GRACO INC. S10595

GG 17M367

ULTRAMAX DCHH SPRAYER, 120V

Graco 17M367 UltraMAX Cordless Handheld Airless Sprayer

Tested by Pros, the UltraMAX Cordless is the ONLY Handheld sprayer capable of spraying water-based, solvent and flammable architectural coatings. SmartControl technology delivers a flawless finish with no thinning required.

• Triax II Triple Piston Pump


  Pump 3X more gallons before service

  Clean up in minutes

  No inlet check valve to get stuck - prime and spray in seconds

  Fast, on-the-job pump replacement with ProConnect

• DEWALT 20V MAX Lithium Ion Battery System

  Spray up to 1 gallon with each charge

  Compatible with any DEWALT 20V MAX Lithium Ion battery

  Comes standard with 2 batteries

  Lightweight design and 30% faster charge time (35 minutes)

• ProConnect

  On-The-Job Pump Replacement System

  One Tool Replacement - Replace the pump in 3 steps using only a screwdriver

• ProControl II

  Adjust motor speed to spray at any speed the job demands

  More control to deliver a professional finish - every job, every time

• Hot Solvent Compatible

  Sprays hot solvents such as solvent-based lacquer

  Sprays water, solvent and flammable based materials

• RAC X FF LP Tips

  Provides superior finish at low pressure

  Reverse-A-Clean (RAC) SwitchTips make cleaning tip clogs simple

  Large range of sizes available to meet the job requirements

  Works on all Graco Airless Sprayers - handhelds to large airless

• 32 oz FlexLiner Paint Bags

  Fast cleanup with disposable liners and no suction tube to clean

  Easy Setup

• FlexLiner QuickFill Funnel

  Click and fill design for faster refills

  Automatically strains paint while pouring

• Model: UltraMAX
• Series: Cordless

• Battery Capacity (Ah): 2

• Battery Chemistry: Lithium-ion
• Battery Voltage (V): 20

• Charging Time (min): 35

• Compatible Replacement Pump: 17P187

• Frame Configuration: Handheld

• Includes: RAC X FF LP 210 Spray Tip, RAC X FF LP 514 Spray Tip, RAC X Guard, 6 - 32 oz FlexLiner Bags, 2 - DEWALT 20V MAX 2.0 Ah Lithium Ion Batteries, DEWALT 20V MAX Battery Charger, 60 Mesh Filter, 100 Mesh Filter, Storage Bag, Pump Armor 4 oz, QuickFill Funnel

• Maximum Tip Size (in): 0.016

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (MPa): 14
• Maximum Working Pressure (psi): 2000

• Minimum Working Pressure (bar): 35
• Minimum Working Pressure (kPa): 3500

• Minimum Working Pressure (psi): 500

• Overall Height (cm): 26.7
• Overall Height (in): 10.5
• Overall Height (mm): 266.7
• Overall Length (cm): 36
• Overall Length (in): 14
• Overall Length (mm): 356
• Overall Width (cm): 12.7
• Overall Width (in): 5
• Overall Width (mm): 127

• Power Source: Battery Powered
• Pressure Control Type: ProControl II

• Pump Type: Triax Triple Piston

GG 17M565

GG 17L983

SWITCH, PROXIMITY ADAPT, 7/16-20

Graco 17L983 Proximity Switch, 7/16-20, 7500 psi (517.1 bar)

Magnetically-operated sensing devices for sending system data to the controller or PLC.

• Available in 115 VAC or 12-32 VDC
• Available for all series progressive families to provide cycle rates up to 200 CPM
• Pressure ratings up to 10,000 psi (690 bar)
• Select models available with UL and CSA approvals

• Model: Trabon

• Application: Off-Road Equipment, On-Road Vehicles, In-Plant Machinery

• Compatible Material: Oil, Grease

• Material: PBT (Pocan), PC (Makrolon), FPM, Stainless Steel

• Maximum Voltage (V dc): 32

• Maximum Working Pressure (bar): 517.1
• Maximum Working Pressure (kPa): 51710
• Maximum Working Pressure (MPa): 51.7
• Maximum Working Pressure (psi): 7500

• Minimum Voltage (V dc): 9.6

• Power Connection Type: M12

GG 17M363

ULTRA SPRAYER, DC, HH, 120V

Graco 17M363 Ultra Cordless Handheld Airless Sprayer

Proven By Pros, Ultra Cordless sprayers provide the fastest way to finish small jobs. Deliver a perfect airless finish in seconds with fast, easy setup and the easy-to-clean design reduces cleanup to just a few minutes so you get to the next job quicker.

