Medium Duty Short Cable Spring Balancer, 13.2-17.6 lb Capacity, 6.5' Lift

Description: B Series spring balancers are designed to increase productivity in any situation where repetitive or prompt vertical movement of fixed load is required. They compensate weight of your power tools or other manufacturing equipment and enable operator to lift or lower it with minimal effort.

Features And Benefits:

• Rugged construction, cast aluminum body
• Stainless steel cable and anti-friction cable guide
• Adjustable capacity
• Adjustable stroke limiting device
• Upper suspension shackle included on balancer for ease of installation
• Axial Mounting Circlip to ensure greater durability
• Screw-lock system that allows for re-beating and a higher level of reliability in a heavy-duty environments, on BMDS models only
• Anti-reverse spanner adjustable bushing to protect the balancer from potential damages caused by an incorrect spring unloading
• Safety Cap added to the front of the balancer for greater durability by absorbing impact while in motion
• Safety device against load dropping due to the spring breakage (>6.5 lb)

• Cable Material: Stainless steel
• Capacity (lb): 13.2 - 17.6

• Color: Red
• Duty Rating: Medium Duty

• Housing Material: Aluminum
• Lift (ft): 6.5
• Lock Mechanism: Ratchet
• Lower Hook: Spring Clip

• Product Length (in): 11.75

• Product Width (in): 5.75
• Product Height (in): 3.4
• Product Weight (lb): 5.5
• Reel Height (in): 13.78
• Reel Mount Type: Suspension Shackle
• Rotation Type: Fixed

• Tension Adjustment: Front Screw with Spanner Wrench

• Warranty: 1-year
