EP CST27151
6110 lbs Capacity, 0.59 in Stroke, Single-Acting, Threaded Body, Hydraulic Cylinder
Applications: Push
- Type: Hydraulic Cylinders
- Max PSI: 5000
- Product Group: Cylinders and Jacks
- Product Line: Work Holding Tools
- Series: CST
- Stroke Inches: 0.59
- SubTypes: Workholding Threaded Cylinder
- Minimum cylinder diameter combined with maximized clamping forces
- Threaded body allows fine positioning and easy installation
- Internal plunger wipers allow maintenance-free, high-cycle performance
- Center-tapped plungers will hold workpiece contact buttons
- Single-acting models with spring return simplify hydraulic tubing requirements
- Double-acting models are recommended for high-cycle applications
- Accessories: MF421, FN421, BS91
