GRACO INC. S10595

GG 289208

REGULATOR, HEATED FLUID

GG 161578

GG 161590

GG 161586

GG 162238

GG 162301

GG 521903

GG 521975

GG 289641

TRITON SPRAYER, AL PUMP CART MNT, ELECTRO

Graco 289641 Triton Alum Spray Package, Cart, 60 psi Fluid Regulator, Pro Xp85 Electrostatic Gun, Suction, Air & Fluid Hoses

Air-operated diaphragm spray package designed for the finishing market. It is a more effective alternative to traditional pressure pots and standard diaphragm pumps.

• Superior finish quality for conventional, HVLP and compliant or electrostatic applications
• Supplies up to 35% extra air flow to gun for superior atomization
• Saves material and time during flushing, priming and color changes
• Rugged, stainless steel or aluminum construction pump handles a wide variety of fluids

• Model: Triton
• Series: 308

• Application: Metal

• Compatible Material: Varnish Primers, Latex, Solvent borne Paints, Solvent borne, High Solids, Single Components, CARC, Metallics, Stains, Lacquer, Enamel, Epoxies

• Feed Type: Suction Hose

• Fluid Inlet Size (cm): 1.905
• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Type: NPT

• Gun Included: 1
• Gun Model: Pro Xp 85 kV Standard
• Gun Technology: Electrostatic
• Gun Type: Electrostatic

• Includes: 25 ft Air Hose, 25 ft Fluid Hose, Regulator, Applicator

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (psi): 100

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kg/cm 2): 7.03
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Mount Location: Cart Mount
• Mount Type: Cart Mount

• Power Source: Air

• Pressure Type: Low Pressure
• Product Type: Spray Package

• Pump Ratio: 1:1
• Pump Type: Pneumatic Diaphragm Pump

GG 15K824

ROD, PISTON

GG 15F449

GG 161556

GG 296693

GG 296731

GG 296788

GG 296791

GG 296813

GG 296836

GG 296837

GG 296849

GG 296860

GG 296866

GG 296896

GG 296897

GG 296928

GG 296932

GG 296935

GG 296937

GG 296939

GG 296940

GG 299518

GG 296942

GG 297832

GG 297898

GX-8 GUN

Graco 297898 GX-8 Spray Gun

The GX-8 Gun is designed for very low output, fast-set polyurea, polyurethane and hybrid coatings. It is designed to save on material consumption by significantly reducing overspray associated with low-output spraying.

• Solvent-free, mechanically self-cleaning
• Direct impingement mixing assures high yield per unit of material and superior surface finish
• More air volume to air cap helps keep the guns tip cleaner longer

• Model: GX-8
• Series: Standard

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• Compatible Material: Plural Component Protective Coating, Polyurea, Elastomeric Coating, Polyurethane Coating
• Component A Inlet Size (cm): 1.27

• Component A Inlet Size (in): 1/2-20
• Component A Inlet Size (mm): 12.7
• Component A Inlet Thread Type: UNF
• Component B Inlet Size (cm): 1.42875
• Component B Inlet Size (in): 9/16
• Component B Inlet Size (mm): 14.2875
• Component B Inlet Thread Type: UNF

• Gun Activation: Manual
• Gun Model: GX-8
• Gun Type: Mechanical-Purge
• Gun Weight (g): 1588
• Gun Weight (kg): 1.59
• Gun Weight (lb): 3.5
• Gun Weight (oz): 56

• Includes: Mix Module, Tip

• Maximum Air Inlet Pressure (bar): 8.6
• Maximum Air Inlet Pressure (kPa): 860
• Maximum Air Inlet Pressure (MPa): 0.86
• Maximum Air Inlet Pressure (psi): 125
• Maximum Air Pressure (bar): 8.6

• Maximum Air Pressure (kPa): 860
• Maximum Air Pressure (MPa): 0.86
• Maximum Air Pressure (psi): 125

• Maximum Flow Rate (kg/min): 0.7
• Maximum Flow Rate (lb/min): 1.5

• Maximum Fluid Pressure (bar): 241
• Maximum Fluid Pressure (kPa): 24100
• Maximum Fluid Pressure (MPa): 24.1
• Maximum Fluid Pressure (psi): 3500

• Maximum Fluid Pressure (bar): 241
• Maximum Fluid Pressure (kPa): 24100
• Maximum Fluid Pressure (MPa): 24.1
• Maximum Fluid Pressure (psi): 3500

• Maximum Fluid Working Pressure (bar): 240
• Maximum Fluid Working Pressure (MPa): 24
• Maximum Fluid Working Pressure (psi): 3500

• Minimum Air Inlet Pressure (bar): 6.9
• Minimum Air Inlet Pressure (kPa): 690
• Minimum Air Inlet Pressure (MPa): 0.69
• Minimum Air Inlet Pressure (psi): 100

• Minimum Flow Rate (kg/min): 0.45
• Minimum Flow Rate (lb/min): 1

• Overall Height (cm): 19
• Overall Height (in): 7.5
• Overall Height (mm): 190
• Overall Length (cm): 17.8
• Overall Length (in): 7
• Overall Length (mm): 178
• Overall Width (cm): 6.25
• Overall Width (in): 2.5
• Overall Width (mm): 62.5

• Pattern Size (in): 6 in @ 18-24 in from target
• Pattern Size (mm): 152.4

• Pressure Type: High Pressure

• Purge Method: Mechanical

GG 296945

GG 296956

GG 296941

GG 296962

GG 289012

AIRPRO GUN, ASSY, CONV, GRAVITY W/CUP

Graco 289012 AirPro Air Spray Gravity Feed Gun, Conventional, 0.070 inch (1.8 mm) Nozzle, Plastic Gravity Cup

The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you're a custom shop or a high volume manufacturing facility.

