IR 260-724

IR 261-3

3/4" Air Impact Wrench, 3" Ext Anvil, Super Duty, 1100 ft-lb Torque, Friction Ring Retainer, Pistol

Description: The 261 Series impact wrench is ideal for vehicle repair and heavy truck and machinery jobs where you'll benefit from the square socket retaining ring and the power behind the vane motor. Trigger actuation and a power regulator let you complete projects with control and ease.

Features And Benefits:

• Power: The 6 vane motor provides a high torque output for increased power.
• Jumbo Hammer Mechanism: The patented jumbo hammer is unaffected by air pressure changes and delivers 1100 ft-lbs. of max torque and a working torque of 200-900 ft-lbs.
• Lasting Performance: This power tool is equipped with a pressure-fed lube system which provides trouble-free, longer performance.
• Square Socket: The square socket retaining ring makes this an ideal impact wrench for projects where you need increased socket connection, like auto repair and heavy truck and machinery jobs.
• Handle Exhaust: Handle exhaust directs dust and dirt from being blow at you while working as it directs air away from the operator.
• Extended Reach: The 3-inch extended anvil provides you with increased reach that's invaluable when working with deeper fasteners.

Product Application and Uses:

Applications include tire changing, engine repair, engine component installation and removal, body work installation and removal, farm implement assembly and repair, auto repair and maintenance, and truck repair.

• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 38
• Air Consumption @ Load (l/min): 1076
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90
• Anvil Length: 3" Extended
• Average Air Consumption (cfm): 9.5
• Average Air Consumption (l/min): 269

• Blows per Min: 1000

• Color: Silver
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Super Duty

• End Plates: Cast Iron
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 100.3 / 111.3

• Hammer Case: Steel
• Handle Material: Aluminum
• Housing Material: Aluminum
• Impact Mechanism: Jumbo Hammer
• Impacting Sound Pressure/Power Db(A): 98.4 / 109.4

• Max Bolt Diameter (in): 1
• Max Free Speed (rpm): 5500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1100
• Max Torque (in-lb): 13196
• Max Torque (nm): 1491
• Min Hose Size (in): 1/2
• Motor: Non-Biased

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 11.8

• Product Width (in): 3.76
• Product Height (in): 10.3
• Product Weight (lb): 13
• Recommended Forward Torque Range (ft-lb): 200-600
• Recommended Forward Torque Range (in-lb): 2399-7196
• Recommended Forward Torque Range (nm): 271-813
• Recommended Reverse Torque (ft-lb): 200-600
• Recommended Reverse Torque (nm): 271-813
• Retainer Type: Friction Ring

• Side to Center Distance (in): 1.88
• Side to Center Distance (mm): 48

• Speed Setting: Variable Speed
• Standards/Certifications: CE

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 10.4
• Warranty: 1-year

• Accessories: 261-BOOT

• Lubrication:

IR 26686

IR 244-TK2

Tune-Up kit for 244A Series Impact Wrench

• Includes: throttle valve face and spring, reverse valve bushing seal (2), reverse valve dentent ball and spring, front and rear rotor bearings, rear rotor bearing retainer, vane pack (6), hammer and end plate gaskets, socket retainer, retainer o-ring

• For Use With: 244A
• For Use With: 244A-2

IR 261-283

Reverse Valve Seal for Ingersoll Rand 261, 271 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 261 and 271 Series Impact Wrench

• Includes: (2) Seals

• For Use With: 261
• For Use With: 261-3
• For Use With: 261-6
• For Use With: 271

IR 2705P1

1/2" Air Impact Wrench, Heavy Duty, 600 ft-lb Torque, Pin Retainer, Pistol

Description: The 2700 Series impact wrench is built strong with a twin hammer impact mechanism, smooth trigger actuation and an easy-to-hold pistol grip. This wrench's vane motor delivers high torque output, while the power regulator allows for increased control.

Features And Benefits:

• Durability: Steel hammer case and metal housing increases the ability to withstand drops or harsh conditions.
• Power and Performance: Finely tuned twin hammer impact mechanism and power regulator

Product Application and Uses:

Heavy Industry, Oil&Gas, Foundry

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 4.2
• Air Consumption @ Load (l/min): 119
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard

• Blows per Min: 1200

• Color: Silver
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/2
• Drive Type: Square
• Duty Rating: Heavy Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 99.0 / 110.0

• Hammer Case: Steel
• Handle Material: Aluminum
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer

• Max Bolt Diameter (in): 9/16
• Max Free Speed (rpm): 8500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 600
• Max Torque (in-lb): 7196
• Max Torque (nm): 813
• Min Hose Size (in): 3/8
• Motor: Non-Biased

• Number of Power Settings: 6
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 106.5
• Product Length (in): 7.3

• Product Width (in): 2.81
• Product Height (in): 7.7
• Product Weight (lb): 5.63
• Recommended Forward Torque Range (ft-lb): 40-200
• Recommended Forward Torque Range (in-lb): 478-2399
• Recommended Forward Torque Range (nm): 54-271
• Retainer Type: Pin Detent

• Side to Center Distance (in): 1.4
• Side to Center Distance (mm): 36

• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 6.5
• Warranty: 1-year

• Accessories: S64H1316L-PS1
• Accessories: S64H1516L-PS1
• Accessories: S64H34L-PS1
• Accessories: S64H78L-PS1
• Accessories: S64M17L-PS1
• Accessories: S64M18L-PS1
• Accessories: S64M21L-PS1
• Accessories: S64M22L-PS1
• Accessories: S64M24L-PS1
• Accessories: S64M26L-PS1
• Accessories: SK4H13N
• Accessories: SK4M14LN

• Lubrication: 105-LBK1
• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 2705-TK3
• Parts: 402-302

• Parts: 402-303
• Parts: 404-50A
• Parts: 405-159
• Parts: 705-93

IR 261-TK2

Tune-up Kit for Ingersoll Rand 261 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 261 3/4" air impact wrench.

