GRACO INC. S10595

GG 24R441

XD SERIES 70 REEL, 7010, LP, 24 VDC, NPT, YELLOW

Graco 24R441 XD70â„¢, Air/Water/Diesel Fuel, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 100 ft. (25 mm X 30 m) Capacity), NPT, 24 VDC Electric Motor, Yellow

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Air, Water, Diesel Fuel

• Bare Reel: 1

• Color: Yellow

• Dry Weight (lb): 132

• Frame Type: Box Frame

• Hose Length (ft): 100

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Operating Voltage (V dc): 24
• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 61.2
• Overall Width (in): 24.1
• Overall Width (mm): 612

• Rated Power (HP): 0.67
• Rated Speed (RPM): 500
• Rating Current (A): 38
• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water, Diesel Fuel

GG 24R442

GG 24R443

XD SERIES 70 REEL, 7010, LP, 115VAC, NPT, BLUE

Graco 24R443 XD70â„¢, Air/Water/Diesel Fuel, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 100 ft. (25 mm X 30 m), NPT, 115 VAC Electric Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Air, Water, Diesel Fuel

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 132

• Frame Type: Box Frame
• Frequency (Hz): 50/60

• Hose Length (ft): 100

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Operating Voltage (V ac): 115
• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 61.2
• Overall Width (in): 24.1
• Overall Width (mm): 612

• Rated Power (HP): 0.4
• Rated Speed (RPM): 500
• Rating Current (A): 6.5
• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water, Diesel Fuel

GG 24R444

GG 24R446

XD SERIES 70 REEL, 7010, LP, HYD, NPT, BLUE

Graco 24R446 XD70â„¢, Air/Water/Diesel Fuel, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 100 ft. (25 mm X 30 m) Capacity), NPT, Hydraulic Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Air, Water, Diesel Fuel

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 100

• Frame Type: Box Frame

• Hose Length (ft): 100

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 46.2
• Overall Width (in): 18.2
• Overall Width (mm): 462

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water, Diesel Fuel

GG 24R447

GG 24R448

XD SERIES 70 REEL, 7010, LP, HYD, NPT, WHITE

Graco 24R448 XD70â„¢, Air/Water/Diesel Fuel, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 100 ft. (25 mm X 30 m) Capacity), NPT, Hydraulic Motor, White

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Air, Water, Diesel Fuel

• Bare Reel: 1

• Color: White

• Dry Weight (lb): 100

• Frame Type: Box Frame

• Hose Length (ft): 100

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 46.2
• Overall Width (in): 18.2
• Overall Width (mm): 462

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water, Diesel Fuel

GG 24R449

XD SERIES 70 REEL, 7010, LP, PNEU, NPT, BLUE

Graco 24R449 XD70â„¢, Air/Water/Diesel Fuel, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 100 ft. (25 mm X 30 m) Capacity), NPT, Pneumatic Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Air, Water, Diesel Fuel

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 122

• Frame Type: Box Frame

• Hose Length (ft): 100

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 6.7
• Maximum Working Pressure (kPa): 670
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 46.2
• Overall Width (in): 18.2
• Overall Width (mm): 462

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water, Diesel Fuel

GG 24R450

XD SERIES 70 REEL, 7010, LP, PNEU, NPT, YELLOW

Graco 24R450 XD70â„¢, Air/Water/Diesel Fuel, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 100 ft. (25 mm X 30 m) Capacity), NPT, Pneumatic Motor, Yellow

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Air, Water, Diesel Fuel

• Bare Reel: 1

• Color: Yellow

• Dry Weight (lb): 122

• Frame Type: Box Frame

• Hose Length (ft): 100

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 6.7
• Maximum Working Pressure (kPa): 670
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 58.2
• Overall Width (in): 22.9
• Overall Width (mm): 582

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water, Diesel Fuel

GG 24R451

GG 24R455

XD SERIES 70 REEL, 7010, MP, 24 VDC, NPT, BLUE

Graco 24R455 XD70â„¢, Oil, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 100 ft. (25 mm X 30 m) Capacity), NPT, 24 VDC Electric Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Oil

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 133

• Frame Type: Box Frame

• Hose Length (ft): 100

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Operating Voltage (V dc): 24
• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 61.2
• Overall Width (in): 24.1
• Overall Width (mm): 612

• Rated Power (HP): 0.67
• Rated Speed (RPM): 500
• Rating Current (A): 38
• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Oil