• Even material distribution through the spray pattern for optimum coverage
• Improved transfer efficiency through reduced air consumption
• Enhanced atomization through material-specific aircaps
• Ultra-light trigger pull reduces operator muscle stress
• Ergonomic gun handle provides a comfortable grip
• Rounded control knobs for operator comfort
• Optimize spray performance with our cutting edge aircap and nozzle design
• Choose from a wide range of gun models to meet the needs of your specific application

• Model: AirPro

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPSM

• Application: Specialty
• Applicator Type: Manual

• Bleed Type: Non-Bleeder

• Compatible Material: CARC, Enamel, Epoxies, Fast-Set, High Solids, Latex, Plural Component Materials, Sealants, Solvent borne, Urethane, Waterborne

• Feed Type: Gravity Feed

• Fluid Inlet Size (cm): 0.9525
• Fluid Inlet Size (in): 3/8
• Fluid Inlet Size (mm): 9.525
• Fluid Inlet Thread Type: NPSM
• Fluid Orifice Size (cm): 0.18
• Fluid Orifice Size (in): 0.070
• Fluid Orifice Size (mm): 1.8

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: Conventional Gun
• Gun Weight (g): 410

• Includes: Air Cap, Needle Assembly, Nozzle, Tool Kit, Cup

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (MPa): 0.7
• Maximum Air Inlet Pressure (psi): 100
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Product Type: Spray Gun

GG 289035

AIRPRO GUN, AUTOMOTIVE, HVLP, .047

Graco 289035 AirPro Air Spray Pressure Feed Gun, HVLP, 0.047 inch (1.2 mm) Nozzle, for Automotive Applications

The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you're a custom shop or a high volume manufacturing facility.

• Even material distribution through the spray pattern for optimum coverage
• Improved transfer efficiency through reduced air consumption
• Enhanced atomization through material-specific aircaps
• Ultra-light trigger pull reduces operator muscle stress
• Ergonomic gun handle provides a comfortable grip
• Rounded control knobs for operator comfort
• Optimize spray performance with our cutting edge aircap and nozzle design
• Choose from a wide range of gun models to meet the needs of your specific application

• Model: AirPro

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPSM

• Application: Automotive
• Applicator Type: Manual

• Bleed Type: Non-Bleeder

• Compatible Material: Base Coat, Clear Coat, Latex, Plural Component Materials, Primer, Solvent borne, Waterborne

• Feed Type: Pressure Feed

• Fluid Inlet Size (cm): 0.9525
• Fluid Inlet Size (in): 3/8
• Fluid Inlet Size (mm): 9.525
• Fluid Inlet Thread Type: NPSM
• Fluid Orifice Size (cm): 0.12
• Fluid Orifice Size (in): 0.047
• Fluid Orifice Size (mm): 1.2

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: HVLP Gun
• Gun Weight (g): 410

• Includes: Air Cap, Needle Assembly, Nozzle, Tool Kit

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (MPa): 0.7
• Maximum Air Inlet Pressure (psi): 100
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Product Type: Spray Gun

GG 289029

AIRPRO GUN, SIPHON, CONV, .070

Graco 289029 AirPro Air Spray Siphon Feed Gun, Conventional, 0.070 inch (1.8 mm) Nozzle, Metal Siphon Cup

The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you're a custom shop or a high volume manufacturing facility.

• Even material distribution through the spray pattern for optimum coverage
• Improved transfer efficiency through reduced air consumption
• Enhanced atomization through material-specific aircaps
• Ultra-light trigger pull reduces operator muscle stress
• Ergonomic gun handle provides a comfortable grip
• Rounded control knobs for operator comfort
• Optimize spray performance with our cutting edge aircap and nozzle design
• Choose from a wide range of gun models to meet the needs of your specific application

• Model: AirPro

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPSM

• Application: Specialty
• Applicator Type: Manual

• Bleed Type: Non-Bleeder

• Compatible Material: CARC, Enamel, Epoxies, Fast-Set, High Solids, Latex, Plural Component Materials, Sealants, Solvent borne, Urethane, Waterborne

• Feed Type: Siphon Feed

• Fluid Inlet Size (cm): 0.9525
• Fluid Inlet Size (in): 3/8
• Fluid Inlet Size (mm): 9.525
• Fluid Inlet Thread Type: NPSM
• Fluid Orifice Size (cm): 0.18
• Fluid Orifice Size (in): 0.070
• Fluid Orifice Size (mm): 1.8

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: Conventional Gun
• Gun Weight (g): 410

• Includes: Air Cap, Needle Assembly, Nozzle, Tool Kit, Cup

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (MPa): 0.7
• Maximum Air Inlet Pressure (psi): 100
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Product Type: Spray Gun

GG 289037

AIRPRO GUN, AUTOMOTIVE, COMPLIANT, .047

Graco 289037 AirPro Air Spray Pressure Feed Gun, Compliant, 0.047 inch (1.2 mm) Nozzle, for Automotive Applications

The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you're a custom shop or a high volume manufacturing facility.

