Kit, Bare Preset Meter

GG 25N771

KIT, BARE PRESET METER

Graco 25N771 SDP Series Electronic Preset Oil Bar Meter

Gracoâ€™s premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

Upgradeableâ€”SD Preset meters are compatible with PULSE FC fluid control system
Large, Intuitive Displayâ€”high-contrast display for low and bright light conditions
Long valve lifeâ€”cartridge spool valve specifically designed to reduce wear and reduce costly down time
Reliableâ€”time-tested Graco engineering
Durableâ€”Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
Long battery lifeâ€”uses 4 AA easy-to-replace batteries

Model: SD

Compatible Material: Oil, Antifreeze, ATF, Gear Oil

Dispense Type: Preset

Display Type: Electronic

Extension Type: Bare

Fluid Inlet Thread Gender: Female

Fluid Outlet Thread Gender: Female

Includes: Bare Meter

Maximum Flow Rate (GPM): 8
Maximum Flow Rate (L/min): 30

Maximum Operating Temperature (Â°C): 70
Maximum Operating Temperature (Â°F): 158

Maximum Recorded Dispense: 9999

Maximum Storage Temperature (Â°C): 70
Maximum Storage Temperature (Â°F): 158

Maximum Working Pressure (bar): 103.4
Maximum Working Pressure (kPa): 10340
Maximum Working Pressure (MPa): 10.3
Maximum Working Pressure (psi): 1500
Meter Accuracy (%): Â±0.5
Meter Technology: Oval Gear

Metering Gun Weight (kg): 2.4
Metering Gun Weight (lb): 5.3

Minimum Flow Rate (GPM): 0.25
Minimum Flow Rate (L/min): 0.9

Minimum Operating Temperature (Â°C): -16
Minimum Operating Temperature (Â°F): 4

Nozzle Type: None

Outlet Thread Type: Straight Thread O-Ring Boss

Overall Height (cm): 14.6
Overall Height (in): 5.75
Overall Height (mm): 146
Overall Length (cm): 33
Overall Length (in): 13
Overall Length (mm): 330
Overall Width (cm): 9.5
Overall Width (in): 3.75
Overall Width (mm): 95