• Triax II Triple Piston Pump


  Pump 3X more gallons before service

  Clean up in minutes

  No inlet check valve to get stuck - prime and spray in seconds

  Fast, on-the-job pump replacement with ProConnect

• DEWALT 20V MAX Lithium Ion Battery System

  Spray up to 1 gallon with each charge

  Compatible with any DEWALT 20V MAX Lithium Ion battery

  Comes standard with 2 batteries and charger

  3-LED fuel gauge system allows immediate feedback on state of charge

  Lightweight design and 30% faster charge time (35 minutes)

• ProConnect

  On-The-Job Pump Replacement System

  One Tool Replacement - Replace the pump in 3 steps using only a screwdriver

• ProControl II

  Adjust motor speed to spray at any speed the job demands

  More control to deliver a professional finish - every job, every time

• RAC X FF LP Tips

  Provides superior finish at low pressure

  Reverse-A-Clean (RAC) SwitchTips make cleaning tip clogs simple

  Large range of sizes available to meet the job requirements

  Works on all Graco Airless Sprayers - handhelds to large airless

• 32 oz FlexLiner Paint Bags

  Fast cleanup with disposable liners and no suction tube to clean

  Easy Setup

• FlexLiner QuickFill Funnel

  Click and fill design for faster refills

  Automatically strains paint while pouring

• Model: Ultra
• Series: Cordless

• Battery Capacity (Ah): 2

• Battery Chemistry: Lithium-ion
• Battery Voltage (V): 20

• Charging Time (min): 35

• Compatible Replacement Pump: 17P186

• Filter Mesh Size: 60

• Frame Configuration: Handheld

• Includes: RAC X FF LP 514 Spray Tip, RAC X Guard, 4 - 32 oz FlexLiner Bags, 2 - DEWALT 20V MAX 2.0 Ah Lithium Ion Batteries, DEWALT 20V MAX Battery Charger, 60 Mesh Filter, Storage Bag, Pump Armor 4 oz, QuickFill Funnel

• Maximum Tip Size (in): 0.016

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (MPa): 14
• Maximum Working Pressure (psi): 2000

• Minimum Working Pressure (bar): 35
• Minimum Working Pressure (kPa): 3500

• Minimum Working Pressure (psi): 500

• Overall Height (cm): 26.7
• Overall Height (in): 10.5
• Overall Height (mm): 266.7
• Overall Length (cm): 36
• Overall Length (in): 14
• Overall Length (mm): 356
• Overall Width (cm): 12.7
• Overall Width (in): 5
• Overall Width (mm): 127

• Power Source: Battery Powered
• Pressure Control Type: ProControl II

• Pump Type: Triax Triple Piston

GG 17M359

ULTRA SPRAYER, AC HH, 120V

Graco 17M359 Ultra Corded Handheld Airless Sprayer

Pros agree. Airless handheld sprayers are the essential tool for turning small jobs around fast. Industry-tested Graco Ultra handhelds are the most advanced in the world, delivering unbeatable speed, flawless finish, and unmatched reliability.

