Kits

GG 687329

Kit, Repair, Pump, Lwr, Gh-3640

GG 7004

Kit, Parts, 2 Qt. Pressure Cup

GG 7418-F

Extension, Maxi/Mini, Pole Kit, F

GG 7418-SG

Extension, Mini/Maxi Pole Kit

GG 7506-A

Kit, Fitting, Angle Head

GG 7506-AG

Kit, Fitting, Angle Head

GG 7722

Kit, Accessory, Cover, 9In X 1/2In

GG 7723

Kit, Accessory, Cover, 9In X 3/4In

GG 77X111

KIT, INJ, STDDRUM, 24VDC, HP, 120#

Graco 77X111 Standard Drum Injector Kits - 24 VDC HP Pump, Vent Valve, Cover with Tube-in-Tube for 120 lb (55 kg). Reservoir

The Dyna-Star HP and HF 24VDC Electric Lubrication Pumps complement our Dyna-Star 10:1 Hydraulic and Fire-Ball 300 50:1 Pneumatic pump offering. Now you have three power source options for automatic lubrication systems and transfer applications. Heavy-duty construction and mining equipment rely on fresh lubricant to flush contaminants from critical pivot points. An automatic lubrication system from Graco provides continuous lube replenishment, reducing expensive component failures to keep your equipment working.

Application: Electric pumps for heavy duty automatic lubrication and transfer systems.

• Auto Fill Shut Off - mechanical shut off of fill pump for clean and efficient refill
• Graco Advantage Drive - heavy duty gear drive-lubed for life
• Tube-in-tube vent and fill path - convert drum to injector system instantly
• Motor control - speed and AMP control
• Cold weather performance (-40º C)
• More efficient seal replacement

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• Application: In-Plant Machinery, Off-Road Equipment

• Compatible Material: Grease
• Compatible Metering Device: Single Line Parallel

• Fluid Outlet Size (in): 0.375
• Fluid Outlet Size (mm): 9.5250
• Fluid Outlet Thread Type: NPT

• Includes: HP Pump 24 VDC, Vent Valve, Tube-in-Tube, Cover for 120 pound reservoir

• IP Rating: IP69K

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (MPa): 34.5
• Maximum Working Pressure (psi): 5000

• Minimum cST Grade (cST): 40

• Motor Type: Electric Motor

• Overall Height (cm): 92.7
• Overall Height (in): 36.5
• Overall Height (mm): 927
• Overall Width (cm): 27.9
• Overall Width (in): 11
• Overall Width (mm): 279

• Power Connection Type: M23

• Power Type: Electric

GG 77X112

KIT, INJ, STDDRUM, 24VDC, HP, 400#

Graco 77X112 Standard Drum Injector Kits - 24 VDC HP Pump, Vent Valve, Cover with Tube-in-Tube for 400 lb (180 kg) Reservoir

The Dyna-Star HP and HF 24VDC Electric Lubrication Pumps complement our Dyna-Star 10:1 Hydraulic and Fire-Ball 300 50:1 Pneumatic pump offering. Now you have three power source options for automatic lubrication systems and transfer applications. Heavy-duty construction and mining equipment rely on fresh lubricant to flush contaminants from critical pivot points. An automatic lubrication system from Graco provides continuous lube replenishment, reducing expensive component failures to keep your equipment working.

Application: Electric pumps for heavy duty automatic lubrication and transfer systems.

• Auto Fill Shut Off - mechanical shut off of fill pump for clean and efficient refill
• Graco Advantage Drive - heavy duty gear drive-lubed for life
• Tube-in-tube vent and fill path - convert drum to injector system instantly
• Motor control - speed and AMP control
• Cold weather performance (-40º C)
• More efficient seal replacement

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• Application: In-Plant Machinery, Off-Road Equipment

• Compatible Material: Grease
• Compatible Metering Device: Single Line Parallel

• Fluid Outlet Size (in): 0.375
• Fluid Outlet Size (mm): 9.5250
• Fluid Outlet Thread Type: NPT

• Includes: HP Pump 24 VDC, Vent Valve, Tube-in-Tube, Cover for 400 lb (180 kg) reservoir

• IP Rating: IP69K

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (MPa): 34.5
• Maximum Working Pressure (psi): 5000

• Minimum cST Grade (cST): 40

• Motor Type: Electric Motor

• Overall Height (cm): 112.5
• Overall Height (in): 44.3
• Overall Height (mm): 1125
• Overall Width (cm): 27.9
• Overall Width (in): 11
• Overall Width (mm): 279

• Power Connection Type: M23

• Power Type: Electric

GG 77X121

KIT, STDRUM, 24VDC, HF, 90/120#

Graco 77X121 Standard Drum Kits - 24 VDC HF Pump and Cover for 120 lb (55 kg) Reservoir

The Dyna-Star HP and HF 24VDC Electric Lubrication Pumps complement our Dyna-Star 10:1 Hydraulic and Fire-Ball 300 50:1 Pneumatic pump offering. Now you have three power source options for automatic lubrication systems and transfer applications. Heavy-duty construction and mining equipment rely on fresh lubricant to flush contaminants from critical pivot points. An automatic lubrication system from Graco provides continuous lube replenishment, reducing expensive component failures to keep your equipment working.

