QX NO RADIO, NO DISPLAY, 20V PISTOL 24 NM ETS SQUARE 3/8 INCH
IR QXFN2PT024ES06
IR QXFN2PT024ES06
3/8" 20V Cordless QX Precision Fastening ETS Screwdriver, 212 in-lb Torque, 500 RPM, Pistol
Designed to replace traditional clutch tools, the 20V pistol grip QXFN Precision Screwdriver offers the precision and quality of the QX Connect Series in an affordable, simple to set up tool. Add mobility and enhance the simplicity and flexibility of Ingersoll Rand QX Connect Series cordless assembly tools with the INSIGHT Connect app. Reducing torque reaction doesn’t have to be complicated with the QX Connect Series Ergonomic Tightening System. Control and ergonomics, not compromise – that is what the QX ETS is all about. The QX ETS offers all the capabilities found in the QX Series™ platform, without the torque reaction.Features And Benefits
- Comes with 32 programmable tightening configuration.
- 1,200 cycles of onboard tightening data storage
- Configurable preventative maintenance alarms.
- Intuitive qualitative feedback using Green, Red, and Yellow indicators.
- All QX Series™ IQV® 20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20 volt batteries utilize our 20V battery charger.
- Ergonomic tightening system to reduce torque reaction experienced by operator.
- Insight Connect Android APP Link.
- Programming Methods: Through USB with Insight Connect App available on Android; Through ICS Software; Through INISGHTqcx Controllers.
Includes: Bare tool only; batteries and charger sold separately.
Actuation/Throttle Type/Switch Type: Trigger
Anvil Length: Standard
Built-in Light: Yes
Color: Grey
Configuration/Handle Type: Pistol – ETS (ergonomic tightening system)
Data Storage Capacity: 1200 cycles
Drive Size (in): 3/8
Drive Type: Square
Max Free Speed (rpm): 500
Max Torque (ft-lb): 18
Max Torque (in-lb): 212
Max Torque (nm): 24
Motor: Brushless Motor
Power Source: Battery Powered
Product Length (in): 8.35
Product Height (in) (with Battery): 10.07
Product Weight (lb): 2
Recommended Forward Torque Range (ft-lb): -
Recommended Forward Torque Range (in-lb): -
Recommended Forward Torque Range (nm): 4.8 – 24
Retainer Type: Pin Detent
Reversible: Reversible
Side to Center Distance (in): 1
Side to Center Distance (mm): 25
User Interface: No Display
Voltage DC: 20
Warranty: 1-year Tool, 2-year Battery, 3-year Charger
Wireless Tool Tracking: No Wireless Functionality
Wireless Tool Tracking: Mini USB
Call for pricing
BACKCAP ASSEMBLY, 40V ANGLE, NO RADIO, NO DISPLAY, ETS
IR QXFN5AT000E000
IR QXFN5AT000E000
BACKCAP ASSEMBLY, 40V ANGLE, NO RADIO, NO DISPLAY, ETS
Call for pricing
Motor Controller Board, 40 V
IR TA-VA2T-499-1
IR TA-VA2T-499-1
Motor Controller Board, 40 V
Call for pricing
ANVIL KIT, PIN 3/8" SQUARE
IR TK-RTS-726-S6
IR TK-RTS-726-S6
ANVIL KIT, PIN 3/8" SQUARE
Call for pricing
ANVIL KIT, PIN 1/2" SQUARE
IR TK-RTS-726-S8
IR TK-RTS-726-S8
ANVIL KIT, PIN 1/2" SQUARE
Call for pricing
QX PISTOL BOOT, BLACK, CLOSED BACK
IR VP1-BK-BOOT-NP
IR VP1-BK-BOOT-NP
QX PISTOL BOOT, BLACK, CLOSED BACK
Call for pricing
QX PISTOL BOOT, BLUE, CLOSED BACK
IR VP1-BL-BOOT-NP
IR VP1-BL-BOOT-NP
QX PISTOL BOOT, BLUE, CLOSED BACK
Call for pricing
QX PISTOL BOOT, GREEN, CLOSED BACK
IR VP1-GN-BOOT-NP
IR VP1-GN-BOOT-NP
QX PISTOL BOOT, GREEN, CLOSED BACK
Call for pricing
QX PISTOL BOOT, WHITE, CLOSED BACK