• Triax II Triple Piston Pump


  Pump 3X more gallons before service

  Clean up in minutes

  No inlet check valve to get stuck - prime and spray in seconds

  Fast, on-the-job pump replacement with ProConnect

• ProConnect

  On-The-Job Pump Replacement System

  One Tool Replacement - Replace the pump in 3 steps using only a screwdriver

• SmartControl

  Spray at any hand speed with professional finish every time

  Precision pressure control delivers a consistent spray fan without pressure fluctuations

• RAC X FF LP Tips

  Provides superior finish at low pressure

  Reverse-A-Clean (RAC) SwitchTips make cleaning tip clogs simple

  Large range of sizes available to meet the job requirements

  Works on all Graco Airless Sprayers - handhelds to large airless

• 32 oz FlexLiner Paint Bags

  Fast cleanup with disposable liners and no suction tube to clean

  Easy Setup

• FlexLiner QuickFill Funnel

  Click and fill design for faster refills

  Automatically strains paint while pouring

• Model: Ultra
• Series: Corded

• Amperage (A): 15

• Compatible Replacement Pump: 17P185

• Frame Configuration: Handheld

• Includes: RAC X FF LP 514 Spray Tip, RAC X Guard, 4 - 32 oz FlexLiner Bags, 60 Mesh Filter, Storage Bag, Pump Armor 4 oz, QuickFill Funnel

• Maximum Tip Size (in): 0.016

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (MPa): 14
• Maximum Working Pressure (psi): 2000

• Motor Type: AC

• Overall Height (cm): 26.7
• Overall Height (in): 10.5
• Overall Height (mm): 266.7
• Overall Length (cm): 36
• Overall Length (in): 14
• Overall Length (mm): 356
• Overall Width (cm): 12.7
• Overall Width (in): 5
• Overall Width (mm): 127

• Power Cord Length (cm): 46
• Power Cord Length (in): 18
• Power Cord Length (mm): 457
• Power Source: Electric
• Pressure Control Type: SmartControl

• Pump Type: Triax Triple Piston

• Recommended Annual Usage (gal): 50

GG 17L390

GG 17M835

GG 17L622

VALVE, SAFETY RELIEF, 220 PSI

GG 17M842

GG 17N042

GG 17N269

FINISHPRO HVLP SPRAYER, 9.5, PRO COMP SERIES

Graco 17N269 FinishPro HVLP 9.5 ProComp Series Sprayer

The FinishPro HVLP 9.5 ProComp Series sprayer provides unmatched long-life with SmartStart, double the fluid capacity and an integrated compressor for the ultimate in power and performance to spray thicker materials on medium to large fine finish jobs.

• Integrated Compressor

  Pressurize remote cup up to 25 psi

  Allows spraying of thicker materials

  Quick connect hose connections


• 2-Quart Remote Cup

  Fewer refills

  Increase productivity and ease-of-use without cup mounted on the gun

  Fine-tune pressure with pressure regulator and gauge

  Includes belt hook and convenient shoulder strap


• TurboForce Technology

  Exclusive, proprietary turbine design builds more pressure through each stage, resulting in more performance at the gun

  More air flow and air pressure means higher production with less thinning of material

  Generates less heat and provides longer turbine life

• TurboControl System with LED Display

  Adjust the TurboForce turbine speed to match the performance you require

  Reduces heat build up

  Runs quieter

  Extends turbine system life

  50% longer hoses

• Industry Leading Dual Filtration System

  Automotive-grade filter has high performance filtration

  Outperforms foam and traditional paper filters used on most HVLP systems

• EDGE II Plus Gun

  Ultimate control with independent user controls for material volume, air flow, and spray fan size

  4X more productivity

  FlexLiner Bag System

  Learn more: EDGE II Plus Gun

• 1-Quart FlexLiner Cup

  FlexLiner Paint Bag System replaces traditional material cups

  Includes conversion kit use gun-mounted 1-quart FlexLiner cup

  Spray at any angle with no adjustment - even upside down!

• Super-Flex Air Hose

  15% lighter weight than other leading brands for more control at the gun

  30 ft length included

  No tools needed to connect

• Stainless Steel Tough BoxDesign

  Rugged, all steel enclosure protects the turbine on the job and during transport

  Utility toolbox for separate tool and needle and nozzle storage

  On-Board Gun and Cup Holder stores gun when not in use

• Model: FinishPro
• Series: 9.5
• Product Series: ProComp

• Gun Included: 1

• Includes: EDGE II Plus Gun, 2 qt Remote Cup, 5 ft Material and Air Hose, Shoulder Strap, 32 oz FlexLiner System, #3 Quick-Release Fluid Set, #4 Quick-Release Fluid Set, #5 Quick-Release Fluid Set, 30 ft Super-Flex Air Hose, 4 ft Whip Hose, Automotive Main Filter

