Chipping Hammer, 2 In Stroke, 2200 Bpm

IR 2DA2SA

Air Chipping Hammer, 2" Stroke, 2200 BPM, Round Shank Oval Collar

Description: The D Series chipping hammers are ready and equipped for any task, from light demolition work to metal removing. With an easily serviceable D-handle and directional exhaust for your convenience, these are hammers you can rely on.

Features And Benefits:

• Weight: At 11.75 lbs., these tools are lightweight and easy to use.
• Reliability: Equipped with a steel cone, you never have to worry that the bit will fall out during production. Comes with a 1-year warranty.

Product Application and Uses:

These Air Percussive Chipping Hammers are designed for chipping, cutting, chiseling and breaking of hardened materials through repetitive application of linear impacts of a tool steel that is retained and driven by the chipper.

• Actuation/Throttle Type/Switch Type: Outside Trigger
• Air Consumption @ Load (cfm): 28
• Air Consumption @ Load (l/min): 793
• Air Inlet: 7/8" NPT
• Air Pressure (psi): 90

• Blows per Min: 2200
• Bore Diameter (in): 1.125

• Collar Type: Oval
• Color: Beige
• Configuration/Handle Type: D-Handle
• Duty Rating: Industrial Duty

• Exhaust Location: Side - Adjustable

• Housing Material: Aluminum

• Max Pressure (bar): 6.2
• Min Hose Size (in): 1
• Muffler: No

• Power Source: Air Powered
• Product Length (in): 13.75

• Product Weight (lb): 11.75
• Retainer Type: Grooved Barrel with Lock-spring (Plain Arrow)

• Shank SIze (in): 0.68
• Shank Type: Round

• Stroke Length (in): 2

• Warranty: 1-year

• Accessories: HH1-1190
• Accessories: HH1-215-12
• Accessories: HH1-215-18
• Accessories: HH1-215B-12
• Accessories: HH1-215B-18
• Accessories: HH1-215B-9
• Accessories: HH1-215D-12
• Accessories: HH1-215F-12
• Accessories: HH1-215F-18
• Accessories: HH1-215F-24
• Accessories: HH1-215F-36
• Accessories: HH1-215F-48
• Accessories: HH1-215F-60
• Accessories: HH1-215F-72
• Accessories: HH1-215F-9
• Accessories: HH1-215F-96
• Accessories: HH1-215M-12
• Accessories: HH1-215M-18
• Accessories: HH1-215M-24
• Accessories: HH1-215M-36
• Accessories: HH1-215M-9
• Accessories: HH1-215S-12

• Accessories: HH1-215T-9
• Accessories: HH1-323-12
• Accessories: HH1-323-18
• Accessories: HH1-323-24
• Accessories: HH1-323-48
• Accessories: HH1-323-60
• Accessories: HH1-323-72
• Accessories: HH1-323-9
• Accessories: HH1-323-96

• Lubrication: 10P
• Parts: HH1-1194