GG 24R456

GG 24R457

GG 24R458

XD SERIES 70 REEL, 7010, MP, 115VAC, NPT, BLUE

Graco 24R458 XD70â„¢, Oil, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 100 ft. (25 mm X 30 m) Capacity), NPT, 115 VAC Electric Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Oil

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 133

• Frame Type: Box Frame
• Frequency (Hz): 50/60

• Hose Length (ft): 100

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Operating Voltage (V ac): 115
• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 61.2
• Overall Width (in): 24.1
• Overall Width (mm): 612

• Rated Power (HP): 0.4
• Rated Speed (RPM): 500
• Rating Current (A): 6.5
• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Oil

GG 24R459

GG 24R460

GG 24R461

GG 24R462

GG 24R463

GG 24R464

XD SERIES 70 REEL, 7010, MP, PNEU, NPT, BLUE

Graco 24R464 XD70â„¢, Oil, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 100 ft. (25 mm X 30 m) Capacity), NPT, Pneumatic Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Oil

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 124

• Frame Type: Box Frame

• Hose Length (ft): 100

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 6.7
• Maximum Working Pressure (kPa): 670
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 58.2
• Overall Width (in): 22.9
• Overall Width (mm): 582

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Oil

GG 24R465

XD SERIES 70 REEL, 7010, MP, PNEU, NPT, YELLOW

Graco 24R465 XD70â„¢, Oil, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 100 ft. (25 mm X 30 m) Capacity), NPT, Pneumatic Motor, Yellow

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Oil

• Bare Reel: 1

• Color: Yellow

• Dry Weight (lb): 124

• Frame Type: Box Frame

• Hose Length (ft): 100

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 6.7
• Maximum Working Pressure (kPa): 670
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 58.2
• Overall Width (in): 22.9
• Overall Width (mm): 582

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Oil

GG 24R466

GG 24R489

GG 24R468

GG 24R506

XD SERIES 70 REEL, 7015, LP, 24 VDC, NPT, BLUE

Graco 24R506 XD70â„¢, Diesel Fuel/WOE, 1-1/2 in. (38 mm) Inlet/Outlet, Bare Reel (1-1/2 in. X 50 ft. (38 mm X 15 m), NPT, 24 VDC Electric Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Diesel Fuel, WOE

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 133

• Frame Type: Box Frame

• Hose Length (ft): 50

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 3.81
• Inlet Size (in): 1.5
• Inlet Size (mm): 38.1

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Operating Voltage (V dc): 24
• Outlet Size (cm): 3.81
• Outlet Size (in): 1.5
• Outlet Size (mm): 38.1
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 63.0
• Overall Width (in): 24.8
• Overall Width (mm): 630

• Rated Power (HP): 0.67
• Rated Speed (RPM): 500
• Rating Current (A): 38
• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Diesel Fuel, WOE

GG 24R508

GG 24R510

XD SERIES 70 REEL, 7015, LP, 115VAC, NPT, YELLOW

Graco 24R510 XD70â„¢, Diesel Fuel/WOE, 1-1/2 in. (38 mm) Inlet/Outlet, Bare Reel (1-1/2 in. X 50 ft. (38 mm X 15 m) Capacity), NPT, 115 VAC Electric Motor, Yellow

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Diesel Fuel, WOE

• Bare Reel: 1

• Color: Yellow

• Dry Weight (lb): 133

• Frame Type: Box Frame
• Frequency (Hz): 50/60

• Hose Length (ft): 50

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 3.81
• Inlet Size (in): 1.5
• Inlet Size (mm): 38.1

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Operating Voltage (V ac): 115
• Outlet Size (cm): 3.81
• Outlet Size (in): 1.5
• Outlet Size (mm): 38.1
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 63.0
• Overall Width (in): 24.8
• Overall Width (mm): 630

• Rated Power (HP): 0.4
• Rated Speed (RPM): 500
• Rating Current (A): 6.5
• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Diesel Fuel, WOE

GG 24R509

XD SERIES 70 REEL, 7015, LP, 115VAC, NPT, BLUE

Graco 24R509 XD70â„¢, Diesel Fuel/WOE, 1-1/2 in. (38 mm) Inlet/Outlet, Bare Reel (1-1/2 in. X 50 ft. (38 mm X 15 m), NPT, 115 VAC Electric Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Diesel Fuel, WOE