• Maximum Air Inlet Pressure (bar): 1
• Maximum Air Inlet Pressure (kPa): 10
• Maximum Air Inlet Pressure (psi): 9.5

• Maximum Hose Length (ft): 60
• Maximum Hose Length (m): 18.0

• Maximum Working Pressure (bar): 0.7
• Maximum Working Pressure (kPa): 70
• Maximum Working Pressure (psi): 10

• Product Type: Spray Package

• Recommended Annual Usage: Up to 50

GG 17N040

GG 17L796

KIT,REPAIR,PACKINGS

Graco 17L796 UHMWPE and PTFE Packings Repair Kit, Dura-Flo 1800, standard for 68705

KIT INCLUDES: GLAND, PACKING, MALE [QTY. 1], GLAND, PACKING, FEMALE [QTY. 1], PACKING, VEE, GRAPHITE/TFE DURA [QTY. 2], GLAND, PACKING, MALE [QTY. 1], GLAND, PACKING, FEMALE [QTY. 1], PACKING, VEE, GRAPHITE/TFE [QTY. 2], PACKING, VEE [QTY. 3], PACKING, VEE [QTY. 3], PACKING, O-RING [QTY. 1], SEAL, ACETAL [QTY. 2], PACKING, O-RING [QTY. 1]

• Bell Cup Edge Type: Serrated
• Bell Cup Material: Aluminum Standard
• Bell Cup Size (cm): 5
• Bell Cup Size (in): 2.0
• Bell Cup Size (mm): 50

• Compatible Paint Type: Solventborne

GG 17L332

GG 17L928

GG 17N266

FINISHPRO HVLP SPRAYER, 9.0, PRO CONTRACTOR

Graco 17N266 FinishPro HVLP 9.0 ProContractor Series Sprayer

The FinishPro HVLP 9.0 ProContractor Series sprayer is loaded with features that provide on-demand power control and easier operation with independent material, air and spray fan controls to increase productivity on small to medium-sized fine finish jobs.

• TurboForce Technology

  Exclusive, proprietary turbine design builds more pressure through each stage, resulting in more performance at the gun

  More air flow and air pressure means higher production with less thinning of material

  Generates less heat and provides longer turbine life

• SmartStart Turbine

  Automatically shuts off when not in use - if you're not spraying, it's not running

  Reduces jobsite noise, resulting in less fatigue

  Automatic shut-off reduces heat and extends turbine life

• TurboControl System with LED Display

  Adjust the TurboForce turbine speed to match the performance you require

  Reduces heat build up

  Runs quieter

  Extends turbine system life

  50% longer hoses

• EDGE II Plus Gun

  Ultimate control with independent user controls for material volume, air flow, and spray fan size

  4X more productivity

  FlexLiner Bag System

  Learn more: EDGE II Plus Gun

• FlexLiner Bag System

  FlexLiner Paint Bag System replaces traditional material cups

  Spray at any angle with no adjustment - even upside down!

• Super-Flex Air Hose

  15% lighter weight than other leading brands for more control at the gun

  30 ft length included

  No tools needed to connect

• Stainless Steel Tough BoxDesign


  Rugged, all steel enclosure protects the turbine on the job and during transport

  Smaller and lighter than previous models

• Utility Toolbox

  Separate tool storage for extra needles and nozzles

• On-Board Gun and Cup Holder

  Holds gun when not in use

  Allows for easy paint refills with less spills

• Model: FinishPro
• Series: 9.0
• Product Series: ProContractor

• Gun Included: 1

• Includes: EDGE II Plus Gun, 32 oz FlexLiner System, #3 Quick-Release Fluid Set, #4 Quick-Release Fluid Set, 30 ft Super-Flex Air Hose, Automotive Main Filter

• Maximum Air Inlet Pressure (bar): 1
• Maximum Air Inlet Pressure (kPa): 10
• Maximum Air Inlet Pressure (psi): 9

