GRACO INC. S10595

GG 17P485

GG 246215

GUARD, RAC X

Graco 246215 RAC X HandTite Tip Guard

The RAC X HandTite Tip Guard helps to eliminate paint build-up, dripping and spitting. It also helps to provide safer spraying at higher pressures. Its finger grip design makes it easy to attach or remove without the need for tools. For use with all RAC X SwitchTips.

• Model: RAC X
• Series: Tip Guard

• Compatible Tip Type: RAC X

• For Use With: Widerac RAC X Switchtip

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

GG 246297

GG 246340

GG 246294

GG 246101

FUSION AP GUN, ROUND 01

Graco 246101 Round Fusion Air-Purge Gun with 01 Mix Chamber and 0.042 in (1.6 mm) Orifice Size

With long-life mix chamber and durable side seals, Fusion guns are designed to reduce maintenance and downtime, and provide a better mix.

• Easy air-blast tip cleaning reduces build-up and tip clogging.
• Long-lasting side seals means less downtime for maintenance
• Quick-release fluid housing - lets you easily change the mix chambers without tools
• Ergonomic handle

• Model: Fusion AP
• Series: Round

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• Applicator Type: Manual

• Compatible Material: Adhesives, Polyurethane, Polyurea, Polyurethane Coating, Spray Polyurethane Foam
• Component A Inlet Size (cm): 1.27

• Component A Inlet Size (in): 1/2-20
• Component A Inlet Size (mm): 12.7
• Component A Inlet Thread Type: UNF
• Component B Inlet Size (cm): 1.42875
• Component B Inlet Size (in): 9/16-18
• Component B Inlet Size (mm): 14.2875
• Component B Inlet Thread Type: UNF
• Component Type: Plural-Component

• Fluid Orifice Size (cm): 0.107
• Fluid Orifice Size (in): 0.042
• Fluid Orifice Size (mm): 1.07

• For Use With: Non-Flammable Foam and Polyurea

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: Air Purge Gun
• Gun Weight (g): 1130
• Gun Weight (kg): 1.1
• Gun Weight (lb): 2.5
• Gun Weight (oz): 40

• Impingement Port Size (in): 0.042
• Impingement Port Size (mm): 1.00
• Includes: AR4242 Mix Chamber Tip

• Maximum Air Inlet Pressure (bar): 9
• Maximum Air Inlet Pressure (kPa): 900
• Maximum Air Inlet Pressure (MPa): 0.9
• Maximum Air Inlet Pressure (psi): 130
• Maximum Air Pressure (bar): 9

• Maximum Air Pressure (kPa): 900
• Maximum Air Pressure (MPa): 0.9
• Maximum Air Pressure (psi): 130

• Maximum Flow Rate @ PSI (lb/min): 50

• Maximum Fluid Pressure (bar): 241
• Maximum Fluid Pressure (kPa): 24100
• Maximum Fluid Pressure (MPa): 24.1
• Maximum Fluid Pressure (psi): 3500
• Maximum Fluid Temperature ( degree C): 93
• Maximum Fluid Temperature ( degree F): 200

• Maximum Fluid Pressure (bar): 241
• Maximum Fluid Pressure (kPa): 24100
• Maximum Fluid Pressure (MPa): 24.1
• Maximum Fluid Pressure (psi): 3500
• Maximum Fluid Temperature ( degree C): 93
• Maximum Fluid Temperature ( degree F): 200

• Maximum Fluid Working Pressure (bar): 245
• Maximum Fluid Working Pressure (MPa): 24.5
• Maximum Fluid Working Pressure (psi): 3500

• Minimum Air Inlet Pressure (bar): 5.5
• Minimum Air Inlet Pressure (kPa): 550
• Minimum Air Inlet Pressure (MPa): 0.55
• Minimum Air Inlet Pressure (psi): 80

• Mix Chamber: 01 (.042)

• Overall Height (cm): 20.6
• Overall Height (in): 8.1
• Overall Height (mm): 206
• Overall Length (cm): 19.1
• Overall Length (in): 7.5
• Overall Length (mm): 191
• Ove

GG 246102

FUSION AP GUN, ROUND 02

Graco 246102 Round Fusion Air-Purge Gun with 02 Mix Chamber and 0.052 in (1.3 mm) Orifice Size

With long-life mix chamber and durable side seals, Fusion guns are designed to reduce maintenance and downtime, and provide a better mix.

