GRACO INC. S10595
GRACO INC. S10595 branded products
Kit, Needle Packing
GG 289455
GG 289455
KIT,NEEDLE PACKING
Graco 289455 Needle Packing Repair Kit
$73.75
Kit, Needle And Nozzle, .055 Sst
GG 289463
GG 289463
KIT,NEEDLE AND NOZZLE,.055 SST
Graco 289463 Needle/ Nozzle Kit for AirPro Guns with 0.055 inch (1.4 mm) Nozzle, General Metal with Stainless Steel Tip
$188.50
Triton SST Package, Wall, Air and Fluid Hoses, Airpro Compliant Gun .055 Nozzle, 100 PSI Reg
GG 289623
GG 289623
TRITON SPRAYER, SS PUMP WALL MNT, COMP
Graco 289623 Triton SST Spray Package, Wall, 100 psi Regulator, Air & Fluid Hoses, AirPro Compliant Gun .055 in (1.4 mm) Nozzle, Waterborne Applications
Air-operated diaphragm spray package designed for the finishing market. It is a more effective alternative to traditional pressure pots and standard diaphragm pumps.
- Superior finish quality for conventional, HVLP and compliant or electrostatic applications
- Supplies up to 35% extra air flow to gun for superior atomization
- Saves material and time during flushing, priming and color changes
- Rugged, stainless steel or aluminum construction pump handles a wide variety of fluids
- Model: Triton
- Series: 308
- Application: Waterborne
- Compatible Material: CARC, Enamel, Epoxies, High Solids, Latex, Lacquer, Metallics, Stains, Single Components, Solvent borne Paints, Solvent borne, Varnish Primers, Waterborne
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 0.9525
- Fluid Outlet Size (in): 3/8
- Fluid Outlet Size (mm): 9.525
- Fluid Outlet Thread Type: NPT
- Gun Included: 1
- Gun Model: AirPro
- Gun Technology: Compliant
- Gun Type: Air Spray
- Includes: 25 ft Air Hose, 25 ft Fluid Hose, Regulator, Applicator
- Maximum Air Inlet Pressure (bar): 7
- Maximum Air Inlet Pressure (kPa): 700
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (GPM): 8.5
- Maximum Flow Rate (L/min): 32
- Maximum Working Pressure (bar): 7
- Maximum Working Pressure (kPa): 700
- Maximum Working Pressure (psi): 100
- Mount Location: Wall Mount
- Mount Type: Wall Mount
- Power Source: Air
- Pressure Type: Low Pressure
- Product Type: Spray Package
- Pump Ratio: 1:1
- Pump Type: Pneumatic Diaphragm Pump
Call for pricing
Sprayer Wall Mount
GG 289630
GG 289630
TRITON SPRAYER, AL WALL MNT CONV STAIN
Triton Alum Spray Package, Wall, Air & Fluid Hoses, AirPro Conventional Gun .040 in (1.0 mm) Nozzle for Wood ApplicationsAir-operated diaphragm spray package designed for the finishing market. It is a more effective alternative to traditional pressure pots and standard diaphragm pumps.Superior finish quality for conventional, HVLP and compliant or electrostatic applicationsSupplies up to 35% extra air flow to gun for superior atomizationSaves material and time during flushing, priming and color changesDelivers a consistent spray pattern and uniform film thicknessRugged, stainless steel or aluminum construction pump handles a wide variety of fluids
$3,140.00
Triton Spray Package, Xp 85KV
GG 289641
GG 289641
TRITON SPRAYER, AL PUMP CART MNT, ELECTRO
Triton Alum Spray Package, Cart, 60 psi Fluid Regulator, Pro Xp85 Electrostatic Gun, Suction, Air & Fluid HosesTriton® air operated diaphragm pump with Pro XpTM electrostatic air spray gun brings affordable, fine finish spraying to wood and metal applications.Effective alternative to traditional pressure pots and standard diaphragm pumps saves material and time during flushing, priming and color changes.Triton® air operated pump produces 30 percent more pumping power and 50 percent less pressure pulsation than standard diaphragm pumps.Rugged, aluminum pump handles a wide variety of fluids.Pro Xp electrostatic air spray gun delivers high transfer efficiency when spraying standard or specialty coatings.With a maximum voltage output of 85 kV, the electrostatic applicator meets strict requirements for spray pattern, mechanical and electrical performance.