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 133

• Frame Type: Box Frame
• Frequency (Hz): 50/60

• Hose Length (ft): 50

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 3.81
• Inlet Size (in): 1.5
• Inlet Size (mm): 38.1

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Operating Voltage (V ac): 115
• Outlet Size (cm): 3.81
• Outlet Size (in): 1.5
• Outlet Size (mm): 38.1
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 63.0
• Overall Width (in): 24.8
• Overall Width (mm): 630

• Rated Power (HP): 0.4
• Rated Speed (RPM): 500
• Rating Current (A): 6.5
• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Diesel Fuel, WOE

GG 24R511

GG 24R512

XD SERIES 70 REEL, 7015, LP, HYD, NPT, BLUE

GG 24R514

GG 24R515

GG 24R516

XD SERIES 70 REEL, 7015, LP, PNEU, NPT, BLUE

Graco 24R516 XD70â„¢, Diesel Fuel/WOE, 1-1/2 in. (38 mm) Inlet/Outlet, Bare Reel (1-1/2 in. X 50 ft. (38 mm X 15 m) Capacity), NPT, Pneumatic Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Diesel Fuel, WOE

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 124

• Frame Type: Box Frame

• Hose Length (ft): 50

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 3.81
• Inlet Size (in): 1.5
• Inlet Size (mm): 38.1

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 6.7
• Maximum Working Pressure (kPa): 670
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 3.81
• Outlet Size (in): 1.5
• Outlet Size (mm): 38.1
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 60.2
• Overall Width (in): 23.7
• Overall Width (mm): 602

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Diesel Fuel, WOE

GG 24R517

XD SERIES 70 REEL, 7015, LP, PNEU, NPT, YELLOW

Graco 24R517 XD70â„¢, Diesel Fuel/WOE, 1-1/2 in. (38 mm) Inlet/Outlet, Bare Reel (1-1/2 in. X 50 ft. (38 mm X 15 m) Capacity), NPT, Pneumatic Motor, Yellow

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 70

• Application: Diesel Fuel, WOE

• Bare Reel: 1

• Color: Yellow

• Dry Weight (lb): 124

• Frame Type: Box Frame

• Hose Length (ft): 50

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 3.81
• Inlet Size (in): 1.5
• Inlet Size (mm): 38.1

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 6.7
• Maximum Working Pressure (kPa): 670
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 3.81
• Outlet Size (in): 1.5
• Outlet Size (mm): 38.1
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 66.3
• Overall Height (in): 26.1
• Overall Height (mm): 663
• Overall Length (cm): 66
• Overall Length (in): 26
• Overall Length (mm): 660
• Overall Width (cm): 60.2
• Overall Width (in): 23.7
• Overall Width (mm): 602

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Diesel Fuel, WOE

GG 24R518

GG 24R522

GG 24R523

GG 24R524

GG 24R525

GG 24R526

XD SERIES 80 REEL, 8010, LP, 115VAC, NPT, YELLOW

Graco 24R526 XD80â„¢, Air/Water/Diesel Fuel, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 150 ft. (25 mm X 46 m) Capacity), NPT, 115 VAC Electric Motor, Yellow

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 80

• Application: Air, Water, Diesel Fuel

• Bare Reel: 1

• Color: Yellow

• Dry Weight (lb): 173

• Frame Type: Box Frame
• Frequency (Hz): 50/60

• Hose Length (ft): 150

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Operating Voltage (V ac): 115
• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 76.5
• Overall Height (in): 30.1
• Overall Height (mm): 765
• Overall Length (cm): 77
• Overall Length (in): 30.4
• Overall Length (mm): 772
• Overall Width (cm): 80.8
• Overall Width (in): 31.8
• Overall Width (mm): 808

• Rated Power (HP): 0.4
• Rated Speed (RPM): 500
• Rating Current (A): 6.5
• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water, Diesel Fuel

GG 24R527

XD SERIES 80 REEL, 8010, LP, 115VAC, NPT, WHITE

Graco 24R527 XD80â„¢, Air/Water/Diesel Fuel, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 150 ft. (25 mm X 46 m) Capacity), NPT, 115 VAC Electric Motor, White

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 80

• Application: Air, Water, Diesel Fuel

• Bare Reel: 1

• Color: White

• Dry Weight (lb): 173

• Frame Type: Box Frame
• Frequency (Hz): 50/60

• Hose Length (ft): 150

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Operating Voltage (V ac): 115
• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 76.5
• Overall Height (in): 30.1
• Overall Height (mm): 765
• Overall Length (cm): 77
• Overall Length (in): 30.4
• Overall Length (mm): 772
• Overall Width (cm): 80.8
• Overall Width (in): 31.8
• Overall Width (mm): 808

