POWER MOTOR
IR 7811-B
IR 7811-B
Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 250 RPM, 0.7 HP, 74 NM, Reversible
Air Consumption at Max HP (scfm): 37.3Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 250
Max Pressure (bar): 6.2
Max Torque (ft-lb): 55
Max Torque (in-lb): 655
Max Torque (nm): 74
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 5.17
Rated Power (hp): 0.7
Rated Power (kW): 0.52
Reversible: Reversible
Sound Level dB(A): 85
Speed at Max Power (rpm): 130
Torque Output @ Max HP (ft-lb): 29
Torque Output @ Max HP (nm): 38.7
Warranty: 1-year
$2,322.00
O-Ring 74-3M Non-Returnable Part
IR 5823-5129
IR 5823-5129
O-Ring 74-3M Non-Returnable Part Call for pricing
O-Ring 92-3M Non-Returnable Part
IR 5823-5229
IR 5823-5229
O-Ring 92-3M Non-Returnable Part Call for pricing
1 1/2 Inch Impacttool
IR 5980A1
IR 5980A1
1-1/2" Air Impact Wrench, Super Duty, 10,000 ft-lb Torque, Thru-hole Retainer, T-handle
The 5980 series is not only one of the most powerful impacts in the industry, they are also one of the most durable and reliable.Features And Benefits
- Durability: With an aluminum hammer case, metal housing, and bronze end-plate, this series is corrosion resistant. It will last through just about anything.
- Reliability: Ingersoll Rand products are built to last, and this series is no different. These tools will deliver the right amount of power every time you pull the trigger.
- Power: This series has a high torque output of 10,000 ft.-lbs. max. torque and the planetary gear drive delivers smooth constant speed from the motor, so you never have to worry about power.
- Built-in lubricator
Product Application and Uses: Engineered to withstand the harshest working conditions in oilfields, mines, and shipyards
Actuation/Throttle Type/Switch Type: Lever
Air Inlet: 3/4" NPT
Air Pressure (psi): 90
Anvil Length: Standard
Average Air Consumption (cfm): 138
Average Air Consumption (l/min): 3908
Blows per Min: 1000
Color: Grey
Configuration/Handle Type: T-handle
Drive Size (in): 1-1/2
Drive Type: Square
Duty Rating: Super Duty
End Plates: Bronze
Exhaust Location: Bottom
Free Speed Sound Pressure/Power Db(A): 103.1 / 114.1
Gear Train: Planetary
Hammer Case: Aluminum
Handle Material: Composite
Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
Impact Mechanism: Ball and Cam
Max Bolt Diameter (in): 2
Max Free Speed (rpm): 830
Max Pressure (bar): 6.2
Max Torque (ft-lb): 10000
Max Torque (in-lb): 119998
Max Torque (nm): 13558
Min Hose Size (in): 1
Motor: Non-Biased
Number of Power Settings: Continuous
Power Source: Air Powered
Product Length (in): 23
Product Weight (lb): 88
Recommended Forward Torque Range (ft-lb): 5500
Recommended Forward Torque Range (in-lb): 66000
Recommended Forward Torque Range (nm): 7457
Retainer Type: Thru-hole
Side to Center Distance (in): 3.06
Side to Center Distance (mm): 78
Speed Setting: Variable Speed
Standards/Certifications: CE
Tool Type: Full-size
Vanes: 5
Vibration Level (m/s2): 20.5
Warranty: 1-year
Similar IR
- 588A1
- 5982A1
$15,606.00
Stylus Medium Tip
AA TP-EP51-516
AA TP-EP51-516
Medium Tip Stylus for Ingersoll Rand EP51 Engraving Pen
Product Application and Uses:
For use with Ingersoll Rand EP51 Air Engraving pen
$65.00
3" CHISEL - 18" SHK 1-1/8" X 6"
IR 50193754
IR 50193754
3" Pavement Breaker/Digger Chisel Steel, 18"L Hex 1-1/8" x 6" Shank
Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Choose from a complete line of tool steels for your pavement breaker, with products for many applications including concrete, asphalt, excavation, and general demolition.Includes: (5) Chisel Steels
Product Application and Uses: Designed for concrete demolition and asphalt cutting. For use with Ingersoll Rand PB50A, MX60A, MX90A pavement breakers.