$15,540.00
Triton Spray Pkg., Al, Comp Stain
GG 289646
GG 289646
TRITON SPRAYER, AL, PAIL MNT, COMP STAIN
Graco 289646 Triton Alum Spray Package, Pail, 60 psi Regulator, Suction, Air & Fluid Hoses, AirPro Compliant Gun .040 in (1.0 mm) Nozzle for Wood
Air-operated diaphragm spray package designed for the finishing market. It is a more effective alternative to traditional pressure pots and standard diaphragm pumps.
- Superior finish quality for conventional, HVLP and compliant or electrostatic applications
- Supplies up to 35% extra air flow to gun for superior atomization
- Saves material and time during flushing, priming and color changes
- Rugged, stainless steel or aluminum construction pump handles a wide variety of fluids
- Model: Triton
- Series: 308
- Application: Wood
- Compatible Material: CARC, Enamel, Epoxies, High Solids, Latex, Lacquer, Metallics, Stains, Single Components, Solvent borne Paints, Solvent borne, Varnish Primers
- Feed Type: Suction Hose
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 0.9525
- Fluid Outlet Size (in): 3/8
- Fluid Outlet Size (mm): 9.525
- Fluid Outlet Thread Type: NPT
- Gun Included: 1
- Gun Model: AirPro
- Gun Technology: Compliant
- Gun Type: Air Spray
- Includes: 25 ft Air Hose, 25 ft Fluid Hose, Regulator, Applicator
- Maximum Air Inlet Pressure (bar): 7
- Maximum Air Inlet Pressure (kPa): 700
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (GPM): 8.5
- Maximum Flow Rate (L/min): 32
- Maximum Working Pressure (bar): 7
- Maximum Working Pressure (kPa): 700
- Maximum Working Pressure (psi): 100
- Mount Location: Pail Mount
- Mount Type: Pail Mount
- Power Source: Air
- Pressure Type: Low Pressure
- Product Type: Spray Package
- Pump Ratio: 1:1
- Pump Type: Pneumatic Diaphragm Pump
Call for pricing
Spray ES Pkg, Triton, Pail Mount
GG 289648
GG 289648
TRITON SPRAYER, AL, PUMP PAIL MNT, ELECTRO
Triton Alum Spray Package, Pail, 60 psi Fluid Regulator, Pro Xp85 Electrostatic Gun, Suction, Air & Fluid HosesTriton® air operated diaphragm pump with Pro XpTM electrostatic air spray gun brings affordable, fine finish spraying to wood and metal applications.Effective alternative to traditional pressure pots and standard diaphragm pumps saves material and time during flushing, priming and color changes.Triton® air operated pump produces 30 percent more pumping power and 50 percent less pressure pulsation than standard diaphragm pumps.Rugged, aluminum pump handles a wide variety of fluids.Pro Xp electrostatic air spray gun delivers high transfer efficiency when spraying standard or specialty coatings.With a maximum voltage output of 85 kV, the electrostatic applicator meets strict requirements for spray pattern, mechanical and electrical performance.
$15,690.00
Manifold, Mix, Plural Component
GG 289695
GG 289695
MANIFOLD, MIX,PLURAL COMPONENT
Graco 289695 Fluid Mix Manifold- For ProMix 2KS Proportioner
$10,720.00
Kit, Accessory, Plastic Cup
GG 289770
GG 289770
KIT, ACCY, PLASTIC CUP
Sharpe Plastic Cup for AirPro Gravity Feed Air Spray Gun, 23oz
$77.25
Triton Alum Spray Package, Stand, 60 psi Fluid Regulator, Pro Xp85 Electrostatic Gun, Suction, Air & Fluid Hoses
GG 289649
GG 289649
TRITON SPRAYER, AL, PUMP STAND MNT, ELECTRO
Triton Alum Spray Package, Stand, 60 psi Fluid Regulator, Pro Xp85 Electrostatic Gun, Suction, Air & Fluid HosesTriton® air operated diaphragm pump with Pro XpTM electrostatic air spray gun brings affordable, fine finish spraying to wood and metal applications.Effective alternative to traditional pressure pots and standard diaphragm pumps saves material and time during flushing, priming and color changes.Triton® air operated pump produces 30 percent more pumping power and 50 percent less pressure pulsation than standard diaphragm pumps.Rugged, aluminum pump handles a wide variety of fluids.Pro Xp electrostatic air spray gun delivers high transfer efficiency when spraying standard or specialty coatings.With a maximum voltage output of 85 kV, the electrostatic applicator meets strict requirements for spray pattern, mechanical and electrical performance.
