Solotech St30 Pump, Ln/Cs/Ss/A1/A1/0/
GG 19X154
GG 19X154
SOLOTECH ST30 PUMP, LN/CS/SS/A1/A1/0/
Graco 19X154 SoloTech i30 Low Speed Hypalon Peristaltic Hose Pump with CSM Hose, 316 Stainless Steel Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 2.1
- Gear Ratio: 157.43:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: CSM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 0.35
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Low Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Height (cm): 51
- Overall Height (in): 20
- Overall Height (mm): 508
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 2-12
$13,570.00
Solotech St30 Pump, Ln/Ep/Ss/A1/A1/0/
GG 19X155
GG 19X155
SOLOTECH ST30 PUMP, LN/EP/SS/A1/A1/0/
Graco 19X155 SoloTech i30 Low Speed EPDM Peristaltic Hose Pump with EPDM Hose, 316 Stainless Steel Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 2.1
- Gear Ratio: 157.43:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: EPDM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 0.35
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Low Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Height (cm): 51
- Overall Height (in): 20
- Overall Height (mm): 508
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 2-12
$13,120.00
Solotech St30 Pump, Ln/Cs/Pv/A1/A1/0/
GG 19X156
GG 19X156
SOLOTECH ST30 PUMP, LN/CS/PV/A1/A1/0/
Graco 19X156 SoloTech i30 Low Speed Hypalon Peristaltic Hose Pump with CSM Hose, PVDF Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: PVDF
- Flow Rate (GPM): 2.1
- Gear Ratio: 157.43:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: CSM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 0.35
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Low Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Height (cm): 51
- Overall Height (in): 20
- Overall Height (mm): 508
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 2-12
$13,930.00
Solotech St30 Pump, Ln/Ep/Pv/A1/A1/0/
GG 19X157
GG 19X157
SOLOTECH ST30 PUMP, LN/EP/PV/A1/A1/0/
Graco 19X157 SoloTech i30 Low Speed EPDM Peristaltic Hose Pump with EPDM Hose, PVDF Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: PVDF
- Flow Rate (GPM): 2.1
- Gear Ratio: 157.43:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: EPDM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 0.35
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Low Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Height (cm): 51
- Overall Height (in): 20
- Overall Height (mm): 508
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 2-12
$13,490.00
Solotech St30 Pump, Ln/Bn/Ss/A1/A1/0/
GG 19X160
GG 19X160
SOLOTECH ST30 PUMP, LN/BN/SS/A1/A1/0/
Graco 19X160 SoloTech i30 Low Speed Buna-N Peristaltic Hose Pump with Nitrile Hose, 316 Stainless Steel Barb
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 2.1
- Gear Ratio: 157.43:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: Nitrile
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 0.35
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Low Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Height (cm): 51
- Overall Height (in): 20
- Overall Height (mm): 508
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 2-12
$13,930.00
SOLOTECH ST30 PUMP, HC/NR/SS/A1/A1/0/
GG 19X161
GG 19X161
SOLOTECH ST30 PUMP, HC/NR/SS/A1/A1/0/
SoloTech™ i30 Natural Rubber Peristaltic Hose PumpGraco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
Single Roller Design
- Single roller design improves hose life by reducing the number of compressions, temperature and friction
- Metallic roller with bearings provides constant compression and flow
Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
$13,760.00
Solotech St30 Pump, Hc/Cs/Ss/A1/A1/0/
GG 19X162
GG 19X162
SOLOTECH ST30 PUMP, HC/CS/SS/A1/A1/0/
Graco 19X162 SoloTech i30 High Speed Hypalon Peristaltic Hose Pump with CSM Hose, PVDF Barb & IEC Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 16
- Gear Ratio: 19.13:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: CSM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 2.675
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: High Speed, IEC Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 15-91
$13,570.00
Solotech St30 Pump, Hc/Ep/Ss/A1/A1/0/
GG 19X163
GG 19X163
SOLOTECH ST30 PUMP, HC/EP/SS/A1/A1/0/
Graco 19X163 SoloTech i30 High Speed EPDM Peristaltic Hose Pump with Ethylene Propylene Diene Monomar Hose and Stainless Steel Barb
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 16
- Gear Ratio: 19.13:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: EPDM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 2.675
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: High Speed, IEC Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 15-91
$13,120.00
