GRACO INC. S10595
Silver Tip
GG 163317
SILVER FLAT TIP, SPRAY TC
Graco 163317 Silver Flat Tip, 317
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 317 Silver Flat Tip has a 0.017 inch orifice and produces a 6 to 8 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 15
- Maximum Fan Width (in): 6
- Maximum Fan Width (mm): 203
- Maximum Flow Rate (GPM): 0.31
- Maximum Flow Rate (L/min): 1.17
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 6
- Minimum Fan Width (mm): 152
- Orifice Diameter (in): 0.017
- Pattern Size (in): 6 to 8
- Pattern Size (mm): 152.4 to 203.2
Silver Tip
GG 163517
SILVER FLAT TIP, SPRAY TC
Graco 163517 Silver Flat Tip, 517
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 517 Silver Flat Tip has a 0.017 inch orifice and produces a 10 to 12 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 25
- Maximum Fan Width (in): 10
- Maximum Fan Width (mm): 305
- Maximum Flow Rate (GPM): 0.31
- Maximum Flow Rate (L/min): 1.17
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 10
- Minimum Fan Width (mm): 254
- Orifice Diameter (in): 0.017
- Pattern Size (in): 10 to 12
- Pattern Size (mm): 254 to 304.8
Silver Tip, .015 x 6
GG 163315
SILVER FLAT TIP, SPRAY TC
Graco 163315 Silver Flat Tip, 315
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 315 Silver Flat Tip has a 0.015 inch orifice and produces a 6 to 8 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 15
- Maximum Fan Width (in): 6
- Maximum Fan Width (mm): 203
- Maximum Flow Rate (GPM): 0.24
- Maximum Flow Rate (L/min): 0.91
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 6
- Minimum Fan Width (mm): 152
- Orifice Diameter (in): 0.015
- Pattern Size (in): 6 to 8
- Pattern Size (mm): 152.4 to 203.2
Motor, Air
GG 162425
MOTOR, AIR
Graco 162425 Stainless Steel, Heavy-Duty Agitator Air Motor, compatible with 5,10 &15 gallon drum size
Cylinder, Motor, Air, Gray
GG 162629
CYLINDER, MOTOR, AIR, GRAY
Graco 162629 Air Motor Cylinder
FF Flat Tip, Spray Tc
GG 163610
FF FLAT TIP, SPRAY TC
Graco 163610 Fine Finish Flat Tip, 610
The 610 Fine Finish Flat Tip produces a 12 to 14 inch fan pattern and a 0.010 inch orifice.
- Model: Fine Finish
- Series: Flat Tip
- Compatible Material: Lacquer, Varnish, Urethane, Fine Finish Material
- For Use With: Silver Plus Airless Spray Gun
- Maximum Fan Width (cm): 35.6
- Maximum Fan Width (in): 12
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 0.11
- Maximum Flow Rate (L/min): 0.42
- Maximum Working Pressure (bar): 207
- Maximum Working Pressure (kPa): 20700
- Maximum Working Pressure (psi): 3000
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.010
- Pattern Size (in): 12 to 14
- Pattern Size (mm): 304.8 to 355.6
Silver Tip
GG 163615
SILVER FLAT TIP, SPRAY TC
Graco 163615 Silver Flat Tip, 615
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 615 Silver Flat Tip has a 0.015 inch orifice and produces a 12 to 14 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 30
- Maximum Fan Width (in): 12
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 0.24
- Maximum Flow Rate (L/min): 0.91
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.015
- Pattern Size (in): 12 to 14
- Pattern Size (mm): 304.8 to 355.6
Silver Flat Tip, 719
GG 163719
SILVER FLAT TIP, SPRAY TC
Graco 163719 Silver Flat Tip, 719
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 719 Silver Flat Tip has a 0.019 inch orifice and produces a 14 to 16 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 35
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 406
- Maximum Flow Rate (GPM): 0.39
- Maximum Flow Rate (L/min): 1.48
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 14
- Minimum Fan Width (mm): 356
- Orifice Diameter (in): 0.019
- Pattern Size (in): 14 to 16
- Pattern Size (mm): 355.6 to 406.4
Silver Flat Tip, 723, Ea, Sold in Multiplies of 6
GG 163723
SILVER FLAT TIP, SPRAY TC
Graco 163723 Silver Flat Tip, 723
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 723 Silver Flat Tip has a 0.023 inch orifice and produces a 14 to 16 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 35
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 406
- Maximum Flow Rate (GPM): 0.57
- Maximum Flow Rate (L/min): 2.16
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 14
- Minimum Fan Width (mm): 356
- Orifice Diameter (in): 0.023
- Pattern Size (in): 14 to 16
- Pattern Size (mm): 355.6 to 406.4
Silver Flat Tip, 716
GG 163716
FF FLAT TIP, SPRAY TC
Graco 163716 Fine Finish Flat Tip, 716
The 716 Fine Finish Flat Tip produces a 14 to 16 inch fan pattern and a 0.016 inch orifice.