$15,540.00
Meter, Gear, Assembly, G3000Hr
GG 289814
GG 289814
METER, GEAR,ASSY,G3000HR
Graco 289814 High Pressure Fluid Meter, Model G3000HR, .01 to .5 gpm Flow Range
- Accuracy (%): +/- 0.5
- Compatible Material: Sealants, Adhesives
$5,630.00
Airpro Gun, Siphon, HVLP, .055
GG 289993
GG 289993
AIRPRO GUN, SIPHON, HVLP, .055
Graco 289993 AirPro Air Spray Siphon Feed Gun, HVLP, 0.055 inch (1.4 mm) Nozzle, without Siphon Cup
The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you're a custom shop or a high volume manufacturing facility.
- Even material distribution through the spray pattern for optimum coverage
- Improved transfer efficiency through reduced air consumption
- Enhanced atomization through material-specific aircaps
- Ultra-light trigger pull reduces operator muscle stress
- Ergonomic gun handle provides a comfortable grip
- Rounded control knobs for operator comfort
- Optimize spray performance with our cutting edge aircap and nozzle design
- Choose from a wide range of gun models to meet the needs of your specific application
- Model: AirPro
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Type: NPSM
- Application: Specialty
- Applicator Type: Manual
- Bleed Type: Non-Bleeder
- Compatible Material: CARC, Enamel, Epoxies, Fast-Set, High Solids, Latex, Plural Component Materials, Sealants, Solvent borne, Urethane, Waterborne
- Feed Type: Siphon Feed
- Fluid Inlet Size (cm): 0.9525
- Fluid Inlet Size (in): 3/8
- Fluid Inlet Size (mm): 9.525
- Fluid Inlet Thread Type: NPSM
- Fluid Orifice Size (cm): 0.14
- Fluid Orifice Size (in): 0.055
- Fluid Orifice Size (mm): 1.4
- Gun Activation: Manual
- Gun Included: 1
- Gun Type: HVLP Gun
- Gun Weight (g): 410
- Includes: Air Cap, Needle Assembly, Nozzle, Tool Kit
- Maximum Air Inlet Pressure (bar): 7
- Maximum Air Inlet Pressure (kPa): 700
- Maximum Air Inlet Pressure (MPa): 0.7
- Maximum Air Inlet Pressure (psi): 100
- Maximum Air Pressure (bar): 7
- Maximum Air Pressure (kPa): 700
- Maximum Air Pressure (MPa): 0.7
- Maximum Air Pressure (psi): 100
- Maximum Fluid Pressure (bar): 21
- Maximum Fluid Pressure (kPa): 2100
- Maximum Fluid Pressure (MPa): 2.1
- Maximum Fluid Pressure (psi): 300
- Maximum Fluid Temperature ( degree C): 43
- Maximum Fluid Temperature ( degree F): 109
- Maximum Fluid Pressure (bar): 21
- Maximum Fluid Pressure (kPa): 2100
- Maximum Fluid Pressure (MPa): 2.1
- Maximum Fluid Pressure (psi): 300
- Maximum Fluid Temperature ( degree C): 43
- Maximum Fluid Temperature ( degree F): 109
- Product Type: Spray Gun
$832.00
Kit, Repair, Hot Melt Guns
GG 289901
GG 289901
KIT,REPAIR,HOT MELT GUNS
KIT INCLUDES: NEEDLE, ASSEMBLY [QTY. 1], ADAPTER, BALL SEAT [QTY. 1], PACKING, O-RING [QTY. 1]
$1,925.00
Meter, Gear, Assembly, G3000
GG 289813
GG 289813
METER, GEAR,ASSY,G3000
Graco 289813 G3000 Gear Flow Meter, positive displacement, 0.02 to 1.0 gpm (75 to 3800 cc/min), low to medium viscosity materials
- Designed for non-abrasive and unfilled materials
- Highly accurate, even with low flow rates
- Stainless steel components can handle low to medium viscosity materials
- Accuracy (%): +/- 0.5
- Compatible Material: Sealants, Adhesives
$7,180.00
Airpro Gun, Siphon, Conv, .055
GG 289991
GG 289991
AIRPRO GUN, SIPHON, CONV, .055
Graco 289991 AirPro Air Spray Siphon Feed Gun, Conventional, 0.055 inch (1.4 mm) Nozzle, without Siphon Cup
The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you're a custom shop or a high volume manufacturing facility.
