Kit, Seal, 20L, Single, Ptfe
GG 257641
KIT, SEAL, 20L, SINGLE, PTFE
KIT INCLUDES: SPACER, [QTY. 1], WIPER, MAIN [QTY. 1], WIPER, PE SUPPORT [QTY. 1], PLATE, BOTTOM, PLATEN [QTY. 1], O-RING, PACKING -162 [QTY. 1], CLAMP, 20 LITER, RETAINING [QTY. 1], NUT, 1/4 HEX W/ TOOTH WASHER [QTY. 12 ], WIPER, SUPPPORT [QTY. 1], COVER, 20L, SHROUD [QTY. 1], PIN, HAIRPIN, COTTER [QTY. 2], LUBRICANT, GREASE [QTY. 1]
CONTRACTOR FLAT TIP, SPRAY
GG 269619
CONTRACTOR FLAT TIP, SPRAY
Contractor Flat Tip, 619 The 619 Contractor Flat Tip produces a 12 to 14 inch fan and has a 0.019 inch orifice.
RAC 5 TIP, SPRAY
GG 286315
RAC 5 TIP, SPRAY
RAC 5 SwitchTip, 315 The Reverse-A-Clean (RAC) 315 RAC 5 SwitchTip is designed for narrow surfaces. The 315 SwitchTip has a 0.015 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs. Used for residential, commerical or industrial applicaitions. Best used with materials ranging from lacquers, latex paints and mastics. Most Widely Used Reversible Spray Tip on the Market (Black Handle)- Used for residential and commercial applications
- Includes OneSeal for most common coatings
- Large selection of tip sizes available
- Easy to identify laser stamped tip size
- Solvent seal available when using extremely hot solvents
RAC 5 TIP, SPRAY
GG 286655
RAC 5 TIP, SPRAY
RAC 5 SwitchTip, 655 The Reverse-A-Clean (RAC) 655 RAC 5 SwitchTip produces a 12 to 14 inch fan and has a 0.055 inch orifice. Reverse the SwitchTip to easily clear clogs.Most Widely Used Reversible Spray Tip on the Market (Black Handle)
Manifold, Bottom Inlet (In)
GG 288221
MANIFOLD, BOTTOM INLET (IN)
Graco 288221 Manifold with bottom fluid ports
REGULATOR, LOW PRESSURE
GG 830353
REGULATOR, LOW PRESSURE
Graco 830353 Low Pressure Fluid Regulator, 250 Max psi, 3-100 psi Range, 3.0 GPM, SST, Air Type, 3/8 (f) x 1/4 (f)
Fluid pressure regulators control pressure of the downstream fluid, allowing operators to accurately control the pressure to guns, applicators and dispense valves
- Actuation Type: Air
- Includes: Regulator Only
- Inlet Size (cm): 0.9525
- Inlet Size (in): 3/8
- Inlet Size (mm): 9.525
- Inlet Thread Type: NPSM
- Maximum Flow Rate (GPM): 3
- Maximum Flow Rate (L/min): 11.36
- Maximum Regulated Pressure (bar): 7.0
- Maximum Regulated Pressure (kPa): 700
- Maximum Regulated Pressure (MPa): 0.7
- Maximum Regulated Pressure (psi): 100
- Maximum Viscosity (cP): 1000
- Maximum Working Pressure (bar): 18
- Maximum Working Pressure (kPa): 1800
- Maximum Working Pressure (MPa): 1.8
- Maximum Working Pressure (psi): 250
- Minimum Regulated Pressure (bar): 0.2
- Minimum Regulated Pressure (kPa): 20
- Minimum Regulated Pressure (MPa): 0.02
- Minimum Regulated Pressure (psi): 3
- Outlet Size (cm): 0.635
- Outlet Size (in): 1/4
- Outlet Size (mm): 6.35