- Model: Fine Finish
- Series: Flat Tip
- Compatible Material: Lacquer, Varnish, Urethane, Fine Finish Material
- For Use With: Silver Plus Airless Spray Gun
- Maximum Fan Width (cm): 40.6
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 406
- Maximum Flow Rate (GPM): 0.27
- Maximum Flow Rate (L/min): 1.02
- Maximum Working Pressure (bar): 207
- Maximum Working Pressure (kPa): 20700
- Maximum Working Pressure (psi): 3000
- Minimum Fan Width (in): 14
- Minimum Fan Width (mm): 356
- Orifice Diameter (in): 0.016
- Pattern Size (in): 14 to 16
- Pattern Size (mm): 355.6 to 406.4
Silver Flat Tip, 715
GG 163715
SILVER FLAT TIP, SPRAY TC
Graco 163715 Silver Flat Tip, 715
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 715 Silver Flat Tip has a 0.015 inch orifice and produces a 14 to 16 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 35
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 406
- Maximum Flow Rate (GPM): 0.24
- Maximum Flow Rate (L/min): 0.91
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 14
- Minimum Fan Width (mm): 356
- Orifice Diameter (in): 0.015
- Pattern Size (in): 14 to 16
- Pattern Size (mm): 355.6 to 406.4
Silver Tip
GG 163617
SILVER FLAT TIP, SPRAY TC
Graco 163617 Silver Flat Tip, 617
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 617 Silver Flat Tip has a 0.017 inch orifice and produces a 12 to 14 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 30
- Maximum Fan Width (in): 12
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 0.31
- Maximum Flow Rate (L/min): 1.17
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.017
- Pattern Size (in): 12 to 14
- Pattern Size (mm): 304.8 to 355.6
FF Flat Tip, Spray Tc
GG 163618
FF FLAT TIP, SPRAY TC
Graco 163618 Fine Finish Flat Tip, 618
The 618 Fine Finish Flat Tip produces a 12 to 14 inch fan pattern and a 0.018 inch orifice.
- Model: Fine Finish
- Series: Flat Tip
- Compatible Material: Lacquer, Varnish, Urethane, Fine Finish Material
- For Use With: Silver Plus Airless Spray Gun
- Maximum Fan Width (cm): 35.6
- Maximum Fan Width (in): 12
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 0.35
- Maximum Flow Rate (L/min): 1.32
- Maximum Working Pressure (bar): 207
- Maximum Working Pressure (kPa): 20700
- Maximum Working Pressure (psi): 3000
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.018
- Pattern Size (in): 12 to 14
- Pattern Size (mm): 304.8 to 355.6
Silver Tip
GG 163521
SILVER FLAT TIP, SPRAY TC
Graco 163521 Silver Flat Tip, 521
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 521 Silver Flat Tip has a 0.021 inch orifice and produces a 10 to 12 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 25
- Maximum Fan Width (in): 10
- Maximum Fan Width (mm): 305
- Maximum Flow Rate (GPM): 0.47
- Maximum Flow Rate (L/min): 1.78
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 10
- Minimum Fan Width (mm): 254
- Orifice Diameter (in): 0.021
- Pattern Size (in): 10 to 12
- Pattern Size (mm): 254 to 304.8
Silver Flat Tip, 712
GG 163712
FF FLAT TIP, SPRAY TC
Graco 163712 Fine Finish Flat Tip, 712
The 712 Fine Finish Flat Tip produces a 14 to 16 inch fan pattern and a 0.012 inch orifice.