• Includes: Throttle Valve, Throttle Valve Seat, Throttle Valve Spring, Housing Plate Gasket, (2) Reverse Valve Seals, Rotor Bearing Retainer, Rear Rotor Bearing, Front Rotor BearingRear End Plate Gasket, (6-pc) Vane Packet, Hammer Case Gasket, Socket Retainer, Socket Retainer O-ring.

• For Use With: 261
• For Use With: 261-3
• For Use With: 261-6
• For Use With: 271

IR 273H-22

IR 2850-11

IR 2850-229

IR 2850-724

IR 2850-A626-6

Anvil Assembly Replacement Part For Ingersoll Rand 2175MAX Series Air Impact Wrench

Product Application and Uses:

For use with 2175MAX-6 air impact wrench

• Includes: anvil, socket retaining kit, o-ring, socket retaining spring

• For Use With: 2175MAX-6
• For Use With: 2850MAX-6

IR 2850-K303

IR 2850MAX

1" Air Impact Wrench, 2100 ft-lb Torque, Friction Ring-Thru-hole Retainer, D-handle Inside Trigger

Description: The 2850MAX 1" D-handle Impact Wrench, our fiercest 1" wrench, engineered to make quick work of big jobs like semi, bus and tractor tires. This tool has been made lighter, pushed harder and worked longer to make sure it can handle repeated demands without sacrificing power. Every time you need extreme torque, this lightweight boss can get the job done.

Features And Benefits:

• Solid steel impact mechanism: Deliver 2,100 ft.-lbs. of torque.
• Chemical resistant housing & steel core: Stands up to drops and harsh work environments.
• Lightweight: Weighs under 20 lbs. and is 25% lighter than the industry's leading 1" wrench.
• 360 degree adjustable handle: The side handle rotates fully around the tool as the job demands.
• Swivel hose connection: Keeps cords from getting tangled so you can move freely around the garage.

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Inside Trigger
• Air Consumption @ Load (cfm): 56
• Air Consumption @ Load (l/min): 1587
• Air Inlet: 1/2in NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 14
• Average Air Consumption (l/min): 397

• Blows per Min: 770

• Color: Grey
• Configuration/Handle Type: D-Handle
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Aluminum with Steel Wear Plate
• Exhaust Location: Top
• Free Speed Sound Pressure/Power Db(A): 105.0 / 116.0

• Hammer Case: Steel
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 96.7 / 107.7

• Max Bolt Diameter (in): 1-1/4
• Max Free Speed (rpm): 5500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 2102
• Max Torque (in-lb): 25225
• Max Torque (nm): 2850
• Min Hose Size (in): 3/4
• Motor: Reverse Bias

• Number of Power Settings: 3
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 108.2
• Product Length (in): 13.1

• Product Width (in): 6.5
• Product Height (in): 9
• Product Weight (lb): 19.43
• Recommended Forward Torque Range (ft-lb): 2002
• Recommended Forward Torque Range (in-lb): 24030
• Recommended Forward Torque Range (nm): 2715
• Retainer Type: Friction Ring and Thru-hole

• Side to Center Distance (in): 3.3
• Side to Center Distance (mm): 84

• Special Features: 2-Year Max warranty
• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

• Tool Type: Full-size
• Vanes: 7
• Vibration Level (m/s2): 12.6
• Warranty: 2-year

• Accessories: SK8H9TN
• Accessories: SK8M4LN
• Accessories: TB3

• Lubrication: 105-LBK1
• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 2850-A626
• Parts: 2850MAX-TK1

IR 2850MAX-6

1" Air Impact Wrench, 6" Ext Anvil, 2100 ft-lb Torque, Friction Ring-Thru-hole Retainer, D-handle Inside Trigger

Description: The 2850MAX 1" D-handle 6 inch extended anvil Impact Wrench, our fiercest 1" wrench, engineered to make quick work of big jobs like semi, bus and tractor tires. This tool has been made lighter, pushed harder and worked longer to make sure it can handle repeated demands without sacrificing power. Every time you need extreme torque, this lightweight boss can get the job done.

Features And Benefits:

• Solid steel impact mechanism: Deliver 2,100 ft- lbs of torque
• Chemical resistant housing & steel core: Stands up to drops and harsh work environments
• Lightweight: Weighs under 20 lbs. and is 25% lighter than the industry's leading 1" wrench.
• 360 degree adjustable handle: The side handle rotates fully around the tool as the job demands
• Swivel hose connection: Keeps cords from getting tangled so you can move freely around the garage
• 6" anvil extension: Increases accessibility in hard to reach places

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Inside Trigger
• Air Consumption @ Load (cfm): 56
• Air Consumption @ Load (l/min): 1587
• Air Inlet: 1/2in NPT
• Air Pressure (psi): 90
• Anvil Length: 6" Extended
• Average Air Consumption (cfm): 14
• Average Air Consumption (l/min): 397

• Blows per Min: 770

• Color: Grey
• Configuration/Handle Type: D-Handle
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Aluminum with Steel Wear Plate
• Exhaust Location: Top
• Free Speed Sound Pressure/Power Db(A): 105.0 / 116.0

• Hammer Case: Steel
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 96.7 / 107.7

• Max Bolt Diameter (in): 1-1/4
• Max Free Speed (rpm): 5500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 2102
• Max Torque (in-lb): 25225
• Max Torque (nm): 2850
• Min Hose Size (in): 3/4
• Motor: Reverse Bias