• Maximum Hose Length (ft): 60
• Maximum Hose Length (m): 18.0

• Maximum Working Pressure (bar): 0.7
• Maximum Working Pressure (kPa): 70
• Maximum Working Pressure (psi): 10

• Product Type: Spray Package

• Recommended Annual Usage: Up to 50 gallons per year

GG 17N369

GG 17N712

GG 17N357

GG 17N415

GG 17N949

GG 17P009

GG 17P174

GG 17P186

KIT, PUMP, DC

Graco 17P186 Triax II Replacement Pump for Cordless Handheld

The Triax II triple piston pump gives you the most reliable performance in the industry and full tip support. It is built from durable stainless steel and carbide components and bonded with a high strength polymer for the most durable, lightest weight pump. Innovative drop-in on-the-job Triax II Pump Replacement with ProConnect lets you replace your modular pump right on the job.

• Triax II Triple Piston Pump


  Pump 3X more gallons before service

  Clean up in minutes

  No inlet check valve to get stuck - prime and spray in seconds

  Fast, on-the-job pump replacement with ProConnect

• Model: Triax
• Series: II

• For Use With: Cordless Ultra Airless Handheld

• Number of Pieces: 1

GG 17P185

KIT, PUMP, AC

Graco 17P185 Triax II Replacement Pump for Corded Handheld

The Triax II triple piston pump gives you the most reliable performance in the industry and full tip support. It is built from durable stainless steel and carbide components and bonded with a high strength polymer for the most durable, lightest weight pump. Innovative drop-in on-the-job Triax II Pump Replacement with ProConnect lets you replace your modular pump right on the job.

• Triax II Triple Piston Pump
  • Pump 3X more gallons before service
  • Clean up in minutes
  • No inlet check valve to get stuck - prime and spray in seconds
  • Fast, on-the-job pump replacement with ProConnect

• Model: Triax
• Series: II

• For Use With: Corded Ultra Airless Handheld

• Number of Pieces: 1

GG 17P212

GG 17P484

EDGE II GUN, HVLP, PLUS, CUP, PKG

Graco 17P484 EDGE II Plus Gun with Metal Cup

Maximize your spraying performance with the innovative HVLP EDGE II Plus Gun. Cutting edge technology such as intuitive gun controls, Quick Release fluid set, and optimized air pressure and airflow will help you achieve the highest quality finish available in fine finish spraying.

• Integrated Flow Control

  Combines material and air flow into one simple control

  Optimized to spray the majority of fine finish applications

  Quick adjustment with 360 degree rotation and indicator for repeatable spray setting

• Adjustable Air Cap

  3-position rotation to change spray pattern

  Conveniently located at the front of the gun

• Exclusive Quick Clean Check Valve

  Allows more air pressure into the material cup to spray heavier material

  Easily clean and reuse versus replace

  Located by gun to reduce clogged valves due to paint contamination

• Quick Release Needle Design

  Change out needles from the front of the gun with just a click

  Easy to change, easy to clean with no tools needed

  Remove front air cap and nozzle

  Slide trigger lever to release needle

  Pull needle out

• Model: HVLP
• Series: EDGE II Plus

• Compatible Material: Varnish, Enamel, Latex, Stains

• For Use With: FinishPro HVLP Sprayers

• Gun Activation: Manual
• Gun Type: HVLP Gun
• Gun Weight (oz): 20

• Includes: 1 qt (0.95 L) Metal Cup, #3 Quick Release Fluid Set

• Maximum Air Inlet Pressure (bar): 0.7
• Maximum Air Inlet Pressure (kPa): 70
• Maximum Air Inlet Pressure (MPa): 0.07
• Maximum Air Inlet Pressure (psi): 12
• Maximum Air Pressure (bar): 0.7

• Maximum Air Pressure (kPa): 70
• Maximum Air Pressure (MPa): 0.07
• Maximum Air Pressure (psi): 10

• Maximum Fluid Pressure (bar): 3.5
• Maximum Fluid Pressure (kPa): 350
• Maximum Fluid Pressure (MPa): 0.35
• Maximum Fluid Pressure (psi): 50

