Parts

DY 01950

GG 101178

GG 106560

GG 111710

GG 150647

GG 15B211

GG 177431

GG 188610

GG 24A547

KIT, SEALS, MOTOR 6.0

Graco 24A547 Air Motor Seal Kit

GG 24C821

KIT, AGITATOR, SUB ASSEMBLY

Graco 24C821 Drum Agitator Kit Assembly

GG 24N666

KIT, GUN BODY ASSY, 60KV

Graco 24N666 60 kV Gun Body Assembly Kit

GG 255149

GG 262700

KIT,AIR CAP,HORIZONTAL

Graco 262700 Horizontal Air Cap Kit

KIT INCLUDES: AIR CAP, ASM, HORIZ, EXTERNAL MIX [QTY. 1], KIT INCLUDES: AIR CAP, ASM, INTERNAL MIX [QTY. 1],

GG 4-441-200

GG 94/0553/85

GG AEM613

TIP,MANUAL,ES

Graco AEM613 AEM Fine Finish Spray Tips, 0.013 inch (0.330 mm) Orifice Size, 12-14 inches (300-350 mm) Fan Width

• Coating Type: Standard

• Compatible Paint Type: Epoxy, High Solids, Lacquers, Plural Component Materials, Polyurethanes, Solventborne, Urethanes, UV Curing, Varnishes,

GG CST521

FRP RS CHOP TIP SPRAY 521

Graco CST521 0.021 in Orifice RS Airless Spray Gun Tip with 10 in Pattern Width

GG LTX513

RAC X LTX TIP, SPRAY, 513

Graco LTX513 RAC X SwitchTip, 513

The Reverse-A-Clean (RAC) 513 RAC X SwitchTip produces a 10 to 12 inch fan and has a 0.013 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Best Tip on the Market

  Longest lasting fan pattern

  Highest quality finish with a consistent spray pattern

• Easy to Identify Tip Size

  Large raised tip size numbers are always legible - even when covered with paint

• Superior Tip Design

  Locking tab ensures tip stays securely in guard

  Snaps tip in spray or reverse position

  OneSeal tip gasket installs with no tools

  Solvent seal available when using extremely hot solvents

• Model: RAC X
• Series: LTX SwitchTip

• Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain

• For Use With: RAC X HandTite Tip Guard

• Maximum Fan Width (cm): 25
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 305

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.013

• Pattern Size (in): 10 to 12
• Pattern Size (mm): 254 to 304.8

GV 123004

IR 125-A

Air Needle Scaler, 4800 BPM, 1-1/8" Stroke

Description: Great for surface preparation work involving the cleaning and removal of paint, rust, dirt or weld slag, the 125 Series Needle Scalers are a durable, dependable and economic option. This series comes with 19 needles, each with a diameter of 1/8".

Features And Benefits:

• Durability: Reengineered needle spring delivers more than twice the life of its previous version.
• Versatility: Can be used with 1/8" round needles (Qty 19) or with chisel attachments to match up with many of your surface preparation needs.
• Uses: Powerfully cleans surfaces by removing old paint, rust, dirt and weld slag from metal quickly without letting the grime collect in hard to reach areas like solvents do.

Product Application and Uses:

Remove Paint, Rust, Dirt, Weld Slags

• Includes: 19 steel precision heat-treated needles (1/8" diameter 7" Length)
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 20
• Air Consumption @ Load (l/min): 566
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Blows per Min: 4800
• Bore Diameter (in): 1

• Color: Black
• Configuration/Handle Type: Straight
• Duty Rating: Medium Duty

• Housing Material: Steel

• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Needle Qty: 19 Needles

• Non Sparking: No
• Power Source: Air Powered
• Product Length (in): 18.3

• Product Width (in): 3.5
• Product Height (in): 2.37
• Product Weight (lb): 6.24

• Sound Pressure/Power Db(A): 96.3 / 107.3
• Standards/Certifications: Ce, Eac
• Stroke Length (in): 1.13

• Vibration Level (m/s2): 9.6
• Warranty: 1-year

• Accessories: PF2219-22-19

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 125-A-20
• Parts: 125-A-227

• Parts: 125-A-24

IR 2135-D249A

Power Regulator Assembly for Ingersoll Rand 2135 Series Impact Wrench

• For Use With: 2135PQXPA
• For Use With: 2135QXPA-2

IR 2145-11X

Wear Plate for Ingersoll Rand 2145 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2145QIMAX, 2145QIMAX-3, 2145QIMAX-6, and 2155QIMAX Impacts

• For Use With: 2145QIMAX
• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6
• For Use With: 2155QIMAX

IR M007RVR000AR4

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 20000 RPM, 0.7 HP, 0.85 NM, Reversible

Features And Benefits:

• Safety: Meets ATEX Standards

• Air Consumption at Max HP (scfm): 33
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Drive Size (in): 1/2
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide and Anodize
• Gear Ratio: 1:1
• Gear Reduction: Direct Drive
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 20000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 0.6
• Max Torque (in-lb): 7.5
• Max Torque (nm): 0.85
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Flanged Mounting

• Number of Mounting Holes: 2
• Power Source: Air Powered

• Product Weight (lb): 3.06
• Rated Power (hp): 0.7
• Rated Power (kW): 0.52
• Reversible: Reversible

• Speed at Max Power (rpm): 10000
• Standards/Certifications: ATEX
• Starting Torque (ft-lb): 0.5
• Starting Torque (nm): 0.64

• Warranty: 1-year

LOB 10454

MP 69694201
