Adapter, Valve, Dose

GG 15T600

Adapter, Valve, Dose

$153.00

REACTOR HEATED HOSE, WHIP, 1/4ID, 3500PSI, 20FT

GG 25P773

REACTOR HEATED HOSE, WHIP, 1/4ID, 3500PSI, 20FT

Graco 25P773 20 ft x 1/4 in High Flex Whip Hose, 3500 psi, Without Cable, Xtreme-Wrap, Reactor 1 & 2

Graco’s Improved Flex heated hoses are designed specifically for use with Reactor Equipment. Hoses are a key component to the total system, making it important to achieve accurate and uniform heating for the best application possible.

Application: For Reactor proportioners.

Improved Flex design, making it easier to spray in tight areas
20% Lighter than previous whip hose
Includes 18&Prime, of insulated, non-heated section near gun
Includes reliable Xtreme Wrap scuff guard

Model: Reactor 1
Series: Xtreme Wrap

Compatible Sprayer: Reactor 1 & 2
Connection Type: Male x Female
Hose Diameter (in): 1/4"
Hose Diameter (mm): 6.35
Hose Heating Type: External Heated
Hose Length (ft): 20
Hose Length (m): 6
Inside Diameter (in): 0.25
Material: PTFE
Maximum Temperature (°C): 82
Maximum Temperature (°F): 180
Maximum Working Pressure (bar): 241
Maximum Working Pressure (MPa): 24.1
Maximum Working Pressure (psi): 3500

$2,020.00

HOSE, CPLD, 3/8"X3', 4000WPR

GG 277351

HOSE, CPLD, 3/8"X3', 4000WPR

Graco 277351 BlueMax II HP Airless Whip Hose, 3/8 in x 3 ft, 4000 psi

The BlueMax II HP Whip Hose provides more flexibility and increased operator control at the gun. This BlueMax II Whip Hose has a 3/8 inch diameter and is 3 feet long and rated for up to 4000 psi.

Lighter Weight
Over 10% lighter weight and increased hose flexibility improves under pressure
Highest Safety Standards
Conductive core meets the highest worldwide safety standards unlike competitive ground wire hose designs
Minimal Hose Coil Memory
BlueMax II Hose has superior flexibility and reduced coil memory providing ease of use during coiling and uncoiling

Model: BlueMax II
Series: Whip Hose

Connection Type: Male x Female
Hose Diameter (in): 3/8
Hose Length (cm): 91
Hose Length (ft): 3
Hose Length (in): 36
Hose Length (m): 0.9
Hose Length (mm): 912
Inside Diameter (cm): 0.9525
Inside Diameter (in): 3/8
Inside Diameter (mm): 9.525
Material: Nylon
Maximum Working Pressure (bar): 276
Maximum Working Pressure (kPa): 27600
Maximum Working Pressure (MPa): 27.6
Maximum Working Pressure (psi): 4000

$57.25

HOSE, CPLD, 4500PSI, 1/4ID, 3FT

GG H42503

HOSE, CPLD, 4500PSI, 1/4ID, 3FT

Graco H42503 Xtreme-Duty 4500 psi High Pressure Hose- 1/4 in hose diameter, 3 ft length

Xtreme-Duty Airless High-Pressure Hose is designed to withstand the rigors of high-pressure spraying. Its durable design meets exacting standards – ultimately reducing downtime due to hose failure.

Application: For high-pressure spraying applications

A complete line of hoses for all your high pressure spraying – up to 7250 psi
Passes rigorous tests for quality and performance standards
Hose cover is chemical resistant – withstands a variety of solvents, acids and bases
Color-coded by pressure to take the guesswork out of using the right hose

Connection Type: Coupling

Inside Diameter (cm): 0.635
Inside Diameter (in): 1/4
Inside Diameter (mm): 6.35
Material: Nylon
Maximum Working Pressure (bar): 315
Maximum Working Pressure (kPa): 3150
Maximum Working Pressure (MPa): 31.5
Maximum Working Pressure (psi): 4500

$39.60

HOSE CPLD, 4500PSI, 3/8ID, 100FT

GG H4381X

HOSE CPLD, 4500PSI, 3/8ID, 100FT

Xtreme-Duty 4500 psi High Pressure Hose- 3/8 in hose diameter, 100 ft length

Xtreme-Duty Airless High-Pressure Hose is designed to withstand the rigors of high-pressure spraying. Its durable design meets exacting standards – ultimately reducing downtime due to hose failure.