- Even material distribution through the spray pattern for optimum coverage
- Improved transfer efficiency through reduced air consumption
- Enhanced atomization through material-specific aircaps
- Ultra-light trigger pull reduces operator muscle stress
- Ergonomic gun handle provides a comfortable grip
- Rounded control knobs for operator comfort
- Optimize spray performance with our cutting edge aircap and nozzle design
- Choose from a wide range of gun models to meet the needs of your specific application
- Model: AirPro
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Type: NPSM
- Application: Specialty
- Applicator Type: Manual
- Bleed Type: Non-Bleeder
- Compatible Material: CARC, Enamel, Epoxies, Fast-Set, High Solids, Latex, Plural Component Materials, Sealants, Solvent borne, Urethane, Waterborne
- Feed Type: Siphon Feed
- Fluid Inlet Size (cm): 0.9525
- Fluid Inlet Size (in): 3/8
- Fluid Inlet Size (mm): 9.525
- Fluid Inlet Thread Type: NPSM
- Fluid Orifice Size (cm): 0.14
- Fluid Orifice Size (in): 0.055
- Fluid Orifice Size (mm): 1.4
- Gun Activation: Manual
- Gun Included: 1
- Gun Type: Conventional Gun
- Gun Weight (g): 410
- Includes: Air Cap, Needle Assembly, Nozzle, Tool Kit
- Maximum Air Inlet Pressure (bar): 7
- Maximum Air Inlet Pressure (kPa): 700
- Maximum Air Inlet Pressure (MPa): 0.7
- Maximum Air Inlet Pressure (psi): 100
- Maximum Air Pressure (bar): 7
- Maximum Air Pressure (kPa): 700
- Maximum Air Pressure (MPa): 0.7
- Maximum Air Pressure (psi): 100
- Maximum Fluid Pressure (bar): 21
- Maximum Fluid Pressure (kPa): 2100
- Maximum Fluid Pressure (MPa): 2.1
- Maximum Fluid Pressure (psi): 300
- Maximum Fluid Temperature ( degree C): 43
- Maximum Fluid Temperature ( degree F): 109
- Maximum Fluid Pressure (bar): 21
- Maximum Fluid Pressure (kPa): 2100
- Maximum Fluid Pressure (MPa): 2.1
- Maximum Fluid Pressure (psi): 300
- Maximum Fluid Temperature ( degree C): 43
- Maximum Fluid Temperature ( degree F): 109
- Product Type: Spray Gun
$515.00
Airpro Gun, Siphon, Conv, .070
GG 289992
GG 289992
AIRPRO GUN, SIPHON, CONV, .070
Graco 289992 AirPro Air Spray Siphon Feed Gun, Conventional, 0.070 inch (1.8 mm) Nozzle, without Siphon Cup
The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you're a custom shop or a high volume manufacturing facility.
- Even material distribution through the spray pattern for optimum coverage
- Improved transfer efficiency through reduced air consumption
- Enhanced atomization through material-specific aircaps
- Ultra-light trigger pull reduces operator muscle stress
- Ergonomic gun handle provides a comfortable grip
- Rounded control knobs for operator comfort
- Optimize spray performance with our cutting edge aircap and nozzle design
- Choose from a wide range of gun models to meet the needs of your specific application
- Model: AirPro
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Type: NPSM
- Application: Specialty
- Applicator Type: Manual
- Bleed Type: Non-Bleeder
- Compatible Material: CARC, Enamel, Epoxies, Fast-Set, High Solids, Latex, Plural Component Materials, Sealants, Solvent borne, Urethane, Waterborne
- Feed Type: Siphon Feed
- Fluid Inlet Size (cm): 0.9525
- Fluid Inlet Size (in): 3/8
- Fluid Inlet Size (mm): 9.525
- Fluid Inlet Thread Type: NPSM
- Fluid Orifice Size (cm): 0.18
- Fluid Orifice Size (in): 0.070
- Fluid Orifice Size (mm): 1.8
- Gun Activation: Manual
- Gun Included: 1
- Gun Type: Conventional Gun
- Gun Weight (g): 410
- Includes: Air Cap, Needle Assembly, Nozzle, Tool Kit
- Maximum Air Inlet Pressure (bar): 7
- Maximum Air Inlet Pressure (kPa): 700
- Maximum Air Inlet Pressure (MPa): 0.7
- Maximum Air Inlet Pressure (psi): 100
- Maximum Air Pressure (bar): 7
- Maximum Air Pressure (kPa): 700
- Maximum Air Pressure (MPa): 0.7
- Maximum Air Pressure (psi): 100
- Maximum Fluid Pressure (bar): 21
- Maximum Fluid Pressure (kPa): 2100
- Maximum Fluid Pressure (MPa): 2.1
- Maximum Fluid Pressure (psi): 300
- Maximum Fluid Temperature ( degree C): 43
- Maximum Fluid Temperature ( degree F): 109
- Maximum Fluid Pressure (bar): 21
- Maximum Fluid Pressure (kPa): 2100
- Maximum Fluid Pressure (MPa): 2.1
- Maximum Fluid Pressure (psi): 300
- Maximum Fluid Temperature ( degree C): 43
- Maximum Fluid Temperature ( degree F): 109
- Product Type: Spray Gun
$454.00
Airpro Gun, Siphon, Comp, .070
GG 289996
GG 289996
AIRPRO GUN, SIPHON, COMP, .070
Graco 289996 AirPro Air Spray Siphon Feed Gun, Compliant, 0.070 inch (1.8 mm) Nozzle, without Siphon Cup
The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you're a custom shop or a high volume manufacturing facility.