Chisel Style: 3" Wide
Collar Type: Round
Collar Width (in): 1.563
Housing Material: Steel
Length Under Collar (in): 18
Product Length (in): 24
Product Width (in): 3
Product Weight (lb): 7.25
Shank Length (in): 6
Shank SIze (in): 1-1/8 x 6
Shank Type: Hex
For Use With
- MX60A
- MX90A
- PB50AL1
- PB50AS1
$106.00
NARROW CHISEL - 14" SHK 1-1/4" X 6" , QTY 5
IR 50196385
IR 50196385
1" Narrow Pavement Breaker/Digger Chisel Steel, 14"L Hex 1-1/4" x 6" Shank
Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Choose from a complete line of tool steels for your pavement breaker, with products for many applications including concrete, asphalt, excavation, and general demolition.Includes: (10) Chisel Steels
Product Application and Uses: Designed for general demolition. For use with Ingersoll Rand MX60B, MX90B pavement breakers.
Chisel Style: Narrow
Collar Type: Round
Collar Width (in): 1.563
Housing Material: Steel
Length Under Collar (in): 14
Product Length (in): 20
Product Width (in): 1
Product Weight (lb): 7.5
Shank Length (in): 6
Shank SIze (in): 1-1/4 x 6
Shank Type: Hex
For Use With
- MX60B
- MX90B
$100.00
END TRK-DUAL-ZRA2/FLAT TRACK, FLAT RAIL 1000#
IR 30918-2
IR 30918-2
END TRK-DUAL-ZRA2/FLAT TRACK, FLAT RAIL 1000# $2,270.00
MOTOR
IR 3800U
IR 3800U
Inline Multi-Vane Air Motor, 3/4" Keyed Shaft, 220 RPM, 1.45 HP, 189 NM, Non-reversible
Air Consumption at Max HP (scfm): 48Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 3/4
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Keyaway Length (in): 1.5
Max Free Speed (rpm): 220
Max Pressure (bar): 6.2
Max Torque (ft-lb): 139
Max Torque (in-lb): 1673
Max Torque (nm): 189
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Power Source: Air Powered
Product Length (in): 8.69
Product Width (in): 3.25
Product Height (in): 3.25
Product Weight (lb): 8.5
Rated Power (hp): 1.45
Rated Power (kW): 1.08
Reversible: Non-reversible
Speed at Max Power (rpm): 105
Standards/Certifications: ATEX
Starting Torque (ft-lb): 105
Starting Torque (nm): 142
Warranty: 1-year
$4,085.00
MOTOR
IR 3840Q
IR 3840Q
Inline Multi-Vane Air Motor, 3/4" Keyed Shaft, 280 RPM, 1.35 HP, 106 NM, Reversible
Air Consumption at Max HP (scfm): 44Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 3/4
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Keyaway Length (in): 1.5
Max Free Speed (rpm): 280
Max Pressure (bar): 6.2
Max Torque (ft-lb): 78
Max Torque (in-lb): 938
Max Torque (nm): 106
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Power Source: Air Powered
Product Length (in): 8.69
Product Width (in): 3.25
Product Height (in): 3.25
Product Weight (lb): 8.75
Rated Power (hp): 1.35
Rated Power (kW): 1.01
Reversible: Reversible
Speed at Max Power (rpm): 130
Standards/Certifications: ATEX
Starting Torque (ft-lb): 60
Starting Torque (nm): 81.4
Warranty: 1-year
$3,848.50
MOTOR
IR 3840P
IR 3840P
Inline Multi-Vane Air Motor, 3/4" Keyed Shaft, 440 RPM, 1.35 HP, 72.6 NM, Reversible
With durable inline planetary gearing and a robust vane motor, the 3800 Series is one of the most durable motors on the market.Features And Benefits
- Safety: Meets ATEX Standards
- Durable: The 3800 Series is designed to withstand harsh environments and keep on running.
- Ease of Service: Easily serviceable, the 3800 Series will enhance productivity by eliminating long repair times.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 44
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Length (in): 2.1875
Drive Size (in): 3/4
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Ratio: 19.3:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Keyaway Length (in): 1.5
Max Free Speed (rpm): 440
Max Pressure (bar): 6.2
Max Torque (ft-lb): 54
Max Torque (in-lb): 643
Max Torque (nm): 72.6
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Operating Temperature Range: 0F to 150F
Power Source: Air Powered
Product Length (in): 8.69
Product Width (in): 3.25
Product Height (in): 3.25
Product Weight (lb): 8.75
Rated Power (hp): 1.35
Rated Power (kW): 1.01
Reversible: Reversible
Speed at Max Power (rpm): 215
Standards/Certifications: ATEX
Starting Torque (ft-lb): 40
Starting Torque (nm): 54.2
Warranty: 1-year
$3,655.00
MOTOR
IR 3840M
IR 3840M
Inline Multi-Vane Air Motor, 3/4" Keyed Shaft, 825 RPM, 1.40 HP, 47.7 NM, Reversible
With durable inline planetary gearing and a robust vane motor, the 3800 Series is one of the most durable motors on the market.Features And Benefits
- Safety: Meets ATEX Standards
- Durable: The 3800 Series is designed to withstand harsh environments and keep on running.