• Number of Power Settings: 3
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 97.2
• Product Length (in): 19.1

• Product Width (in): 9.5
• Product Height (in): 6.5
• Product Weight (lb): 21.58
• Recommended Forward Torque Range (ft-lb): 2002
• Recommended Forward Torque Range (in-lb): 24030
• Recommended Forward Torque Range (nm): 2715
• Retainer Type: Friction Ring and Thru-hole

• Side to Center Distance (in): 4.8
• Side to Center Distance (mm): 122

• Special Features: 2-year Max warranty
• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

• Tool Type: Full-size
• Vanes: 7
• Vibration Level (m/s2): 10.3
• Warranty: 2-year

• Accessories: SK8H9TN
• Accessories: TB3

• Lubrication: 105-LBK1
• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 2850-A626-6
• Parts: 2850MAX-TK1

IR 2850MAX-TK1

Tune-up Kit for Ingersoll Rand 2850MAX Series Impact Wrench

• Includes: inlet parts kit, spring pins (3), reverse valve O-ring, gasket handle, retaining ring, ball bearing cylinder, exhaust defuser, cylinder dowel, vane pack (7), ball bearing end plate, hammer case gasket, socket retaining kit

• For Use With: 2850MAX
• For Use With: 2850MAX-6

IR 2850-THK1

IR 285B

1" Air Impact Wrench, Heavy Duty, 1475 ft-lb Torque, Friction Ring -Thru-hole Retainer, D-handle Inside Trigger

Description: The 285B combine exceptional power, control and durability. It delivers 1770 ft-lb of maximum torque @ 120 psi, with 5,250 rpm free speed and a high-efficiency, 6-vane motor. The swept-back 285B handle provides excellent maneuverability. The 285B 6-inch extended anvil makes changing tires and deeper fastening will be a breeze.

Features And Benefits:

• Power: The rocking dog's combination of high inertia and low BPM means this tool can deliver a powerful blow with little air, giving you all the power you want without having to overextend yourself.
• Professional Use: Designed for the professional with over 1770 ft.-lbs. of torque for the toughest applications.
• Reliability: Built with a steel hammer case and metal housing, this wrench can withstand repeated drops and harsh weather conditions.
• Durable and Resistant: Phenolic 6 vane motor resist harsh environments for less downtime on the job. A protective rubber boot shields the tool from exterior damage.
• Control: Feather Touch trigger and 3 position power regulator in both forward and reverse. Ergonomic swept-back handle provides excellent maneuverability.
• Speed: The impact wrench has a free speed of 5,250 rpm.
• Optimized: Optimized for the vehicle repair industry, heavy trucks, tire lanes, and MRO. 1-year warranty.

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Actuation/Throttle Type/Switch Type: Inside Trigger
• Actuation/Throttle Type/Switch Type: Feather-touch Trigger
• Air Consumption @ Load (cfm): 61
• Air Consumption @ Load (l/min): 1727
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 120
• Anvil Length: Standard
• Average Air Consumption (cfm): 10
• Average Air Consumption (l/min): 283

• Blows per Min: 830

• Color: Grey
• Configuration/Handle Type: D-Handle
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Heavy Duty

• End Plates: Cast Iron
• Exhaust Location: Bottom

• Hammer Case: Aluminum
• Housing Material: Aluminum core with composite sleeve
• Impact Mechanism: Rocking Dog

• Max Bolt Diameter (in): 1-1/4
• Max Free Speed (rpm): 5250
• Max Torque (ft-lb): 1770
• Max Torque (in-lb): 21242
• Max Torque (nm): 2400
• Min Hose Size (in): 3/4
• Motor: Non-Biased

• Number of Power Settings: 3
• Power Source: Air Powered
• Product Length (in): 13.2

• Product Width (in): 9.1
• Product Height (in): 7.2
• Product Weight (lb): 24.6
• Recommended Forward Torque Range (ft-lb): 120-1080
• Recommended Forward Torque Range (in-lb): 1443-12957
• Recommended Forward Torque Range (nm): 163-1464
• Retainer Type: Friction Ring and Thru-hole

• Sound Pressure/Power Db(A): 107/118
• Speed Setting: Variable Speed

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 16.5
• Vibration Uncertainy K* (m/s2): 3.4
• Warranty: 1-year

• Accessories: 285-BOOT
• Accessories: SK8H9TN

• Lubrication: 105-LBK1
• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 285B-283
• Parts: 285B-302

• Parts: 285B-333

IR 285B-11

IR 285B-283

Handle Gasket for Ingersoll Rand 285B Series Air Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 285B Series Air Impact Wrench.

• For Use With: 285B
• For Use With: 285B-6
• For Use With: 285B-6-AP
• For Use With: 285B-S6

IR 285B-302

Throttle Valve Plunger for Ingersoll Rand 285B Series Air Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 285B Series Air Impact Wrench.

• For Use With: 285B
• For Use With: 285B-6
• For Use With: 285B-6-AP
• For Use With: 285B-S6

IR 41SC10LTQ4

IR 444

Extended Air Angle Grinder, 4" Type 27 Wheel, 14,000 RPM, 0.9 HP, 3/8" -24 Thread, Rear Exhaust

Description: Don't let grinding in tight spaces slow you down. The 440 Series Air Extended Angle Grinders from Ingersoll Rand deliver dependable performance featuring a powerful 0.9 hp motor that maximizes material removal and reduces job completion time in hard-to-reach areas. At under 4lbs, its lightweight construction, slim grip, and low-profile lever throttle make it an ideal tool for all day use without operator fatigue. An adjustable guard allows for orientation changes in seconds and spindle lock enables quick abrasive changeovers with a single wrench. The 440 Series Air Extended Angle Grinders are offered in three guard sizes from 4" to 5". For reliable grinding in hard-to-reach areas, keep your operation running with the 440 Series Extended Angle Grinders.