- Even material distribution through the spray pattern for optimum coverage
- Improved transfer efficiency through reduced air consumption
- Enhanced atomization through material-specific aircaps
- Ultra-light trigger pull reduces operator muscle stress
- Ergonomic gun handle provides a comfortable grip
- Rounded control knobs for operator comfort
- Optimize spray performance with our cutting edge aircap and nozzle design
- Choose from a wide range of gun models to meet the needs of your specific application
- Model: AirPro
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Type: NPSM
- Application: Specialty
- Applicator Type: Manual
- Bleed Type: Non-Bleeder
- Compatible Material: CARC, Enamel, Epoxies, Fast-Set, High Solids, Latex, Plural Component Materials, Sealants, Solvent borne, Urethane, Waterborne
- Feed Type: Siphon Feed
- Fluid Inlet Size (cm): 0.9525
- Fluid Inlet Size (in): 3/8
- Fluid Inlet Size (mm): 9.525
- Fluid Inlet Thread Type: NPSM
- Fluid Orifice Size (cm): 0.18
- Fluid Orifice Size (in): 0.070
- Fluid Orifice Size (mm): 1.8
- Gun Activation: Manual
- Gun Included: 1
- Gun Type: Compliant Gun
- Gun Weight (g): 410
- Includes: Air Cap, Needle Assembly, Nozzle, Tool Kit
- Maximum Air Inlet Pressure (bar): 7
- Maximum Air Inlet Pressure (kPa): 700
- Maximum Air Inlet Pressure (MPa): 0.7
- Maximum Air Inlet Pressure (psi): 100
- Maximum Air Pressure (bar): 7
- Maximum Air Pressure (kPa): 700
- Maximum Air Pressure (MPa): 0.7
- Maximum Air Pressure (psi): 100
- Maximum Fluid Pressure (bar): 21
- Maximum Fluid Pressure (kPa): 2100
- Maximum Fluid Pressure (MPa): 2.1
- Maximum Fluid Pressure (psi): 300
- Maximum Fluid Temperature ( degree C): 43
- Maximum Fluid Temperature ( degree F): 109
- Maximum Fluid Pressure (bar): 21
- Maximum Fluid Pressure (kPa): 2100
- Maximum Fluid Pressure (MPa): 2.1
- Maximum Fluid Pressure (psi): 300
- Maximum Fluid Temperature ( degree C): 43
- Maximum Fluid Temperature ( degree F): 109
- Product Type: Spray Gun
$832.00
Block, Coupling, Gx7
GG 295383
GG 295383
BLOCK, COUPLING, GX7
GX-7 Coupling BlockGenuine Graco replacement parts for GX-7 Coupling Block. Refer to the parts manual for your sprayer to ensure part compatibilityGraco’s dedication to delivering the highest quality products also allows you to protect your investment by offering products that can be repaired to ensure years of reliable service. High quality parts have years of service, but wear parts will need replacement over time. Use Genuine Graco parts to keep your sprayer in peak working order for years to come.Graco Tech Support can further assist with troubleshooting sprayer operation
$859.00
LD Series Oil Pump, 5:1, Universal, Npt
GG 24G588
GG 24G588
LD SERIES OIL PUMP, 5:1, UNIVERSAL, NPT
LD Series 5:1 Universal Oil Pump with Bung Adapter - NPTThe LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LDâ„¢ has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.
Three Inch Air Motor - Provides more power to create better flow.Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.Modular Air Valve - Air inlet and exhaust locations are easy to configure with just four bolts for simple, hassle free installations.Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.
$1,125.00
Trabon MSP Divider Valve - 8 Section Base Plate Assemblies - NPSF
GG 24G490
GG 24G490
PLATE, BASE, 8 SECTION, MSP NPSF
Trabon® MSP Divider Valve - 8 Section Base Plate Assemblies - NPSFThe Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve–and is still the best!