Solotech St30 Pump, Hc/Bn/Ss/A1/A1/0/
GG 19X164
GG 19X164
SOLOTECH ST30 PUMP, HC/BN/SS/A1/A1/0/
Graco 19X164 SoloTech i30 Buna-N Peristaltic Hose Pump
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 16
- Gear Ratio: 19.13:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: Nitrile
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 2.675
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: High Speed, IEC Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 15-91
$13,930.00
Solotech St30 Pump, Hc/Cs/Pv/A1/A1/0/
GG 19X165
GG 19X165
SOLOTECH ST30 PUMP, HC/CS/PV/A1/A1/0/
Graco 19X165 SoloTech i30 High Speed Hypalon Peristaltic Hose Pump with Chlorosulfonated Polyethylene Hose and PVDF Barb
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: PVDF
- Flow Rate (GPM): 16
- Gear Ratio: 19.13:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: CSM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 2.675
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: High Speed, IEC Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 15-91
$13,930.00
Solotech St30 Pump, Hc/Ep/Pv/A1/A1/0/
GG 19X166
GG 19X166
SOLOTECH ST30 PUMP, HC/EP/PV/A1/A1/0/
Graco 19X166 SoloTech i30 High Speed EPDM Peristaltic Hose Pump with Ethylene Propylene Diene Monomar Hose and PVDF Barb
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: PVDF
- Flow Rate (GPM): 16
- Gear Ratio: 19.13:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: EPDM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 2.675
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: High Speed, IEC Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 15-91
$13,490.00
Solotech St30 Pump, Hn/Nr/Ss/A1/A1/0/
GG 19X169
GG 19X169
SOLOTECH ST30 PUMP, HN/NR/SS/A1/A1/0/
Graco 19X169 SoloTech i30 High Speed Natural Rubber Peristaltic Hose Pump with Natural Rubber Hose, 316 Stainless Steel Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 16
- Gear Ratio: 18.24:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: Rubber
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 2.675
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: High Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 15-91
$13,120.00
Solotech St30 Pump, Hn/Ep/Ss/A1/A1/0/
GG 19X171
GG 19X171
SOLOTECH ST30 PUMP, HN/EP/SS/A1/A1/0/
Graco 19X171 SoloTech i30 High Speed EPDM Peristaltic Hose Pump with EPDM Hose, 316 Stainless Steel Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 16
- Gear Ratio: 18.24:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: EPDM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 2.675
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: High Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 15-91
$13,120.00
Solotech St30 Pump, Hn/Cs/Pv/A1/A1/0/
GG 19X172
GG 19X172
SOLOTECH ST30 PUMP, HN/CS/PV/A1/A1/0/
Graco 19X172 SoloTech i30 High Speed Hypalon Peristaltic Hose Pump with CSM Hose, PVDF Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: PVDF
- Flow Rate (GPM): 16
- Gear Ratio: 18.24:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: CSM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 2.675
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: High Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 15-91
$13,930.00
Solotech St30 Pump, Hn/Ep/Pv/A1/A1/0/
GG 19X173
GG 19X173
SOLOTECH ST30 PUMP, HN/EP/PV/A1/A1/0/
Graco 19X173 SoloTech i30 High Speed EPDM Peristaltic Hose Pump with EPDM Hose, PVDF Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: PVDF
- Flow Rate (GPM): 16
- Gear Ratio: 18.24:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: EPDM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 2.675
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: High Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 15-91
$13,490.00
Solotech St30 Pump, Hn/Bn/Ss/A1/A1/0/
GG 19X176
GG 19X176
SOLOTECH ST30 PUMP, HN/BN/SS/A1/A1/0/
Graco 19X176 SoloTech i30 High Speed Buna-N Peristaltic Hose Pump with Nitrile Hose, 316 Stainless Steel Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 16
- Gear Ratio: 18.24:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: Nitrile
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 2.675
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: High Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 15-91
$14,630.00
Solotech St30 Pump, Mc/Nr/Ss/A1/A1/0/
GG 19X177
GG 19X177
Solotech St30 Pump, Mc/Nr/Ss/A1/A1/0/ $13,120.00
Solotech St30 Pump, Mc/Cs/Ss/A1/A1/0/
GG 19X178
GG 19X178
SOLOTECH ST30 PUMP, MC/CS/SS/A1/A1/0/
Graco 19X178 SoloTech i30 Mid Speed Hypalon Peristaltic Hose Pump with CSM Hose, 316 Stainless Steel Barb & IEC Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 6.56
- Gear Ratio: 51.3:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: CSM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 1.09
