IR 335SC4A
Air Die Grinder, 35,000 RPM, 0.37 HP, 1/4" and 6mm Collet, Rear Exhaust
Features And Benefits:
- Comfort: The Revolution Series Die Grinder has composite housing that is lightweight, contoured for comfort, and protects operators from temperature fluctuations.
- Performance: precision gearing and components contribute to long and reliable tool life.
- 1-year warranty.
Product Application and Uses:
Finishing, cutting, polishing, porting, light weld grinding, and breaking sharp edges.
- Includes: Tool, Large Wrench, Small Wrench, 6mm collet
- Actuation/Throttle Type/Switch Location: Handle
- Actuation/Throttle Type/Switch Type: Safety Lever
- Air Consumption @ Load (cfm): 30
- Air Consumption @ Load (l/min): 851
- Air Inlet: 1/4" NPT
- Air Pressure (psi): 90
- Arbor/Collet: 1/4"
- Arbor/Collet: 6mm
- Bearing Type: Ball Bearing
- Configuration/Handle Type: Straight
- Duty Rating: Heavy Duty
- Grinder Type: Die Grinder
- Guard Material: Steel
- Handle Material: Composite
- Height Over Spindle (in): 2.68
- Housing Material: Composite
- Lock Mechanism: Lever lock in off position
- Max Free Speed (rpm): 35000
- Max Pressure (bar): 6.2
- Min Hose Size (in): 3/8
- Power Source: Air Powered
- Product Length (in): 6.5
- Product Weight (lb): 0.9
- Rated Power (hp): 0.37
- Right Angle Length (in): 6.69
- Right Angle Length (mm): 170
- Side to Center Distance (in): 0.79
- Side to Center Distance (mm): 20
- Sound Pressure/Power Db(A): 78.4 / 89.4
- Vibration Level (m/s2): 3
- Warranty: 1-year
- Lubrication: 10P
- Parts: 03A-VAR-KIT