• Even material distribution through the spray pattern for optimum coverage
• Improved transfer efficiency through reduced air consumption
• Enhanced atomization through material-specific aircaps
• Ultra-light trigger pull reduces operator muscle stress
• Ergonomic gun handle provides a comfortable grip
• Rounded control knobs for operator comfort
• Optimize spray performance with our cutting edge aircap and nozzle design
• Choose from a wide range of gun models to meet the needs of your specific application

• Model: AirPro

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPSM

• Application: Automotive
• Applicator Type: Manual

• Bleed Type: Non-Bleeder

• Compatible Material: Base Coat, Clear Coat, Latex, Plural Component Materials, Primer, Solvent borne, Waterborne

• Feed Type: Pressure Feed

• Fluid Inlet Size (cm): 0.9525
• Fluid Inlet Size (in): 3/8
• Fluid Inlet Size (mm): 9.525
• Fluid Inlet Thread Type: NPSM
• Fluid Orifice Size (cm): 0.12
• Fluid Orifice Size (in): 0.047
• Fluid Orifice Size (mm): 1.2

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: Compliant Gun
• Gun Weight (g): 410

• Includes: Air Cap, Needle Assembly, Nozzle, Tool Kit

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (MPa): 0.7
• Maximum Air Inlet Pressure (psi): 100
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Product Type: Spray Gun

GG 289011

AIRPRO GUN, ASSY, CONV, GRAVITY W/CUP

Graco 289011 AirPro Air Spray Gravity Feed Gun, Conventional, 0.055 inch (1.4 mm) Nozzle, Plastic Gravity Cup

The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you're a custom shop or a high volume manufacturing facility.

• Even material distribution through the spray pattern for optimum coverage
• Improved transfer efficiency through reduced air consumption
• Enhanced atomization through material-specific aircaps
• Ultra-light trigger pull reduces operator muscle stress
• Ergonomic gun handle provides a comfortable grip
• Rounded control knobs for operator comfort
• Optimize spray performance with our cutting edge aircap and nozzle design
• Choose from a wide range of gun models to meet the needs of your specific application

• Model: AirPro

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPSM

• Application: Specialty
• Applicator Type: Manual

• Bleed Type: Non-Bleeder

• Compatible Material: CARC, Enamel, Epoxies, Fast-Set, High Solids, Latex, Plural Component Materials, Sealants, Solvent borne, Urethane, Waterborne

• Feed Type: Gravity Feed

• Fluid Inlet Size (cm): 0.9525
• Fluid Inlet Size (in): 3/8
• Fluid Inlet Size (mm): 9.525
• Fluid Inlet Thread Type: NPSM
• Fluid Orifice Size (cm): 0.14
• Fluid Orifice Size (in): 0.055
• Fluid Orifice Size (mm): 1.4

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: Conventional Gun
• Gun Weight (g): 590
• Gun Weight (kg): 0.59
• Gun Weight (lb): 1.3
• Gun Weight (oz): 20.8

• Includes: Air Cap, Needle Assembly, Nozzle, Tool Kit, Cup

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (MPa): 0.7
• Maximum Air Inlet Pressure (psi): 100
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Product Type: Spray Gun

GG 289040

GG 289042

KIT,AIR CAP,GEN METAL,COMP

Graco 289042 Air Cap Kit for AirPro Compliant Guns with 0.020-0.070 inch (0.5-1.8 mm) Nozzle, General Metal

GG 289044

GG 289045

GG 289046

GG 289049

GG 289052

GG 289053

GG 289076

GG 289080

KIT, ACCY,AIRCAP,LACQUER

Graco 289080 Air Cap Lacquer Kit, includes air cap optimized to spray lacquer

GG 289111

AIRPRO GUN, STAIN, COMPLIANT, .040

Graco 289111 AirPro Air Spray Pressure Feed Gun, Compliant, 0.040 inch (1.0 mm) Nozzle, for Wood Applications

The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you're a custom shop or a high volume manufacturing facility.

• Even material distribution through the spray pattern for optimum coverage
• Improved transfer efficiency through reduced air consumption
• Enhanced atomization through material-specific aircaps
• Ultra-light trigger pull reduces operator muscle stress
• Ergonomic gun handle provides a comfortable grip
• Rounded control knobs for operator comfort
• Optimize spray performance with our cutting edge aircap and nozzle design
• Choose from a wide range of gun models to meet the needs of your specific application

• Model: AirPro

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPSM

• Application: Wood
• Applicator Type: Manual

• Bleed Type: Non-Bleeder

• Compatible Material: NGR, Solvent borne, Stains, Toner, UV Coating, Waterborne

• Feed Type: Pressure Feed

• Fluid Inlet Size (cm): 0.9525
• Fluid Inlet Size (in): 3/8
• Fluid Inlet Size (mm): 9.525
• Fluid Inlet Thread Type: NPSM
• Fluid Orifice Size (cm): 0.10
• Fluid Orifice Size (in): 0.040
• Fluid Orifice Size (mm): 1.0

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: Compliant Gun
• Gun Weight (g): 410

• Includes: Air Cap, Needle Assembly, Nozzle, Tool Kit

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (MPa): 0.7
• Maximum Air Inlet Pressure (psi): 100
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Product Type: Spray Gun

GG 563902

KIT, REPAIR PUMP AL-5M

Graco 563902 Modu-Flo Pump Assembly Repair Kits - AL-5, Single or Double Acting Repair Kit

• AL-5M seal kit
• Lubriquip part number 560-001-021

• For Use With: AL-5M Pumps

• Includes: Piston Spring, Check Valve Spring, Check Valve Seat, Hardware

• Kit Type: Repair Kit

GG 563800

TUBE, 3 BUNDLE 10FT PRECHARGE

Graco 563800 10 ft. Pre-Charged Tube - 3 Tube Bundle, 3/16 in. OD - Blue, Orange, Black

