Parts

GG 25D460

GG 25D477

GG 25D480

KIT,12 VALVE CC CONTROL

Graco 25D480 12 Valve Color Change Solenoid Module Kit

GG 25D482

KIT,14 VALVE CC CONTROL

Graco 25D482 14 Valve Color Change Solenoid Module Kit

GG 25D483

KIT,15 VALVE CC CONTROL

Graco 25D483 15 Valve Color Change Solenoid Module Kit

GG 25D486

KIT, 18 VALVE CC CONTROL

Graco 25D486 18 Valve Color Change Solenoid Module Kit

GG 25D529

GG 25D543

KIT, PD2K REMOTE MANIFOLD, DVM LP

Graco 25D543 ProMix PD2K Low Pressure Remote Manifold Custom Valve Mapping Kit

To add optional color change function and at-the-gun mixing of two component materials when used with a ProMix PD Proportioner for Automatic Spray Applications.

• Model: ProMix
• Series: PD2K

GG 25D605

KIT, PD2K REMOTE MAN, DVM HP

Graco 25D605 ProMix PD2K High Pressure Remote Manifold Custom Valve Mapping Kit

To add optional color change function and at-the-gun mixing of two component materials when used with a ProMix PD Proportioner for Automatic Spray Applications.

• Model: ProMix
• Series: PD2K

GG 25E005

GG 25E139

GG 25E268

GG 25E447

GG 25E595

GG 25E619

GG 25E620

gg 25F088

GG 25F109

KIT, ACCESSORY, LEAK SENSE HAZ

Graco 25F109 Hazardous Location Leak Sensor Accessory Kit

• Includes:


  1 level switch sensor

  2 elbow swivels (1/4 in. NPT, 3/8 in. hose port)

  1 tee union

  1 hose (30 in. long, 3/8 in. outer diameter)

  1 elbow swivel (1/4 in. NPT, 1/4 in hose port)

  1 elbow swivel (1/8 in. NPT)

  1 hose (20 in. long, 1/4 in. outer diameter)

  1 pipe bushing

GG 25F155

MANIFOLD, AUTO, GUN

Graco 25F155 Stellair Auto Manifold, Side Fluid Inlet, with Inch Threads

Side fluid inlet manifold connects a Stellair Auto air spray gun to an automated finishing system's robot, reciprocator, or flat line machine.

• Stellair Auto manifold has the same tool center point as legacy AirPro Auto air spray guns, making it easy to upgrade paint line and spray booth equipment.
• Durable and lightweight construction reduces equipment wear, especially on high speed production lines.
• Two-screw, gun-to-manifold connection simplifies automatic air spray gun removal and maintenance.

GG 25F233

GG 25F328

GG 25F344

GG 25M405

SD SERIES SDM8 VALVE, 1/2NPT, RIGID, AF

Graco 25M405 SDM8 Series Electronic Manual Antifreeze Meter - Rigid Extension - 1/2 in. (13 mm) Inlet

Graco's premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Long valve life - cartridge spool valve specifically designed to reduce wear and reduce costly down time
• Ergonomic - four-finger trigger and easy-to-use button pad reduce worker fatigue
• Durable - Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: SDM8

• Compatible Material: Oil, Antifreeze, ATF, Gear Oil

• Dispense Type: Manual

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Rigid Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 8
• Maximum Flow Rate (L/min): 30

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Recorded Dispense: 9999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.3

• Minimum Flow Rate (GPM): 0.25
• Minimum Flow Rate (L/min): 0.9

• Minimum Operating Temperature ( degree C): -16
• Minimum Operating Temperature ( degree F): 4

• Nozzle Type: Manual

• Outlet Thread Type: Straight Thread O-Ring Boss

• Overall Height (cm): 14.6
• Overall Height (in): 5.75
• Overall Height (mm): 146
• Overall Length (cm): 33
• Overall Length (in): 13
• Overall Length (mm): 330
• Overall Width (cm): 9.5
• Overall Width (in): 3.75
• Overall Width (mm): 95

• Recommended Environment: Indoor

GG 25M410

SD SERIES SDM18 VALVE, 1/2NPT, RIGD, OIL, HF

Graco 25M410 SDM18 Series Electronic Manual Oil/Antifreeze Meter - Rigid Extension - 1/2 in. (13 mm) Inlet

Graco's premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Long valve life - cartridge spool valve specifically designed to reduce wear and reduce costly down time
• Ergonomic - four-finger trigger and easy-to-use button pad reduce worker fatigue
• Durable - Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: SDM18

• Compatible Material: Oil, Antifreeze, ATF, Gear Oil

• Dispense Type: Manual

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Rigid Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 18
• Maximum Flow Rate (L/min): 68

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Recorded Dispense: 9999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.3

• Minimum Flow Rate (GPM): 0.25
• Minimum Flow Rate (L/min): 0.9

• Minimum Operating Temperature ( degree C): -16
• Minimum Operating Temperature ( degree F): 4

• Nozzle Type: Manual

• Outlet Thread Type: Straight Thread O-Ring Boss

• Overall Height (cm): 14.6
• Overall Height (in): 5.75
• Overall Height (mm): 146
• Overall Length (cm): 33
• Overall Length (in): 13
• Overall Length (mm): 330
• Overall Width (cm): 9.5
• Overall Width (in): 3.75
• Overall Width (mm): 95

• Recommended Environment: Indoor

GG 25M417

SD SERIES SDM18 VALVE, 3/4NPT, FLEX, OIL, HF

Graco 25M417 SDM18 Series Electronic Manual Oil/Antifreeze Meter - Flexible Extension - 3/4 in. Inlet

Graco's premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Long valve life - cartridge spool valve specifically designed to reduce wear and reduce costly down time
• Ergonomic - four-finger trigger and easy-to-use button pad reduce worker fatigue
• Durable - Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: SDM18

• Compatible Material: Oil, Antifreeze, ATF, Gear Oil

• Dispense Type: Manual

• Display Type: Electronic

• Extension Type: Flexible

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Flexible Extension
• Inlet Size (cm): 1.905
• Inlet Size (in): 3/4
• Inlet Size (mm): 19.05

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 18
• Maximum Flow Rate (L/min): 68

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Recorded Dispense: 9999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.3

• Minimum Flow Rate (GPM): 0.25
• Minimum Flow Rate (L/min): 0.9

• Minimum Operating Temperature ( degree C): -16
• Minimum Operating Temperature ( degree F): 4

• Nozzle Type: Manual

• Outlet Thread Type: Straight Thread O-Ring Boss

• Overall Height (cm): 14.6
• Overall Height (in): 5.75
• Overall Height (mm): 146
• Overall Length (cm): 33
• Overall Length (in): 13
• Overall Length (mm): 330
• Overall Width (cm): 9.5
• Overall Width (in): 3.75
• Overall Width (mm): 95

• Recommended Environment: Indoor