• Rated Power (HP): 0.4
• Rated Speed (RPM): 500
• Rating Current (A): 6.5
• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water, Diesel Fuel

GG 24R528

GG 24R529

GG 24R531

XD SERIES 80 REEL, 8010, LP, PNEU, NPT, BLUE

Graco 24R531 XD80â„¢, Air/Water/Diesel Fuel, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 150 ft. (25 mm X 46 m) Capacity), NPT, Pneumatic Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 80

• Application: Air, Water, Diesel Fuel

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 164

• Frame Type: Box Frame

• Hose Length (ft): 150

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 6.7
• Maximum Working Pressure (kPa): 670
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 76.5
• Overall Height (in): 30.1
• Overall Height (mm): 765
• Overall Length (cm): 77
• Overall Length (in): 30.4
• Overall Length (mm): 772
• Overall Width (cm): 78.0
• Overall Width (in): 30.7
• Overall Width (mm): 780

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water, Diesel Fuel

GG 24R543

XD SERIES 80 REEL, 8010, MP, HYD, NPT, BLUE

Graco 24R543 XD80â„¢, Oil, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 150 ft. (25 mm X 46 m) Capacity), NPT, Hydraulic Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 80

• Application: Oil

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 143

• Frame Type: Box Frame

• Hose Length (ft): 150

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 137.9
• Maximum Working Pressure (kPa): 13790
• Maximum Working Pressure (MPa): 13.8
• Maximum Working Pressure (psi): 2000

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 2.54
• Outlet Size (in): 1
• Outlet Size (mm): 25.4
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 76.5
• Overall Height (in): 30.1
• Overall Height (mm): 765
• Overall Length (cm): 77
• Overall Length (in): 30.4
• Overall Length (mm): 772
• Overall Width (cm): 66.0
• Overall Width (in): 26
• Overall Width (mm): 660

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Oil

GG 24R548

XD SERIES 80 REEL, 8010, HP, PNEU, NPT, WHITE

Graco 24R548 XD80â„¢, Oil, 1 in. (25 mm) Inlet/Outlet, Bare Reel (1 in. X 150 ft. (25 mm X 46 m) Capacity), NPT, Pneumatic Motor, White

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 80

• Application: Oil

• Bare Reel: 1

• Color: White

• Dry Weight (lb): 165

• Frame Type: Box Frame

• Hose Length (ft): 150

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 2.54
• Inlet Size (in): 1
• Inlet Size (mm): 25.4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 82
• Maximum Temperature (°F): 180

• Maximum Working Pressure (bar): 6.7
• Maximum Working Pressure (kPa): 670
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 5.08
• Outlet Size (in): 2
• Outlet Size (mm): 50.8
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 76.5
• Overall Height (in): 30.1
• Overall Height (mm): 765
• Overall Length (cm): 77
• Overall Length (in): 30.4
• Overall Length (mm): 772
• Overall Width (cm): 78.0
• Overall Width (in): 30.7
• Overall Width (mm): 780

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Oil

GG 24R555

XD SERIES 80 REEL, 8015, LP, 115VAC, NPT, BLUE

Graco 24R555 XD80â„¢, Diesel Fuel, 1-1/2 in. (38 mm) Inlet/Outlet, Bare Reel (1-1/2 in. X 100 ft. (38 mm X 30 m), NPT, 115 VAC Electric Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 80

• Application: Diesel Fuel

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 175

• Frame Type: Box Frame
• Frequency (Hz): 50/60

• Hose Length (ft): 100

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 3.81
• Inlet Size (in): 1.5
• Inlet Size (mm): 38.1

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 60
• Maximum Temperature (°F): 140

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Operating Voltage (V ac): 115
• Outlet Size (cm): 3.81
• Outlet Size (in): 1.5
• Outlet Size (mm): 38.1
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 76.5
• Overall Height (in): 30.1
• Overall Height (mm): 765
• Overall Length (cm): 77
• Overall Length (in): 30.4
• Overall Length (mm): 772
• Overall Width (cm): 82.5
• Overall Width (in): 32.5
• Overall Width (mm): 826

• Rated Power (HP): 0.4
• Rated Speed (RPM): 500
• Rating Current (A): 6.5
• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Diesel Fuel

