Torque Transducers: TT and STT Series

Traditional SR hex flange style
Can be mounted to ML 250 and ML 600 Mechanical Loaders
Can be Mounted to Quad Plate for multiple mounting on ML 250
Detachable cable (Part No: 10293) is required for all transducers
TT25IO, TT1000 and TT2000 include detachable cable (Part No: 10293)
Larger sizes (500 ft. lbs. and above) can be mounted on UMB L-bracket
Smaller sizes (up to 400 in. oz. capacity) can be mounted to SSMB, STMB, or UMB brackets

$2,434.13

STR 10357

Calibration Equipment Accessories: Rundown Fixtures, Nm

Testing pulse and clutch power tools are accomplished by allowing the tool to achieve rotational speed prior to torque measurement
Include components to emulate either a hard or medium joint, thus assuring greater test accuracy

$400.95

STR 10683

Product Group	:	DTC Digital Torque and Angle Wrench, ft-lb
Model	:	DTC-150
Capacity (Nm)	:	203 Nm
Capacity (in-lb)	:
Torque Range (ft.lb)	:	30-150 ft.lbf
Overall Length	:	22.13 in
Head Type	:	Dovetail Pin/Spring

Limiting torque value to wrench capacity
Black and white display and colored light bands on the side of the wrench
Bands change yellow to green when the target values are achieved
Auditory beep and vibrating handle provide two additional modes of operator-focused error-proofing guidance
Results log large enough for even the busiest assemblies
Holds 1000 torque results and results can be downloaded
Using the mini-USB port, and DTC Connect Freeware, the results log can be uploaded to a computer in a CSV format
Can be used to set parameters in the wrench
Change units of measure, modes of operation, degrees of fastener rotation, establish a target torque, minimum torque, maximum torque, and more
DTC CONNECT is freeware and is included in the DTC

$1,211.39

STR 816875

Shrink Sleeve (Kit Of 10)

$17.14

STR 816876

Clip ( Kit of 10 )

$21.51

STR 816888

1/8 Inch Steel Ball (Kit Of 10)

$15.28

STR 819424

One piece, cast, proprietary steel selection
All of our heads fit on all of our wrenches
Our smallest head fits on our largest wrench
Our largest head fits on our smallest wrench
Fewer wrenches to buy, calibrate, repair, and manage
No need to buy multiple wrenches and heads to cover different fastener sizes within the same torque range
Sturtevant Richmont interchangeable heads have two common centerlines
Typically for sizes 32 mm and below the common centerline is 365 mm
Sizes larger than 33 mm the common centerline extends to 984 mm

$403.24
