LB

Graco 206699 Fire-Ball 300 Series 15:1 120 lb (55 kg). Grease Pump

As the mainstay pump in the industry for decades, the reputation of Fire-Ball is unrivaled. Built to withstand the test of time with fewer moving parts, our flagship pump is built to extend uptime so customers can be more productive. The durable pumps are renowned for their durability, with pumps built decades ago still operating efficiently.

• Reliable Flow - A 3 inch (76.2 mm) differential air motor and the double-acting pump design provides reliable fluid flow and accurate dispense.
• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Reduce Downtime - Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 300

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 3

• Application: Industrial

• Compatible Material: Grease, Rustproofing, Undercoating

• Cycles Per Gallon: 90

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Grease

• Material: Aluminum, Carbon Steel, Leather, PTFE, Rubber

• Maximum Air Consumption (SCFM): 14
• Maximum Air Inlet Pressure (bar): 12.41
• Maximum Air Inlet Pressure (kPa): 1241
• Maximum Air Inlet Pressure (psi): 180

• Maximum Continuous Cycle Rate (CPM): 66

• Maximum Flow Rate (GPM): 0.7
• Maximum Flow Rate (L/min): 2.65

• Maximum Working Pressure (bar): 186
• Maximum Working Pressure (kPa): 18600
• Maximum Working Pressure (MPa): 18.6
• Maximum Working Pressure (psi): 2700

• Power Type: Pneumatic

• Pump Ratio: 15:1

GG 206700

FIREBALL U-COAT PUMP, 300, 400 LB

Graco 206700 Fire-Ball 300 Series 15:1 400 lb (180 kg). Grease Pump

As the mainstay pump in the industry for decades, the reputation of Fire-Ball is unrivaled. Built to withstand the test of time with fewer moving parts, our flagship pump is built to extend uptime so customers can be more productive. The durable pumps are renowned for their durability, with pumps built decades ago still operating efficiently.

• Reliable Flow - A 3 inch (76.2 mm) differential air motor and the double-acting pump design provides reliable fluid flow and accurate dispense.
• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Reduce Downtime - Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 300

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 3

• Application: Industrial

• Compatible Material: Grease, Rustproofing, Undercoating

• Cycles Per Gallon: 90

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Gender: Female

• For Use With: 180

• Maximum Air Inlet Pressure (bar): 12.41
• Maximum Air Inlet Pressure (kPa): 1241
• Maximum Air Inlet Pressure (psi): 180

• Maximum Working Pressure (bar): 186
• Maximum Working Pressure (kPa): 18600
• Maximum Working Pressure (MPa): 18.6
• Maximum Working Pressure (psi): 2700

• Power Type: Pneumatic

• Pump Ratio: 15:1

GG 206994

TSL FLUID, 8 OZ BOTTLE

Graco 206994 TSL Throat Seal Liquid, 8 oz

Throat Seal Liquid (TSL) prevents paint and coatings from drying onto the displacement rod and packings, extending the life of the pump.

• Model: TSL
• Series: Throat Seal Liquid

• For Use With: Airless Paint Sprayer

GG 20712-00

GG 206995

FLUID, TSL, 1 QT.

Graco 206995 TSL Throat Seal Liquid, 1 qt (0.95 l)

Throat Seal Liquid (TSL) prevents paint and coatings from drying onto the displacement rod and packings, extending the life of the pump.

• Model: TSL
• Series: Throat Seal Liquid

• For Use With: All Contractor Grade Sprayers

GG 206710

GG 206987

SEAT, VALVE

GG 206927

GG 206760

AGITATOR, AIR

Graco 206760 Carbon Steel Agitator for 60-Gallon Mix tanks, Air-Driven, 1-1/2 HP, 33.25 inches (84.4 cm) long, CS/Aluminum

Dual round prop

• Agitators mount directly to mix tank or drum covers
• Dual propeller ensures efficient and thorough mixing
• Easy adjustment knob for fine tuning agitator speed to ideal mixing parameters

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• For Use With: 60 Gallon Mix Tanks

• Maximum Speed (RPM): 3000

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Motor Type: Pneumatic - Rotary Vane

• Power Rating (HP): 1.5

GG 207149

SEAT, VALVE

Graco 207149 Seat Valve for Hydra-Mastic Spray Gun, 416 SST, carbide with diffuser

GG 206998

GG 207160

KIT, REPAIR

KIT INCLUDES: WASHER, FLAT [QTY. 2], GASKET, [QTY. 1], PACKING, VEE, PTFE [QTY. 6 ], GLAND, PKG FEMALE [QTY. 1], GLAND, PKG MALE [QTY. 1], GASKET, COPPER [QTY. 2], ROD, VALVE [QTY. 1], SEAT, VALVE [QTY. 1]