GG 24R554

GG 24R556

GG 24R557

XD SERIES 80 REEL, 8015, LP, 115VAC, NPT, WHITE

Graco 24R557 XD80â„¢, Diesel Fuel, 1-1/2 in. (38 mm) Inlet/Outlet, Bare Reel (1-1/2 in. X 100 ft. (38 mm X 30 m) Capacity), NPT, 115 VAC Electric Motor, White

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 80

• Application: Diesel Fuel

• Bare Reel: 1

• Color: White

• Dry Weight (lb): 175

• Frame Type: Box Frame
• Frequency (Hz): 50/60

• Hose Length (ft): 100

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 3.81
• Inlet Size (in): 1.5
• Inlet Size (mm): 38.1

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 60
• Maximum Temperature (°F): 140

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Operating Voltage (V ac): 115
• Outlet Size (cm): 3.81
• Outlet Size (in): 1.5
• Outlet Size (mm): 38.1
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 76.5
• Overall Height (in): 30.1
• Overall Height (mm): 765
• Overall Length (cm): 77
• Overall Length (in): 30.4
• Overall Length (mm): 772
• Overall Width (cm): 82.5
• Overall Width (in): 32.5
• Overall Width (mm): 826

• Rated Power (HP): 0.4
• Rated Speed (RPM): 500
• Rating Current (A): 6.5
• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Diesel Fuel

GG 24R558

GG 24R560

GG 24R562

XD SERIES 80 REEL, 8015, LP, PNEU, NPT, YELLOW

Graco 24R562 XD80â„¢, Diesel Fuel, 1-1/2 in. (38 mm) Inlet/Outlet, Bare Reel (1-1/2 in. X 100 ft. (38 mm X 30 m) Capacity), NPT, Pneumatic Motor, Yellow

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 80

• Application: Diesel Fuel

• Bare Reel: 1

• Color: Yellow

• Dry Weight (lb): 165

• Frame Type: Box Frame

• Hose Length (ft): 100

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 3.81
• Inlet Size (in): 1.5
• Inlet Size (mm): 38.1

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 60
• Maximum Temperature (°F): 140

• Maximum Working Pressure (bar): 6.7
• Maximum Working Pressure (kPa): 670
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 3.81
• Outlet Size (in): 1.5
• Outlet Size (mm): 38.1
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 76.5
• Overall Height (in): 30.1
• Overall Height (mm): 765
• Overall Length (cm): 77
• Overall Length (in): 30.4
• Overall Length (mm): 772
• Overall Width (cm): 79.8
• Overall Width (in): 31.4
• Overall Width (mm): 798

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Diesel Fuel

GG 24R563

GG 24R568

GG 24R569

GG 24R570

XD SERIES 80 REEL, 8020, LP, 115VAC, NPT, BLUE

Graco 24R570 XD80â„¢, Diesel Fuel, 2 in. (51 mm) Inlet/Outlet, Bare Reel (2 in. X 50 ft. (51 mm X 15 m) Capacity), NPT, 115 VAC Electric Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 80

• Application: Diesel Fuel

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 179

• Frame Type: Box Frame
• Frequency (Hz): 50/60

• Hose Length (ft): 50

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 3.81
• Inlet Size (in): 1.5
• Inlet Size (mm): 38.1

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 60
• Maximum Temperature (°F): 140

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Operating Voltage (V ac): 115
• Outlet Size (cm): 3.81
• Outlet Size (in): 1.5
• Outlet Size (mm): 38.1
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 76.5
• Overall Height (in): 30.1
• Overall Height (mm): 765
• Overall Length (cm): 77
• Overall Length (in): 30.4
• Overall Length (mm): 772
• Overall Width (cm): 83.8
• Overall Width (in): 33
• Overall Width (mm): 838

• Rated Power (HP): 0.4
• Rated Speed (RPM): 500
• Rating Current (A): 6.5
• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Diesel Fuel

GG 24R571

GG 24R572

GG 24R573

XD SERIES 80 REEL, 8020, LP, HYD, NPT, BLUE

Graco 24R573 XD80â„¢, Diesel Fuel, 2 in. (51 mm) Inlet/Outlet, Bare Reel (2 in. X 50 ft. (51 mm X 15 m) Capacity), NPT, Hydraulic Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 80