• Lubriquip part number 550-450-990

• Application: On-Road Vehicles

• Color: Black, Orange, Blue

• Compatible Material: Grease

• Material: Nylon

• Maximum Working Pressure (bar): 56
• Maximum Working Pressure (kPa): 560
• Maximum Working Pressure (psi): 800

• Overall Length (ft): 10
• Overall Length (m): 3

GG 563903

KIT, REPAIR PUMP AL-25M

Graco 563903 Modu-Flo Pump Assembly Repair Kits - AL-25, Single or Double Acting Repair Kit

• AL-25M seal kit
• Lubriquip part number 560-001-031

• For Use With: AL-25M Pumps

• Includes: Piston Spring Retainer, Check Valve Spring, Check Valve Seat, Hardware

• Kit Type: Repair Kit

GG 563906

KIT, REPAIR PUMP HL-25M

Graco 563906 HL-25M Seal Kit

• HL-25M seal kit
• Lubriquip part number 560-001-061

• For Use With: HL-25M Pumps

• Includes: Check Valve Spring, Check Valve Seat, Hardware

• Kit Type: Repair Kit

GG 563918

GG 563909

KIT, REPAIR PUMP E-SERIES

Graco 563909 E-Series Pump Repair Kit (Fixed Output)

• Pump Repair Kit (fixed output)
• Lubriquip part number 560-001-210

• For Use With: E-Series Pumps

• Includes: Check Valve Spring, Check Valve Seat, O-Rings, Hardware

• Kit Type: Repair Kit

GG 563923

GG 563928

KIT, REPAIRI ND CYCLE MSP

Graco 563928 Trabon MSP Mounting Accessories and Spare Parts - MSP Cycle Pin Indicator Repair Kit, Gasket

• MSP cycle pin indicator repair kit, gasket
• Lubriquip part number 560-002-050

• Includes: MX Cycle Indicator, MX Cycle Indicator Stem, Hardware

GG 563929

KIT, REPAIR IND CYC

Graco 563929 Trabon MSP Mounting Accessories and Spare Parts - MSP Cycle Pin Indicator Repair Kit, O-Ring

• MSP cycle pin indicator repair kit, O-ring
• Lubriquip part number 560-002-055

• Includes: MX Cycle Indicator Stem, Hardware

GG 563962

KIT, B/O DISC 1450 PS1 YELLOW

Graco 563962 Blowout Disc Kit - (6) Yellow, 1450 psi, 11/16 in.

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• 1,450 psi - yellow
• Lubriquip part number 560-900-270

• Color: Yellow

• Maximum Working Pressure (bar): 100
• Maximum Working Pressure (kPa): 9991
• Maximum Working Pressure (MPa): 10
• Maximum Working Pressure (psi): 1450

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 563963

KIT, B/O DISC 1750 RED

Graco 563963 Blowout Disc Kit - (6) Red, 1750 psi, 11/16 in.

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• 1,750 psi - red
• Lubriquip part number 560-900-280

• Color: Red

• Maximum Working Pressure (bar): 121
• Maximum Working Pressure (kPa): 12058
• Maximum Working Pressure (MPa): 12.1
• Maximum Working Pressure (psi): 1750

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 563966

KIT, B/O DISC 2950 BLUE

Graco 563966 Blowout Disc Kit - (6) Blue, 2950 psi, 11/16 in.

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• 2,940 psi - blue
• Lubriquip part number 560-900-320

• Color: Blue

• Maximum Working Pressure (bar): 203
• Maximum Working Pressure (kPa): 20326
• Maximum Working Pressure (MPa): 20.3
• Maximum Working Pressure (psi): 2950

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 564086

GG 564350

SWIVEL, BEARING, 90DEG, 1/2 NPT

Graco 564350 Ball Bearing 90 degree Angle Swivel - 1/2 inch (12.7 mm)

• 90 degree Angle Swivel - 1/2 inch (12.7 mm)
• Lubriquip part number 503-706-001

• Angle ( degree ): 90

• Connection Type: Threaded

• For Use With: Pipe

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

GG 567251

GG 564406

FILTER, 138 MIC INLINE 1/4-19 BSPP

Graco 564406 General Accessories - In-Line Oil/Grease Filters (High-Pressure) - 149 Micron, 100 Mesh In-Line Block Strainer, BSPP

• 149 micron, 100 Mesh In-Line Block Strainer, BSPP (ISO 1179)
• Lubriquip part number 527-101-130

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (MPa): 5170
• Maximum Working Pressure (psi): 7500

• Port Size (cm): 0.635
• Port Size (in): 1/4
• Port Size (mm): 6.35

GG 564413

MINI METER-FLO PUMP, MOTOR ASSY 5CU/IN

Graco 564413 Miniature Meter-Flo Assembly - Pump, Gear motor, Reducer Assembly, 5 cu in/min (82 cc/min)

Designed for use with virtually any type of Series Progressive or Single Line Resistive oil lubrication system. The Miniature Meter-Flo has a rugged steel reservoir and motor assembly withstands the toughest applications.

