EP SWi5TE-S
8.7 Ton, External Hydraulic Flange Spreader Single Set, 4 in Maximum Spread
This Equalizer set includes a flange spreader wedgehead, hydraulic cylinder, safety block, stepped block, lanyard, and carry case.
Within the spreader sits an integral hydraulic cylinder, which when used with a separate hydraulic pump (not supplied), makes it easy to exert a powerful force for separating pipe flanges.
Applications: Spread
- Type: Spreader
- Max Bar: 700
- Max PSI: 10000
- Product Group: Flange Maintenance Tools
- Product Line: Bolting Tools
- Series: SWi
- SubTypes: Flange Spreader Set - Wedges
- Capacity Imperial Tons: 8.7
- Capacity KN: 77
- Capacity Metric Tons: 7.7
Set Includes- 1 x SWi5TE Flange Spreader Wedgehead
- 1 x 10,000 psi Hydraulic Cylinder
- 1 x Safety Block
- 1 x Lanyard
- Case dimensions (in) 22.8 x 13.4 x 7.1
User Features- Practical, portable and lightweight
- Molded plastic handle for comfort
- Revolving handle to aid horizontal or vertical spreading
- Removable handle for improved access
Safety Features- No finger pinch-points
- Increased step depth on upper steps
- Safety lanyard - 39 inches (1 m) length
- Forged key components for strength and reliability
Maintenance Features- Rapid disassembly and assembly
- Narrow jaw teeth - improved tool wear