- Model: Fine Finish
- Series: Flat Tip
- Compatible Material: Lacquer, Varnish, Urethane, Fine Finish Material
- For Use With: Silver Plus Airless Spray Gun
- Maximum Fan Width (cm): 40.6
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 406
- Maximum Flow Rate (GPM): 0.15
- Maximum Flow Rate (L/min): 0.57
- Maximum Working Pressure (bar): 207
- Maximum Working Pressure (kPa): 20700
- Maximum Working Pressure (psi): 3000
- Minimum Fan Width (in): 14
- Minimum Fan Width (mm): 356
- Orifice Diameter (in): 0.012
- Pattern Size (in): 14 to 16
- Pattern Size (mm): 355.6 to 406.4
Silver Tip
GG 163621
SILVER FLAT TIP, SPRAY TC
Graco 163621 Silver Flat Tip, 621
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 621 Silver Flat Tip has a 0.021 inch orifice and produces a 12 to 14 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 30
- Maximum Fan Width (in): 12
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 0.47
- Maximum Flow Rate (L/min): 1.78
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.021
- Pattern Size (in): 12 to 14
- Pattern Size (mm): 304.8 to 355.6
Silver Tip
GG 163619
SILVER FLAT TIP, SPRAY TC
Graco 163619 Silver Flat Tip, 619
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 619 Silver Flat Tip has a 0.019 inch orifice and produces a 12 to 14 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 30
- Maximum Fan Width (in): 12
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 0.39
- Maximum Flow Rate (L/min): 1.48
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.019
- Pattern Size (in): 12 to 14
- Pattern Size (mm): 304.8 to 355.6
FF Flat Tip, Spray Tc
GG 163626
FF FLAT TIP, SPRAY TC
Graco 163626 Fine Finish Flat Tip, 626
The 626 Fine Finish Flat Tip produces a 12 to 14 inch fan pattern and a 0.026 inch orifice.
- Model: Fine Finish
- Series: Flat Tip
- Compatible Material: Lacquer, Varnish, Urethane, Fine Finish Material
- For Use With: Silver Plus Airless Spray Gun
- Maximum Fan Width (cm): 35.6
- Maximum Fan Width (in): 12
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 0.73
- Maximum Flow Rate (L/min): 2.76
- Maximum Working Pressure (bar): 207
- Maximum Working Pressure (kPa): 20700
- Maximum Working Pressure (psi): 3000
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.026
- Pattern Size (in): 12 to 14
- Pattern Size (mm): 304.8 to 355.6
Silver Flat Tip, 714
GG 163714
FF FLAT TIP, SPRAY TC
Graco 163714 Fine Finish Flat Tip, 714
The 714 Fine Finish Flat Tip produces a 14 to 16 inch fan pattern and a 0.014 inch orifice.