• Capable of high volumetric output operating continuously at pressures up to 1,000 psi (69 bar)
• Compact with several options to create a complete system using feedback and control
• Nominal displacements of 5 cu. in./min. (82 cc/mm.)
• Pump, Gear motor and Reducer assembly - no reservoir
• Reservoir has a suction line strainer, return line port, visual level gauge, pressure gauge and filler/strainer with spring return cap
• Options include low level switch, high pressure indicator, and lube cycle timer
• Lubriquip part number 540-800-620

• Model: Miniature Meter-Flo

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.25
• Fluid Outlet Size (mm): 6.3500
• Fluid Outlet Thread Type: NPT

• For Use With: Series Progressive Oil Lubrication Systems, Single Line Resistive Oil Lubrication Systems

• Includes: Pump, Gear Motor, Reducer Assembly

• Material: Metal

• Maximum cST Grade (cST): 15000

• Maximum Flow Rate (ci/min): 5

• Maximum Working Pressure (bar): 69
• Maximum Working Pressure (kPa): 6900
• Maximum Working Pressure (MPa): 6.9
• Maximum Working Pressure (psi): 1000

• Minimum cST Grade (cST): 160

• Minimum Voltage (V ac): 103.5

• Power Connection Type: 3 Wire Hook-Up Inside Junction Box

• Power Type: Electric

GG 570267

GG 570268

KIT, REBUILT POLYMITE

Graco 570268 1K Ultra-Lite Valve Rebuild Kit

KIT INCLUDES: PACKING, O-RING [QTY. 1], PACKING, O-RING [QTY. 1], PACKING, O-RING [QTY. 2], PACKING, O-RING, BUNA-N [QTY. 1], GASKET, SEAT [QTY. 1], SEAT, VALVE [QTY. 1], BEARING, SLEEVE 1/4, 3/8, 1/4NYL [QTY. 2], LUBRICANT, SYNTHETIC, GREASE, 3 OZ [QTY. 1], SEAL, U-CUP POLYMT 1/4, 1/2, 1/4 [QTY. 1], PACKING, U-CUP URT 1/4, 1/2, 1/8 UR [QTY. 1], PIN, DOWEL [QTY. 1], GASKET, AIR MANIFOLD [QTY. 1], INSERT, SUFF-BACK, 2K2 [QTY. 1], NEEDLE, 2K2 SST HARDENED [QTY. 1], BEARING, LUBE 2K2 [QTY. 1], PACKING, O-RING [QTY. 2]

GG 571028

KIT, ACC, ADJ PRESSURE RELIEF

Graco 571028 Adjustable Return-to-Reservoir Pressure Relief Kit - 500-3500 psi (35-241 bar) - 1/4" NPT

• Adjustable Return-to-Reservoir Pressure Relief Kit - 500-3500 psi (35-241 bar)

• Model: Trabon

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Oil, Grease

• For Use With: G1 Pumps, G3 Pumps, Pressure Relief Valve

• Includes: Pressure Relief Valve, Fittings, Hardware, Tube

GG 571033

KIT, REMOTE MAN RUN, 24V, W/CABLE

Graco 571033 G-Series Pump Accessory - Remote manual monitoring light run kit - 24 VDC, 90-240 VAC, includes 16 foot M12 cable

• Remote manual monitoring light run kit - 24 VDC, 90-240 VAC, includes 16 foot M12 cable

• For Use With: G-Series Pumps

• Includes: Remote manual run/monitoring light, 16 foot M12 Cable

• Number of Pieces: 2

GG 571041

KIT, ACC, PUMP ELEMENT

Graco 571041 G-Series Pump Accessories - G3 Pump Element

• G3 pump element - the same adjustability as the pump included with G3

• For Use With: G3 Pumps

• Includes: Pump Element, Spacer

• Kit Type: Repair Kit

GG 598141

GG 571167

ADAPTER, OUTLET TO HAND PUMP

Graco 571167 Pump Outlet Adapter

• Includes: Adapter Fitting, O-Ring

GG 5-729-300-2.5LM

GG 575206

XP SYSTEM, 2:1, 180/90, COMPLETE, HAZ

Graco 575206 XP50 Cart System, Hazardous Location, 2:1 With Primary Heaters & Hose Heat, 240V

Two-component spraying made easy and affordable. Graco XP50 Plural-Component Sprayers are designed to pump, mix and atomize medium to high solid coatings with superior results. When you upgrade from hand mixing, you'll find that the XP provides excellent return on investment, by reducing material waste and by using less clean-up solvent. Flexible options for mix ratio, pressure and flow rate - choose the right system for the application. If you occasionally change materials, the Graco XP Sprayers are the right choice. That's because you can change the ratio by simply changing out one or two pump lowers. Available in 1:1, 1.5:1, 2:1, 2.5:1, 3:1 and 4:1 mix ratios.

• Reduced material waste
• No more throwing away unused mixed material at the end of the day
• Save money by using less clean-up solvent
• Easy to operate - minimal training required
• Reduced maintenance costs
• Rated for 5000 psi (345 bar) to handle viscous materials and long hose lengths

• Series: XP50

• Air Inlet Size (in): 3/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPSM

• Applicator Type: Automatic Airless, Manual Airless

• Compatible Material: Protective Coating, Primer, Epoxy, Polyurethane, Two-Component Coating, Solvents

• Component Type: Plural-Component
• Configuration: With Primary Heaters & Hose Heat

• Fluid Inlet Size (in): 1-1/4
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPSM

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Flush Type: Solvent

• Hose Length (ft): 35
• Hose Length (m): 10.7

• Includes: 7 Gallon Hoppers, XTR+ Gun, 35 ft integration Hose and Static Mixer, Merkur Flush Pump, Viscon HP Heaters, Hose Heat Circulation Kit, Remote Carriage, PressureTrak