Features And Benefits:

• Powerful 0.9 hp 14,000 rpm motor maximizes material removal, reducing job completion time in hard-to-reach areas.
• Extended angle head with reduced height over spindle provides superior accessibility in confined spaces.
• Adjustable guard allows for orientation changes in seconds and spindle lock enables quick abrasive changeovers with a single wrench.
• At under 4lbs, its lightweight construction, slim grip, and low-profile lever throttle make it an ideal tool for all day use without operator fatigue.
• Left or right auxiliary handle position for operator preference.

Product Application and Uses:

Designed for material removal using a rotated abrasive wheel for general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding, construction, aerospace, and metal fabrication.

• Includes: Tool, 1 Wrench, Safety Manual, Auxiliary Handle
• Actuation/Throttle Type/Switch Location: Handle
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Free Speed (cfm): 34
• Air Consumption @ Free Speed (l/min): 962
• Air Consumption @ Load (cfm): 29
• Air Consumption @ Load (l/min): 821
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 3/8" -24 Thread
• Average Air Consumption (cfm): 29
• Average Air Consumption (l/min): 821

• Bearing Type: Ball Bearing
• Bearing Type: Needle Bearing

• Color: Grey
• Configuration/Handle Type: Right Angle
• Configuration/Handle Type: Auxiliary Handle
• Duty Rating: Standard Duty

• Exhaust Location: Rear

• Grinder Type: Angle Grinder
• Gripping Length (in): 4.8
• Guard Material: Steel
• Handle Material: Composite
• Height Over Spindle (in): 2.9
• Housing Material: Aluminum core with composite sleeve
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 14000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 10.57

• Product Height (in): 2.9
• Product Weight (lb): 3.7
• Rated Power (hp): 0.9
• Rated Power (kW): 0.67

• Side to Center Distance (in): 0.98
• Side to Center Distance (mm): 25

• Sound Pressure/Power Db(A): 92.2 / 103.2
• Special Features: Adjustable Guard and Spindle Lock, Extended Angle Head
• Speed Setting: Variable Speed
• Standards/Certifications: CE, UKCA

• Vibration Level (m/s2): 6.89
• Vibration Uncertainy K* (m/s2): 1.18
• Warranty: 1-year

IR 4429-B274B

Cap Asm for Ingersoll Rand 4429 Reciprocating Saw

IR 44928-2

IR 45168

IR 45471067

IR 45471091

IR 45510583

IR 45519014

IR 45631025

IR 45635141

IR 45648177

IR 45669389

IR 45832

IR 45928751

IR 47524101001

IR 47607733001

IR 47616821001

IR 47622327001

IR 47668144001

IR 4800Q

Inline Multi-Vane Air Motor, 1" Keyed Shaft, 375 RPM, 3.5 HP, 235 NM, Non-reversible

Description: The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.

Features And Benefits:

• Safety: Meets ATEX Standards
• Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
• Ease of Service: Without having to worry about repair time, you'll be able to spend more time focused on the job.

Product Application and Uses:

Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller

• Air Consumption at Max HP (scfm): 95
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Size (in): 1
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Reduction: Double
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 375
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 173
• Max Torque (in-lb): 2080
• Max Torque (nm): 235
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 6
• Power Source: Air Powered
• Product Length (in): 11.38

• Product Width (in): 4
• Product Height (in): 4
• Product Weight (lb): 19.75
• Rated Power (hp): 3.5
• Rated Power (kW): 2.61
• Reversible: Non-reversible

• Speed at Max Power (rpm): 194
• Standards/Certifications: ATEX
• Starting Torque (ft-lb): 129
• Starting Torque (nm): 175

• Warranty: 1-year

• Parts: 518-104
• Parts: R4901-102

IR 4800-TK1

IR 48254-42-5

Vane Pack Set of 5 for Ingersoll Rand Orbital Sander

IR 4840S2

Inline Multi-Vane Air Motor, 1" Square Shaft, 255 RPM, 3 HP, 292 NM, Reversible

Description: The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.

Features And Benefits:

• Safety: Meets ATEX Standards
• Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
• Ease of Service: Without having to worry about repair time, you'll be able to spend more time focused on the job.

Product Application and Uses:

Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller

• Air Consumption at Max HP (scfm): 95
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Length (in): 2.25
• Drive Size (in): 1
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Ratio: 35.6:1
• Gear Reduction: Double
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 255
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 215
• Max Torque (in-lb): 2584
• Max Torque (nm): 292
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 6
• Operating Temperature Range: 0F to 150F
• Power Source: Air Powered
• Product Length (in): 11.38

• Product Width (in): 4
• Product Height (in): 4
• Product Weight (lb): 20.13
• Rated Power (hp): 3
• Rated Power (kW): 2.24
• Reversible: Reversible

• Speed at Max Power (rpm): 125
• Standards/Certifications: ATEX
• Starting Torque (ft-lb): 161
• Starting Torque (nm): 218

• Warranty: 1-year

• Parts: R4800-A123

IR 4840U2

Inline Multi-Vane Air Motor, 1" Square Shaft, 170 RPM, 3 HP, 407 NM, Reversible

Features And Benefits:

• Safety: Meets ATEX Standards
• Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
• Ease of Service: Without having to worry about repair time, you'll be able to spend more time focused on the job.

