IR 2101XPA-QC
1/4" Hex Air Mini Impact Wrench, 55 ft-lbs Torque, Pistol
Despite its small size, this Mini Impact Wrench packs a punch. Thanks to its rocking dog impact mechanism and finely tuned 5 vane motor, this wrench is as compact as it is powerful delivering 55 ft-lbs of torque.
Features And Benefits
- Performance: Powerful rocking dog impact mechanism and hard-hitting five-vane motor delivers smooth and robust performance engineered to deliver 55 ft-lbs of max torque and 3650 blows per minute.
- Access: Thanks to its small size, this wrench can fit in even the toughest to reach spaces.
- Ease of Use: Easily accessible forward/reverse switch for one-handed operation and quick change hex retainer feature allows for simple and convenient attachment exchange.
Actuation/Throttle Type/Switch Type: Trigger
Air Consumption (l/min): 282
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Anvil Length: Standard
Average Air Consumption (l/min): 382
Blows per Min: 3650
Color: Black
Configuration/Handle Type: Pistol Grip
Drive Size (in): 1/4
Drive Type: Hex
Exhaust Location: Handle
Free Speed Sound Pressure/Power Db(A): 83.6 / 94.6
Impact Mechanism: Rocking Dog
Impacting Sound Pressure/Power Db(A): 84.8 / 95.8
Max Bolt Diameter (in): M5
Max Free Speed (rpm): 14500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 55
Max Torque (in-lb): 664
Max Torque (nm): 75
Power Source: Air Powered
Product Length (in): 7.2
Product Weight (lb): 1.54
Quiet Tool: No
Recommended Forward Torque Range (ft-lb): 50
Recommended Forward Torque Range (in-lb): 602
Recommended Forward Torque Range (nm): 68
Retainer Type: Quick Change
Tool Type: Compact
Vanes: 5
Vibration Level (m/s2): 3.0
Vibration Uncertainy K* (m/s2): 1.0
Warranty: 1-year