• Maximum Fluid Pressure (bar): 3.5
• Maximum Fluid Pressure (kPa): 350
• Maximum Fluid Pressure (MPa): 0.35
• Maximum Fluid Pressure (psi): 50

GG 17P481

EDGE II GUN, HVLP, PACKAGED

Graco 17P481 EDGE II Gun with FlexLiner System

Maximize your spraying performance with the innovative HVLP EDGE II Gun. Cutting edge technology such as intuitive gun controls, Quick Release fluid set, and optimized air pressure and airflow will help you achieve the highest quality finish available in fine finish spraying.

• Integrated Flow Control

  Combines material and air flow into one simple control

  Optimized to spray the majority of fine finish applications

  Quick adjustment with 360 degree rotation and indicator for repeatable spray setting

• Adjustable Air Cap

  3-position rotation to change spray pattern

  Conveniently located at the front of the gun

  Allows more air pressure into the material cup to spray heavier material

  Easily clean and reuse versus replace

  Located by gun to reduce clogged valves due to paint contamination

• EasyGlide 2-Finger Trigger and Ergonomic Handle

  Trigger has up to 75% lighter pull than competition

  2-finger trigger design gives more control while spraying

  Form-fitted handle stays cool to the touch for extended use

• Model: HVLP
• Series: EDGE II

• Compatible Material: Varnish, Enamel, Latex, Stains

• For Use With: FinishPro HVLP Sprayers

• Gun Activation: Manual
• Gun Type: HVLP Gun
• Gun Weight (oz): 20

• Includes: 1 qt FlexLiner Cup, #3 Quick Release Fluid Set

• Maximum Air Inlet Pressure (bar): 0.7
• Maximum Air Inlet Pressure (kPa): 70
• Maximum Air Inlet Pressure (MPa): 0.07
• Maximum Air Inlet Pressure (psi): 10
• Maximum Air Pressure (bar): 0.7

• Maximum Air Pressure (kPa): 70
• Maximum Air Pressure (MPa): 0.07
• Maximum Air Pressure (psi): 10

• Maximum Fluid Pressure (bar): 3.5
• Maximum Fluid Pressure (kPa): 350
• Maximum Fluid Pressure (MPa): 0.35
• Maximum Fluid Pressure (psi): 50

• Maximum Fluid Pressure (bar): 3.5
• Maximum Fluid Pressure (kPa): 350
• Maximum Fluid Pressure (MPa): 0.35
• Maximum Fluid Pressure (psi): 50

GG 17P488

GG 17P492

GG 17P754

GG 17P879

GG 17R220

GG 17P485

GG 17R291

GG 17P502

KIT, GASKET, FFLP, SOLVENT

Graco 17P502 RAC X FF LP Solvent OneSeal, 5 pack

Designed specifically for the RAC X FF LP SwitchTips, these single seal gaskets help keep the tip in place when using solvent-based materials.

• Model: RAC X
• Series: Tip Gasket

• Compatible Tip Type: RAC X

GG 17P486

GG 17P555

KIT, FILTER, FLUID, 100 MESH

Graco 17P555 Handheld Filter 100 mesh

Pump filters improve the look of the final finish by removing unwanted debris from the paint. 100 mesh filter is for thinner material such as stain and lacquer. Compatible with Ultra, Ultimate, and TC Pro Handheld models.

• Model: Graco

• For Use With: TC Pro Corded, TC Pro Cordless, TC Pro PLUS Cordless

• Overall Depth (cm): 3.96875
• Overall Depth (in): 1.5625
• Overall Depth (mm): 39.6875

• Overall Height (cm): 2.06375
• Overall Height (in): 0.8125
• Overall Height (mm): 20.6375
• Overall Width (cm): 3.96875
• Overall Width (in): 1.5625
• Overall Width (mm): 39.6875

GG 17P712

KIT, VACUVALVE

Graco 17P712 VacuValve Cap Replacements, 3 pack

The VacuValve keeps air from entering the FlexLiner System.

