GH130 Hydraulic Airless Sprayer

GG 24W923

GH 130 SPRAYER, STD

Graco 24W923 GH 130 Convertible Standard Series Gas Hydraulic Airless Sprayer

The GH 130 Convertible is the clear choice for entry level contractors who demand maximum power in a small package. With the ability to change out the pump lower and convert to electric power without tools, you can be assured that you have the most versatile sprayer on the market today.

• Endurance Chromex Piston Pump
  • Lasts 2X longer than the next leading brand
  • QuikChange pump design allows you to swap the pump easily on the job
  • Faster cleaning with the QuikAccess intake foot valve
• High-Efficiency Hydraulic Motor
  • Rock-solid performance time after time keeps you up and running
  • Faster, more responsive changeover
  • O-ring sealed fittings and form-fitted hydraulic lines prevent leaks
  • Fewer moving parts mean less maintenance and longer life
• High-Capacity Cooling System
  • Innovative design allows the pump to run cooler and more efficiently
  • Hydraulic reservoir is tapered on the bottom
  • Provides easier and more thorough fluid changes
  • Cooling fins on reservoir deflect heat away from sprayer
• Easy Out Pump Filter
  • Easy maintenance & less clogging
  • Exclusive inside-out filter design won't collapse to ensure a quality finish
  • Vertical design for less mess
• Heavy-Duty Prime Valve
  • Maintenance-free design withstands high-pressure dumping
• Rugged, Durable Cart Design
  • Thick chrome over welded steel withstands rugged environments
  • Full pneumatic wheels absorb impacts and vibrations
  • Retractable handle doubles as coiled hose storage
  • Tilts on its nose for service in the field
• Electric Motor Capability
  • Indoor and outdoor use
  • Quickly swap the gas engine for an electric motor in seconds – without tools
  • Electric motor kit sold separately
• Ready to Work
  Includes everything you need to get spraying:
  • Contractor Airless Spray Gun
  • RAC X SwitchTips and Guard
  • 50 feet of BlueMax II Airless Hose

• Model: GH
• Series: 130
• Product Series: Standard

• Compatible Electric Motor Kits: 288473, 288474 (CSA)
• Compatible Material: Acrylics, Paint, Primer
• Compatible Replacement Pump: 24B748

• Convertible: Yes

• Engine Brand: Honda
• Engine Size (HP): 4

• Features: Endurance Chromex Pump, High-Capacity Cooling System, Honda Engine, Easy Out Filter, Heavy-Duty Prime Valve, Durable Cart Design, Convertible

• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Type: MNPT

• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 3.75
• Fluid Outlet Thread Type: FNPT

• Frame Configuration: Cart

• Includes: Contractor Gun, RAC X LP 517 Spray Tip, RAC X WideRAC 1231 Spray Tip, RAC X Guard, 1/4 in x 50 ft BlueMax II Airless Hose, TSL 4 oz

• Maximum Flow Rate (GPM): 1.30
• Maximum Flow Rate (L/min): 4.9

• Maximum Hose Length (ft): 300
• Maximum Hose Length (m): 92

• Maximum Sound Pressure Level (dB(A)): 88

• Maximum Tip Size (in): 0.037
• Maximum Tip Size 1 Gun - Electric Motor (in): 0.031
• Maximum Tip Size 2 Guns - Electric Motor (in): 0.017
• Maximum Tip Size Gun 1 (in): 0.037
• Maximum Tip Size Gun 2 (in): 0.023

• Maximum Working Pressure (bar): 228
• Maximum Working Pressure (kPa):