For use with mobile, industrial, food and beverage, wind, and many more applications.Quick change valve sections can be removed from the base assembly without disturbing any lube lines–minimizing labor cost and maximizing your machine uptime.Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting.Built-in outlet check valves ensure accurate lube delivery every time
$411.00
Kit, Repair, Pump, 5 to 1 Double Ball
GG 24G551
GG 24G551
KIT, REPAIR, PUMP, 5:1 SANITARY
Lower Repair Kit 5:1 Double Ball
$668.00
LD Series Oil Pump, Assembly, 5:1, Npt
GG 24G594
GG 24G594
LD SERIES OIL PUMP, ASSEMBLY, 5:1, NPT
LDâ„¢ 5:1 Oil Pump with 55 Gallon (200 Liter) Steel Down Tube and Bung Adapter - NPTThe LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LDâ„¢ has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.
Three Inch Air Motor - Provides more power to create better flow.Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.Modular Air Valve - Air inlet and exhaust locations are easy to configure with just four bolts for simple, hassle free installations.Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.Includes 200L (55gal) drum down tube
$1,300.00
LD Series Oil Pump, 3:1, Universal, Npt
GG 24G576
GG 24G576
LD SERIES OIL PUMP, 3:1, UNIVERSAL, NPT
LD Series 3:1 Universal Oil Pump with Bung Adapter - NPTThe LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LDâ„¢ has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.
Three Inch Air Motor - Provides more power to create better flow.Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.Modular Air Valve - Air inlet and exhaust locations are easy to configure with just four bolts for simple, hassle free installations.Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.
$925.00
Plate, Base, 6 Section, MSP NPSF
GG 24G488
GG 24G488
PLATE, BASE, 6 SECTION, MSP NPSF
Trabon® MSP Divider Valve - 6 Section Base Plate Assemblies - NPSFThe Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve–and is still the best!
For use with mobile, industrial, food and beverage, wind, and many more applications.Quick change valve sections can be removed from the base assembly without disturbing any lube lines–minimizing labor cost and maximizing your machine uptime.Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting.Built-in outlet check valves ensure accurate lube delivery every time
$338.00
Plate, Base 4 Section, MSP NPSF
GG 24G486
GG 24G486
PLATE, BASE, 4 SECTION, MSP NPSF
Trabon® MSP Divider Valve - 4 Section Base Plate Assemblies - NPSFThe Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve–and is still the best!
For use with mobile, industrial, food and beverage, wind, and many more applications.Quick change valve sections can be removed from the base assembly without disturbing any lube lines–minimizing labor cost and maximizing your machine uptime.Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting.Built-in outlet check valves ensure accurate lube delivery every time
$273.00
Plate, Base 3 Section
GG 24G485
GG 24G485
PLATE, BASE, 3 SECTION, MSP NPSF
Trabon® MSP Divider Valve - 3 Section Base Plate Assemblies - NPSFThe Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve–and is still the best!
For use with mobile, industrial, food and beverage, wind, and many more applications.Quick change valve sections can be removed from the base assembly without disturbing any lube lines–minimizing labor cost and maximizing your machine uptime.Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting.Built-in outlet check valves ensure accurate lube delivery every time
$240.50
Plate, Base 5 Section, MSP NPSF
GG 24G487
GG 24G487
PLATE, BASE, 5 SECTION, MSP NPSF
Trabon® MSP Divider Valve - 5 Section Base Plate Assemblies - NPSFThe Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve–and is still the best!
For use with mobile, industrial, food and beverage, wind, and many more applications.Quick change valve sections can be removed from the base assembly without disturbing any lube lines–minimizing labor cost and maximizing your machine uptime.Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting.Built-in outlet check valves ensure accurate lube delivery every time
$305.00
LD 5:1 Oil Pump with 275 Gallon (1040 Liter) Steel Down Tube and Bung Adapter - NPT
GG 24G597
GG 24G597
LD SERIES OIL PUMP, ASSEMBLY, 5:1, NPT
LDâ„¢ 5:1 Oil Pump with 275 Gallon (1040 Liter) Steel Down Tube and Bung Adapter - NPTThe LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LDâ„¢ has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.