• Easy air-blast tip cleaning reduces build-up and tip clogging.
• Long-lasting side seals means less downtime for maintenance
• Quick-release fluid housing - lets you easily change the mix chambers without tools
• Ergonomic handle

• Model: Fusion AP
• Series: Round

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• Applicator Type: Manual

• Compatible Material: Adhesives, Polyurethane, Polyurea, Polyurethane Coating, Spray Polyurethane Foam
• Component A Inlet Size (cm): 1.27

• Component A Inlet Size (in): 1/2-20
• Component A Inlet Size (mm): 12.7
• Component A Inlet Thread Type: UNF
• Component B Inlet Size (cm): 1.42875
• Component B Inlet Size (in): 9/16-18
• Component B Inlet Size (mm): 14.2875
• Component B Inlet Thread Type: UNF
• Component Type: Plural-Component

• Fluid Orifice Size (cm): 0.132
• Fluid Orifice Size (in): 0.052
• Fluid Orifice Size (mm): 1.32

• For Use With: Non-Flammable Foam and Polyurea

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: Air Purge Gun
• Gun Weight (g): 1130
• Gun Weight (kg): 1.1
• Gun Weight (lb): 2.5
• Gun Weight (oz): 40

• Impingement Port Size (in): 0.052
• Impingement Port Size (mm): 1.30
• Includes: AR5252 Mix Chamber Tip

• Maximum Air Inlet Pressure (bar): 9
• Maximum Air Inlet Pressure (kPa): 900
• Maximum Air Inlet Pressure (MPa): 0.9
• Maximum Air Inlet Pressure (psi): 130
• Maximum Air Pressure (bar): 9

• Maximum Air Pressure (kPa): 900
• Maximum Air Pressure (MPa): 0.9
• Maximum Air Pressure (psi): 130

• Maximum Flow Rate @ PSI (lb/min): 50

• Maximum Fluid Pressure (bar): 241
• Maximum Fluid Pressure (kPa): 24100
• Maximum Fluid Pressure (MPa): 24.1
• Maximum Fluid Pressure (psi): 3500
• Maximum Fluid Temperature ( degree C): 93
• Maximum Fluid Temperature ( degree F): 200

• Maximum Fluid Pressure (bar): 241
• Maximum Fluid Pressure (kPa): 24100
• Maximum Fluid Pressure (MPa): 24.1
• Maximum Fluid Pressure (psi): 3500
• Maximum Fluid Temperature ( degree C): 93
• Maximum Fluid Temperature ( degree F): 200

• Maximum Fluid Working Pressure (bar): 245
• Maximum Fluid Working Pressure (MPa): 24.5
• Maximum Fluid Working Pressure (psi): 3500

• Minimum Air Inlet Pressure (bar): 5.5
• Minimum Air Inlet Pressure (kPa): 550
• Minimum Air Inlet Pressure (MPa): 0.55
• Minimum Air Inlet Pressure (psi): 80

• Mix Chamber: 02 (.052)

• Overall Height (cm): 20.6
• Overall Height (in): 8.1
• Overall Height (mm): 206
• Overall Length (cm): 19.1
• Overall Length (in): 7.5
• Overall Length (mm): 191
• Ove

GG 246078

GG 246074

REACTOR HEATED HOSE, 50', 1/4, W/O CABLE

Graco 246074 50 ft x 1/4 in Heated Hose, 2000 psi, Without Cable, No Scuff, Reactor 1 & 2

Graco's heated hoses are designed specifically for use with Reactor Equipment. Hoses are a key component to the total system, making it important to achieve accurate and uniform heating for the best application possible.

