GG CM1T4F
CHECK-MATE SUPPLY UNIT, 63:1, 0 VOLT, D60, 20L
Graco CM1T4F Supply Unit, Check-Mate, 63:1, S/S, Severe Duty, 3 in. D60 Ram, Integrated Air Controls, 20L S/S Flat Platen, Single PTFE Wiper
Graco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.
Application: Bulk unloaders for ambient sealants, adhesives and other medium to high-viscosity materials.
- 60 liter (16-gal) pail sizes provides the same proven technologies as the larger systems, but with small NXT Air Motors
- Graco D60 - Provides higher down-force and 60-liter pail capacity
- Industry-first controls give you immediate and important information at the touch of a button
- Platen wipers can be replaced in seconds
- Pump&prime, s quick-disconnect coupler, turnbuckle mount and pump cartridge packings let you service the pump without removing it from the ram
- High-quality, durable parts reduce maintenance time, maximize uptime
- Model: Check-Mate
- Series: D60
- Ambient/Warm Melt/Hot Melt: Ambient
- Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
- Container Type: Pail
- Control Panel Material: N/A
- Material Container Volume (gal): 5.3
- Material Container Volume (l): 20
- Maximum Air Inlet Pressure (bar): 10.34
- Maximum Air Inlet Pressure (kg/cm²): 10.55
- Maximum Air Inlet Pressure (kPa): 1034
- Maximum Air Inlet Pressure (psi): 150
- Maximum Flow Rate (GPM): 1.6
- Maximum Flow Rate (L/min): 6.1
- Maximum Fluid Pressure (bar): 434.4
- Maximum Fluid Pressure (kPa): 43440
- Maximum Fluid Pressure (psi): 6300
- Maximum Fluid Pressure (bar): 434.4
- Maximum Fluid Pressure (kPa): 43440
- Maximum Fluid Pressure (psi): 6300
- Maximum Height (cm): 226.06
- Maximum Height (ft): 7.42
- Maximum Height (in): 89
- Maximum Height (m): 2.26
- Maximum Height (mm): 2260.6
- Maximum Operating Temperature (°C): 49
- Maximum Operating Temperature (°F): 120
- Maximum Working Pressure (bar): 441
- Maximum Working Pressure (kPa): 44100
- Maximum Working Pressure (MPa): 44.1
- Maximum Working Pressure (psi): 6300
- Minimum Height (cm): 149.86
- Minimum Height (ft): 4.92
- Minimum Height (in): 59
- Minimum Height (m): 1.5
- Minimum Height (mm): 1498.6
- Overall Depth (cm): 45.72
- Overall Depth (in): 18
- Overall Depth (mm): 457.2
- Overall Width (cm): 71.12
- Overall Width (in): 28
- Overall Width (mm): 711.2
- Pump Ratio: 63:1
- Pump Type: Priming Piston
- Ram Material: Carbon Steel