• Application: Diesel Fuel

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 147

• Frame Type: Box Frame

• Hose Length (ft): 50

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 5.08
• Inlet Size (in): 2
• Inlet Size (mm): 50.8

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 60
• Maximum Temperature (°F): 140

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 5.08
• Outlet Size (in): 2
• Outlet Size (mm): 50.8
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 76.5
• Overall Height (in): 30.1
• Overall Height (mm): 765
• Overall Length (cm): 77
• Overall Length (in): 30.4
• Overall Length (mm): 772
• Overall Width (cm): 68.8
• Overall Width (in): 27.1
• Overall Width (mm): 688

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Diesel Fuel

GG 24R575

GG 24R576

XD SERIES 80 REEL, 8020, LP, PNEU, NPT, BLUE

Graco 24R576 XD80â„¢, Diesel Fuel, 2 in. (51 mm) Inlet/Outlet, Bare Reel (2 in. X 50 ft. (51 mm X 15 m) Capacity), NPT, Pneumatic Motor, Metallic Blue

The innovative design of the XD60, XD70 and XD80 Series Powered Hose Reel family is packed with features to help you work safer, smarter and faster. The direct-drive motor options include hydraulic, pneumatic and electric for air, water, petroleum- and synthetic-based oil, grease, diesel fuel dispense and waste oil evacuation applications.

• Safe, Reliable Direct Drive and Gear Motors - Drive unit is clean and lubricated for life No need to worry about greasy, exposed drive chains that need maintenance and can be dangerous to operators
• Easy System Integration - Easily change the inlet and motor direction to give you the option of a right or left hand flow orientation
• Heavy-duty Welded Spool - Built to handle the weight of heavy hoses, designed to surround and protect the drive unit from the elements to promote longer lasting, safer operation

• Model: XD
• Series: 80

• Application: Diesel Fuel

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 169

• Frame Type: Box Frame

• Hose Length (ft): 50

• Hose Reel Type: Bare Reel
• Inlet Size (cm): 5.08
• Inlet Size (in): 2
• Inlet Size (mm): 50.8

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Temperature (°C): 60
• Maximum Temperature (°F): 140

• Maximum Working Pressure (bar): 6.7
• Maximum Working Pressure (kPa): 670
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Minimum Temperature (°C): -40
• Minimum Temperature (°F): -40

• Outlet Size (cm): 5.08
• Outlet Size (in): 2
• Outlet Size (mm): 50.8
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

• Overall Height (cm): 76.5
• Overall Height (in): 30.1
• Overall Height (mm): 765
• Overall Length (cm): 77
• Overall Length (in): 30.4
• Overall Length (mm): 772
• Overall Width (cm): 81.0
• Overall Width (in): 31.9
• Overall Width (mm): 810

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Diesel Fuel

GG 24R578

GG 24R582

GG 24R583

GG 24R597

GG 24R598

GG 24R631

KIT, CROSSPORT, MSP, LH/RH, SST

GG 24R602

GG 24R632

KIT, CROSSPORT, MSP, RH, SST

GG 24R633

KIT, CROSSPORT, MSP, LH, SST

GG 24R640

GG 24R646

GG 24R649

GG 24R648

GG 24R664

GG 24R681

GG 24R684

GG 24R685

GG 24R704

GG 24R705

GG 24R706

GG 24R707

GG 24R710

GG 24R711

GG 24R712

GG 24R722

GG 24R723

GG 24R724

GG 24R725

GG 24R736

GG 24R754

GG 24R755

GG 24R758

GG 24R759

GG 24R761

GG 24R763

THERMOLAZER SPRAYER, PROMELT, 6" SMARTDIE II

Graco 24R763 ThermoLazer ProMelt System, 6 in SmartDie II

The ThermoLazer ProMelt System is the perfect solution for first-time stripers wanting to get into the thermoplastic striping business, because it eliminates the need for a costly premelter system. Graco’s breakthrough ProMelt system can melt 300 lbs of thermoplastic in less than 1.5 hours.

