GRACO INC. S10595

GG U23085

GG W45BAS

KIT, PUMP, 45:1, 50CC, SS, STD

Graco W45BAS Merkur Wet Cup Pump Assembly, 45:1, 50 cc Lower, 3 UHMWPE/2 PTFE Packings with Chromex, No Data Monitoring, Low Noise, SST

GG XDH55B

XDX SERIES 20 REEL, HOSE

Graco XDH55B XDX 20, Grease, 1/2 in (13 mm) Inlet, 3/8 in X 50 ft (10 mm X 15 m) Hose, NPT, Truck/Bench Mount, Metallic Blue

Graco's heavy-duty XDX hose reel features a heavy-gauge, robust, dual-pedestal metal frame, steel spool, sealed components and innovative swivel design for high-quality performance in the most demanding applications.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (XD models) or without (XN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (107-198 meters) hose capacity for a wide variety of applications

• Model: XDX
• Series: 20

• Application: Grease

• Color: Metallic Blue

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 3/8
• Hose Inside Diameter (mm): 9.525
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Temperature ( degree C): 93
• Maximum Temperature ( degree F): 200

• Maximum Working Pressure (psi): 4800

• Minimum Temperature ( degree C): -40
• Minimum Temperature ( degree F): -40

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35
• Outlet Thread Gender: Male

• Overall Height (in): 25.2
• Overall Height (mm): 640
• Overall Length (in): 21
• Overall Length (mm): 533
• Overall Width (in): 7.5
• Overall Width (mm): 191

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Grease

GG XF5757

GG XL34D0

GG Y10BK1

E-FLO DCI PUMP, 5HP1-48B0-1000CS-K-S-0

Graco Y10BK1 E-Flo DCi 2-Ball Electric Pump, 10:1, 1000cc, 5 HP, Carbon Steel Construction, Basic Controls, Stand/Wall Mount

Dual control (DC) supply pump with intelligence (i) has a 1000 cc volume per cycle range. The 2-ball lower attains a 10:1 equivalent pressure ratio.

• An annual oil change is all that's needed to keep the 5 horse power (HP) motor running efficiently.
• Three-phase electric motor has an input voltage of 380 to 480 VAC (volts alternating current).
• DCi Link connects via ethernet to your factory's PLC (programmable logic controller), simplifying integration and truly making your pump intelligent.
• Floor/Wall stand has compact footprint with a space-saving vertical design.
• Dual control (DC) allows operation in flow mode for constant circulation or pressure mode for dynamic speed adjustments, whatever your project entails.
• ATEX, IECEx, JPNEx, CCCEx, and KCS certifications confirm safe operation worldwide.
• Wetted section has cost-effective carbon steel construction.

• Model: E-Flo
• Series: DCi 2-Ball

• Application: Supply

• Compatible Material: Solventborne, High Solids, Xirallic, CARC, Metallics

• Control Options: Basic

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 50.8
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 0.75
• Fluid Outlet Size (mm): 19.1
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: 2-Ball

• Input Voltage (V ac): 380 - 480

• Lower Type: UHMW/Leather, Carbon Steel

• Material: Carbon Steel

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 5.8
• Maximum Flow Rate (L/min): 22

• Maximum Input Amperage (A): 20

• Maximum Operating Temperature ( degree C): 40
• Maximum Operating Temperature ( degree F): 104

• Maximum Working Pressure (bar): 76
• Maximum Working Pressure (kPa): 8205
• Maximum Working Pressure (MPa): 7.6
• Maximum Working Pressure (psi): 1100

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Motor Type: BLDC

• Mount Type: Wall or Stand Mount

• Phase: 3

• Portable: Non-Portable

• Power Rating (HP): 5

• Pump Ratio: 10:1
• Pump Size (cc): 1000

GG YB2841

E-FLO DCI PUMP, 3HP1-48B0-2500USS-S-0

Graco YB2841 E-Flo DCi 4-Ball Electric Pump, 2500cc, 3 HP, SST Ultralife Lower, Tri-Clamp, Basic Controls, Stand/Wall Mount

Dual control (DC) circulation pump with intelligence (i) drives efficiency and sustainability in high volume industrial paint systems. The 4-ball lower's 2500 cc configuration powers maximum continuous flow rate.

