EP SLRS201
3900 lbs Force, Swing Clamp, Single-Acting, Right Turning, Lower Flange
Applications: Clamp
- Type: Work Holding Clamp
- Max PSI: 5000
- Min PSI: 500
- Product Group: Workholding Tools
- Product Line: Work Holding Tools
- Series: SLR
- Stroke Inches: 1.16
- SubTypes: Swing Clamp - Lower Flange
- Flexible design allows for manifold or threaded port connection
- No fixture hole preparation required
- Easiest mounting preparation in the swing cylinder line
- Symmetrical rectangular flange design enables clamping at three sides of the cylinder
- Allows extra large parts to be clamped
- 30, 45 and 60 degree swing angles available on request
- Enerpac lower flange series swing clamps can be bolted to the fixture, allowing easy installation of the unit and does not require machined fixture holes. Hydraulic connections are made through SAE or BSPP oil connection or the standard integrated O-ring ports.
