Air Balancer, 200 Lbs, 15 Za Control Drop, Hook Mount
ZM ZAW020S-JM062201
ZM ZAW020S-JM062201
Air Balancer, 200 Lbs, 15 Za Control Drop, Hook Mount $6,425.00
CHIPPER HEX NOZZLEW/RETAINER
IR W2A1
IR W2A1
Air Chipping Hammer, 2" Stroke, 2300 BPM, Hex Shank Round Collar
As the strongest chipping hammers in the Ingersoll Rand lineup, the W Series chipping hammers are ready to take on even the toughest of jobs.Features And Benefits
- Power: With a die cast aluminum housing and a swan neck handle, these tools are as ergonomic as they are powerful and have an excellent power-to-weight ratio, making handling a breeze.
- Durability: These hammers have a heavy duty front end featuring a threaded barrel and rubber buffered retainer for increased steel and retainer life, to last you a long time.
- Reliability: With a long nozzle that allows the bit to rotate, you can expect the same result every time you use these hammers.
Product Application and Uses: These Air Percussive Chipping Hammers are designed for chipping, cutting, chiseling and breaking of hardened materials through repetitive application of linear impacts of a tool steel that is retained and driven by the chipper.
Actuation/Throttle Type/Switch Type: Outside Trigger
Air Consumption @ Load (cfm): 28
Air Consumption @ Load (l/min): 793
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Blows per Min: 2300
Bore Diameter (in): 1.13
Collar Type: Round
Color: Beige
Configuration/Handle Type: Swan Neck
Duty Rating: Industrial Duty
Exhaust Location: Side - Adjustable
Housing Material: Aluminum
Max Pressure (bar): 6.2
Min Hose Size (in): 1/2
Muffler: No
Power Source: Air Powered
Product Length (in): 16.38
Product Weight (lb): 15.13
Retainer Type: Threaded barrel with rubber buffered
Shank SIze (in): 0.58
Shank Type: Hex
Stroke Length (in): 2
Warranty: 1-year
$744.80
KIT, RUNDOWN ADAPTERREPAIR 12NM
IR ETT-RA-12-KIT
IR ETT-RA-12-KIT
KIT, RUNDOWN ADAPTERREPAIR 12NM Call for pricing
KIT, RUNDOWN ADAPTERREPAIR 4NM
IR ETT-RA-4-KIT
IR ETT-RA-4-KIT
KIT, RUNDOWN ADAPTERREPAIR 4NM Call for pricing
ROCKDRILL 7/8 X 3 1/4
IR JRD30-A
IR JRD30-A
Rock Drill, 7/8 x 3-1/4" Hex Shank, 1.44" Stroke
The JRD30 Series rock drill is one of our most versatile units. Perfect for both wet and dry drill jobs, the JRD30 can be used to drill up to 10 feet deep and 1.5 inches wide in concrete or soft to medium rock.Features And Benefits
- Easy Access: The JRD30 Series is easy enough to maneuver in tight spaces, and light enough to use when the occasion calls for horizontal drilling.
- Wet Drilling Capabilities: Take this drill anywhere it needs to go - but wet drilling environments in particular can extend the life of your tool.
- Lightweight: This rock drill is lightweight but powerful, and durable enough to stand up to the toughest conditions.
Product Application and Uses: Perfect for both wet and dry drill jobs, the JRD30 can be used to drill up to 10 feet deep and 1.5 inches wide in concrete or soft to medium rock.
Air Consumption @ Load (cfm): 73
Air Consumption @ Load (l/min): 2067
Air Inlet: 3/4" NPT
Air Pressure (psi): 90
Blows per Min: 2700
Bore Diameter (in): 2.38
Collar Type: Round
Color: Beige
Configuration/Handle Type: T-handle
Exhaust Location: Front
Max Hole Depth (ft): 10
Max Hole Diameter (in): 1.5
Max Pressure (bar): 6.2
Min Hose Size (in): 3/4
Power Source: Air Powered
Product Length (in): 19.5
Product Weight (lb): 29
Shank SIze (in): 7/8 x 3-1/4
Shank Type: Hex
Stroke Length (in): 1.44
Warranty: 1-year
Similar IR
- JRD30-B
- JRD50-B
$2,240.00
MOTOR
IR M004RVR004AR3
IR M004RVR004AR3
Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 3955 RPM, 0.37 HP, 2.05 NM, Reversible
Features And Benefits- Safety: Meets ATEX Standards
Air Consumption at Max HP (scfm): 18.5
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide and Anodize
Gear Ratio: 4:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 3955
Max Pressure (bar): 6.2
Max Torque (ft-lb): 1.5
Max Torque (in-lb): 18
Max Torque (nm): 2.05
Motor: Rotary Vane
Motor: In line
Mounting Type: Flanged Mounting
Number of Mounting Holes: 2
Power Source: Air Powered
Product Weight (lb): 2.19
Rated Power (hp): 0.37
Rated Power (kW): 0.28
Reversible: Reversible
Speed at Max Power (rpm): 1975
Standards/Certifications: ATEX
Starting Torque (ft-lb): 1.1
Starting Torque (nm): 1.53
Warranty: 1-year
$1,522.20
Adj. Stop Zra2, S2, S3 Rail Assembly
ZM ZHS30733
ZM ZHS30733
Adj. Stop Zra2, S2, S3 Rail Assembly $290.00
Kit Control Za-17 Ft Std Std Small & Lrge Za Unit
ZM 15300-17
ZM 15300-17
Kit Control Za-17 Ft Std Std Small & Lrge Za Unit $1,135.00