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Mid Speed, IEC Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 6-37
$13,570.00
Solotech St30 Pump, Mc/Ep/Ss/A1/A1/0/
GG 19X179
GG 19X179
Solotech St30 Pump, Mc/Ep/Ss/A1/A1/0/ $13,760.00
Solotech St30 Pump, Mc/Bn/Ss/A1/A1/0/
GG 19X180
GG 19X180
SOLOTECH ST30 PUMP, MC/BN/SS/A1/A1/0/
Graco 19X180 SoloTech i30 Mid Speed Buna-N Peristaltic Hose Pump with Nitrile Hose, 316 Stainless Steel Barb & IEC Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 6.56
- Gear Ratio: 51.3:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: Nitrile
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 1.09
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Mid Speed, IEC Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 6-37
$13,930.00
Solotech St30 Pump, Mc/Cs/Pv/A1/A1/0/
GG 19X181
GG 19X181
SOLOTECH ST30 PUMP, MC/CS/PV/A1/A1/0/
Graco 19X181 SoloTech i30 Mid Speed Hypalon Peristaltic Hose Pump with CSM Hose, PVDF Barb & IEC Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: PVDF
- Flow Rate (GPM): 6.56
- Gear Ratio: 51.3:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: CSM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 1.09
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Mid Speed, IEC Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 6-37
$13,930.00
Solotech St30 Pump, Mc/Ep/Pv/A1/A1/0/
GG 19X182
GG 19X182
SOLOTECH ST30 PUMP, MC/EP/PV/A1/A1/0/
Graco 19X182 SoloTech i30 Mid Speed EPDM Peristaltic Hose Pump with EPDM Hose, PVDF Barb & IEC Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: PVDF
- Flow Rate (GPM): 6.56
- Gear Ratio: 51.3:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: EPDM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 1.09
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Mid Speed, IEC Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 6-37
$13,490.00
Solotech St30 Pump, Mn/Nr/Ss/A1/A1/0/
GG 19X185
GG 19X185
SOLOTECH ST30 PUMP, MN/NR/SS/A1/A1/0/
Graco 19X185 SoloTech i30 Mid Speed Natural Rubber Peristaltic Hose Pump with Natural Rubber Hose, 316 Stainless Steel Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 6.56
- Gear Ratio: 51.3:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: Rubber
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 1.09
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Mid Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 6-37
$13,120.00
Solotech St30 Pump, Mn/Cs/Ss/A1/A1/0/
GG 19X186
GG 19X186
SOLOTECH ST30 PUMP, MN/CS/SS/A1/A1/0/
Graco 19X186 SoloTech i30 Mid Speed Hypalon Peristaltic Hose Pump with CSM Hose, 316 Stainless Steel Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 6.56
- Gear Ratio: 51.3:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: CSM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 1.09
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Mid Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 6-37
$13,570.00
Solotech St30 Pump, Mn/Ep/Ss/A1/A1/0/
GG 19X187
GG 19X187
SOLOTECH ST30 PUMP, MN/EP/SS/A1/A1/0/
Graco 19X187 SoloTech i30 Mid Speed EPDM Peristaltic Hose Pump with EPDM Hose, 316 Stainless Steel Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 6.56
- Gear Ratio: 51.3:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: EPDM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 1.09
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Mid Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 6-37
$13,120.00
Solotech St30 Pump, Mn/Cs/Pv/A1/A1/0/
GG 19X188
GG 19X188
SOLOTECH ST30 PUMP, MN/CS/PV/A1/A1/0/
Graco 19X188 SoloTech i30 Mid Speed Hypalon Peristaltic Hose Pump with CSM Hose, PVDF Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: PVDF
- Flow Rate (GPM): 6.56
- Gear Ratio: 51.3:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: CSM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 1.09
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Mid Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 6-37
$13,930.00
Solotech St30 Pump, Mn/Ep/Pv/A1/A1/0/
GG 19X189
GG 19X189
SOLOTECH ST30 PUMP, MN/EP/PV/A1/A1/0/
Graco 19X189 SoloTech i30 Mid Speed EPDM Peristaltic Hose Pump with EPDM Hose, PVDF Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: PVDF
- Flow Rate (GPM): 6.56
- Gear Ratio: 51.3:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: EPDM
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 1.09
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Mid Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 6-37
$13,490.00
Solotech St30 Pump, Mn/Bn/Ss/A1/A1/0/
GG 19X192
GG 19X192
SOLOTECH ST30 PUMP, MN/BN/SS/A1/A1/0/
Graco 19X192 SoloTech i30 Mid Speed Buna-N Peristaltic Hose Pump with Nitrile Hose, 316 Stainless Steel Barb & NEMA Connection
Graco’s SoloTech 30 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.