- Ease of Service: Easily serviceable, the 3800 Series will enhance productivity by eliminating long repair times.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 44
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Length (in): 2.1875
Drive Size (in): 3/4
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Ratio: 19.3:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Keyaway Length (in): 1.5
Max Free Speed (rpm): 825
Max Pressure (bar): 6.2
Max Torque (ft-lb): 35
Max Torque (in-lb): 422
Max Torque (nm): 47.7
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Operating Temperature Range: 0F to 150F
Power Source: Air Powered
Product Length (in): 8.69
Product Width (in): 3.25
Product Height (in): 3.25
Product Weight (lb): 7.38
Rated Power (hp): 1.40
Rated Power (kW): 1.04
Reversible: Reversible
Speed at Max Power (rpm): 390
Standards/Certifications: ATEX
Starting Torque (ft-lb): 23
Starting Torque (nm): 31.2
Warranty: 1-year
$3,418.50
PLATE, VALVE CHEST, FAB, MK-549, NO PAINT
IR 382-35944
IR 382-35944
PLATE, VALVE CHEST, FAB, MK-549, NO PAINT $197.00
Kit, Servise, Brake, FA150KGMR
IR 382-31483
IR 382-31483
Kit, Servise, Brake, FA150KGMR Call for pricing
MOTOR
IR 3840S
IR 3840S
Inline Multi-Vane Air Motor, 3/4" Keyed Shaft, 190 RPM, 1.35 HP, 156 NM, Reversible
With durable inline planetary gearing and a robust vane motor, the 3800 Series is one of the most durable motors on the market.Features And Benefits
- Safety: Meets ATEX Standards
- Durable: The 3800 Series is designed to withstand harsh environments and keep on running.
- Ease of Service: Easily serviceable, the 3800 Series will enhance productivity by eliminating long repair times.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 44
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Length (in): 2.1875
Drive Size (in): 3/4
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Ratio: 19.3:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Keyaway Length (in): 1.5
Max Free Speed (rpm): 190
Max Pressure (bar): 6.2
Max Torque (ft-lb): 115
Max Torque (in-lb): 1381
Max Torque (nm): 156
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Operating Temperature Range: 0F to 150F
Power Source: Air Powered
Product Length (in): 8.69
Product Width (in): 3.25
Product Height (in): 3.25
Product Weight (lb): 8.75
Rated Power (hp): 1.35
Rated Power (kW): 1.01
Reversible: Reversible
Speed at Max Power (rpm): 100
Standards/Certifications: ATEX
Starting Torque (ft-lb): 86
Starting Torque (nm): 116
Warranty: 1-year
$4,042.00
MOTOR
IR 3840U
IR 3840U
Inline Multi-Vane Air Motor, 3/4" Keyed Shaft, 162 RPM, 1.35 HP, 181 NM, Reversible
With durable inline planetary gearing and a robust vane motor, the 3800 Series is one of the most durable motors on the market.Features And Benefits
- Safety: Meets ATEX Standards
- Durable: The 3800 Series is designed to withstand harsh environments and keep on running.