- Model: Fine Finish
- Series: Flat Tip
- Compatible Material: Lacquer, Varnish, Urethane, Fine Finish Material
- For Use With: Silver Plus Airless Spray Gun
- Maximum Fan Width (cm): 40.6
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 406
- Maximum Flow Rate (GPM): 0.21
- Maximum Flow Rate (L/min): 0.79
- Maximum Working Pressure (bar): 207
- Maximum Working Pressure (kPa): 20700
- Maximum Working Pressure (psi): 3000
- Minimum Fan Width (in): 14
- Minimum Fan Width (mm): 356
- Orifice Diameter (in): 0.014
- Pattern Size (in): 14 to 16
- Pattern Size (mm): 355.6 to 406.4
Silver Flat Tip, 923
GG 163923
SILVER FLAT TIP, SPRAY TC
Graco 163923 Silver Flat Tip, 923
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 923 Silver Flat Tip has a 0.023 inch orifice and produces a 18 to 20 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 45
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 508
- Maximum Flow Rate (GPM): 0.57
- Maximum Flow Rate (L/min): 2.16
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 18
- Minimum Fan Width (mm): 457
- Orifice Diameter (in): 0.023
- Pattern Size (in): 18 to 20
- Pattern Size (mm): 457.2 to 508
Silver Flat Tip, 925
GG 163925
SILVER FLAT TIP, SPRAY TC
Graco 163925 Silver Flat Tip, 925
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 925 Silver Flat Tip has a 0.025 inch orifice and produces a 18 to 20 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 45
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 508
- Maximum Flow Rate (GPM): 0.67
- Maximum Flow Rate (L/min): 2.54
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 18
- Minimum Fan Width (mm): 457
- Orifice Diameter (in): 0.025
- Pattern Size (in): 18 to 20
- Pattern Size (mm): 457.2 to 508
Silver Flat Tip, 821
GG 163821
SILVER FLAT TIP, SPRAY TC
Graco 163821 Silver Flat Tip, 821
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 821 Silver Flat Tip has a 0.021 inch orifice and produces a 16 to 18 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 40
- Maximum Fan Width (in): 16
- Maximum Fan Width (mm): 457
- Maximum Flow Rate (GPM): 0.47
- Maximum Flow Rate (L/min): 1.78
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 16
- Minimum Fan Width (mm): 406
- Orifice Diameter (in): 0.021
- Pattern Size (in): 16 to 18
- Pattern Size (mm): 406.4 to 457.2
Silver Tip
GG 163819
SILVER FLAT TIP, SPRAY TC
Graco 163819 Silver Flat Tip, 819
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 819 Silver Flat Tip has a 0.019 inch orifice and produces a 16 to 18 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 40
- Maximum Fan Width (in): 16
- Maximum Fan Width (mm): 457
- Maximum Flow Rate (GPM): 0.39
- Maximum Flow Rate (L/min): 1.48
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 16
- Minimum Fan Width (mm): 406
- Orifice Diameter (in): 0.019
- Pattern Size (in): 16 to 18
- Pattern Size (mm): 406.4 to 457.2
Silver Flat Tip, 815
GG 163815
SILVER FLAT TIP, SPRAY TC
Graco 163815 Silver Flat Tip, 815
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 815 Silver Flat Tip has a 0.015 inch orifice and produces a 16 to 18 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 40
- Maximum Fan Width (in): 16
- Maximum Fan Width (mm): 457
- Maximum Flow Rate (GPM): 0.24
- Maximum Flow Rate (L/min): 0.91
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 16
- Minimum Fan Width (mm): 406
- Orifice Diameter (in): 0.015
- Pattern Size (in): 16 to 18
- Pattern Size (mm): 406.4 to 457.2
Silver Tip
GG 163817
SILVER FLAT TIP, SPRAY TC
Graco 163817 Silver Flat Tip, 817
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 817 Silver Flat Tip has a 0.017 inch orifice and produces a 16 to 18 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 40
- Maximum Fan Width (in): 16
- Maximum Fan Width (mm): 457
- Maximum Flow Rate (GPM): 0.31
- Maximum Flow Rate (L/min): 1.17
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 16
- Minimum Fan Width (mm): 406
- Orifice Diameter (in): 0.017
- Pattern Size (in): 16 to 18
- Pattern Size (mm): 406.4 to 457.2
Silver Tip
GG 163823
SILVER FLAT TIP, SPRAY TC
Graco 163823 Silver Flat Tip, 823
