CHECK-MATE SUPPLY UNIT, 20:1, 0 V, S20 CART, 20L

Manufacturer: GRACO INC. S10595

GG CM7A2B

CHECK-MATE SUPPLY UNIT, 20:1, 0 V, S20 CART, 20L

Graco CM7A2B 20:1 Ratio 20 L S20 Cart Mounted Supply Unit

Graco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.

Application: Bulk unloaders for ambient sealants, adhesives and other medium to high-viscosity materials.
  • 20 liter (5 gal) pail sizes provides the same proven technologies as the larger systems, but with small NXT Air Motors
  • Graco S20c - Same as the S20, but includes a cart
  • Industry-first controls give you immediate and important information at the touch of a button
  • Platen wipers can be replaced in seconds
  • Pump&prime, s quick-disconnect coupler, turnbuckle mount and pump cartridge packings let you service the pump without removing it from the ram
  • High-quality, durable parts reduce maintenance time, maximize uptime


  • Model: Check-Mate
  • Series: S20c
  • Ambient/Warm Melt/Hot Melt: Ambient
  • Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
  • Container Type: Pail
  • Material Container Volume (gal): 5.3
  • Material Container Volume (l): 20
  • Maximum Air Inlet Pressure (bar): 8.62
  • Maximum Air Inlet Pressure (kg/cm²): 8.79
  • Maximum Air Inlet Pressure (kPa): 862
  • Maximum Air Inlet Pressure (psi): 125
  • Maximum Flow Rate (GPM): 0.9
  • Maximum Flow Rate (L/min): 3.4
  • Maximum Fluid Pressure (bar): 137.9
  • Maximum Fluid Pressure (kPa): 13790
  • Maximum Fluid Pressure (psi): 2000
  • Maximum Fluid Pressure (bar): 137.9
  • Maximum Fluid Pressure (kPa): 13790
  • Maximum Fluid Pressure (psi): 2000
  • Maximum Height (cm): 228.6
  • Maximum Height (ft): 7.5
  • Maximum Height (in): 90
  • Maximum Height (m): 2.29
  • Maximum Height (mm): 2286
  • Maximum Operating Temperature (°C): 49
  • Maximum Operating Temperature (°F): 120
  • Maximum Working Pressure (bar): 138
  • Maximum Working Pressure (kPa): 13800
  • Maximum Working Pressure (MPa): 13.8
  • Maximum Working Pressure (psi): 2000
  • Minimum Height (cm): 165.1
  • Minimum Height (ft): 5.42
  • Minimum Height (in): 65
  • Minimum Height (m): 1.65
  • Minimum Height (mm): 1651
  • Overall Depth (cm): 66.1
  • Overall Depth (in): 26
  • Overall Depth (mm): 661
  • Overall Width (cm): 56.2
  • Overall Width (in): 22.1
  • Overall Width (mm): 562
  • Power Type: Pneumatic
  • Pump Ratio: 20:1
  • Pump Type: Priming Piston
  • Ram Material: Carbon Steel
SKU: GG CM7A2B
Availability:
Price: $13,170.00
