Hose and Tubing

GG 17K265

HOSE, CPLED, 4000PSI, 400F, 6', #10

Graco 17K265 6 ft. (1.8 M) Stainless Steel Braided PTFE Ambient Hose, No. 10 (0.495 in. / 12.6 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 0.495
• Hose Diameter (mm): 12.6
• Hose Heating Type: Ambient
• Hose Length (ft): 6
• Hose Length (m): 1.8

• Inside Diameter (in): 0.495
• Inside Diameter (mm): 12.573

• JIC Size: JIC 10

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature (°C): 100
• Maximum Temperature (°F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 17K266

HOSE, CPLED, 4000PSI, 400F, 10'#10

Graco 17K266 10 ft. (3.0 M) Stainless Steel Braided PTFE Ambient Hose, No. 10 (0.495 in. / 12.6 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 0.495
• Hose Diameter (mm): 12.6
• Hose Heating Type: Ambient
• Hose Length (ft): 10
• Hose Length (m): 3

• Inside Diameter (in): 0.495
• Inside Diameter (mm): 12.573

• JIC Size: JIC 10

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature ( degrees C): 100
• Maximum Temperature ( degrees F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 17K269

HOSE, CPLED, 4000PSI, 400F, 25'#10

Graco 17K269 25 ft. (7.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 10 (0.495 in. / 12.6 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 0.495
• Hose Diameter (mm): 12.6
• Hose Heating Type: Ambient
• Hose Length (ft): 25
• Hose Length (m): 7.6

• Inside Diameter (in): 0.495
• Inside Diameter (mm): 12.573

• JIC Size: JIC 10

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature (°C): 100
• Maximum Temperature (°F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 17K276

HOSE, CPLED, 4000PSI, 400F, 25'#12

Graco 17K276 25 ft. (7.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 12 (0.617 in. / 15.7 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 0.617
• Hose Diameter (mm): 15.7
• Hose Heating Type: Ambient
• Hose Length (ft): 25
• Hose Length (m): 7.6

• Inside Diameter (in): 0.617
• Inside Diameter (mm): 15.672

• JIC Size: JIC 12

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature (°C): 100
• Maximum Temperature (°F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 17K281

HOSE, CPLED, 4000PSI, 400F, 25'#16

Graco 17K281 25 ft. (7.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 16 (0.867 in. / 22.0 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 0.867
• Hose Diameter (mm): 22.0
• Hose Heating Type: Ambient
• Hose Length (ft): 25
• Hose Length (m): 7.6

• Inside Diameter (in): 0.867
• Inside Diameter (mm): 22.022

• JIC Size: JIC 16

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature (°C): 100
• Maximum Temperature (°F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 17K283

HOSE, CPLED, 3000PSI, 400F, 15'#20

Graco 17K283 15 ft. (4.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 20 (1.125 in. / 28.6 mm ID)

Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.

• For use with Graco sealants and adhesives systems.

• Hose Diameter (in): 1.125
• Hose Diameter (mm): 28.6
• Hose Heating Type: Ambient
• Hose Length (ft): 15
• Hose Length (m): 4.6

• Inside Diameter (in): 1.125
• Inside Diameter (mm): 28.6

• JIC Size: JIC 20

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature (°C): 100
• Maximum Temperature (°F): 212

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 3000

GG 17S558

GG 192871

GG 196094

GG 19M408

THERM-O-FLOW HOSE, HEATED, 25-FT, #10, 3000 PSI

Graco 19M408 25 ft. (7.6 M) Insulated Stainless Steel Braided PTFE Warm Melt/Hot Melt Heated Hose, No. 10 (0.495 in. / 12.6 mm ID)

Graco heated hoses are designed to give accurate and uniform temperature conditioning for your Sealant and Adhesive applications. Use these hoses to keep your material at the ideal temperature for the best possible dispense quality.

• For use with Graco temperature control systems for warm melt and hot melt sealants and adhesives.
• Maximum Fluid Working Pressure is dependent on operating temperature.
• Rated at 4000 psi (276 bar, 27.6 MPa) at Temperatures from -65°F to 212°F (-54°C to 100°C)

• Hose Heating Type: Heated
• Hose Length (ft): 25
• Hose Length (m): 7.6

• Inside Diameter (in): 0.495
• Inside Diameter (mm): 12.6

• Material: PTFE Lined Stainless Steel Braid

• Maximum Temperature (°C): 204
• Maximum Temperature (°F): 400

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 2005139

GG 2009998

GG 203266

GG 205406

GG 21054-01

GG 215445

GG 218689

GG 220593

GG 221092

GG 235072

HOSE, COUPLED

Graco 235072 Grounded Air Hose with stainless steel braid ground path (Red)- 0.315 in. (8 mm) ID, 1/4 npsm(f) x 1/4 npsm(f) left-hand thread, 50 ft (15 m) length

GG 235073

HOSE, COUPLED

Graco 235073 Grounded Air Hose with stainless steel braid ground path, Red, 75 ft (23 m)

GG 236410

GG 237522

HOSE, COUPLED

Graco 237522 Nylon Coupled Hose, 6 ft (1.8 m) long, 1 in. (25 mm) ID for 10:1 Bulldog Portable Hydra-Clean Unit

GG 239634

HOSE, FLUID,3/16 I.D.

Graco 239634 25 ft Fluid Hose Assembly (3/16 in)

• Bleed Type: Non-Bleeder

• Compatible Material: CARC, Enamel, Epoxies, Fast-Set, High Solids, Latex, Plural Component Materials, Sealants, Solventborne, Urethane, Waterborne

GG 239637
