GRACO INC. S10595
Silver Flat Tip, 733
GG 163733
SILVER FLAT TIP, SPRAY TC
Graco 163733 Silver Flat Tip, 733
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 733 Silver Flat Tip has a 0.033 inch orifice and produces a 14 to 16 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 35
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 406
- Maximum Flow Rate (GPM): 1.17
- Maximum Flow Rate (L/min): 4.43
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 14
- Minimum Fan Width (mm): 356
- Orifice Diameter (in): 0.033
- Pattern Size (in): 14 to 16
- Pattern Size (mm): 355.6 to 406.4
Silver Tip
GG 163915
SILVER FLAT TIP, SPRAY TC
Graco 163915 Silver Flat Tip, 915
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 915 Silver Flat Tip has a 0.015 inch orifice and produces a 18 to 20 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 45
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 508
- Maximum Flow Rate (GPM): 0.24
- Maximum Flow Rate (L/min): 0.91
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 18
- Minimum Fan Width (mm): 457
- Orifice Diameter (in): 0.015
- Pattern Size (in): 18 to 20
- Pattern Size (mm): 457.2 to 508
Silver Flat Tip, 931
GG 163931
SILVER FLAT TIP, SPRAY TC
Graco 163931 Silver Flat Tip, 931
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 931 Silver Flat Tip has a 0.031 inch orifice and produces a 18 to 20 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 45
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 508
- Maximum Flow Rate (GPM): 1.03
- Maximum Flow Rate (L/min): 3.90
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 18
- Minimum Fan Width (mm): 457
- Orifice Diameter (in): 0.031
- Pattern Size (in): 18 to 20
- Pattern Size (mm): 457.2 to 508
Silver Flat Tip, 933
GG 163933
SILVER FLAT TIP, SPRAY TC
Graco 163933 Silver Flat Tip, 933
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 933 Silver Flat Tip has a 0.033 inch orifice and produces a 18 to 20 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 45
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 508
- Maximum Flow Rate (GPM): 1.17
- Maximum Flow Rate (L/min): 4.43
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 18
- Minimum Fan Width (mm): 457
- Orifice Diameter (in): 0.033
- Pattern Size (in): 18 to 20
- Pattern Size (mm): 457.2 to 508
Silver Tip
GG 163917
SILVER FLAT TIP, SPRAY TC
Graco 163917 Silver Flat Tip, 917
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 917 Silver Flat Tip has a 0.017 inch orifice and produces a 18 to 20 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 45
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 508
- Maximum Flow Rate (GPM): 0.31
- Maximum Flow Rate (L/min): 1.17
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 18
- Minimum Fan Width (mm): 457
- Orifice Diameter (in): 0.017
- Pattern Size (in): 18 to 20
- Pattern Size (mm): 457.2 to 508
Gauge, 0-200 psig
GG 100960
GAUGE, 200PSI, BOTTOM, GRACO
Graco 100960 Low Pressure Air Gauge, bottom mount, 0-200 psi (0-14 bar) pressure range
- Low Pressure Air Gauges
Black enamel case
Bottom mount
1/8 in NPT and 1/4 in NPT connections
- Dial Diameter (cm): 5
- Dial Diameter (in): 2
- Dial Diameter (mm): 51
- Inlet Size (cm): 0.635
- Inlet Size (in): 1/4
- Inlet Size (mm): 6.35
- Inlet Thread Gender: Male
- Inlet Thread Type: NPT
- Maximum Working Pressure (bar): 14
- Maximum Working Pressure (kPa): 1400
- Maximum Working Pressure (MPa): 1.4
- Maximum Working Pressure (psi): 200
Gauge, Press, Air
GG 101689
GAUGE, PRESS, AIR
Graco 101689 Low Pressure Air Gauge, back mount, 0-200 psi (0-14 bar) pressure range
- Low Pressure Air Gauges
- Back mount
Black enamel case
Back mount
1/8 in NPT and 1/4 in NPT connections
- Dial Diameter (cm): 5
- Dial Diameter (in): 2
- Dial Diameter (mm): 51
- Inlet Size (cm): 0.635
- Inlet Size (in): 1/4
- Inlet Size (mm): 6.35
- Inlet Thread Gender: Male
- Inlet Thread Type: NPT
- Maximum Working Pressure (bar): 14
- Maximum Working Pressure (kPa): 1400
- Maximum Working Pressure (MPa): 1.4
- Maximum Working Pressure (psi): 200
USE GG 2007096
GG 102814
GAUGE, PRESS, FLUID
Graco 102814 Stainless Steel High Pressure Fluid Gauge, 0-5000 psi (0-344 bar) pressure range
- Stainless Steel High Pressure Fluid Gauges
Corrosion Resistant
2.5 in (63 mm) diameter dial
1/4 in NPT(M) connection
Bottom mount
Shatterproof glass
Liquid filled to reduce indicator pulsation
- Dial Diameter (cm): 6
- Dial Diameter (in): 2.5
- Dial Diameter (mm): 64
- Inlet Size (cm): 0.635
- Inlet Size (in): 1/4
- Inlet Size (mm): 6.35
- Inlet Thread Gender: Male
- Inlet Thread Type: NPT
- Material: Stainless Steel
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (MPa): 34.5
- Maximum Working Pressure (psi): 5000
Ball, Bearing
GG 101968
BALL, BEARING
Graco 101968 Stainless Steel Inlet Ball- 1.25 in. Diameter
- Color: Black
3/4 HP, 550 W, Air Motor
GG 101140
MOTOR, ROTARY AIR
Graco 101140 3/4 HP (550 W) Air Motor
Replacement air motor will give new life to your existing agitators
- Easy to install
Motor, Rotary, Air
GG 101687
MOTOR, ROTARY, AIR
Graco 101687 Air Motor for Air Driven Stainless Steel Agitator
Seal, Uppermost Air
GG 103553
SEAL, SHAFT