IR VP1-WT-BOOT-NP
IR VP1-WT-BOOT-NP
QX PISTOL BOOT, WHITE, CLOSED BACK
Call for pricing
QX PISTOL BOOT, YELLOW, CLOSED BACK
IR VP1-YL-BOOT-NP
IR VP1-YL-BOOT-NP
QX PISTOL BOOT, YELLOW, CLOSED BACK
Call for pricing
MAIN BOARD ASSEMBLY(ITEM COMMENTS)
IR GEA40-A499
IR GEA40-A499
MAIN BOARD ASSEMBLY(ITEM COMMENTS)
Call for pricing
QE4 PISTOL PROGRAMMED TOOL BOARD
IR GEP15-B499
IR GEP15-B499
QE4 PISTOL PROGRAMMED TOOL BOARD
Call for pricing
REVERSE RING KITPUSH TO START
IR GEPTS15-K329
IR GEPTS15-K329
REVERSE RING KITPUSH TO START
Call for pricing
CORSET, SHIELDED, 19PIN, 10 METERS
IR IC-19PIN-10M
IR IC-19PIN-10M
CORSET, SHIELDED, 19PIN, 10 METERS
Call for pricing
Fts - Communication Module Ic-Pcm-Us
IR IC-PCM-6-US
IR IC-PCM-6-US
Fts - Communication Module Ic-Pcm-Us
Call for pricing
TORQUE ANALYZER, PORTABLE, USE WITH EXTERNAL TRANSDUCERS
IR IQCTA
IR IQCTA
TORQUE ANALYZER, PORTABLE, USE WITH EXTERNAL TRANSDUCERS
Call for pricing
Torque Tester, Bench Mount, 3.0 - 30 NM
IR IQCTT-30
IR IQCTT-30
Torque Tester, Bench Mount, 3.0 - 30 NM
Call for pricing
IQI Cable 2 Meter
IR IQI-CABLE-2M
IR IQI-CABLE-2M
IQI Cable 2 Meter
Includes: Tool cableProduct Application and Uses: For use with all Ingersoll Rand IQI Series Screwdrivers
Anvil Length: Standard
Color: Black
Product Length (in): 78.74
Product Weight (lb): 0.55
Warranty: 1-year
Wireless Tool Tracking: No Wireless Functionality
For Use With
- IQI2LC0017PM4
- IQI2LC0017PQ4
- IQI2LC0017TM4
- IQI2LC0017TQ4
- IQI2LC0050PQ4
- IQI2LC0050TQ4
- IQI2LC0100PQ4
- IQI2LC0100TQ4
- IQI2LC0200PQ4
- IQI2LC0200TQ4
- IQI2LC0250PQ4
- IQI2LC0250TQ4
- IQI2LT0017PM4
- IQI2LT0017PQ4
- IQI2LT0017TM4
- IQI2LT0017TQ4
- IQI2LT0050PQ4
- IQI2LT0050TQ4
- IQI2LT0100PQ4
- IQI2LT0100TQ4
- IQI2LT0200PQ4
- IQI2LT0200TQ4
- IQI2LT0250PQ4
- IQI2LT0250TQ4
- IQI4LC0500PQ4
- IQI4LC0500TQ4
- IQI4LC1000PQ4
- IQI4LC1000TQ4
- IQI4LC1500PQ4
- IQI4LC1500TQ4
- IQI4LT0500PQ4
- IQI4LT0500TQ4
- IQI4LT1000PQ4
- IQI4LT1000TQ4
- IQI4LT1500PQ4
- IQI4LT1500TQ4
Similar IR
- IQI-CABLE-5M
Call for pricing
IQI Controller Power Supply, 200W
IR IQI-PS-1
IR IQI-PS-1
IQI Controller Power Supply, 200W, IQI Tools Below 2.5Nm
Includes: Power supplyProduct Application and Uses: For use with all Ingersoll Rand IQI Series <2.5Nm Screwdrivers
Anvil Length: Standard
Color: Black
Product Length (in): 6.69
Product Weight (lb): 1.94
Warranty: 1-year
Wireless Tool Tracking: No Wireless Functionality
For Use With
- IQI2LC0017PM4
- IQI2LC0017PQ4
- IQI2LC0017TM4
- IQI2LC0017TQ4
- IQI2LC0050PQ4
- IQI2LC0050TQ4
- IQI2LC0100PQ4
- IQI2LC0100TQ4
- IQI2LC0200PQ4
- IQI2LC0200TQ4
- IQI2LC0250PQ4
- IQI2LC0250TQ4
- IQI2LT0017PM4
- IQI2LT0017PQ4
- IQI2LT0017TM4
- IQI2LT0017TQ4
- IQI2LT0050PQ4
- IQI2LT0050TQ4
- IQI2LT0100PQ4
- IQI2LT0100TQ4
- IQI2LT0200PQ4
- IQI2LT0200TQ4
- IQI2LT0250PQ4
- IQI2LT0250TQ4
- IQI4LC1000PQ4
- IQI4LC1000TQ4
- IQI4LT1000PQ4
- IQI4LT1000TQ4
Similar IR
- IQI-PS-2
Call for pricing
IQI Controller Power Supply, 400W
IR IQI-PS-2
IR IQI-PS-2
IQI Controller Power Supply, 400W, IQI Tools Above 5Nm
Includes: Power supplyProduct Application and Uses: For use with all Ingersoll Rand IQI Series >5Nm Screwdrivers
Anvil Length: Standard
Color: Black
Product Length (in): 11.02
Product Weight (lb): 3.41
Warranty: 1-year
Wireless Tool Tracking: No Wireless Functionality
For Use With