Product Application and Uses:

Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller

• Air Pressure (psi): 90

• Drive Length (in): 2.25
• Drive Size (in): 1
• Drive Type: Square

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Ratio: 53.5:1
• Gear Reduction: Double
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 170
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 300
• Max Torque (in-lb): 3602
• Max Torque (nm): 407
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 6
• Power Source: Air Powered
• Product Length (in): 11.38

• Product Width (in): 4
• Product Height (in): 4
• Product Weight (lb): 20.13
• Rated Power (hp): 3
• Rated Power (kW): 2.24
• Reversible: Reversible

• Speed at Max Power (rpm): 83
• Standards/Certifications: ATEX
• Starting Torque (ft-lb): 225
• Starting Torque (nm): 305

• Torque Output @ Max HP (ft-lb): 150
• Torque Output @ Max HP (nm): 203.37
• Warranty: 1-year

• Parts: 518-104
• Parts: R4901-102

IR 49094-1

5" Disc Backup Pad, Adhesive/PSA

• For Use With: 5151-5
• For Use With: 5151-5-HL
• For Use With: 5152-5
• For Use With: 5152-5-HL

IR 48416051

IR 49121

IR 49613

IR 48487474

IR 49835

IR 48NA-368

IR 49094

IR 48NA-757-4

IR 48NB-764

IR 49879-1

6" Vinyl Face Non-Vacuum Backer Pad for Ingersoll Rand 3/8" Composite Housing Model Random Orbital Sanders

Product Application and Uses:

For use with Ingersoll Rand 3/8 Inch Composite Housing Model Random Orbital Sanders

• For Use With: 5151-6
• For Use With: 5151-6-HL
• For Use With: 5152-6
• For Use With: 5152-6-HL

IR 48NB-765

IR 4E-510

IR 4RA-310

IR 4U-359

IR 4U-102

IR 4U-722

IR 50003375

IR 50003193

IR 50003748

IR 50009158

IR 50009190

IR 50019728

IR 50023126

IR 50045673

IR 50050392

24" Moil Point Pavement Breaker/Digger Steel, Hex 1" x 4-1/4" Shank

Description: Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world's first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Choose from a complete line of tool steels for your pavement breaker, with products for many applications including concrete, asphalt, excavation, and general demolition.

Product Application and Uses:

Ideal for concrete, asphalt, excavation, and general demolition. For use with Ingersoll Rand PB35A pavement breakers.

• Includes: (1) Moil Point Steel

• Chisel Style: Moil Point
• Collar Type: Round
• Collar Width (in): 1.563

• Housing Material: Steel
• Length Under Collar (in): 24

• Product Length (in): 28.25

• Product Weight (lb): 6.75

• Shank Length (in): 4.25
• Shank SIze (in): 1 x 4-1/4
• Shank Type: Hex

• For Use With: PB35AL8
• For Use With: PB35AS8

IR 50055698

18" Moil Point Pavement Breaker/Digger Steel, Hex 1-1/4" x 6" Shank

Description: Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world's first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Choose from a complete line of tool steels for your pavement breaker, with products for many applications including concrete, asphalt, excavation, and general demolition.

Product Application and Uses:

Ideal for concrete, asphalt, excavation, and general demolition. For use with Ingersoll Rand MX60B, MX90B pavement breakers.

• Includes: (10) Moil Point Steels

• Chisel Style: Moil Point
• Collar Type: Round
• Collar Width (in): 1.563

• Housing Material: Steel
• Length Under Collar (in): 18

• Product Length (in): 24

• Product Weight (lb): 9

• Shank Length (in): 6
• Shank SIze (in): 1-1/4 x 6
• Shank Type: Hex

• For Use With: MX60B
• For Use With: MX90B

IR 500M5C11

IR 50055755

IR 50172386

IR 50172394

IR 50170927

IR 50173269

IR 50195361

IR 50185990

5" Asphalt Cutter Steel, 12" L Hex 1-1/4" x 6" Shank

Description: Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world's first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Choose from a complete line of tool steels for your pavement breaker, with products for many applications including concrete, asphalt, excavation, and general demolition.

Product Application and Uses:

Designed for asphalt cutting and removal. For use with Ingersoll Rand MX60B, MX90B pavement breakers.

• Includes: (5) Asphalt Cutter Steels

• Chisel Style: Asphalt Cutter
• Collar Type: Round
• Collar Width (in): 1.563

• Housing Material: Steel
• Length Under Collar (in): 12

• Product Length (in): 18

• Product Width (in): 5
• Product Weight (lb): 9.25

• Shank Length (in): 6
• Shank SIze (in): 1-1/4 x 6
• Shank Type: Hex

• For Use With: 95LA3
• For Use With: MX60B
• For Use With: MX90B

IR 5020-716

Socket Retaining Pin

Product Application and Uses:

For use with Ingersoll Rand 212, 211 Impacts, 5L and 5RL Screwdriver/Angle Wrench, QA64S6 Angle Wrench/Nutrunner, QA4 Angle Wrench/Nutrunner

• For Use With: 211
• For Use With: 212

IR 50196401

1" Narrow Pavement Breaker/Digger Chisel Steel, 18" L Hex 1-1/4" x 6" Shank

Description: Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world's first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Choose from a complete line of tool steels for your pavement breaker, with products for many applications including concrete, asphalt, excavation, and general demolition.

Product Application and Uses:

Designed for general demolition. For use with Ingersoll Rand MX60B, MX90B pavement breakers.