• Model: Graco

• Includes: Cap Hinge Valve (3)

• Number of Pieces: 3

GG 17R827

GG 17P726

KIT,HEAD,PROBLER2,SST

KIT INCLUDES: HEAD, PROBLER2, SST [QTY. 1], KIT INCLUDES: INSERT, CHAMBER, MIX, .059 [QTY. 1],

GG 17P717

GG 17P501

KIT, GASKET, FFLP

Graco 17P501 RAC X FF LP OneSeal, 5 pack

Designed specifically for the RAC X FF LP SwitchTips, these single seal gaskets help keep the tip in place.

• Model: RAC X
• Series: Tip Gasket

• Compatible Tip Type: RAC X

GG 17P653

EDGE II GUN, HVLP, CUP, PKGD

Graco 17P653 EDGE II Gun with Metal Cup

Maximize your spraying performance with the innovative HVLP EDGE II Gun. Cutting edge technology such as intuitive gun controls, Quick Release fluid set, and optimized air pressure and airflow will help you achieve the highest quality finish available in fine finish spraying.

• Integrated Flow Control

  Combines material and air flow into one simple control

  Optimized to spray the majority of fine finish applications

  Quick adjustment with 360 degree rotation and indicator for repeatable spray setting

• Adjustable Air Cap

  3-position rotation to change spray pattern

  Conveniently located at the front of the gun

• Exclusive Quick Clean Check Valve

  Allows more air pressure into the material cup to spray heavier material

  Easily clean and reuse versus replace

  Located by gun to reduce clogged valves due to paint contamination

• Quick Release Needle Design

  Change out needles from the front of the gun with just a click

  Easy to change, easy to clean with no tools needed

  Remove front air cap and nozzle

  Slide trigger lever to release needle

  Pull needle out

• Model: HVLP
• Series: EDGE II

• Compatible Material: Varnish, Enamel, Latex, Stains

• For Use With: FinishPro HVLP Sprayers

• Gun Activation: Manual
• Gun Type: HVLP Gun
• Gun Weight (oz): 20

• Includes: 1 qt (0.95 L) Metal Cup, #3 Quick Release Fluid Set

• Maximum Air Inlet Pressure (bar): 0.7
• Maximum Air Inlet Pressure (kPa): 70
• Maximum Air Inlet Pressure (MPa): 0.07
• Maximum Air Inlet Pressure (psi): 13
• Maximum Air Pressure (bar): 0.7

• Maximum Air Pressure (kPa): 70
• Maximum Air Pressure (MPa): 0.07
• Maximum Air Pressure (psi): 10

• Maximum Fluid Pressure (bar): 3.5
• Maximum Fluid Pressure (kPa): 350
• Maximum Fluid Pressure (MPa): 0.35
• Maximum Fluid Pressure (psi): 50

• Maximum Fluid Pressure (bar): 3.5
• Maximum Fluid Pressure (kPa): 350
• Maximum Fluid Pressure (MPa): 0.35
• Maximum Fluid Pressure (psi): 50

GG 17R301

GG 17R290

GG 17R299

GG 17R462

GG 17P550

KIT, FLEXLINER COMPLETE, 32OZ

Graco 17P550 FlexLiner System 32 oz

Adding an additional FlexLiner System for your handheld will make refilling even easier and faster. Includes 32 ounce cup holder, 32 ounce FlexLiner Paint Bag, lid and plug.

• Model: FlexLiner

• Maximum Volume Capacity (mL): 1000
• Maximum Volume Capacity (oz): 32

GG 17R293

GG 17R693

GG 17R821

KIT, LID, 32OZ, COMPLETE, GRAY

Graco 17R821 FlexLiner System 32 oz

The industry-first innovative FlexLiner System makes cleanup simple. Just toss or reuse the 32 oz bag after you finish spraying, it's your choice. The FlexLiner system allows you to spray in any direction, even upside down. Keep an extra system handy to make switching between colors or materials quick and easy.

