2025 lbs Force, Threaded Body Swing Clamp, Double-Acting, Left Turning

EP STLD92

• Type: Work Holding Clamp
• Max Bar: 350
• Max PSI: 5000
• Min Bar: 35
• Min PSI: 500

• Product Group: Workholding Tools
• Product Line: Work Holding Tools
• Series: ST
• Stroke Inches: 0.9
• Stroke MM: 23
• SubTypes: Swing Clamp - Threaded Body

• Body thread for precise cylinder height positioning
• Threaded port connection
• Easy installation and removal
• Greatest flexibility in fixture design
• 30, 45 and 60 degree swing angles available on request
• Enerpac threaded body swing clamps are threaded directly into the fixture.
• The cylinder height is adjusted to the appropriate height, and then locked in place using a jam nut