• Includes: (5) Chisel Steels

• Chisel Style: Narrow
• Collar Type: Round
• Collar Width (in): 1.563

• Housing Material: Steel
• Length Under Collar (in): 18

• Product Length (in): 24

• Product Width (in): 1
• Product Weight (lb): 9

• Shank Length (in): 6
• Shank SIze (in): 1-1/4 x 6
• Shank Type: Hex

• For Use With: MX60B
• For Use With: MX90B

IR 50250539

IR 50264

IR 502B-120

IR 5040T-962

IR 50460

IR 50719731

IR 5080-638-4

IR 50720572

IR 508-210A

IR 508-51

Throttle Valve Spring Service Part for Ingersoll Rand Power Tools

IR 5102MAX

Angle Air Die Grinder, 20,000 RPM, 0.4 HP, 1/4" Collet, Rear Exhaust

Description: MAX Series premium die grinders are now offered in more configurations and speeds, ensuring you have the best tool for any job. A powerful 0.4HP motor and speeds ranging from 12,000 to 35,000 RPM in angle, straight, and extended tools adds greater flexibility to your tool box. Designed for everyday use in vehicle repair and industrial settings, you won't have to choose between topnotch performance or your wallet.

Features And Benefits:

• MAX Power: With a 0.4HP (0.3kW) motor and speeds up to 20,000 RPM, MAX Series Die Grinders deliver best in class power to tackle the toughest jobs.
• MAX Productivity: Spindle lock feature allows for quick abrasive changeovers reducing operator downtime.
• MAX Comfort: Enhanced ergonomic grip design and low profile level throttle reduces operator fatigue & maximizes operator comfort during extended runtimes.
• MAX Cleanliness: Optimal lube-free vanes eliminates the need for daily oiling and oil contamination of the work piece and surrounding environment.

Product Application and Uses:

Grinding welds, prepping quarter panels for primer and paint, cleaning wheel hubs, removing glue and gasket adhesives, cutting sheet metal, brackets, and bolts, and polishing surfaces.

• Includes: Tool, (2) Wrenches, 1/4" Collet, Piped Away Exhaust Kit, Service Clamp Block and Manuals
• Actuation/Throttle Type/Switch Location: Bottom
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Free Speed (cfm): 25
• Air Consumption @ Free Speed (l/min): 708
• Air Consumption @ Load (cfm): 25
• Air Consumption @ Load (l/min): 708
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Average Air Consumption (cfm): 6
• Average Air Consumption (l/min): 170

• Bearing Type: Ball Bearing

• Color: Grey
• Configuration/Handle Type: Right Angle
• Duty Rating: Heavy Duty

• Exhaust Location: Rear

• Grinder Type: Die Grinder
• Handle Material: Composite
• Height Over Spindle (in): 3.4
• Housing Material: Composite
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 20000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 1.89

• Product Width (in): 7.09
• Product Height (in): 3.43
• Product Weight (lb): 1.4
• Rated Power (hp): 0.4
• Rated Power (kW): 0.29828000000000005
• Right Angle Length (in): 2
• Right Angle Length (mm): 51

• Side to Center Distance (in): 0.79
• Side to Center Distance (mm): 20

• Sound Pressure/Power Db(A): 84.1 / 95.1
• Special Features: Lube-free Motor, Spindle Lock
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, En Iso 28927, En Iso 15744, En Iso 11148-9

• Vibration Level (m/s2): 3.3
• Vibration Uncertainy K* (m/s2): 1.1
• Warranty: 1-year
• Wheel Type: Burr

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Lubrication: 67-4T
• Lubrication: 67-LBK1
• Parts: 5102MAX-24
• Parts: 5108MAX-K284

• Parts: RG1-42L-LF-5

IR 5102MAX-24

Bearing for Ingersoll Rand 5102MAX and 5104MAX Die Grinder

Product Application and Uses:

For use use Ingersoll Rand 5102MAX and 5104MAX Air Die Grinder

• For Use With: 5102MAX

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Lubrication: 67-4T
• Lubrication: 67-LBK1
• Parts: 5108MAX-K284
• Parts: RG1-42L-LF-5

IR 5103MAX-24

Angle Air Die Grinder, 20,000 RPM, 0.4 HP, 1/4" Collet, Rear Exhaust, Top Mounted Lever, 24-Piece

Description: MAX Series premium die grinders are now offered in more configurations and speeds, ensuring you have the best tool for any job. A powerful 0.4HP motor and speeds ranging from 12,000 to 35,000 RPM in angle, straight, and extended tools adds greater flexibility to your tool box. Designed for everyday use in vehicle repair and industrial settings, you won't have to choose between topnotch performance or your wallet.

Features And Benefits:

• MAX Power: With a 0.4HP (0.3kW) motor and speeds up to 20,000 RPM, MAX Series Die Grinders deliver best in class power to tackle the toughest jobs.
• MAX Productivity: Spindle lock feature allows for quick abrasive changeovers reducing operator downtime.
• MAX Comfort: Enhanced ergonomic grip design and low profile level throttle reduces operator fatigue & maximizes operator comfort during extended runtimes.
• MAX Cleanliness: Optimal lube-free vanes eliminates the need for daily oiling and oil contamination of the work piece and surrounding environment.

Product Application and Uses:

Grinding welds, prepping quarter panels for primer and paint, cleaning wheel hubs, removing glue and gasket adhesives, cutting sheet metal, brackets, and bolts, and polishing surfaces.