- Pump Construction
- Cast aluminum housing reduces pump weight
- Improved mounting flexibility with adjustable feet
- Electric Motor
- Choose between AC and Brushless DC models
- Multiple gearbox offerings to meet your exact flow rate needs
- Hazardous location motors available
- Brushless DC Motor
- Batch dispense mode
- Wider turndown ratio allows for larger flow range
- Maintenance reminders
- Removable Cover
- Aluminum covers with larger sight window makes it easy to access and see internal parts
- Optional leak detector kit mounts on cover
- Hose Barb Assembly
- Easy to install or remove – no special tools needed
- Available with PVDF and SST barbs options
- Floating flange for easy installation
- More flow per revolution than conventional designs
- Inexpensive to maintain - no valves, seals or glands
- Pumps are reversible and can be used to empty lines or clear blockages
- Extended hose life - only one hose compression per revolution
- Model: SoloTech
- Series: i30
- Application: Industrial
- Barb Material: Stainless Steel
- Flow Rate (GPM): 6.56
- Gear Ratio: 51.3:1
- Hose Diameter (cm): 3
- Hose Diameter (in): 1.2
- Hose Diameter (mm): 30
- Hose Material: Nitrile
- Housing Material: Powder Coated Aluminum
- Inlet Size (cm): 3.2
- Inlet Size (in): 1-1/4
- Inlet Size (mm): 32
- Inlet Thread Type: Flange
- Maximum Flow Rate (GPM): 15.8
- Maximum Flow Rate (L/min): 59.8
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Fluid Pressure (bar): 9
- Maximum Fluid Pressure (kPa): 900
- Maximum Fluid Pressure (psi): 125
- Maximum Storage Temperature (°C): 40
- Maximum Storage Temperature (°F): 104
- Minimum Flow Rate (GPM): 1.09
- Minimum Storage Temperature (°C): -10
- Minimum Storage Temperature (°F): 14
- Motor Type: Mid Speed, NEMA Gearbox Only
- Outlet Size (cm): 12.5
- Outlet Size (in): 4.92
- Outlet Size (mm): 125
- Overall Width (cm): 59
- Overall Width (in): 23.3
- Overall Width (mm): 592
- Pump Speed (RPM): 6-37
$13,930.00
Solotech St10 Pump, I10-0-Cs-Hs-A1-A1-0
GG 19Y001
GG 19Y001
Solotech St10 Pump, I10-0-Cs-Hs-A1-A1-0 $6,790.00
Solotech St10 Pump, I10-0-Cs-Pv-A1-A1-0
GG 19Y002
GG 19Y002
Solotech St10 Pump, I10-0-Cs-Pv-A1-A1-0 $5,850.00
Solotech St10 Pump, I10-0-Cs-Ss-A1-A1-0
GG 19Y003
GG 19Y003
Solotech St10 Pump, I10-0-Cs-Ss-A1-A1-0 $5,640.00
Solotech St10 Pump, I10-0-Ep-Hs-A1-A1-0
GG 19Y004
GG 19Y004
Solotech St10 Pump, I10-0-Ep-Hs-A1-A1-0 $6,650.00
Solotech St10 Pump, I10-0-Ep-Pv-A1-A1-0
GG 19Y005
GG 19Y005
Solotech St10 Pump, I10-0-Ep-Pv-A1-A1-0 $5,710.00
Solotech St10 Pump, I10-0-Ep-Ss-A1-A1-0
GG 19Y006
GG 19Y006
Solotech St10 Pump, I10-0-Ep-Ss-A1-A1-0 $5,770.00
Solotech St10 Pump, I10-0-Nr-Pv-A1-A1-0
GG 19Y007
GG 19Y007