• Modular 3 horse power (HP) motor enables the easy replacement of existing Graco pneumatic or hydraulic pump motors.
• Three-phase electric motor has an input voltage of 380 to 480 VAC (volts alternating current).
• DCi Link connects via ethernet to your factory's PLC (programmable logic controller), simplifying integration and truly making your pump intelligent.
• Floor/Wall stand has compact footprint with a space-saving vertical design.
• Dual control (DC) allows operation in flow mode for constant circulation or pressure mode for dynamic speed adjustments, whatever your project entails.
• ATEX, IECEx, JPNEx, CCCEx, and KCS certifications confirm safe operation worldwide.
• Stainless steel (SST) lower is coated with Ultralife for extensive durability.

• Model: E-Flo
• Series: Dci 4-Ball

• Application: Circulation

• Compatible Material: Solventborne, High Solids, Xirallic, Metallics, Varnish, CARC, Waterborne

• Control Options: Basic

• Cycles Per Gallon: 1.5

• Fluid Inlet Size (in): 1.5
• Fluid Inlet Size (mm): 38.1
• Fluid Inlet Thread Type: Tri-Clamp

• Fluid Outlet Size (in): 1.5
• Fluid Outlet Size (mm): 38.1
• Fluid Outlet Thread Type: Tri-Clamp

• Input Voltage (V ac): 380 - 480

• Lower Type: Sealed Ultralife

• Material: Stainless Steel

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 13.2
• Maximum Flow Rate (L/min): 50

• Maximum Input Amperage (A): 20

• Maximum Operating Temperature ( degree C): 40
• Maximum Operating Temperature ( degree F): 104

• Maximum Working Pressure (bar): 19
• Maximum Working Pressure (kPa): 1930.6
• Maximum Working Pressure (MPa): 1.9
• Maximum Working Pressure (psi): 280

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Motor Type: AC

• Mount Type: Wall or Stand Mount

• Output Per Cycle (cm cu ): 2500

• Phase: 3

• Portable: Non-Portable

• Power Rating (HP): 5

• Pump Size (cc): 2500

GG YB3341

E-FLO DCI PUMP, 5HP1-48B0-4000USS-S-0

Graco YB3341 E-Flo DCi 4-Ball Electric Pump, 4000cc, 5 HP, SST Ultralife Lower, Tri-Clamp, Basic Controls, Stand/Wall Mount

Dual control (DC) circulation pump with intelligence (i) drives efficiency and sustainability in high volume industrial paint systems. The 4-ball lower's 4000 cc configuration powers maximum continuous flow rate.

• An annual oil change is all that's needed to keep the 5 horse power (HP) motor running efficiently.
• Three-phase electric motor has an input voltage of 380 to 480 VAC (volts alternating current).
• DCi Link connects via ethernet to your factory's PLC (programmable logic controller), simplifying integration and truly making your pump intelligent.
• Floor/Wall stand has compact footprint with a space-saving vertical design.
• Dual control (DC) allows operation in flow mode for constant circulation or pressure mode for dynamic speed adjustments, whatever your project entails.
• ATEX, IECEx, JPNEx, CCCEx, and KCS certifications confirm safe operation worldwide.
• Stainless steel (SST) lower is coated with Ultralife for extensive durability.

• Model: E-Flo
• Series: Dci 4-Ball

• Application: Circulation

• Compatible Material: Solventborne, High Solids, Xirallic, Metallics, Varnish, CARC, Waterborne

• Control Options: Basic

• Cycles Per Gallon: 0.95

• Fluid Inlet Size (in): 1.5
• Fluid Inlet Size (mm): 38.1
• Fluid Inlet Thread Type: Tri-Clamp

• Fluid Outlet Size (in): 1.5
• Fluid Outlet Size (mm): 38.1
• Fluid Outlet Thread Type: Tri-Clamp

• Input Voltage (V ac): 380 - 480

• Lower Type: Sealed Ultralife

• Material: Stainless Steel

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 21.1
• Maximum Flow Rate (L/min): 80