• Model: FlexLiner

• For Use With: TrueCoat 360, TrueCoat 360 DS, TrueCoat 360 DSP, TC Pro Corded, TC Pro Cordless, TC Pro PLUS Cordless

GG 17R799

GG 17S340

GG 17T131

GG 17T198

GG 17R875

GG 17S552

GG 17S558

GG 17S339

GG 17S338

GG 17R835

GG 17T051

GG 17T039

KIT,MD2,SUPER,HARD

KIT INCLUDES: KIT, SEAL, CYLINDER, AIR, VALVE [QTY. 1], KIT, SEAL, LUBE, VALVE [QTY. 1], KIT, HOUSING, SEAL, NOSE, UL2K [QTY. 1]

GG 17S843

KIT,MODULE,ADCM, TANK CONTROL

GG 17T207

GG 17T211

GG 17T610

GG 17U084

GG 17T040

KIT,MD2,SUPER,SOFT

KIT INCLUDES: KIT, SEAL, CYLINDER, AIR, VALVE [QTY. 1], KIT, SEAL, LUBE, VALVE [QTY. 1], KIT, SEAL, NOSE, GLC, VALVE [QTY. 1]

GG 17U128

GG 17T371

GG 17U129

GG 17U130

GG 17V093

GG 17V232

KIT, DISPLAY

Graco 17V232 Control Module Kit (480v) for E-Flo DC Advanced Motors

• Compatible Material: High Solids, Xirallic, CARC, Metallics, Stains, Varnish, Fast-Set

GG 17V316

GG 17V315

GG 17V344

GG 17V319

GG 17V345

GG 17V754

GG 17V781

KIT, REPAIR, MAGNUM, PUMP

Graco 17V781 Repair Kit, Pump, X5, X7

Replace a worn or damaged pump with genuine Graco parts. Completely assembled for easy installation. Replacement pump for Magnum X5 and X7 paint sprayers. Refer to the parts manual for your sprayer to ensure part compatibility

• Sprayer doesnt prime or spray, it may be due to piston pump packing wear or check ball valve failure
• Pump and valves come completely assembled
• For X5-series E, 262800, X7-series D, 262805

• For Use With: X5, X7

• Includes: Repair Manual, Screws (6), Grease, Pin, Piston, Housing, Foam Pad (2), Cap, Ball Knocker Module, Diaphram Pressure Control, Outlet Valve, Drain Valve, Inlet Housing, Bearing Sleeve (2), Compression Sleeve, Ball, Seal, Drain Valve Handle, Ball Knocker Button, Solenoid Cover, Labels (4)

• Number of Pieces: 31

GG 17V756

GG 17V958

GG 17W201

GG 17W453

GG 17W739

TANK, SURGE, SUPPRESSOR

Graco 17W739 Active Surge Suppressor

Manufacturers concerned about paint line pulsation can set and forget the active surge suppressor. It automatically adjusts itself for peak performance in changing conditions. Once you set it up, you can forget about manual adjustments.

• Works off shop air, eliminating need for and extra cost of high pressure charge air
• Flushes cleanly and thoroughly in between colors
• Saves space with pump-mount configuration

• Inlet Size (cm): 3.81
• Inlet Size (in): 1-1/2
• Inlet Size (mm): 38.1

• Maximum Flow Rate (GPM): " 10 (single pump), 20 (E-flo DC 2X)"
• Maximum Flow Rate (L/min): 76

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300

• Outlet Size (cm): 3.81
• Outlet Size (in): 1-1/2
• Outlet Size (mm): 38.1

GG 17W770

GG 17W769

GG 17W950

GG 17X355

GG 17X499

GG 17X521

GG 17X563

GG 17X562

GG 17X684

GG 17Y297

KIT, REPAIR, CARTRIDGE, PC GUN

Graco 17Y297 Contractor PC ProConnect Replacement Cartridge

The exclusive ProConnect Replacement Cartridge allows you to finish jobs faster by providing a fast, on-the-job gun rebuild solution. The needle and all wear parts are included in one simple part. Simply replace the cartridge to keep spraying. Its like getting a brand new gun in seconds!

• Model: ProConnect
• Series: Cartridge

GG 17Y666

GG 17Y504