Three Inch Air Motor - Provides more power to create better flow.Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.Modular Air Valve - Air inlet and exhaust locations are easy to configure with just four bolts for simple, hassle free installations.Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.Includes 1040 liter (275gal) tote down tube
$1,350.00
6:1 RATIO SANIFORCE BIN LENGTH DOUBLE BALL PISTON PUMP
GG 24F942
GG 24F942
SANIFORCE PISTON PUMP, 6:1 DB BL
6:1 Ratio SaniForce Bin Length Double Ball Piston PumpGraco's SaniForce 6:1 quick knockdown piston pumps are constructed of 300 series stainless steel. The air motor improves serviceability, increases efficiency and offers a lower cost of ownership. Our sanitary piston pumps are ideal for most food-related, cosmetic and personal care applications.
Quick Knockdown Sanitary Piston Pumps for Food and Personal Care ApplicationsMost advanced air motor on the marketAvailable in double-ball and priming piston designsFluid transfer and supply of low to medium viscosity fluidsSuitable to pump products such as: cosmetics, fruit juice concentrates, creamy candy fillings, ice cream variegates, jams and jelliesFDA-Compliant Shroud:
- Easily removable FDA-compliant shroud to clean and access modular air valve - reducing downtime
- Quick knockdown lowers are made with 300 series stainless steel for long-lasting durability
$13,240.00
LD Series 3:1 Universal Oil Pump with Bung Adapter - BSPT
GG 24G578
GG 24G578
LD SERIES OIL PUMP, 3:1, UNIVERSAL, BSPT
LD Series 3:1 Universal Oil Pump with Bung Adapter - BSPTThe LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LDâ„¢ has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.
Three Inch Air Motor - Provides more power to create better flow.Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.Modular Air Valve - Air inlet and exhaust locations are easy to configure with just four bolts for simple, hassle free installations.Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.
$975.00
LD Series Oil Pump, Assembly, 3:1, Npt
GG 24G585
GG 24G585
LD SERIES OIL PUMP, ASSEMBLY, 3:1, NPT
LDâ„¢ 3:1 Oil Pump with 275 Gallon (1040 Liter) Steel Down Tube and Bung Adapter - NPTThe LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LDâ„¢ has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.
Three Inch Air Motor - Provides more power to create better flow.
Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.
Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.
Modular Air Valve - Air inlet and exhaust locations are easy to configure with just four bolts for simple, hassle free installations.
Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.
Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.
Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.
Includes 1040 liter (275gal) tote down tube
$1,150.00
LD™ 3:1 Oil Pump with Cut-to-Length PVC Downtube and Bung Adapter - NPT
GG 24G579
GG 24G579
LD SERIES OIL PUMP, ASSEMBLY, 3:1, NPT
LDâ„¢ 3:1 Oil Pump with Cut-to-Length PVC Downtube and Bung Adapter - NPTThe LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LDâ„¢ has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.
Three Inch Air Motor - Provides more power to create better flow.Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.Modular Air Valve - Air inlet and exhaust locations are easy to configure with just four bolts for simple, hassle free installations.Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.Includes cut-to-length downtube
$1,000.00
LD Series Grease Pump, 50:1, 16 Kg, Npt
GG 24G600
GG 24G600
LD SERIES GREASE PUMP, 50:1, 16 KG, NPT
LD Series 50:1 Pump for 35 lb (16 kg). Pail - NPTThe LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LDâ„¢ has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.
Three Inch Air Motor - Provides more power to create better flow.Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.Modular Air Valve - Air inlet and exhaust locations are easy to configure with just four bolts for simple, hassle free installations.Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.35 lb (16 kg) Grease Pump - 50:1
$1,115.00
Kit, REPAIR, PUMP, 5
GG 24G552
GG 24G552
KIT, REPAIR, PUMP, 5:1 SANITARY
Lower Repair Kit 5:1 Priming Piston
$1,050.00
LD Series Oil Pump, Assembly, 3:1, Npt
GG 24G582
GG 24G582
LD SERIES OIL PUMP, ASSEMBLY, 3:1, NPT
LDâ„¢ 3:1 Oil Pump with 55 Gallon (200 Liter) Down Tube and Bung Adapter - NPTThe LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LDâ„¢ has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.
Three Inch Air Motor - Provides more power to create better flow.Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.Modular Air Valve - Air inlet and exhaust locations are easy to configure with just four bolts for simple, hassle free installations.Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.Includes 200L (55gal) drum down tube
$1,100.00
LD Series Grease Pump, 50:1, 55 Kg, Npt
GG 24G603
GG 24G603
LD SERIES GREASE PUMP, 50:1, 55 KG, NPT
LD Series 50:1 Pump for 120 lb (55 kg). Pail - NPTThe LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LDâ„¢ has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.