• Location Category: Hazardous Location

• Material Application: Coatings, Paints, Primers

• Maximum Air Consumption (SCFM): 60 scfm/gpm at 100 psi
• Maximum Air Inlet Pressure (bar): 12.07
• Maximum Air Inlet Pressure (kPa): 1207
• Maximum Air Inlet Pressure (MPa): 1.21
• Maximum Air Inlet Pressure (psi): 175

• Maximum Cycle Rate (CPM): 40

• Maximum Flow Rate (cc/min): 10970

• Maximum Flow Rate (GPM): 2.9
• Maximum Flow Rate (L/min): 10.97

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Hose Length (ft): 300
• Maximum Hose Length (m): 91.4

• Maximum Operating Temperature ( degree C): 54
• Maximum Operating Temperature ( degree F): 130

• Maximum Spray Pressure (bar): 344

• Maximum Spray Pressure (kPa): 34400
• Maximum Spray Pressure (MPa): 34
• Maximum Spray Pressure (psi): 5000

• Maximum Working Pressure (bar): 331
• Maximum Working Pressure (kPa): 33100
• Maximum Working Pressure (MPa): 33
• Maximum Working Pressure (psi): 4800
• Measurin

GG 598140

GG 60/0111-1/50

GG 571102

XP SYSTEM, 1:1, 90/90, BF, CH

Graco 571102 XP70 Hazardous Location Spray Package, Cart, 1:1 Mix Ratio, Hopper, XTR Gun

The Graco XP70 Plural-Component Sprayer is designed to pump, mix and atomize high-viscosity, high-solids coatings with superior results. In addition, the XP70's design allows you to gravity feed, which may eliminate the need for feed pumps, saving you money. When you upgrade from hand mixing, youll find that the XP70 provides excellent return on investment, by reducing material waste and by using less clean-up solvent.

• Reduced material waste
• No more throwing away unused mixed material at the end of the day
• Save money by using less clean-up solvent
• Easy to operate - minimal training required
• Reduced maintenance costs
• Rated for 7250 psi (500 bar, 50 MPa) to handle viscous materials and long hose lengths

• Series: XP70

• Air Inlet Size (in): 3/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPSM

• Applicator Type: Automatic Airless, Manual Airless

• Compatible Material: Protective Coatings, Primer, Epoxies, Polyurethane, Two-Component Coating, Solvents

• Component Type: Plural-Component
• Configuration: Cart Mount with 7 gallon (26.5 Liter) Hopper

• Fluid Inlet Size (in): 1-1/4
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPSM

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Flush Type: Solvent

• Hose Length (ft): 35
• Hose Length (m): 10.7

• Includes: XTR Spray Gun, Fluid Hose, NXT Air Motor

• Material Application: Coatings, Paints, Primers

• Maximum Air Consumption (SCFM): 75 scfm/gpm at 100 psi
• Maximum Air Inlet Pressure (bar): 12.07
• Maximum Air Inlet Pressure (kPa): 1207
• Maximum Air Inlet Pressure (MPa): 1.21
• Maximum Air Inlet Pressure (psi): 175

• Maximum Cycle Rate (CPM): 40

• Maximum Flow Rate (cc/min): 7200

• Maximum Flow Rate (GPM): 1.9
• Maximum Flow Rate (L/min): 7.2

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Hose Length (ft): 300
• Maximum Hose Length (m): 91.4

• Maximum Operating Temperature ( degree C): 54
• Maximum Operating Temperature ( degree F): 130

• Maximum Spray Pressure (bar): 500

• Maximum Spray Pressure (kPa): 50000
• Maximum Spray Pressure (MPa): 50
• Maximum Spray Pressure (psi): 7250

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (MPa): 50
• Maximum Working Pressure (psi): 7250
• Measuring Type: Fixed Mechanical Positive Displacement

• Minimum Fluid Viscosity (cP): 200

• Mix Accuracy (%): +/- 5
• Mix Ratio: 1:1

• Number of Catalysts: 1

• Number of Reducers: 0

• Number of Resin Colors: 1
• Number of Tanks: 2

• Ov

GG 60/0116-1/50

GG 576205

XP SYSTEM, 2:1, 115/58, BF, CH, HS, JB

Graco 576205 XP70 Non-Hazardous Spray Package, Cart, 2:1 Mix Ratio, Hopper, Solvent Pump, Heaters, Junction Box, XTR Gun, 240V

Two-component spraying made easy and affordable. The Graco XP70 Plural-Component Sprayer is designed to pump, mix and atomize high to 100% solid coatings with superior results. In addition, the XP70's design allows you to gravity feed, which may eliminate the need for feed pumps, saving you money. When you upgrade from hand mixing, youll find that the XP70 provides excellent return on investment, by reducing material waste and by using less clean-up solvent. Flexible options for mix ratio, pressure and flow rate - choose the right system for the application. If you occasionally change materials, the Graco XP Sprayers are the right choice. That's because you can change the ratio by simply changing out one or two pump lowers. Available in 1:1, 1.5:1, 2:1, 2.5:1, 3:1 and 4:1 mix ratios.