• Maximum Input Amperage (A): 20

• Maximum Operating Temperature ( degree C): 40
• Maximum Operating Temperature ( degree F): 104

• Maximum Working Pressure (bar): 20.7
• Maximum Working Pressure (kPa): 2068.5
• Maximum Working Pressure (MPa): 2
• Maximum Working Pressure (psi): 300

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Motor Type: AC

• Mount Type: Wall or Stand Mount

• Output Per Cycle (cm cu ): 4000

• Phase: 3

• Portable: Non-Portable

• Power Rating (HP): 5

• Pump Size (cc): 4000

GG YB4441

E-FLO DCI PUMP, 5HP1-48B0-3000USS-S-0

Graco YB4441 E-Flo DCi 4-Ball Electric Pump, 3000cc, 5 HP, SST Ultralife Lower, Tri-Clamp, Basic Controls, Stand/Wall Mount

Dual control (DC) circulation pump with intelligence (i) drives efficiency and sustainability in high volume industrial paint systems. The 4-ball lower's 3000 cc configuration powers maximum continuous flow rate.

• An annual oil change is all that's needed to keep the 5 horse power (HP) motor running efficiently.
• Three-phase electric motor has an input voltage of 380 to 480 VAC (volts alternating current).
• DCi Link connects via ethernet to your factory's PLC (programmable logic controller), simplifying integration and truly making your pump intelligent.
• Floor/Wall stand has compact footprint with a space-saving vertical design.
• Dual control (DC) allows operation in flow mode for constant circulation or pressure mode for dynamic speed adjustments, whatever your project entails.
• ATEX, IECEx, JPNEx, CCCEx, and KCS certifications confirm safe operation worldwide.
• Stainless steel (SST) lower is coated with Ultralife for extensive durability.

• Model: E-Flo
• Series: Dci 4-Ball

• Application: Circulation

• Compatible Material: Solventborne, High Solids, Xirallic, Metallics, Varnish, CARC, Waterborne

• Control Options: Basic

• Cycles Per Gallon: 1.3

• Fluid Inlet Size (in): 1.5
• Fluid Inlet Size (mm): 38.1
• Fluid Inlet Thread Type: Tri-Clamp

• Fluid Outlet Size (in): 1.5
• Fluid Outlet Size (mm): 38.1
• Fluid Outlet Thread Type: Tri-Clamp

• Input Voltage (V ac): 380 - 480

• Lower Type: Sealed Ultralife

• Material: Stainless Steel

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 15.9
• Maximum Flow Rate (L/min): 60

• Maximum Input Amperage (A): 20

• Maximum Operating Temperature ( degree C): 40
• Maximum Operating Temperature ( degree F): 104

• Maximum Working Pressure (bar): 28
• Maximum Working Pressure (kPa): 2758
• Maximum Working Pressure (MPa): 2.8
• Maximum Working Pressure (psi): 400

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Motor Type: AC

• Mount Type: Wall or Stand Mount

• Output Per Cycle (cm cu ): 3000

• Phase: 3

• Portable: Non-Portable

• Power Rating (HP): 5

• Pump Size (cc): 3000

GG 24V764

GG 296621

GG 296614

GG 296622

GG 296625

GG 296627

GG 296628

GG 296640

GG 296641

GG 296652

GG 296713

GG 296745

GG 296742

GG 296768

GG 296786

GG 296794

GG 296815

GG 296895

GG 296884

GG 297251

GG 297357

GG 297911

GG 297966

GG 298011

GG 298776

GG 331210

GG 425MSN

GG 501095

GG 501511

GG 512613

GG 513308

GG 513697

GG 513817

GG 513937

GG 514768

GG 521229

GG 552180

GG 570122

GG 5901-F

GG 605286

GG 6690-16-771500R

GG 6690-16-772800R

GG 803350

GG 833232

GG 947076

GG 947077

GG 947078

GG 96A504

GG AAM719

GG AD132N

GG AD141N

GG AEF512

GG AEF514

GG AEM209

GG AEM425

GG AEM609

GG AEM815

GG AEM621

GG EC1141

E-FLO PUMP, 1HP, 750, BSC, TRI, SLD, STND

Graco EC1141 E-Flo DC 4-Ball Electric Circulation Pump, 750cc, 1 HP, Basic, ATEX/FM/IECEx, Sealed, Ultralife Rod/Cylinder, Tri-Clamp, Stand