- Ease of Service: Easily serviceable, the 3800 Series will enhance productivity by eliminating long repair times.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 44
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Length (in): 2.1875
Drive Size (in): 3/4
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Ratio: 19.3:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Keyaway Length (in): 1.5
Max Free Speed (rpm): 162
Max Pressure (bar): 6.2
Max Torque (ft-lb): 133
Max Torque (in-lb): 1602
Max Torque (nm): 181
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Operating Temperature Range: 0F to 150F
Power Source: Air Powered
Product Length (in): 8.69
Product Width (in): 3.25
Product Height (in): 3.25
Product Weight (lb): 8.75
Rated Power (hp): 1.35
Rated Power (kW): 1.01
Reversible: Reversible
Speed at Max Power (rpm): 83
Standards/Certifications: ATEX
Starting Torque (ft-lb): 100
Starting Torque (nm): 135
Warranty: 1-year
$4,950.00
MOTOR
IR 3840Q2
IR 3840Q2
Inline Multi-Vane Air Motor, 3/4" Square Shaft, 280 RPM, 1.35 HP, 106 NM, Reversible
Air Consumption at Max HP (scfm): 44Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 3/4
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Keyaway Length (in): 1.5
Max Free Speed (rpm): 280
Max Pressure (bar): 6.2
Max Torque (ft-lb): 78
Max Torque (in-lb): 938
Max Torque (nm): 106
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Operating Temperature Range: 0F to 150F
Power Source: Air Powered
Product Length (in): 8.69
Product Width (in): 3.25
Product Height (in): 3.25
Product Weight (lb): 8.75
Rated Power (hp): 1.35
Rated Power (kW): 1.01
Reversible: Reversible
Speed at Max Power (rpm): 130
Standards/Certifications: ATEX
Starting Torque (ft-lb): 60
Starting Torque (nm): 81.4
Warranty: 1-year
$3,956.00
MOTOR
IR 3840R
IR 3840R
Inline Multi-Vane Air Motor, 3/4" Keyed Shaft, 238 RPM, 1.35 HP, 125 NM, Reversible
Air Consumption at Max HP (scfm): 44Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 3/4
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Keyaway Length (in): 1.5
Max Free Speed (rpm): 238
Max Pressure (bar): 6.2
Max Torque (ft-lb): 92
Max Torque (in-lb): 1106
Max Torque (nm): 125
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Power Source: Air Powered
Product Length (in): 8.69
Product Width (in): 3.25
Product Height (in): 3.25
Product Weight (lb): 8.75
Rated Power (hp): 1.35
Rated Power (kW): 1.01
Reversible: Reversible
Speed at Max Power (rpm): 122
Standards/Certifications: ATEX
Starting Torque (ft-lb): 69
Starting Torque (nm): 93
Warranty: 1-year
$4,063.50
RIGID END TRUCK - ZRA1/T ON ZRA2 12 INCH 45519618-1200
IR 45519618-1200
IR 45519618-1200
RIGID END TRUCK - ZRA1/T ON ZRA2 12 INCH 45519618-1200 $1,570.00
VACUUM CUP, ROUND, 8.63 DIAMETER, 60 DUROMETER
IR 47549516001
IR 47549516001
VACUUM CUP, ROUND, 8.63 DIAMETER, 60 DUROMETER $275.00
VACUUM CUP, ROUND, 7.042 DIAMETER, 50 DUROMETER
IR 47549517001
IR 47549517001
VACUUM CUP, ROUND, 7.042 DIAMETER, 50 DUROMETER $155.00
MOTOR
IR 4800M
IR 4800M
Inline Multi-Vane Air Motor, 1" Keyed Shaft, 1050 RPM, 3.7 HP, 93.6 NM, Non-reversible
The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.Features And Benefits
- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you’ll be able to spend more time focused on the job.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1050
Max Pressure (bar): 6.2
Max Torque (ft-lb): 69
Max Torque (in-lb): 828
Max Torque (nm): 93.6
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Power Source: Air Powered
Product Length (in): 11.38
Product Width (in): 4
Product Height (in): 4
Product Weight (lb): 15.25
Rated Power (hp): 3.7
Rated Power (kW): 2.76
Reversible: Non-reversible
Speed at Max Power (rpm): 560
Standards/Certifications: ATEX
Starting Torque (ft-lb): 51
Starting Torque (nm): 69.2
Warranty: 1-year
$5,525.00
MOTOR
IR 4800U2
IR 4800U2
Inline Multi-Vane Air Motor, 1" Square Shaft, 185 RPM, 3.5 HP, 480 NM, Non-reversible
The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.Features And Benefits
- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you’ll be able to spend more time focused on the job.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Length (in): 2.25
Drive Size (in): 1
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Ratio: 53.5:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 185
Max Pressure (bar): 6.2
Max Torque (ft-lb): 354
Max Torque (in-lb): 4248
Max Torque (nm): 480
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Operating Temperature Range: 0F to 150F