• Reduced material waste
• No more throwing away unused mixed material at the end of the day
• Save money by using less clean-up solvent
• Easy to operate - minimal training required
• Reduced maintenance costs
• Rated for 7250 psi (500 bar, 50 MPa) to handle viscous materials and long hose lengths

• Series: XP70

• Air Inlet Size (in): 3/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPSM

• Applicator Type: Automatic Airless, Manual Airless

• Compatible Material: Protective Coatings, Primer, Epoxies, Polyurethane, Two-Component Coating, Solvents

• Component Type: Plural-Component
• Configuration: Cart Mount with 7 gallon (26.5 Liter) Hopper

• Fluid Inlet Size (in): 1-1/4
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPSM

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Flush Type: Solvent

• Hose Length (ft): 35
• Hose Length (m): 10.7

• Includes: Heaters, Solvent Flush Pump, Hoppers

• Material Application: Coatings, Paints, Primers

• Maximum Air Consumption (SCFM): 75 scfm/gpm at 100 psi
• Maximum Air Inlet Pressure (bar): 12.07
• Maximum Air Inlet Pressure (kPa): 1207
• Maximum Air Inlet Pressure (MPa): 1.21
• Maximum Air Inlet Pressure (psi): 175

• Maximum Cycle Rate (CPM): 40

• Maximum Flow Rate (cc/min): 6800

• Maximum Flow Rate (GPM): 1.8
• Maximum Flow Rate (L/min): 6.8

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Hose Length (ft): 300
• Maximum Hose Length (m): 91.4

• Maximum Operating Temperature ( degree C): 54
• Maximum Operating Temperature ( degree F): 130

• Maximum Spray Pressure (bar): 500

• Maximum Spray Pressure (kPa): 50000
• Maximum Spray Pressure (MPa): 50
• Maximum Spray Pressure (psi): 7250

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (MPa): 50
• Maximum Working Pressure (psi):

GG 571042

KIT, REPAIR, 2L RESERVOIR, G3

Graco 571042 G-Series Repair Kit - 2L Reservoir

• Repair kit 2L reservoir with wiper arm

• Includes: Wiper Arm

GG 571170

VALVE, VENT 24VDC N.C. NPT

Graco 571170 Direct-Mount Vent Valves for G3 Pumps - NPT, 24 VDC, 500-3500 psi (35-241 bar), Normally Closed, RH

Industry leading feature for your lube system needs.

• Easily mounts to your G3 pump.
• Eliminates time and material costs associated with remote mounted vent valves.
• 24 VDC
• The normally closed valve works with the G3 Max pumps controller, and vents pressure based on the time duration you program into the G3 control.
• Adjustable pressure relief is integrated into the valve, no need to purchase an additional relief valve.
• Deutsch Power Connection

• Model: Trabon

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Oil, Grease

• For Use With: G3 Pumps

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 5
• Maximum Flow Rate (L/min): 19

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 24
• Maximum Working Pressure (psi): 3500

• Outlet Thread Type: NPT

GG 577005

GG 571183

KIT, REPAIR, RESERVOIR, GRS 4L

Graco 571183 G-Series Repair Kit - 4L Reservoir

• Reservoir Repair Kit - for 4 Liter Grease models

• For Use With: G1 Pumps, G3 Pumps

• Includes: Reservoir, Hardware

• Kit Type: Repair Kit

GG 24Z715

GG 24Z015

PROMIX 2KE PROPORTIONER, METER, ACID

Graco 24Z015 ProMix 2KE Acid Catalyst Meter, 1 color/1 catalyst, non intrinsically safe alternator power

The ProMix 2KE meter-based system manages tough acid catalyst materials, such as conversion varnish for cabinetry and bar counter tops. The compact, entry-level proportioner easily handles strong acid catalysts with its corrosion resistant fluid section and smart fluid plate.

• Made with durable, high grade, stainless steel components like gears with ceramic bearings, the G3000A meter gauges the exact mix ratio while withstanding corrosion.
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: 2KE Meter-Based Proportioner, G3000 (A), G3000A (B), 1 Color, 1 Catalyst, Non Intrinsically Safe AC Powered

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 206.8
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000
• Measuring Type: Meter

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Power Source: Electric

• Proportioning Type: Manual Electronic

• Pump Ratio: Meter only

GG 24Z487

CSP VALVE, 8 OUTLET, NPT, PKG

Graco 24Z487 CSP Divider Valve, 1/8 inch NPT, 8 Outlets

Compact Series Progressive (CSP) valve with broad market versatility. Combine with field-proven G-Series pumps for a complete system solution.

• 1/8 inch NPT inlet
• Space efficient design with 8 outlets, without indicator
• Outlets can be combined to meet larger bearing needs
• High output pressure - maximum working pressure of 5,076 psi (350 bar) for both oil and grease

• Model: Trabon
• Series: CSP

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): N/A

• Divider Valve Series: CSP

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: NPT

• Material: Carbon Steel

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 100
• Maximum Operating Temperature ( degree F): 212

• Maximum Working Pressure (bar): 350
• Maximum Working Pressure (kPa): 35000
• Maximum Working Pressure (psi): 5076

• Minimum Output Volume (cm cu ): 0.2

• Minimum Working Pressure (bar): 15
• Minimum Working Pressure (kPa): 1500

• Minimum Working Pressure (psi): 217.5

• Number of Outlets: 8

• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

GG 24Z119

GG 24Z504

CSP VALVE, 6 OUTLET, NPT, IND, PKG

Graco 24Z504 CSP Divider Valve, 1/8 inch NPT, 6 Outlets, Indicator Included

Compact Series Progressive (CSP) valve with broad market versatility. Combine with field-proven G-Series pumps for a complete system solution.