Graco 103553 Shaft Seal for Stainless Steel Heavy-Duty Agitators (5, 10, 15 gallon size)
- Color: Black
FRP Rs Chop System, Ic, 13:1, Cmb, 25
GG 16R004
FRP RS CHOP SYSTEM, IC, 13:1, CMB, 25
Graco 16R004 13:1 Ratio Internal Mix Chop System with 25 ft (7.6 m) Hose, Cart, Mast, and Boom
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized Ratio Stability
- Lower Cost of Ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: IC
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Includes: Hose, Cart, Mast, Boom
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa):
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower Cost of Ownership
FRP Rs Chop System, Xc, 13:1, No, 25
GG 16R100
FRP RS CHOP SYSTEM, XC, 13:1, NO, 25
Graco 16R100 13:1 Ratio External Mix Chop System with 25 ft (7.6 m) Hose
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
Easy user interface with all gauges in one location
- Model: FRP
- Series: XC
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Includes: Hose,
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa): 9000
- Maximum Working Pressure (MPa): 9
- Maximum Working Pressure (psi): 1300
- Overall Depth (cm): 81.3
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
Diaphragm, Regulator
GG 171868
DIAPHRAGM, REGULATOR
Graco 171868 Diaphragm for Stainless Steel, Waterbase Compatible Pressure Regulators, PTFE with Nylon Fabric/Buna-N Base
FRP Rs Chop System, Xc, 13:1, Cmb, 35
GG 16R091
FRP RS CHOP SYSTEM, XC, 13:1, CMB, 35
Graco 16R091 13:1 Ratio External Mix Chop System with 35 ft (10.7 m) Hose, Cart, Mast, and Boom
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XC
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 35
- Hose Length (m): 10.7
- Includes: Hose, Cart, Mast, Boom
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 5680
- Maximum Flow Rate (GPM): 1.5
- Maximum Flow Rate (L/min): 5.68
- Maximum Working Pressure (bar): 90
- Maximum Working Pressure (kPa):
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
Gear Box Lubricant Kit, Oil
GG 16W645
GEAR BOX LUBRICANT KIT,OIL
Graco 16W645 ISO 220 Silicone-Free Synthetic Gear Oil, 1 quart (0.95 liter)
FRP Rs Gel System, Xg, 17:1, Cart, 35
GG 16R149
FRP RS GEL SYSTEM, XG, 17:1, CART, 35
Graco 16R149 17:1 Ratio External Mix Gel System with 35 ft (10.7 m) Hose and Cart
To keep material costs low, the system has been designed so that it doesn't need a surge bottle and a low amount of solvent and resin is needed to prime the pump. It also features a dual trigger function, allowing operators to change from wet-out to chop without removing the chopper. By purely using Graco components, that are proven in multiple industries, you will have a solution that is technologically advanced, durable and long lasting.
Application: Fiberglass chopper System for Open Molding Handle fiberglass and catalyzed resin with ease with Graco spray-up laminating components and systems. The FRP system can be used to apply chopped fiberglass on your open mold applications. It offers precise on-ratio dispensing with easy transition from wet-out to chop.- Optimized ratio stability
- Lower cost of ownership
- Optional DataTrak Control
- Gravity Fed Catalyst System
- New Linkage and Catalyst Pump
- Balanced Graco NXT Air Motor
- Control Panel
- Stable, Lightweight Cart
Easy to maneuver
Strong, durable casters
- Model: FRP
- Series: XG
- Air Inlet Size (in): 1/4
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Component A Inlet Size (in): 3/8
- Component B Inlet Size (in): 1-5/16
- Component B Thread Gender: Male
- Component B Thread Type: UN-2A
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Hose Length (ft): 35
- Hose Length (m): 10.7
- Includes: Hose, Cart
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 4160
- Maximum Flow Rate (GPM): 1.1
- Maximum Flow Rate (L/min): 4.16
- Maximum Working Pressure (bar): 119
- Maximum Working Pressure (kPa): 11900
- Maximu
Easy user interface with all gauges in one location
- Stable, Lightweight Cart
Provides same output pressure on upstroke and downstroke, resulting in more consistent spray pattern
Shortened stroke on pump for better spray pattern
- Control Panel
Truly engineered linkage for superior ratio control
Allows for infinite adjustment of catalyst percentage - no tools required
Ensures proper catalyst percentage and optimum results
Variance of 1% or less
- Balanced Graco NXT Air Motor
Keeps the catalyst pump primed for consistent delivery
- New Linkage and Catalyst Pump
Monitors resin usage - Helps ensure product quality by tracking resin usage per piece, shift or day
Tracks cycles for preventive maintenance schedule
Displays real time flow rate - eliminates material waste due to worn spray tips
- Gravity Fed Catalyst System
Easy maintenance - fewer repair parts
Long lasting seals mean less downtime
Pumps last longer between planned maintenances
No surge bottle necessary, less parts, solvent and resin needed to prime the pump
- Optional DataTrak Control
Adjustable ratio catalyst pump - no tools are required for a quick and easy ratio change.
Precision engineered linkage offers you superior ratio control and consistent cure
- Lower cost of ownership
Payment options