• Includes: (24) 5103MAX Die Grinders, 1/4" Collet, 24 Large Wrenches, 24 Small Wrenches,
• Actuation/Throttle Type/Switch Location: Top
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Free Speed (cfm): 25
• Air Consumption @ Free Speed (l/min): 708
• Air Consumption @ Load (cfm): 25
• Air Consumption @ Load (l/min): 708
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Average Air Consumption (cfm): 6
• Average Air Consumption (l/min): 170

• Bearing Type: Ball Bearing

• Color: Grey
• Configuration/Handle Type: Right Angle
• Duty Rating: Heavy Duty

• Exhaust Location: Rear

• Grinder Type: Die Grinder
• Handle Material: Composite
• Housing Material: Composite
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 20000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 7

• Product Height (in): 4.4
• Product Weight (lb): 1.4
• Rated Power (hp): 0.4
• Rated Power (kW): 0.29828000000000005
• Right Angle Length (in): 2
• Right Angle Length (mm): 51

• Side to Center Distance (in): 0.74
• Side to Center Distance (mm): 19

• Sound Pressure/Power Db(A): 84.1 / 95.1
• Special Features: Lube-free Motor, Spindle Lock
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, En Iso 28927, En Iso 15744, En Iso 11148-9

• Vibration Level (m/s2): 3.3
• Vibration Uncertainy K* (m/s2): 1.1
• Warranty: 1-year
• Wheel Type: Burr

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Lubrication: 67-4T
• Lubrication: 67-LBK1
• Parts: 03A-VAR-KIT

IR 5107MAX

Air Die Grinder, 30,000 RPM, 0.4 HP, 1/4" Collet, Rear Exhaust

Description: MAX Series premium die grinders are now offered in more configurations and speeds, ensuring you have the best tool for any job. A powerful 0.4HP motor and speeds ranging from 12,000 to 35,000 RPM in angle, straight, and extended tools adds greater flexibility to your tool box. Designed for everyday use in vehicle repair and industrial settings, you won't have to choose between topnotch performance or your wallet.

Features And Benefits:

• MAX Power: With a 0.4HP (0.3kW) motor and speeds up to 30,000 RPM, MAX Series Die Grinders deliver best in class power to tackle the toughest jobs.
• MAX Comfort: Enhanced ergonomic grip design and low profile level throttle reduces operator fatigue & maximizes operator comfort during extended runtimes.
• MAX Cleanliness: Optimal lube-free vanes eliminates the need for daily oiling and oil contamination of the work piece and surrounding environment.

Product Application and Uses:

Grinding welds, prepping quarter panels for primer and paint, cleaning wheel hubs, removing glue and gasket adhesives, cutting sheet metal, brackets, and bolts, and polishing surfaces.

• Includes: Tool, (3) Wrenches, 1/4" Collet, Piped Away Exhaust Kit, Service Clamp Block and Manuals
• Actuation/Throttle Type/Switch Location: Bottom
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Free Speed (cfm): 25
• Air Consumption @ Free Speed (l/min): 708
• Air Consumption @ Load (cfm): 25
• Air Consumption @ Load (l/min): 708
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Average Air Consumption (cfm): 6
• Average Air Consumption (l/min): 170

• Bearing Type: Ball Bearing

• Color: Grey
• Configuration/Handle Type: Straight
• Duty Rating: Heavy Duty

• Exhaust Location: Rear

• Grinder Type: Die Grinder
• Handle Material: Composite
• Housing Material: Composite
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 30000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 6.56

• Product Height (in): 1.6
• Product Weight (lb): 1
• Rated Power (hp): 0.4
• Rated Power (kW): 0.29828000000000005

• Side to Center Distance (in): 0.79
• Side to Center Distance (mm): 20

• Sound Pressure/Power Db(A): 81.6 / 92.6
• Special Features: Lube-Free Motor
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, En Iso 28927, En Iso 15744, En Iso 11148-9

• Vibration Level (m/s2): 3.5
• Vibration Uncertainy K* (m/s2): 1.4
• Warranty: 1-year
• Wheel Type: Burr

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Lubrication: 67-4T
• Lubrication: 67-LBK1
• Parts: 5108MAX-K284
• Parts: RG1-42L-LF-5

IR 5151-6-HL

Random Orbital Air Sander, 3/16" Orbit, 6" Hook & Loop Pad, 12,000 RPM, 0.3 HP

Description: The Ingersoll Rand 5100 Series Random Orbital Sander delivers the efficiency you need to improve your productivity and the power you need to get the job done.

Features And Benefits:

• Power: Maximum removal rate- to get the job done quickly - allow more work to get done in a day.
• Productivity: Complete more work in a day. Our versatile sander produces a fine, swirl free finish on a variety of surfaces such as wood, composites, fiberglass, sheet metal, and other materials.
• Performance: 12000 RPM to match optimal material removal speeds for your application.
• Versatility: Comfort grip for user comfort and safety.
• Vacuum Ready: Connects to a number of central or portable vacuum systems for efficient particle removal.

Product Application and Uses:

For sanding on a variety of surfaces such as wood, composites, fiberglass, sheet metal and other materials

• Includes: Sander with pad, wrench, 32mm and 28mm sleeve kit, Safety manual, webcard
• Actuation/Throttle Type/Switch Type: Lever
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/16" -24 Thread
• Average Air Consumption (cfm): 17.5
• Average Air Consumption (l/min): 496

• Color: Red
• Configuration/Handle Type: Palm
• Dust Collection Port Size: 28mm end size to connect with the hose
• Dust Collection Port Size: 22mm end size to connect with the tool
• Dust Collection Type: Vacuum Hose Mount
• Duty Rating: Maintenance Duty

• Exhaust Location: Rear

• Housing Material: Composite

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Motor: Air Gear Motor

• Number of Vacuum Holes: 6
• Orbit Diameter (in): 3/16
• Pad Diameter or Size (in): 6
• Pad Face: Hook & Loop
• Power Source: Air Powered
• Product Length (in): 6.54

• Product Width (in): 3.94
• Product Height (in): 4.9
• Product Weight (lb): 1.8
• Rated Power (hp): 0.3

• Shroud Style: Short

• Sound Pressure/Power Db(A): 77.6 / 88.6
• Special Features: Vacuum Ready, Lube-free Motor
• Speed Setting: Variable Speed

• Tool Type: Full-size
• Vacuum: Vacuum Ready/Central Vacuum
• Vibration Level (m/s2): 6
• Vibration Uncertainy K* (m/s2): 2
• Warranty: 1-year

• Accessories: 49694
• Accessories: 49879-1

• Lubrication: 10P

IR 5152-5

Random Orbital Air Sander, 3/32" Orbit, 5" Vinyl Pad, 12,000 RPM, 0.3 HP

Description: The Ingersoll Rand 5100 Series Random Orbital Sander delivers the efficiency you need to improve your productivity and the power you need to get the job done.