The E-Flo DC (Dual Control) electric circulating pump has been found to be up to five times more efficient than similar sized pneumatic pumps - lowering your energy bill and saving you money

• Sealed lower has longer maintenance cycles, plus it can be used for every pumping application in your mix room, including catalyzed coatings
• Minimal pulsation at changeover provides a more consistent finish
• Electric motor eliminates icing - giving you smoother pump operation and better finished product

• Model: E-Flo
• Series: DC 4-Ball

• Application: Circulation

• Compatible Material: Solventborne, High Solids, Xirallic, Metallics, Varnish, CARC

• Fluid Inlet Size (in): 1-1/2
• Fluid Inlet Size (mm): 38.1

• Fluid Outlet Size (in): 1-1/2
• Fluid Outlet Size (mm): 38.1
• Fluid Section Type: Sealed

• Includes: Basic Control, Stand

• Input Voltage (V ac): 250

• Material: Stainless Steel

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 4
• Maximum Flow Rate (L/min): 15.14

• Maximum Input Amperage (A): 20

• Maximum Operating Temperature ( degree C): 40
• Maximum Operating Temperature ( degree F): 104

• Maximum Working Pressure (bar): 20.7
• Maximum Working Pressure (kPa): 2070
• Maximum Working Pressure (MPa): 2.1
• Maximum Working Pressure (psi): 300

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Motor Type: AC

• Portable: Non-Portable

• Power Rating (HP): 1

GG EC4441

E-FLO PUMP, 2HP, 2000, ADV, TRI, SLD, STND

Graco EC4441 E-Flo DC 4-Ball Electric Circulation Pump, 2000cc, 2 HP, Advanced, ATEX/FM/IECEx, Sealed, Ultralife Rod/Cylinder, Tri-Clamp, Stand

E-Flo DC (Dual Control) electric pumps are up to five times more efficient than pneumatic pumps, lowering energy bills and saving money. Unique 4-ball lower minimizes pulsation while increasing flow rates. Advanced control module improves performance with Intelligent Paint Kitchen (IPK) compatibility.

• Sealed lower has longer maintenance cycles, plus it can be used for every pumping application in your mix room, including catalyzed coatings
• Minimal pulsation at changeover provides a more consistent finish
• Electric motor eliminates icing - giving you smoother pump operation and better finished product

• Model: E-Flo
• Series: DC 4-Ball

• Application: Circulation

• Compatible Material: Solventborne, High Solids, Xirallic, Metallics, Varnish, CARC

• Fluid Inlet Size (in): 1-1/2
• Fluid Inlet Size (mm): 38.1

• Fluid Outlet Size (in): 1-1/2
• Fluid Outlet Size (mm): 38.1
• Fluid Section Type: Sealed

• Includes: Advanced Control Input, Stand

• Input Voltage (V ac): 250

• Material: Stainless Steel

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 10.5
• Maximum Flow Rate (L/min): 39.75

• Maximum Input Amperage (A): 20

• Maximum Operating Temperature ( degree C): 40
• Maximum Operating Temperature ( degree F): 104

• Maximum Working Pressure (bar): 15.2
• Maximum Working Pressure (kPa): 1520
• Maximum Working Pressure (MPa): 1.5
• Maximum Working Pressure (psi): 220

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Motor Type: AC

• Portable: Non-Portable

• Power Rating (HP): 2

GG EM0022

GG EM0024

GG FT0848

GG GC0480

GG GC1881

GG GC1882

GG GC1904

GG GC2237

GG GC2505

GG GC2540

GG GC2575

GG GC2576

GG GC2577

GG GC2594

GG GC2644

GG GG0331

GG L054C0

GG L072C0

GG L18AC1

GG L22AC0

GG LB100A

GG LB150A

GG M07LNL

GG 4-405-02

GG 4-419-54C

GG 4-420-PV-24.312

GG 4-443-21F

GG 4-443-51

GG 502526

GG 512152

GG 512838