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 823 Silver Flat Tip has a 0.023 inch orifice and produces a 16 to 18 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 40
- Maximum Fan Width (in): 16
- Maximum Fan Width (mm): 457
- Maximum Flow Rate (GPM): 0.57
- Maximum Flow Rate (L/min): 2.16
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 16
- Minimum Fan Width (mm): 406
- Orifice Diameter (in): 0.023
- Pattern Size (in): 16 to 18
- Pattern Size (mm): 406.4 to 457.2
Silver Flat Tip, 833
GG 163833
SILVER FLAT TIP, SPRAY TC
Graco 163833 Silver Flat Tip, 833
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 833 Silver Flat Tip has a 0.033 inch orifice and produces a 16 to 18 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 40
- Maximum Fan Width (in): 16
- Maximum Fan Width (mm): 457
- Maximum Flow Rate (GPM): 1.17
- Maximum Flow Rate (L/min): 4.43
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 16
- Minimum Fan Width (mm): 406
- Orifice Diameter (in): 0.033
- Pattern Size (in): 16 to 18
- Pattern Size (mm): 406.4 to 457.2
Silver Flat Tip, 919
GG 163919
SILVER FLAT TIP, SPRAY TC
Graco 163919 Silver Flat Tip, 919
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 919 Silver Flat Tip has a 0.019 inch orifice and produces a 18 to 20 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 45
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 508
- Maximum Flow Rate (GPM): 0.39
- Maximum Flow Rate (L/min): 1.48
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 18
- Minimum Fan Width (mm): 457
- Orifice Diameter (in): 0.019
- Pattern Size (in): 18 to 20
- Pattern Size (mm): 457.2 to 508
Silver Tip
GG 163921
SILVER FLAT TIP, SPRAY TC
Graco 163921 Silver Flat Tip, 921
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 921 Silver Flat Tip has a 0.021 inch orifice and produces a 18 to 20 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 45
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 508
- Maximum Flow Rate (GPM): 0.47
- Maximum Flow Rate (L/min): 1.78
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 18
- Minimum Fan Width (mm): 457
- Orifice Diameter (in): 0.021
- Pattern Size (in): 18 to 20
- Pattern Size (mm): 457.2 to 508
Silver Tip
GG 163625
SILVER FLAT TIP, SPRAY TC
Graco 163625 Silver Flat Tip, 625
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 625 Silver Flat Tip has a 0.025 inch orifice and produces a 12 to 14 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 30
- Maximum Fan Width (in): 12
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 0.67
- Maximum Flow Rate (L/min): 2.54
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.025
- Pattern Size (in): 12 to 14
- Pattern Size (mm): 304.8 to 355.6
Silver Tip
GG 163623
SILVER FLAT TIP, SPRAY TC
Graco 163623 Silver Flat Tip, 623
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 623 Silver Flat Tip has a 0.023 inch orifice and produces a 12 to 14 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 30
- Maximum Fan Width (in): 12
- Maximum Fan Width (mm): 356
- Maximum Flow Rate (GPM): 0.57
- Maximum Flow Rate (L/min): 2.16
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 12
- Minimum Fan Width (mm): 305
- Orifice Diameter (in): 0.023
- Pattern Size (in): 12 to 14
- Pattern Size (mm): 304.8 to 355.6
Silver Flat Tip, 839
GG 163839
SILVER FLAT TIP, SPRAY TC
Graco 163839 Silver Flat Tip, 839
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 839 Silver Flat Tip has a 0.039 inch orifice and produces a 16 to 18 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 40
- Maximum Fan Width (in): 16
- Maximum Fan Width (mm): 457
- Maximum Flow Rate (GPM): 1.63
- Maximum Flow Rate (L/min): 6.17
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 16
- Minimum Fan Width (mm): 406
- Orifice Diameter (in): 0.039
- Pattern Size (in): 16 to 18
- Pattern Size (mm): 406.4 to 457.2
Silver Flat Tip, 835
GG 163835
SILVER FLAT TIP, SPRAY TC
Graco 163835 Silver Flat Tip, 835
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 835 Silver Flat Tip has a 0.035 inch orifice and produces a 16 to 18 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 40