Solotech St10 Pump, I10-0-Nr-Pv-A1-A1-0 $5,580.00
Solotech St10 Pump, I10-0-Nr-Ss-A1-A1-0
GG 19Y008
GG 19Y008
Solotech St10 Pump, I10-0-Nr-Ss-A1-A1-0 $5,480.00
Solotech St23 Pump, I23-0-Bn-Ss-A1-A1-0
GG 19Y009
GG 19Y009
Solotech St23 Pump, I23-0-Bn-Ss-A1-A1-0 $7,240.00
Solotech St23 Pump, I23-0-Cs-Hs-A1-A1-0
GG 19Y010
GG 19Y010
Solotech St23 Pump, I23-0-Cs-Hs-A1-A1-0 $9,130.00
Solotech St23 Pump, I23-0-Cs-Pv-A1-A1-0
GG 19Y011
GG 19Y011
Solotech St23 Pump, I23-0-Cs-Pv-A1-A1-0 $7,730.00
Solotech St23 Pump, I23-0-Cs-Ss-A1-A1-0
GG 19Y012
GG 19Y012
Solotech St23 Pump, I23-0-Cs-Ss-A1-A1-0 $7,460.00
Solotech St23 Pump, I23-0-Ep-Hs-A1-A1-0
GG 19Y013
GG 19Y013
Solotech St23 Pump, I23-0-Ep-Hs-A1-A1-0 $8,860.00
Solotech St23 Pump, I23-0-Ep-Pv-A1-A1-0
GG 19Y014
GG 19Y014
Solotech St23 Pump, I23-0-Ep-Pv-A1-A1-0 $7,490.00
Solotech St23 Pump, I23-0-Ep-Ss-A1-A1-0
GG 19Y015
GG 19Y015
Solotech St23 Pump, I23-0-Ep-Ss-A1-A1-0 $7,250.00
Solotech St23 Pump, I23-0-Nr-Pv-A1-A1-0
GG 19Y016
GG 19Y016
Solotech St23 Pump, I23-0-Nr-Pv-A1-A1-0 $7,320.00
Solotech St23 Pump, I23-0-Nr-Ss-A1-A1-0
GG 19Y017
GG 19Y017
Solotech St23 Pump, I23-0-Nr-Ss-A1-A1-0 $7,240.00
Solotech St26 Pump, I26-0-Bn-Ss-A1-A1-0
GG 19Y018
GG 19Y018
Solotech St26 Pump, I26-0-Bn-Ss-A1-A1-0 $10,420.00
Solotech St26 Pump, I26-0-Cs-Hs-A1-A1-0
GG 19Y019
GG 19Y019
Solotech St26 Pump, I26-0-Cs-Hs-A1-A1-0 $12,630.00
Solotech St26 Pump, I26-0-Cs-Pv-A1-A1-0
GG 19Y020
GG 19Y020
Solotech St26 Pump, I26-0-Cs-Pv-A1-A1-0 $11,100.00
Solotech St26 Pump, I26-0-Cs-Ss-A1-A1-0
GG 19Y021
GG 19Y021
Solotech St26 Pump, I26-0-Cs-Ss-A1-A1-0 $10,820.00
Solotech St26 Pump, I26-0-Ep-Hs-A1-A1-0
GG 19Y022
GG 19Y022
Solotech St26 Pump, I26-0-Ep-Hs-A1-A1-0 $12,290.00
Solotech St26 Pump, I26-0-Ep-Pv-A1-A1-0
GG 19Y023
GG 19Y023
Solotech St26 Pump, I26-0-Ep-Pv-A1-A1-0 $10,770.00
Solotech St26 Pump, I26-0-Ep-Ss-A1-A1-0
GG 19Y024
GG 19Y024
Solotech St26 Pump, I26-0-Ep-Ss-A1-A1-0 $10,460.00
Solotech St26 Pump, I26-0-Nr-Pv-A1-A1-0
GG 19Y025
GG 19Y025
Solotech St26 Pump, I26-0-Nr-Pv-A1-A1-0 $10,530.00
Solotech St26 Pump, I26-0-Nr-Ss-A1-A1-0
GG 19Y026
GG 19Y026
Solotech St26 Pump, I26-0-Nr-Ss-A1-A1-0 $10,420.00
Solotech St30 Pump, 0/Bn/Ss/A1/A1/0/
GG 19Y027
GG 19Y027
Solotech St30 Pump, 0/Bn/Ss/A1/A1/0/ $12,900.00
Solotech St30 Pump, 0/Cs/Pv/A1/A1/0/
GG 19Y029
GG 19Y029
Solotech St30 Pump, 0/Cs/Pv/A1/A1/0/ $13,690.00
Solotech St30 Pump, 0/Cs/Ss/A1/A1/0/
GG 19Y030
GG 19Y030
Solotech St30 Pump, 0/Cs/Ss/A1/A1/0/ $13,330.00
Solotech St30 Pump, 0/Ep/Pv/A1/A1/0/
GG 19Y032
GG 19Y032
Solotech St30 Pump, 0/Ep/Pv/A1/A1/0/ $13,240.00
Solotech St30 Pump, 0/Ep/Ss/A1/A1/0/
GG 19Y033
GG 19Y033
Solotech St30 Pump, 0/Ep/Ss/A1/A1/0/ $13,580.00
Solotech St30 Pump, 0/Nr/Pv/A1/A1/0/
GG 19Y034
GG 19Y034