For high-pressure spraying applications

A complete line of hoses for all your high pressure spraying – up to 7250 psi

Passes rigorous tests for quality and performance standards

Hose cover is chemical resistant – withstands a variety of solvents, acids and bases

Hose cover stands up to sunlight, ozone, oxygen and extreme weather conditions

Color-coded by pressure to take the guesswork out of using the right hose

$601.00

IQ SNUFF BACK VALVE, 25, NPT/S, 000, ADJ/RM, AMB

GG V25AS000DA

IQ SNUFF BACK VALVE, 25, NPT/S, 000, ADJ/RM, AMB

Graco V25AS000DA iQ Dispense Valve, Snuff Back, Ambient, NPT Tip, 0in (000mm) Nozzle, Remote Mount Solenoid

The iQ Snuff Back Dispense Valve offers high reliability for single component sealant and adhesive dispensing applications.

Maximize dispense time while minimizing maintenance costs and effort
Delivers reliable and consistent performance with snuff back action to prevent dripping
Ideal for low to high viscosity materials
Easy repeatable mounting for robotic and automated applications.

Air Inlet Size (in): 1/8
Air Inlet Thread Gender: Female
Air Inlet Thread Type: NPT

Ambient/Warm Melt/Hot Melt: Ambient
Applicator Type: Snuff Back
Component Type: Single Component
Fluid Inlet Size (in): 1/4
Fluid Inlet Thread Gender: Female
Fluid Inlet Thread Type: NPT
Fluid Outlet Size (in): 1/4
Fluid Outlet Thread Gender: Female
Fluid Outlet Thread Type: NPT
Gun Activation: Automatic
Maximum Air Pressure (bar): 8.3
Maximum Air Pressure (MPa): 0.83
Maximum Air Pressure (psi): 120
Maximum Fluid Pressure (bar): 276
Maximum Fluid Pressure (MPa): 28
Maximum Fluid Pressure (psi): 4000
Maximum Fluid Pressure (bar): 276
Maximum Fluid Pressure (MPa): 28
Maximum Fluid Pressure (psi): 4000
Mount Location: Remote Mount Solenoid
Nozzle Size (in): N/A
Nozzle Size (mm): N/A
Outlet Block Length (in): NA
Outlet Block Length (mm): NA

Call for pricing

IQ TIP SEAL VALVE, 25, 1.0/T, 060, ADJ/RM, AMB

GG V25DT060DA

IQ TIP SEAL VALVE, 25, 1.0/T, 060, ADJ/RM, AMB

Graco V25DT060DA iQ Dispense Valve, Tip-Seal, Ambient, 0.039in (1.0mm) Tip, 2.36in (60mm) Nozzle, Remote Mount Solenoid

The iQ Tip Seal Dispense Valve offers high reliability for single component sealant and adhesive dispensing applications.

Maximize dispense time while minimizing maintenance costs and effort
Delivers precise, consistent dispensing with clean starts and stops
Ideal for low to high viscosity materials
Easy repeatable mounting for robotic and automated applications.
60mm nozzle is compatible with 60mm focal length vision systems

Air Inlet Size (in): 1/8
Air Inlet Thread Gender: Female
Air Inlet Thread Type: NPT

Ambient/Warm Melt/Hot Melt: Ambient
Applicator Type: Tip-Seal
Component Type: Single Component
Fluid Inlet Size (in): 1/4
Fluid Inlet Thread Gender: Female
Fluid Inlet Thread Type: NPT
Gun Activation: Automatic
Maximum Air Pressure (bar): 8.3
Maximum Air Pressure (MPa): 0.83
Maximum Air Pressure (psi): 120
Maximum Fluid Pressure (bar): 276
Maximum Fluid Pressure (MPa): 28
Maximum Fluid Pressure (psi): 4000
Maximum Fluid Pressure (bar): 276
Maximum Fluid Pressure (MPa): 28
Maximum Fluid Pressure (psi): 4000
Mount Location: Remote Mount Solenoid
Nozzle Size (in): 0.039
Nozzle Size (mm): 1.0
Outlet Block Length (in): 2.4
Outlet Block Length (mm): 60