Features And Benefits:

• Power: Maximum removal rate- to get the job done quickly - allow more work to get done in a day.
• Productivity: Complete more work in a day. Our versatile sander produces a fine, swirl free finish on a variety of surfaces such as wood, composites, fiberglass, sheet metal, and other materials.
• Performance: 12000 RPM to match optimal material removal speeds for your application.
• Versatility: Comfort grip for user comfort and safety.
• Vacuum Ready: Connects to a number of central or portable vacuum systems for efficient particle removal.

Product Application and Uses:

For sanding on a variety of surfaces such as wood, composites, fiberglass, sheet metal and other materials

• Includes: Sander with pad, wrench, 25mm sleeve kit, plug, safety manual, webcard
• Actuation/Throttle Type/Switch Type: Lever
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 5/16" -24 Thread
• Average Air Consumption (cfm): 17.5
• Average Air Consumption (l/min): 496

• Color: Red
• Configuration/Handle Type: Palm
• Dust Collection Port Size: 25mm end size to connect with the hose
• Dust Collection Port Size: 22mm end size to connect with the tool
• Dust Collection Type: Vacuum Hose Mount
• Duty Rating: Maintenance Duty

• Exhaust Location: Rear

• Housing Material: Composite

• Max Free Speed (rpm): 12000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Motor: Air Gear Motor

• Number of Vacuum Holes: 6
• Orbit Diameter (in): 3/32
• Pad Diameter or Size (in): 5
• Pad Face: Adhesive
• Power Source: Air Powered
• Product Length (in): 6.54

• Product Width (in): 3.94
• Product Height (in): 4.9
• Product Weight (lb): 1.8
• Rated Power (hp): 0.3

• Shroud Style: Short

• Sound Pressure/Power Db(A): 77.3 / 88.6
• Special Features: Vacuum Ready, Lube-free Motor
• Speed Setting: Variable Speed

• Tool Type: Full-size
• Vacuum: Vacuum Ready/Central Vacuum
• Vibration Level (m/s2): 6
• Vibration Uncertainy K* (m/s2): 2
• Warranty: 1-year

• Accessories: 49094-1
• Accessories: 49096-1

• Lubrication: 10P

IR 5108MAX

Air Die Grinder, 25,000 RPM, 0.4 HP, 1/4" Collet, Rear Exhaust

Description: MAX Series premium die grinders are now offered in more configurations and speeds, ensuring you have the best tool for any job. A powerful 0.4HP motor and speeds ranging from 12,000 to 35,000 RPM in angle, straight, and extended tools adds greater flexibility to your tool box. Designed for everyday use in vehicle repair and industrial settings, you won't have to choose between topnotch performance or your wallet.

Features And Benefits:

• MAX Power: With a 0.4HP (0.3kW) motor and speeds up to 25,000 RPM, MAX Series Die Grinders deliver best in class power to tackle the toughest jobs.
• MAX Comfort: Enhanced ergonomic grip design and low profile level throttle reduces operator fatigue & maximizes operator comfort during extended runtimes.
• MAX Cleanliness: Optimal lube-free vanes eliminates the need for daily oiling and oil contamination of the work piece and surrounding environment.

Product Application and Uses:

Grinding welds, prepping quarter panels for primer and paint, cleaning wheel hubs, removing glue and gasket adhesives, cutting sheet metal, brackets, and bolts, and polishing surfaces.

• Includes: Tool, (3) Wrenches, 1/4" Collet, Piped Away Exhaust Kit, Service Clamp Block and Manuals
• Actuation/Throttle Type/Switch Location: Bottom
• Actuation/Throttle Type/Switch Type: Safety Lever
• Air Consumption @ Free Speed (cfm): 25
• Air Consumption @ Free Speed (l/min): 708
• Air Consumption @ Load (cfm): 25
• Air Consumption @ Load (l/min): 708
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Arbor/Collet: 1/4"
• Average Air Consumption (cfm): 6
• Average Air Consumption (l/min): 170

• Bearing Type: Ball Bearing

• Color: Grey
• Configuration/Handle Type: Straight
• Duty Rating: Heavy Duty

• Exhaust Location: Rear

• Grinder Type: Die Grinder
• Handle Material: Composite
• Housing Material: Composite
• Lock Mechanism: Lever lock in off position

• Max Free Speed (rpm): 25000
• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 6.56

• Product Width (in): 7.09
• Product Height (in): 1.6
• Product Weight (lb): 1
• Rated Power (hp): 0.4
• Rated Power (kW): 0.298

• Side to Center Distance (in): 0.79
• Side to Center Distance (mm): 20

• Sound Pressure/Power Db(A): 83.3 / 94.3
• Special Features: Lube-Free Motor
• Speed Setting: Variable Speed
• Standards/Certifications: 2006/42/Ec, En Iso 28927, En Iso 15744, En Iso 11148-9

• Vibration Level (m/s2): 1.8
• Vibration Uncertainy K* (m/s2): 0.8
• Warranty: 1-year
• Wheel Type: Burr

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Lubrication: 67-4T
• Lubrication: 67-LBK1
• Parts: 5108MAX-K284
• Parts: RG1-42L-LF-5