Three Inch Air Motor - Provides more power to create better flow.Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.Modular Air Valve - Air inlet and exhaust locations are easy to configure with just four bolts for simple, hassle free installations.Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.120 lb (55 kg) Grease Pump - 50:1
$1,115.00
LD Series Grease Pump, 50:1, 180 Kg, Npt
GG 24G606
GG 24G606
LD SERIES GREASE PUMP, 50:1, 180 KG, NPT
LD Series 50:1 Pump for 400 lb (180 kg). Pail - NPTThe LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LDâ„¢ has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.
Three Inch Air Motor - Provides more power to create better flow.Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.Modular Air Valve - Air inlet and exhaust locations are easy to configure with just four bolts for simple, hassle free installations.Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.400 lb (180 kg) Grease Pump - 50:1
$1,225.00
Meter, Inline, Bspp
GG 24G738
GG 24G738
METER, INLINE, BSPP
Graco 24G738 SDI15 Series Medium/High Pressure - Medium/High Flow In-Line Meter for Diesel Exhaust Fluid Applications - BSPP
Tracks totals in two modes - reset for periodic history and
Application: Typical applications include automotive and heavy-duty dealerships, service and fast lube centers, fleet service facilities and in-plant.- Durable design for rugged, indoor use
- Easy to use - dispenses pints, quarts, liters or gallons
- 0.5 gpm to 15 gpm (1.9 lpm to 57 lpm) flow rate
- Battery Chemistry: Alkaline
- Battery Size: AA
- Compatible Material: Diesel Exhaust Fluid
- For Use With: Diesel Exhaust Fluid
- Inlet Size (cm): 1.27
- Inlet Size (in): 0.5
- Inlet Size (mm): 12.7
- Inlet Thread Type: BSPP
- Maximum Flow Rate (GPM): 15
- Maximum Flow Rate (L/min): 57
- Maximum Operating Temperature ( degree C): 50
- Maximum Operating Temperature ( degree F): 122
- Maximum Working Pressure (bar): 105
- Maximum Working Pressure (kPa): 10500
- Maximum Working Pressure (MPa): 10.5
- Maximum Working Pressure (psi): 1500
- Meter Accuracy (%): plus/minus 00.5
- Meter Repeatability (%): plus/minus 00.15
- Minimum Operating Temperature ( degree C): -20
- Minimum Operating Temperature ( degree F): -4
$674.00
Saniforce Piston Pump, 6:1 DB DLF
GG 24G740
GG 24G740
SANIFORCE PISTON PUMP, 6:1 DB DLF
6:1 Ratio SaniForce Drum Length RAM Double Ball Piston PumpGraco's SaniForce 6:1 quick knockdown piston pumps are constructed of 300 series stainless steel. The air motor improves serviceability, increases efficiency and offers a lower cost of ownership. Our sanitary piston pumps are ideal for most food-related, cosmetic and personal care applications.
Quick Knockdown Sanitary Piston Pumps for Food and Personal Care ApplicationsMost advanced air motor on the marketAvailable in double-ball and priming piston designsFluid transfer and supply of low to medium viscosity fluidsSuitable to pump products such as: cosmetics, fruit juice concentrates, creamy candy fillings, ice cream variegates, jams and jelliesFDA-Compliant Shroud:
- Easily removable FDA-compliant shroud to clean and access modular air valve - reducing downtime
- Quick knockdown lowers are made with 300 series stainless steel for long-lasting durability
$10,450.00
Diaphragm Pump, 515P-Pp01Ap4Ppfkptpt-Fk
GG 24G745
GG 24G745
DIAPHRAGM PUMP, 515P-PP01AP4PPFKPTPT-FK
SDâ„¢ Blue Husky 515 Series Pump - 3/4 in. BSPPThe Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.
The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.
Center and end porting options.No mechanical seals to cause fluid leaks or failuresRuns quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levelsEasy-to-service air valve and ball checksOperates on as little as 20 psi (1.4 bar, 0.14 MPa)Split manifold option to pump multiple fluids without mixingDelivery up to 15 gpm (56.7 lpm)Easy-to-service air valve and ball checksReliable air valve for years of dependable performance
$1,175.00
Hfr Hose, Whip, Htd, 1/4X1/4, 10', Cs, S
GG 24H076
GG 24H076
HFR HOSE,WHIP,HTD,1/4X1/4,10',CS,S
Graco 24H076 10 ft Carbon Steel Single Heat Zone Whip Hose
$1,750.00
Kit, 3 Color Valve Stack
GG 24H255
GG 24H255
KIT, 3 COLOR VALVE STACK
Graco 24H255 3 Color Valve Stack Kit
$4,820.00
Payment options