• New multi-strand copper heating element has greatly increased hose quality:

  Provides 10-times* the flex life compared to previous flat copper heating element

  Long-term, even heating without hot spots

  Backwards compatible with existing Reactor heated hoses

  • Copper-heated hoses are designed specifically for use with Graco proportioners
  • Covered with proprietary butyl cover for protection against moisture sensitive isocyanate
  • Different fitting sizes on the isocyanate and resin hoses prevent accidentally connecting the wrong hoses together
  • Hoses use custom designed splice kit to electrically connect hoses without having to run copper under the fittings
  • Helix-design whip hose uses braided copper wires for added flexibility and longer life




  • Model: Reactor 1
  • Series: No Scuff
  • Compatible Sprayer: Reactor 1 & 2
  • For Use With: Plural Component Proportioners
  • Hose Heating Type: External Heated
  • Hose Inside Diameter (in): 1/4
  • Hose Inside Diameter (mm): 6.35
  • Hose Length (ft): 50
  • Hose Length (m): 15.2
  • Inside Diameter (in): 1/4
  • Maximum Working Pressure (bar): 138
  • Maximum Working Pressure (kPa): 13800
  • Maximum Working Pressure (MPa): 13.8
  • Maximum Working Pressure (psi): 2000

GG 245850

GG 245863

GG 245864

GG 246348

GG 246347

GG 244535

VALVE, ENDURE,DISP,200 DEG F

Graco 244535 Endure Displacement Valve

• Model: Endure

• Air Inlet Size (cm): 0.3175
• Air Inlet Size (in): 1/8
• Air Inlet Size (mm): 3.175
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Ambient/Warm Melt/Hot Melt: Ambient, Warm Melt
• Application: Bonding, Sealing, Gasketing

GG 246382

KIT, REPAIR, FILTER, 100 MESH

Graco 246382 Easy Out Pump Manifold Filter, Short, 100 mesh

Using an Easy Out Pump Manifold Filter is the easiest way to maximize spray performance while also saving time and money by extending the life of your equipment and reducing down time. Use 100 mesh for materials such as lacquers and solvent-based enamels and paints.

• Model: Easy Out
• Series: Manifold Filter

• For Use With: ST, STX, 390, Ultra 395/495/595 Airless Sprayers

• Mesh Size: 100

• Number of Pieces: 1

GG 246421

GG 246429

GG 100053

GG 100068

GG 100081

GG 100103

GG 100113

GG 100132

GG 100175

GG 100179

GG 100385

GG 100509

GG 10054-8-10

GG 100579

GG 100627

GG 100672

GG 100854

GG 100848

GG 100896

GG 101021

GG 101078

GG 101108

GG 101891

BRUSH

Graco 101891 Tip Brush

Use to clean spray tips, filters and guns. 3/8 in x 2.25 in nylon bristle

GG 101281

GG 101180

GG 101354

GG 101831

GG 101529

GG 101754

GG 101920

GG 101909

GG 101960

GG 101961

GG 101954

GG 101962

GG 102005

GG 102123

GG 102124

GG 102180

GG 102325

GG 102550

GG 102620

GG 102762

GG 102848

GG 102921

SEAL, BLK VEE,.375OD X .125ID

• Bleed Type: Non-Bleeder
• Body Material: Metal

• Compatible Material: Epoxies, High Solids, Latex, Plural Component Materials, Sealants, Solventborne, Urethane, Waterborne

GG 102929

GG 102931

GG 102973

GG 103181

GG 103413

PACKING O-RING

Graco 103413 ProX21 Packing O-Ring

Replace a worn or damaged o-ring with genuine Graco parts. Refer to the parts manual for your sprayer to ensure part compatibility

• O-ring seal for pickup tube from inlet valve to foot valve
• For use with ProX 21 cart sprayer model, 17G182
• Graco tech support can further assist with troubleshooting sprayer operation
• Genuine Graco parts includes O-ring

• For Use With: ProX21

GG 103473

GG 103833

GG 103972

GG 103975

GG 104488

GG 104301

GG 104636

GG 104430

GG 104413

GG 104371

GG 104084

GG 105280

GG 105332

GG 105468

GG 105510

GG 106082

GG 106115

GG 106204

GG 107052

GG 107141

GG 107218

GG 107460

GG 107542

GG 107558

GG 107590

COVER, ROLLER

Graco 107590 9 in Pressure Roller Cover, 1/2 in nap

Roller cover specifically created for the EvenFlow Pressure Roller, 1/2 inch nap for semi-smooth surfaces.

• Model: Graco
• Series: Roller Cover

• For Use With: EvenFlow Roller Frame

GG 108357

GG 108513

GG 108324

GG 108358

GG 108235

GG 108523

GG 108636

GG 108792

GG 108780