- Maximum Fan Width (in): 16
- Maximum Fan Width (mm): 457
- Maximum Flow Rate (GPM): 1.31
- Maximum Flow Rate (L/min): 4.96
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 16
- Minimum Fan Width (mm): 406
- Orifice Diameter (in): 0.035
- Pattern Size (in): 16 to 18
- Pattern Size (mm): 406.4 to 457.2
Silver Flat Tip, 929
GG 163929
SILVER FLAT TIP, SPRAY TC
Graco 163929 Silver Flat Tip, 929
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 929 Silver Flat Tip has a 0.029 inch orifice and produces a 18 to 20 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 45
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 508
- Maximum Flow Rate (GPM): 0.9
- Maximum Flow Rate (L/min): 3.41
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 18
- Minimum Fan Width (mm): 457
- Orifice Diameter (in): 0.029
- Pattern Size (in): 18 to 20
- Pattern Size (mm): 457.2 to 508
Silver Flat Tip, 927
GG 163927
SILVER FLAT TIP, SPRAY TC
Graco 163927 Silver Flat Tip, 927
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 927 Silver Flat Tip has a 0.027 inch orifice and produces a 18 to 20 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 45
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 508
- Maximum Flow Rate (GPM): 0.78
- Maximum Flow Rate (L/min): 2.95
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 18
- Minimum Fan Width (mm): 457
- Orifice Diameter (in): 0.027
- Pattern Size (in): 18 to 20
- Pattern Size (mm): 457.2 to 508
Silver Flat Tip, 731
GG 163731
SILVER FLAT TIP, SPRAY TC
Graco 163731 Silver Flat Tip, 731
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 731 Silver Flat Tip has a 0.031 inch orifice and produces a 14 to 16 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 35
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 406
- Maximum Flow Rate (GPM): 1.03
- Maximum Flow Rate (L/min): 3.90
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 14
- Minimum Fan Width (mm): 356
- Orifice Diameter (in): 0.031
- Pattern Size (in): 14 to 16
- Pattern Size (mm): 355.6 to 406.4
Silver Flat Tip, 721
GG 163721
SILVER FLAT TIP, SPRAY TC
Graco 163721 Silver Flat Tip, 721
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 721 Silver Flat Tip has a 0.021 inch orifice and produces a 14 to 16 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 35
- Maximum Fan Width (in): 14
- Maximum Fan Width (mm): 406
- Maximum Flow Rate (GPM): 0.47
- Maximum Flow Rate (L/min): 1.78
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 14
- Minimum Fan Width (mm): 356
- Orifice Diameter (in): 0.021
- Pattern Size (in): 14 to 16
- Pattern Size (mm): 355.6 to 406.4
Silver Flat Tip, 935
GG 163935
SILVER FLAT TIP, SPRAY TC
Graco 163935 Silver Flat Tip, 935
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 935 Silver Flat Tip has a 0.035 inch orifice and produces a 18 to 20 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 45
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 508
- Maximum Flow Rate (GPM): 1.31
- Maximum Flow Rate (L/min): 4.96
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 18
- Minimum Fan Width (mm): 457
- Orifice Diameter (in): 0.035
- Pattern Size (in): 18 to 20
- Pattern Size (mm): 457.2 to 508
Silver Flat Tip, 939
GG 163939
SILVER FLAT TIP, SPRAY TC
Graco 163939 Silver Flat Tip, 939
Silver Flat Tips are precision spray tips that are held at the highest level of cut tolerance for specialty architectural and industrial applications. The 939 Silver Flat Tip has a 0.039 inch orifice and produces a 18 to 20 inch fan.
Application: Simply install the flat tip into the backside of the guard and thread onto the gun. Remove guard and flush spray tip to clear any clog.- Model: Silver
- Series: Flat Tip
- Maximum Fan Width (cm): 45
- Maximum Fan Width (in): 18
- Maximum Fan Width (mm): 508
- Maximum Flow Rate (GPM): 1.63
- Maximum Flow Rate (L/min): 6.17
- Maximum Working Pressure (bar): 345
- Maximum Working Pressure (kPa): 34500
- Maximum Working Pressure (psi): 5000
- Minimum Fan Width (in): 18
- Minimum Fan Width (mm): 457
- Orifice Diameter (in): 0.039
- Pattern Size (in): 18 to 20
- Pattern Size (mm): 457.2 to 508
Payment options