- IQI4LC0500PQ4
- IQI4LC0500TQ4
- IQI4LC1500PQ4
- IQI4LC1500TQ4
- IQI4LT0500PQ4
- IQI4LT0500TQ4
- IQI4LT1500PQ4
- IQI4LT1500TQ4
Similar IR
- IQI-PS-1
Call for pricing
IQI Series Controller with Fieldbus and MES
IR IQI11-FM
IR IQI11-FM
IQI Series Controller with Fieldbus and MES
Ingersoll Rand® IQi Series, is an inline low torque electric screwdriver offering available in transducerized and current control configurations. Customers will experience increased efficiency with faster set up, automated workflows and remote system access, while improving quality through advanced fastening strategies, real-time data traceability and the industry’s first tilt angle control. From high-volume assembly to quality-critical manufacturing, IQi Series delivers unmatched efficiency, precision and reliability at a reduced total cost of ownership.Features And Benefits
- Increase Efficiency: Reduce setup time up to 50% by reducing costly workflow interruptions with an intuitive web-based interface that eliminates the need for manual controller adjustments. Rapid deployment ensures seamless operational readiness. Seamless MES and Fieldbus integration automates tool and job selection, reducing manual errors and improving uptime. Operators can focus on high-value tasks for increased efficiency.
- Maximize Productivity: With real-time traceability, live access to production data enhances continuous quality control, enabling quick issue identification and resolution to improve productivity and compliance. Program, troubleshoot, and monitor systems remotely. Real-time adjustments from anywhere reduce the on-site presence and operational costs while enhancing scalability for production teams.
- Improve Quality: Achieve fastening precision with ±3.5% accuracy on transducerized models to minimize assembly errors and significantly lower rework costs with precise torque and angle control, ensuring consistent, high-quality results. Improve assembly quality with the industry-leading tilt angle control that ensures precise tool alignment, prevents cross-threading, and maintains optimal joint integrity.
- Reduce Total Cost: Designed to withstand over 1 million maintenance-free cycles, reducing maintenance frequency and downtime for long-term operational efficiency. The robust design and durable brushless motors extend tool lifespan, minimizing replacement needs and lowering total cost of ownership.
Includes: Controller with power cable
Product Application and Uses: For use with all Ingersoll Rand IQI Series Screwdrivers.
Anvil Length: Standard
Color: Black
Power Source: Electric
Product Length (in): 7.68
Product Weight (lb): 2.97
Warranty: 1-year
Wireless Tool Tracking: No Wireless Functionality
For Use With
- IQI2LC0017PM4
- IQI2LC0017PQ4
- IQI2LC0017TM4
- IQI2LC0017TQ4
- IQI2LC0050PQ4
- IQI2LC0050TQ4
- IQI2LC0100PQ4
- IQI2LC0100TQ4
- IQI2LC0200PQ4
- IQI2LC0200TQ4
- IQI2LC0250PQ4
- IQI2LC0250TQ4
- IQI2LT0017PM4
- IQI2LT0017PQ4
- IQI2LT0017TM4
- IQI2LT0017TQ4
- IQI2LT0050PQ4
- IQI2LT0050TQ4
- IQI2LT0100PQ4
- IQI2LT0100TQ4
- IQI2LT0200PQ4
- IQI2LT0200TQ4
- IQI2LT0250PQ4
- IQI2LT0250TQ4
- IQI4LC0500PQ4
- IQI4LC0500TQ4
- IQI4LC1000PQ4
- IQI4LC1000TQ4
- IQI4LC1500PQ4
- IQI4LC1500TQ4
- IQI4LT0500PQ4
- IQI4LT0500TQ4
- IQI4LT1000PQ4
- IQI4LT1000TQ4
- IQI4LT1500PQ4
- IQI4LT1500TQ4
Call for pricing