Power Source: Air Powered
Product Length (in): 11.38
Product Width (in): 4
Product Height (in): 4
Product Weight (lb): 19.75
Rated Power (hp): 3.5
Rated Power (kW): 2.61
Reversible: Non-reversible
Speed at Max Power (rpm): 97
Standards/Certifications: ATEX
Starting Torque (ft-lb): 265
Starting Torque (nm): 359
Warranty: 1-year
$6,750.00
MOTOR
IR 4840K
IR 4840K
Inline Multi-Vane Air Motor, 1" Keyed Shaft, 1429 RPM, 3.2 HP, 57 NM, Reversible
Features And Benefits- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you’ll be able to spend more time focused on the job.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1429
Max Pressure (bar): 6.2
Max Torque (ft-lb): 42
Max Torque (in-lb): 504
Max Torque (nm): 57
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Power Source: Air Powered
Product Length (in): 11.38
Product Width (in): 4
Product Height (in): 4
Product Weight (lb): 15.25
Rated Power (hp): 3.2
Rated Power (kW): 2.39
Reversible: Reversible
Speed at Max Power (rpm): 711
Standards/Certifications: ATEX
Starting Torque (ft-lb): 32
Starting Torque (nm): 43.4
Warranty: 1-year
$4,988.00
MOTOR
IR 4840M
IR 4840M
Inline Multi-Vane Air Motor, 1" Keyed Shaft, 975 RPM, 3.2 HP, 85.4 NM, Reversible
The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.Features And Benefits
- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you’ll be able to spend more time focused on the job.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Length (in): 2.25
Drive Size (in): 1
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Ratio: 35.6:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Keyaway Length (in): 1.625
Max Free Speed (rpm): 975
Max Pressure (bar): 6.2
Max Torque (ft-lb): 63
Max Torque (in-lb): 756
Max Torque (nm): 85.4
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Operating Temperature Range: 0F to 150F
Power Source: Air Powered
Product Length (in): 11.38
Product Width (in): 4
Product Height (in): 4
Product Weight (lb): 15.25
Rated Power (hp): 3.2
Rated Power (kW): 2.39
Reversible: Reversible
Speed at Max Power (rpm): 485
Standards/Certifications: ATEX
Starting Torque (ft-lb): 47
Starting Torque (nm): 64
Warranty: 1-year
$5,181.50
MOTOR
IR 4840P
IR 4840P
Inline Multi-Vane Air Motor, 1" Keyed Shaft, 475 RPM, 3 HP, 170 NM, Reversible
The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.Features And Benefits
- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you’ll be able to spend more time focused on the job.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Length (in): 2.25
Drive Size (in): 1
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Ratio: 35.6:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Keyaway Length (in): 1.625
Max Free Speed (rpm): 475
Max Pressure (bar): 6.2
Max Torque (ft-lb): 125
Max Torque (in-lb): 1505
Max Torque (nm): 170
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Operating Temperature Range: 0F to 150F
Power Source: Air Powered
Product Length (in): 11.38
Product Width (in): 4
Product Height (in): 4
Product Weight (lb): 20.13
Rated Power (hp): 3
Rated Power (kW): 2.24
Reversible: Reversible
Speed at Max Power (rpm): 228
Standards/Certifications: ATEX
Starting Torque (ft-lb): 93
Starting Torque (nm): 126
Warranty: 1-year
$5,396.50
MOTOR
IR 4840S
IR 4840S
Inline Multi-Vane Air Motor, 1" Keyed Shaft, 255 RPM, 3 HP, 292 NM, Reversible
The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.Features And Benefits
- Safety: Meets ATEX Standards
- Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
- Ease of Service: Without having to worry about repair time, you’ll be able to spend more time focused on the job.
Product Application and Uses: Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller
Air Consumption at Max HP (scfm): 95
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Length (in): 2.25
Drive Size (in): 1
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Ratio: 35.6:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Keyaway Length (in): 1.625
Max Free Speed (rpm): 255
Max Pressure (bar): 6.2
Max Torque (ft-lb): 215
Max Torque (in-lb): 2584
Max Torque (nm): 292
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 6
Operating Temperature Range: 0F to 150F
Power Source: Air Powered
Product Length (in): 11.38
Product Width (in): 4
Product Height (in): 4
Product Weight (lb): 20.13
Rated Power (hp): 3
Rated Power (kW): 2.24
Reversible: Reversible
Speed at Max Power (rpm): 125
Standards/Certifications: ATEX
Starting Torque (ft-lb): 161
Starting Torque (nm): 218
Warranty: 1-year
$5,805.00