GG 207199

COVER, DRUM & AGIT., 55GL

Graco 207199 Cover-Mounted Agitator for 55 gallon open drum

• Compatible Material: Catalyst, Waterborne

GG 206734

KIT, REPAIR MOTOR

GG 207335

KIT, REPAIR, MOTOR, AIR

Graco 207335 Air motor repair kit

GG 207337

GG 17K268

GG 17K269

HOSE, CPLED, 4000PSI, 400F, 25'#10

Graco 17K269 25 ft. (7.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 10 (0.495 in. / 12.6 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 0.495
• Hose Diameter (mm): 12.6
• Hose Heating Type: Ambient
• Hose Length (ft): 25
• Hose Length (m): 7.6

• Inside Diameter (in): 0.495
• Inside Diameter (mm): 12.573

• JIC Size: JIC 10

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 100
• Maximum Temperature ( degree F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 17K272

HOSE, CPLED, 4000PSI, 400F, 6'#12

Graco 17K272 6 ft. (1.8 M) Stainless Steel Braided PTFE Ambient Hose, No. 12 (0.617 in. / 15.7 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 0.617
• Hose Diameter (mm): 15.7
• Hose Heating Type: Ambient
• Hose Length (ft): 6
• Hose Length (m): 1.8

• Inside Diameter (in): 0.617
• Inside Diameter (mm): 15.672

• JIC Size: JIC 12

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 100
• Maximum Temperature ( degree F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 17K275

HOSE, CPLED, 4000PSI, 400F, 20'#12

Graco 17K275 20 ft. (6.1 M) Stainless Steel Braided PTFE Ambient Hose, No. 12 (0.617 in. / 15.7 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 0.617
• Hose Diameter (mm): 15.7
• Hose Heating Type: Ambient
• Hose Length (ft): 20
• Hose Length (m): 6.1

• Inside Diameter (in): 0.617
• Inside Diameter (mm): 15.672

• JIC Size: JIC 12

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 100
• Maximum Temperature ( degree F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 17K276

HOSE, CPLED, 4000PSI, 400F, 25'#12

Graco 17K276 25 ft. (7.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 12 (0.617 in. / 15.7 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 0.617
• Hose Diameter (mm): 15.7
• Hose Heating Type: Ambient
• Hose Length (ft): 25
• Hose Length (m): 7.6

• Inside Diameter (in): 0.617
• Inside Diameter (mm): 15.672

• JIC Size: JIC 12

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 100
• Maximum Temperature ( degree F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 17K273

HOSE, CPLED, 4000PSI, 400F, 10'#12

Graco 17K273 10 ft. (3.0 M) Stainless Steel Braided PTFE Ambient Hose, No. 12 (0.617 in. / 15.7 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 0.617
• Hose Diameter (mm): 15.7
• Hose Heating Type: Ambient
• Hose Length (ft): 10
• Hose Length (m): 3

• Inside Diameter (in): 0.617
• Inside Diameter (mm): 15.672

• JIC Size: JIC 12

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degrees C): 100
• Maximum Temperature ( degrees F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 17K278

HOSE, CPLED, 4000PSI, 400F, 10'#16

Graco 17K278 10 ft. (3.0 M) Stainless Steel Braided PTFE Ambient Hose, No. 16 (0.867 in. / 22.0 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 0.867
• Hose Diameter (mm): 22.0
• Hose Heating Type: Ambient
• Hose Length (ft): 10
• Hose Length (m): 3

• Inside Diameter (in): 0.867
• Inside Diameter (mm): 22.022

• JIC Size: JIC 16

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degrees C): 100
• Maximum Temperature ( degrees F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 17K279

HOSE, CPLED, 4000PSI, 400F, 15'#16

Graco 17K279 15 ft. (4.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 16 (0.867 in. / 22.0 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 0.867
• Hose Diameter (mm): 22.0
• Hose Heating Type: Ambient
• Hose Length (ft): 15
• Hose Length (m): 4.6

• Inside Diameter (in): 0.867
• Inside Diameter (mm): 22.022

• JIC Size: JIC 16

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 100
• Maximum Temperature ( degree F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 17K281

HOSE, CPLED, 4000PSI, 400F, 25'#16

Graco 17K281 25 ft. (7.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 16 (0.867 in. / 22.0 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 0.867
• Hose Diameter (mm): 22.0
• Hose Heating Type: Ambient
• Hose Length (ft): 25
• Hose Length (m): 7.6

• Inside Diameter (in): 0.867
• Inside Diameter (mm): 22.022

• JIC Size: JIC 16

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degree C): 100
• Maximum Temperature ( degree F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 17K282