• 1/8 inch NPT inlet
• Space efficient design with 6 outlets, with indicator
• Outlets can be combined to meet larger bearing needs
• High output pressure - maximum working pressure of 5,076 psi (350 bar) for both oil and grease

• Model: Trabon
• Series: CSP

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Oil, Grease

• Cycle Indicator: Cycle Indicator

• Discharge Per Piston Stroke (in cu ): N/A

• Divider Valve Series: CSP

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: NPT

• Material: Carbon Steel

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 100
• Maximum Operating Temperature ( degree F): 212

• Maximum Working Pressure (bar): 350
• Maximum Working Pressure (kPa): 35000
• Maximum Working Pressure (psi): 5076

• Minimum Output Volume (cm cu ): 0.2

• Minimum Working Pressure (bar): 15
• Minimum Working Pressure (kPa): 1500

• Minimum Working Pressure (psi): 217.5

• Number of Outlets: 6

• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

GG 24Z486

CSP VALVE, 6 OUTLET, NPT, PKG

Graco 24Z486 CSP Divider Valve, 1/8 inch NPT, 6 Outlets

Compact Series Progressive (CSP) valve with broad market versatility. Combine with field-proven G-Series pumps for a complete system solution.

• 1/8 inch NPT inlet
• Space efficient design with 6 outlets, without indicator
• Outlets can be combined to meet larger bearing needs
• High output pressure - maximum working pressure of 5,076 psi (350 bar) for both oil and grease

• Model: Trabon
• Series: CSP

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): N/A

• Divider Valve Series: CSP

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: NPT

• Material: Carbon Steel

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 100
• Maximum Operating Temperature ( degree F): 212

• Maximum Working Pressure (bar): 350
• Maximum Working Pressure (kPa): 35000
• Maximum Working Pressure (psi): 5076

• Minimum Output Volume (cm cu ): 0.2

• Minimum Working Pressure (bar): 15
• Minimum Working Pressure (kPa): 1500

• Minimum Working Pressure (psi): 217.5

• Number of Outlets: 6

• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

GG 24Z728

PULSE PRO PUMP AIR CONTROL VALVE, NPT

Graco 24Z728 Pulse Pump Air Control - NPT with NEMA 5-15 Plug

Graco's Pulse Pump Air Control (PAC) is integral to the Pulse fluid management system. These reliable devices prevent unauthorized access to fluid inventory.

• Ensure better inventory control
• Built with Graco quality for a long life
• When combined with other components of the Pulse fluid management system you'll improve shop efficiency
• Installs easily - built-in mounting bracket
• Simple wireless setup - automatically identifies networks
• High-volume air valve supports a variety of pump

• Model: Pulse

• For Use With: Pulse Fluid Management

• Maximum Air Flow Rate (CFM): 93

• Maximum Operating Pressure (psi): 145
• Maximum Operating Temperature ( degree F): 122

• Maximum Storage Temperature ( degree F): 185

• Minimum Operating Pressure (psi): 36
• Minimum Operating Temperature ( degree F): 14

• Power Supply (VAC): 100-240

• Product Type: Pump Air Control (PAC)

GG 24Z962

KIT, COVER, FRONT, NO LOGO, CLEAR

Graco 24Z962 Electric Grease Jockey Pump Protective Pump Cover

• Protective pump cover

• Model: Grease Jockey

• For Use With: Grease Jockey Pumps

• Number of Pieces: 3

GG 24Z834

T3 PUMP, CS

Graco 24Z834 T3 Supply Pump (Carbon Steel): 3:1 Fluid to Air Ratio

Transfer Pumps are required to move A and B materials to the Reactor Spray Systems. The T3 Transfer Pump combines Graco's proven Merkur air-motor and popular T2 stainless steel lower. The T3 is a 3:1 ratio pump - using less air pressure to provide the same fluid pressure required.

• Easier to maneuver - The overall height of the T3 is 3.7 inches (9.4 cm) shorter above the drum than the T2, making it easier to remove from the drum inside of a spray rig.
• More quiet - Studies show the T3 Transfer Pump is about 3x more quiet than the T2 Transfer Pump.
• Less maintenance - the Merkur air-motor is based on air pilot valve technology. The air-motor switching

  is purely pneumatic. This differs from T1 and T2 Transfer Pumps, which use a mechanical

  reversing mechanism in the air-motor

• Model: T3
• Series: Carbon Steel

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Compatible Material: Polyurethane Foam, Polyurea

• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (MPa): 0.69
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 4.5
• Maximum Flow Rate (L/min): 17.03

• Maximum Operating Temperature ( degree C): 88
• Maximum Operating Temperature ( degree F): 190

• Maximum Working Pressure (bar): 21.7
• Maximum Working Pressure (kPa): 2170
• Maximum Working Pressure (MPa): 2.2
• Maximum Working Pressure (psi): 315

• Package Options: Bare

• Pump Ratio: 3:1

GG 253032

GG 253215

KIT, REPAIR, BRG, HELICAL FLWMTR

KIT INCLUDES: HOUSING, MIDDLE, HELICAL GEAR MTR [QTY. 1], INSERT, BEARING, HELICAL GEAR MTR [QTY. 2], INSERT, BEARING, HELICAL GEAR MTR [QTY. 1], BEARING, GEAR [QTY. 3], BALL, BEARING [QTY. 3], O-RING, SEAL, HELICAL GEAR METER [QTY. 2], LUBRICANT, GREASE [QTY. 1], PIN, DOWEL, .550 in. [QTY. 2], PIN, DOWEL, .750 in. [QTY. 2]