Application: Electric pumps for heavy duty automatic lubrication and transfer systems.

• Auto Fill Shut Off - mechanical shut off of fill pump for clean and efficient refill
• Graco Advantage Drive - heavy duty gear drive-lubed for life
• Tube-in-tube vent and fill path - convert drum to injector system instantly
• Motor control - speed and AMP control
• Cold weather performance (-40º C)
• More efficient seal replacement

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• Application: In-Plant Machinery, Off-Road Equipment

• Compatible Material: Grease
• Compatible Metering Device: Single Line Parallel

• Fluid Outlet Size (in): 0.375
• Fluid Outlet Size (mm): 9.5250
• Fluid Outlet Thread Type: NPT

• Includes: HF Pump 24 VDC, Cover for 400 pound reservoir

• IP Rating: IP69K

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 24.1
• Maximum Working Pressure (psi): 3500

• Minimum cST Grade (cST): 40

• Motor Type: Electric Motor

• Overall Height (cm): 92.7
• Overall Height (in): 36.5
• Overall Height (mm): 927
• Overall Width (cm): 27.9
• Overall Width (in): 11
• Overall Width (mm): 279

• Power Connection Type: M23

• Power Type: Electric

GG 77X127

Kit, Eds Parts, Bti

GG 77X540

Kit, Vent, Valve 24Vdc Pump Mnt

GG 77X541

Kit, Filter And Seal

GG 77X543

KIT, ADAPTER, OUTLET, 4000PSI

Dyna-Star® Accessories - HF Manifold with 4,000 psi Pressure Relief

GG 77X544

KIT, ADAPTER, OUTLET, 5000PSI

Dyna-Star® Accessories - HP Manifold with 5,000 psi Pressure Relief

GG 77X545

KIT, HARNESS, EDS, 15', N/VV

Dyna-Star® Accessories - Power Cable for Series Progressive Systems, M23 Connector, 15 ft (4.6 m)

GG 77X546

KIT, HARNESS, EDS, 15', W/VV

Dyna-Star® Accessories - Power Cable for Injector Systems, M23 Connector, 15 ft (4.6 m)

GG 77X551

KIT, HARNESS, 4" FRONT MOUNT

Cable Harness Kits - Power Cable, Straight, 15 feet, Vent Valve For use with Electric Dyna-Star® HP Lubrication Systems.

GG 77X990

KIT, EDS HP, AFSO, LL, 90#

Graco 77X990 Dyna-Star® 24 VDC HP Pump, AFSO, Low Level, GLC 2200, Wiring Harness, Cables, Pressure Switch, Remote Fill Manifold for 90 lb (41 kg).

Heavy-duty construction and mining equipment rely on fresh lubricant to flush contaminants from critical pivot points. An automatic lubrication system from Graco provides continuous lube replenishment, reducing expensive component failures to keep your equipment working.

Application: Electric pumps for heavy duty automatic lubrication and transfer systems.

• Auto Fill Shut Off - mechanical shut off of fill pump for clean and efficient refill
• Graco Advantage Drive - heavy duty gear drive - lubed for life
• Tube-in-tube vent and fill path - convert drum to injector system instantly
• Motor control - speed and AMP control
• Cold weather performance (-40°C)
• More efficient seal replacement
• Remote Fill Manifold with Vent (with built in pressure gauge) allows you to conveniently locate the fill port where you want it

• Model: Dyna-Star

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Grease

• Fluid Outlet Size (in): 0.375
• Fluid Outlet Size (mm): 9.5250
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Includes: 24 VDC HP pump with Auto-Fill Shutoff and Low-Level Monitor, GLC2200 Controller, Wiring Harness, Low-Level Sensor Cable, Power Cable, Pressure Switch, Remote Fill Manifold for 90 pound reservoir

• IP Rating: IP69K

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 344
• Maximum Working Pressure (kPa): 34400
• Maximum Working Pressure (MPa): 34.4
• Maximum Working Pressure (psi): 5000

• Minimum cST Grade (cST): 40

• Minimum Voltage (V dc): 18

• Motor Type: Electric Motor

• Overall Depth (cm): 41
• Overall Depth (in): 16.13
• Overall Depth (mm): 410

• Overall Height (cm): 96.5
• Overall Height (in): 38
• Overall Height (mm): 965
• Overall Width (cm): 36.8
• Overall Width (in): 14.5
• Overall Width (mm): 368

• Power Connection Type: M12

• Power Type: Electric

GG 800708

Kit, Spray Tip #04

GG 800742

Kit, Thermal Relief Valve 3/8

GG 803510

Kit, Repair, Plunger #107

GG 803511

Kit, Packing #109

GG 803512

Kit, Packing&Retainer #112