Solotech St30 Pump, 0/Nr/Pv/A1/A1/0/ $12,970.00
Solotech St30 Pump, 0/Nr/Ss/A1/A1/0/
GG 19Y035
GG 19Y035
Solotech St30 Pump, 0/Nr/Ss/A1/A1/0/ $13,550.00
KIT, REPLACEMENT, PUMP, 650
GG 19Y298
GG 19Y298
KIT, REPLACEMENT, PUMP, 650
Endurance Chromex Piston Pump Genuine Graco Endurance Pumps lead the industry in durability and ease of installation. Keep a spare on hand to minimize downtime in the field. Replacement pump for Ultra Max II 650 PC Pro. Lasts 2X longer than the next leading brand Long Life V-Max Blue Packings, Chromex rod and hardened stainless steel cylinder Faster cleaning with the QuikAccess intake valve $481.00
CONTRACTOR PC COMPACT GUN, LP, PKGD
GG 19Y350
GG 19Y350
CONTRACTOR PC COMPACT GUN, LP, PKGD
Contractor PC Compact Airless Spray Gun with RAC X LP 517 SwitchTip The Contractor PC Compact airless spray gun provides all-day comfort and control, fast on-the-job gun rebuild capability and industry-proven Graco durability. Spray longer with 25% lighter weight and 25% smaller size than the Contractor gun with a 50% lighter trigger pull force. Compact designs delivers maximum flexibility for every application. The RAC X LP 517 SwitchTip provides the industry’s best finish at the lowest airless spray pressure for reduced overspray and longer pump life. Finish Jobs Faster with Less Fatigue- Delivers the most comfortable and lightest-weight spray experience ever
- Lightest trigger pull force at all spray pressures
- Lightest trigger hold force at all spray pressures
- 1-part, on-the-job gun rebuild
- Needle and all wear parts in one simple part
- Simply replace cartridge — it's like getting a brand new gun
$575.00
KIT, FILTER, PC COMPACT, 60
GG 19Y355
GG 19Y355
KIT, FILTER, PC COMPACT, 60
Contractor PC Compact Gun Filter, 60 Mesh The Gun Filter helps reduce tip plugging and provides a better quality finish by eliminating unwanted particles from the spray pattern. Use 60 mesh for materials such as primer and latex paint. $12.60
KIT, FILTER, PC COMPACT, 100
GG 19Y356
GG 19Y356
KIT, FILTER, PC COMPACT, 100
Contractor PC Compact Gun Filter, 100 Mesh The Gun Filter helps reduce tip plugging and provides a better quality finish by eliminating unwanted particles from the spray pattern. Use 100 mesh for thinner materials such as stain and lacquer. $12.60
CONTRACTOR PC COMPACT GUN, FF, PKGD
GG 19Y443
GG 19Y443
CONTRACTOR PC COMPACT GUN, FF, PKGD