• QuadMelt System

  • Four chamber melting system provides more melting surface for higher production
  • 100,000 BTU heating system melts material fast
• SmartDie II System
  • Floats on the for a superior line
  • No-tool change out design makes swapping dies easy
  • Built-in adjustment for mil thickness
  • Hardened steel for durability
• Bead Dispensing System

  • Line width adjustments take seconds and require no tools
  • Holds over 90 lbs of beads
  • Optional Double Drop Conversion Kit available
• Fat Track Front Swivel Wheel
  • Allows for easier turning when striping curves, arrows, and other hard-to-stripe jobs
• Ease-Z-Steer Handle Bar System

  • Makes turning and handling smooth and easy
• Die Burner System

  • Direct head keeps material flowing even in cooler conditions
• Compatible with LineDriver

  • Add a LineDriver for unmatched performance

• Model: ThermoLazer
• Series: ProMelt

• Compatible Material: Thermoplastics, Glass Beads, Alkyds
• Compatible Surfaces: Pavement

• Includes: 6 in SmartDie II

• Maximum Working Pressure (bar): 17.24
• Maximum Working Pressure (kPa): 172.4
• Maximum Working Pressure (psi): 250

• Number of Colors: One Color

• Number of Hoppers: 1

GG 24R762

THERMOLAZER SPRAYER, PROMELT, 5" SMARTDIE II

Graco 24R762 ThermoLazer ProMelt System, 5 in SmartDie II

The ThermoLazer ProMelt unit is your solution for first-time stripers wanting to get into the highly profitable thermoplastic marking business, as it lets you avoid the additional costs of adding a premelt kettle truck or trailer, thus saving you time and labor, resulting in more money in your pocket. Graco's breakthrough technology allows you to melt 300 lbs of thermoplastic on board in less than an hour.

• ProMelt Technology
  • 4 Chamber Melting System—More surface area to melt thermoplastic fast
  • 100,000 BTUs—Faster melt time means more jobs get done everyday
• SmartDie II System
  • Fast change-out system—Hardened steel dies with mil thickness adjustment system built in
  • Use with or without heat—Allows you to optimize your striping in all weather conditions
  • "Floats" with the surface—Puts the thermoplastic where you want it for superior line quality
  • External Heat System—4-torch die heat system keeps it hot
• Optional LineDriver System - LineDriver and LineDriver HD Systems adaptable for the ThermoLazer 300 tc System
  • Get higher productivity and straighter lines with less fatigue
  • Move between jobs without having to push
  • Dual Pedal System—Multiple positions allow for simple forward and reverse

• Model: ThermoLazer
• Series: ProMelt

• Compatible Material: Thermoplastics, Glass Beads, Alkyds
• Compatible Surfaces: Pavement

• Includes: 5 in SmartDie II

• Maximum Working Pressure (bar): 17.24
• Maximum Working Pressure (kPa): 172.4
• Maximum Working Pressure (psi): 250

• Number of Colors: One Color

• Number of Hoppers: 1

GG 24R764

GG 24R765

THERMOLAZER SPRAYER, PROMELT, 8" SMARTDIE II

Graco 24R765 ThermoLazer ProMelt System, 8 in SmartDie II

The ThermoLazer ProMelt unit is your solution for first-time stripers wanting to get into the highly profitable thermoplastic marking business, as it lets you avoid the additional costs of adding a premelt kettle truck or trailer, thus saving you time and labor, resulting in more money in your pocket. Graco's breakthrough technology allows you to melt 300 lbs of thermoplastic on board in less than an hour.

• Ease-Z-Steer Handle Bar System
  • Makes turning and handling as simple as a LineLazer System
  • Adjustable handle bar for users of all sizes
• ProMelt Technology
  • 4 Chamber Melting System—More surface area to melt thermoplastic fast
  • 100,000 BTUs—Faster melt time means more jobs get done everyday
• SmartDie II System
  • Fast change-out system—Hardened steel dies with mil thickness adjustment system built in
  • Use with or without heat—Allows you to optimize your striping in all weather conditions
  • "Floats" with the surface—Puts the thermoplastic where you want it for superior line quality
  • External Heat System—4-torch die heat system keeps it hot
• Optional LineDriver System - LineDriver and LineDriver HD Systems adaptable for the ThermoLazer 300 tc System
  • Get higher productivity and straighter lines with less fatigue
  • Move between jobs without having to push
  • Dual Pedal System—Multiple positions allow for simple forward and reverse

• Model: ThermoLazer
• Series: ProMelt

• Compatible Material: Thermoplastics, Glass Beads, Alkyds
• Compatible Surfaces: Pavement

• Includes: 8 in SmartDie II

• Maximum Working Pressure (bar): 17.24
• Maximum Working Pressure (kPa): 172.4
• Maximum Working Pressure (psi): 250

• Number of Colors: One Color

• Number of Hoppers: 1