Contractor PC Compact Airless Spray Gun with RAC X FFLP 210 SwitchTip The Contractor PC Compact airless spray gun provides all-day comfort and control, fast on-the-job gun rebuild capability and industry-proven Graco durability. Spray longer with 25% lighter weight and 25% smaller size than the Contractor gun with a 50% lighter trigger pull force. Compact design delivers maximum flexibility for every application. The RAC X FFLP 210 SwitchTip provides the industry’s best fine finish at the lowest airless spray pressure for reduced overspray and longer pump life. Finish Jobs Faster with Less Fatigue- Delivers the most comfortable and lightest-weight spray experience ever
- Lightest trigger pull force at all spray pressures
- Lightest trigger hold force at all spray pressures
- 1-part, on-the-job gun rebuild
- Needle and all wear parts in one simple part
- Simply replace cartridge — it's like getting a brand new gun
$575.00
CONTRACTOR PC COMPACT GUN, /WHIP, LTX
GG 19Y444
GG 19Y444
CONTRACTOR PC COMPACT GUN, /WHIP, LTX
Contractor PC Compact Gun, 1/8 in x 4.5 ft Whip Hose, RAC X LTX 517 SwitchTip Bundling the Contractor PC Compact gun with the 1/8 in whip hose to deliver unmatched flexibility, comfort and control. $616.00
CONTRACTOR PC COMPACT GUN, /WHIP, LP
GG 19Y445
GG 19Y445
CONTRACTOR PC COMPACT GUN, /WHIP, LP
Contractor PC Compact Gun, 1/8 in x 4.5 ft Whip Hose, RAC X LP 517 SwitchTip Bundling the Contractor PC Compact gun with the 1/8 in whip hose to deliver unmatched flexibility, comfort and control. $616.00
CONTRACTOR PC COMPACT GUN, /WHIP, FF
GG 19Y446
GG 19Y446
CONTRACTOR PC COMPACT GUN, /WHIP, FF
Contractor PC Compact Gun, 1/8 in x 4.5 ft Whip Hose, RAC X FFLP 210 SwitchTip Bundling the Contractor PC Compact gun with the 1/8 in whip hose to deliver unmatched flexibility, comfort and control. $616.00
Contractor Pc Compact Gun, /Whip, Ltx
GG 19Y447
GG 19Y447
Contractor Pc Compact Gun, /Whip, Ltx $657.00
KIT, CONTR PC COMPACT GUN/HOSE
GG 19Y475
GG 19Y475
KIT, CONTR PC COMPACT GUN/HOSE
Contractor PC Compact Gun, 1/4 in x 50 ft BlueMax II Airless Hose, 1/8 in x 4.5 ft Whip Hose, RAC X LTX 517 SwitchTip Bundling the Contractor PC Compact gun with 50 ft of 1/4 in airless hose and the 1/8 in whip hose to deliver unmatched flexibility, comfort and control. $697.00
KIT, CONTR PC COMPACT GUN/HOSE
GG 19Y489
GG 19Y489
KIT, CONTR PC COMPACT GUN/HOSE
Contractor PC Compact Gun, 1/4 in x 50 ft BlueMax II Airless Hose, 1/8 in x 4.5 ft Whip Hose, RAC X LP 517 SwitchTip Bundling the Contractor PC Compact gun with 50 ft of 1/4 in airless hose and the 1/8 in whip hose to deliver unmatched flexibility, comfort and control. $711.00
KIT, CONTR PC COMPACT GUN/HOSE
GG 19Y490
GG 19Y490
KIT, CONTR PC COMPACT GUN/HOSE
Contractor PC Compact Gun, 1/4 in x 50 ft BlueMax II Airless Hose, 1/8 in x 4.5 ft Whip Hose, RAC X FFLP 210 SwitchTip Bundling the Contractor PC Compact gun with 50 ft of 1/4 in airless hose and the 1/8 in whip hose to deliver unmatched flexibility, comfort and control. $697.00
